KD-DV6206/KD-DV6205
Installation/Connection Manual
GET0383-007A
[A]
0306DTSMDTJEIN
EN
Parts list for installation and connection
The following parts are provided for this unit. If any item is missing, consult your JVC car
audio dealer immediately.
This unit is designed to operate on 12 V DC, NEGATIVE ground electrical systems. If your
vehicle does not have this system, a voltage inverter is required, which can be purchased at
JVC car audio dealers.
WARNINGS
• DO NOT install any unit in locations where;
– it may obstruct the steering wheel and gearshift lever operations, as this may result in
a traffic accident.
– it may obstruct the operation of safety devices such as air bags, as this may result in
a fatal accident.
– it may obstruct visibility.
• DO NOT operate any unit while manipulating the steering wheel, as this may result in a
traffic accident.
• The driver must not watch the monitor while driving.
If the driver watches the monitor while driving, it may lead to carelessness and cause
an accident.
• The driver must not put on the headphones while driving. It is dangerous to shut off the
outside sounds while driving.
• If you need to operate the unit while driving, be sure to look ahead carefully or you may
be involved in a traffic accident.
• If the parking brake is not engaged, “DRIVER MUST NOT WATCH THE MONITOR WHILE
DRIVING.” appears on the monitor, and no playback picture will be shown.
– This warning appears only when the parking brake wire is connected to the parking
brake system built in the car.
To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and
make all electrical connections before installing the unit.
• Be sure to ground this unit to the car’s chassis again after installation.
Notes:
• Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC
car audio dealer.
•It is recommended to connect to the speakers with maximum power of more than 50 W (both
at the rear and at the front, with an impedance of 4Ωto 8 Ω). If the maximum power is less
than 50 W, change “AMP GAIN”setting to prevent the speakers from being damaged (see
page 36 of the INSTRUCTIONS).
•To prevent short-circuit, cover the terminals of the UNUSED leads with insulating tape.
•The heat sink becomes very hot after use. Be careful not to touch it when removing this unit.
1
TROUBLESHOOTING
•The fuse blows.
* Are the red and black leads connected correctly?
•Power cannot be turned on.
* Is the yellow lead connected?
•No sound from the speakers.
* Is the speaker output lead short-circuited?
•Sound is distorted.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
•Noise interfere with sounds.
* Is the rear ground terminal connected to the car’s chassis using shorter and thicker cords?
•The unit becomes hot.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
•This unit does not work at all.
* Have you reset your unit?
About sounds reproduced through the rear terminals
•Through the analog terminals (Speaker out/LINE OUT/2nd AUDIO OUT):
2-channel signal is emitted. When playing a multi-channel encoded disc, multi-channel
signals are downmixed. (AUDIO—DOWN MIX: see page 28 of the INSTRUCTIONS.)
•Through DIGITAL OUT (optical):
Digital signals (Linear PCM, Dolby Digital*1, DTS*2, MPEG Audio) are emitted through this
terminal. (For more details, see page 47 of the INSTRUCTIONS.)
To reproduce multi-channel sounds such as Dolby Digital and DTS, connect an amplifier or
a decoder compatible with these multi-channel sources to this terminal, and set “DIGITAL
AUDIO OUTPUT”correctly. (See page 28 of the INSTRUCTIONS.)
*1Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks
of Dolby Laboratories.
*2“DTS”and “DTS 2.0 + Digital Out”are trademarks of Digital Theater Systems, Inc.
© 2006 Victor Company of Japan, Limited
PRECAUTIONS on power supply and speaker connections:
•DO NOT connect the speaker leads of the power cord to the car battery; otherwise,
the unit will be seriously damaged.
•BEFORE connecting the speaker leads of the power cord to the speakers, check the
speaker wiring in your car.
Heat sink
F
Crimp connector
K
Handles
G
Washer (ø5)
H
Lock nut (M5)
I
Mounting bolt (M5 ×20 mm)
J
Rubber cushion
A/ B
Hard case/Control panel
C
Sleeve
D
Trim plate
E
Power cord
L
Remote controller
M
Battery
Instal1-2_DV6206_007A_1.indd 1Instal1-2_DV6206_007A_1.indd 1 2/7/06 12:10:34 PM2/7/06 12:10:34 PM

2
INSTALLATION (IN-DASH MOUNTING)
The following illustration shows a typical installation. If you have any questions or require information regarding installation kits, consult your JVC car audio dealer or a company supplying kits.
• If you are not sure how to install this unit correctly, have it installed by a qualified technician.
*3
When you stand the unit, be careful not to damage the fuse on the rear.
Do the required electrical
connections.
Bend the appropriate tabs to hold
the sleeve firmly in place.
Removing the unit
Before removing the unit, release the rear section.
Insert the two handles, then pull them
as illustrated so that the unit can be
removed.
When using the optional stay
Screw (option)
Stay (option)
Fire wall
Dashboard
Install the unit at an angle of less than 30˚.
When installing the unit without using the sleeve
In a Toyota car for example, first remove the car radio and install the unit in its place.
Bracket *4
Bracket *4
*4Not supplied for this unit.
Flat type screws (M5 ×8 mm) *4
Pocket
Flat type screws (M5 ×8 mm) *4
Note : When installing the unit on the mounting bracket, make sure to use the 8 mm-long screws. If
longer screws are used, they could damage the unit.
Instal1-2_KD-DV6206[A]1.indd 2Instal1-2_KD-DV6206[A]1.indd 2 2/7/06 12:20:03 PM2/7/06 12:20:03 PM

*1 Not supplied for this unit.
Ignition switch
SUBWOOFER (see diagram )
To external components
(see diagram )
Rear ground terminal
15 A fuse
Black
To metallic body or chassis of the car
Yellow *2To a live terminal in the fuse block connecting to the car battery
(bypassing the ignition switch) (constant 12 V)
Red
To an accessory terminal in the fuse block
Blue To the automatic antenna if any
(250 mA max.)
Blue with white stripe
To the remote lead of other equipment (200 mA max.)
Orange with white stripe
To car light control switch
To cellular phone system
Brown
White with black stripe White Gray with black stripe
Left speaker (front)
Gray Green with black stripe
Right speaker (front)
Green Purple with black stripe
Left speaker (rear)
Purple
Right speaker (rear)
Fuse block
Light green
Line out
(see diagram )
VIDEO OUT (see diagram )
2nd AUDIO OUT (see diagram )
LINE IN (see diagram )
To parking brake, metallic body or chassis of the car
DIGITAL OUT
(see diagram )
*2 Before checking the operation of this unit prior to
installation, this lead must be connected, otherwise
power cannot be turned on.
Antenna connector
3
ATypical connections
Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious damage to this unit.
The leads of the power cord and those of the connector from the car body may be different in color.
1Connect the colored leads of the power cord in the order specified in the illustration below.
2Connect the antenna cord.
3Finally connect the wiring harness to the unit.
Connecting the crimp connector
C
Wire connecting the battery and the parking brake switch.
Attach the parking brake wire to this point.
Contact the metallic part of the crimp to the wires inside.
Pinch the crimp firmly.
BConnecting the parking brake wire
When installing the monitor in a location where it can be seen by the driver
Connect the parking brake wire to the parking brake system built in the car.
Parking brake
Parking brake wire
(light green)
To metallic body or
chassis of the car
Parking brake switch
(inside the car)
When installing the monitor in a location where it cannot be seen by the
driver
Connect the parking brake wire to metallic body or chassis of the car.
Parking brake wire (light green)
*3 Not supplied for this unit.
ELECTRICAL CONNECTIONS
Instal3-4_KD-DV6206[A]f.indd 3Instal3-4_KD-DV6206[A]f.indd 3 2/23/06 4:16:14 PM2/23/06 4:16:14 PM

4
Required connections for DVD playback
D
Audio/video control amplifier or the decoder
compatible with the multichannel digital sources
When using JVC’s KV-MR9010 and KS-HP2,
connect using a conversioncable of this type
(not supplied).
Headphones (not supplied)*4
KS-HP2
Cordless headphones
(not supplied)*4
KV-MR9010
9-INCH WIDESCREEN MONITOR
(not supplied)
Video cord (not supplied)
Stereo mini plug
RCA Pin plugs
Digital optical cable (not supplied) DIGITAL OUT
See “About sounds reproduced
through the rear terminals.”
*4To listen to disc playback sound while in Dual Zone
operations (see page 32 of INSTRUCTIONS).
EConnecting the external amplifiers and/or subwoofer
You can connect amplifiers to upgrade your car stereo system.
•Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so that it can be controlled through this unit.
•For amplifier only:
–Disconnect the speakers from this unit, connect them to the amplifier. Leave the speaker leads of this unit unused.
–The line output level of this unit is kept high to maintain the hi-fi sounds reproduced from this unit.
When connecting an external amplifier to this unit, turn down the gain control on the external amplifier to obtain the best performance from this unit.
To the remote lead of other equipment or auto antenna if any
Y-connector (not supplied for this unit)Remote lead
*5
Signal cord (not supplied for this unit)
Front speakers
Rear speakers
JVC Amplifier
JVC Amplifier Subwoofer
Front speakers
Remote lead (Blue with white stripe)
*6Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place
uncoated with paint (if coated with paint, remove the paint before attaching the wire). Failure to do
so may cause damage to the unit.
FConnecting the external components
Other external component
Rear side
or
JVC Amplifier
CD changer, Apple iPod
®, or JVC D. player
You can connect these components as illustrated below. The iPod*7or D. player can be connected using an interface adapter (not supplied)—KS-PD100 (for iPod) or KS-PD500 (for D. player).
• Set “CHANGER” for the external input setting (See page 36 of the INSTRUCTIONS.)
Apple iPod (separately purchased)
JVC D. player (separately purchased)
JVC CD changer
or
CAUTION :
•Before connecting the external components, make sure that the unit is turned off.
*8Connecting cord supplied for your CD changer *7iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
CD changer jack
External component
*9
Signal cord (not supplied for this unit)
