JVC NX-T5 User manual

COMPACT COMPONENT SYSTEM
NX-T5
—Consists of CA-NXT5, SP-NXT5F, and SP-NXT5W
INSTRUCTIONS
LVT2145-001A
[B]
EN_NX-T5[B].indb 1EN_NX-T5[B].indb 1 10.3.19 5:25:55 PM10.3.19 5:25:55 PM

G-1
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover or cabinet. There are
no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE
THE UNIT.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to get
out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems must
be considered and local rules or laws governing the disposal
of these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping
or splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
CAUTION:
Battery shall not be exposed to excessive heat such as
sunshine, fire, or the like.
Dear Customer,
This apparatus is in conformance with the valid European
directives and standards regarding electromagnetic
compatibility and electrical safety.
European representative of Victor Company of Japan, Limited is:
JVC Technical Services Europe GmbH
Postfach 10 05 04
61145 Friedberg
Germany
Warnings, Cautions and Others
IMPORTANT for the U.K.
DO NOT cut off the mains plug from this equipment. If the
plug fitted is not suitable for the power points in your home
or the cable is too short to reach a power point, then obtain
an appropriate safety approved extension lead or consult
your dealer.
BE SURE to replace the fuse only with an identical approved
type, as originally fitted.
If nonetheless the mains plug is cut off ensure to remove the
fuse and dispose of the plug immediately, to avoid a possible
shock hazard by inadvertent connection to the mains supply.
If this product is not supplied fitted with a mains plug then
follow the instructions given below:
IMPORTANT:
DO NOT make any connection to the terminal which is
marked with the letter E or by the safety earth symbol or
coloured green or green-and-yellow.
The wires in the mains lead on this product are coloured in
accordance with the following code:
Blue: Neutral
Brown: Live
As these colours may not correspond with the coloured
markings identifying the terminals in your plug proceed as
follows:
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.
CAUTION
The button in any position does not disconnect the mains
line.
Disconnect the mains plug of SP-NXT5W (subwoofer) to shut
the power off completely (the lamp on CA-NXT5 and POWER
ON/STANDBY lamp on SP-NXT5W go off).
The MAINS plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily
operable.
• When the System is on standby, the and POWER ON/
STANDBY lamps light red.
• When the System is turned on, the and POWER ON/
STANDBY lamps light blue.
The power can be remote controlled.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
COMPACTCOMPONENTSYSTEM
MODELNO.CA-NXT10
Victor CompanyofJapan,Limited
B/E/EN/EV7111-081500100
SERIALNO.:
MADEINCHINA
Rating label
Rating label is placed on the exterior of CA-NXT5 as illustrated
below.
EN_NX-T5[B].indb 1EN_NX-T5[B].indb 1 10.3.19 5:25:57 PM10.3.19 5:25:57 PM

G-2
Information for Users on Disposal of Old Equipment and Batteries
Products
Battery
Notice:
The sign Pb below the
symbol for batteries
indicates that this battery
contains lead.
[European Union]
These symbols indicate that the electrical and electronic equipment and the battery with this symbol
should not be disposed of as general household waste at its end-of-life. Instead, the products should
be handed over to the applicable collection points for the recycling of electrical and electronic
equipment as well as batteries for proper treatment, recovery and recycling in accordance with your
national legislation and the Directive 2002/96/EC and 2006/66/EC.
By disposing of these products correctly, you will help to conserve natural resources and will help to
prevent potential negative effects on the environment and human health which could otherwise be
caused by inappropriate waste handling of these products.
For more information about collection points and recycling of these products, please contact your
local municipal office, your household waste disposal service or the shop where you purchased the
product.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.
[Business users]
If you wish to dispose of this product, please visit our web page http://www.jvc.eu/ to obtain
information about the take-back of the product.
[Other Countries outside the European Union]
These symbols are only valid in the European Union.
If you wish to dispose of these items, please do so in accordance with applicable national legislation or
other rules in your country for the treatment of old electrical and electronic equipment and batteries.
CAUTION: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1. Front: No obstructions and open spacing.
2. Sides/Top/Back: No obstructions should be placed in the areas indicated by the dimensions in the illustration.
3. Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm or
more.
Front view Side view
Main unitSpeaker Speaker Subwoofer Subwoofer
EN_NX-T5[B].indb 2EN_NX-T5[B].indb 2 10.3.19 5:25:57 PM10.3.19 5:25:57 PM

1
How to Read This Manual
• Button and control operations are explained in the table
below.
• Some related tips and notes are explained later in
the sections “Learning More about This System”
and “Troubleshooting,” but not in the same section
explaining the operations (
INFO
indicates that the
content has some information).
• English indications are used for the explanation of the
on-screen indications on the TV. You can select the
indication language from the Setup menu. See page 32.
Indicates that you press the button briefly.
Indicates that you press the button briefly
and repeatedly until the option you want
is selected.
Indicates that you press one of the buttons.
2 sec.
Indicates that you press and hold the
button for a specified period.
Indicates that you turn the control in the
specified direction(s).
Remote
ONLY
Indicates that this operation is only
possible using the remote control.
Main Unit
ONLY
Indicates that this operation is only
possible using the main unit.
Introduction
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete
understanding and to obtain the best possible performance from the System.
Precautions
Installation
• Install the System in a location with adequate ventilation
to prevent internal heat build-up in the System.
DO NOT install the System in a location near
heat sources, or in a place subject to direct
sunlight, excessive dust or vibration.
• Install in a place which is level, dry and neither too hot
nor too cold—between 5°C and 35°C.
• Leave sufficient distance between the System and the TV.
• Keep the speakers away from the TV to avoid
interference with the TV.
Power sources
• When unplugging the System from the wall outlet, always
pull on the plug, not the power cord.
DO NOT handle the power cord with wet
hands.
Moisture condensation
Moisture may condense on the lens inside the System in the
following cases:
• After starting to heat the room
• In a damp room
• If the System is brought directly from a cold to a warm
place.
Should this occur, the System may malfunction. In this
case, leave the System turned on for a few hours until the
moisture evaporates, unplug the power cord, then plug it
in again.
Internal heat
• Make sure there is good ventilation around the System.
Poor ventilation could overheat and damage the System.
DO NOT block the ventilation openings or
holes. If they are blocked by a newspaper or
cloth, etc., the heat may not be able to get out.
Others
Should any metallic object or liquid fall into the System,
unplug the power cord and consult your dealer before
operating any further.
DO NOT disassemble the System since there
are no user serviceable parts inside.
• If you are not going to operate the System for an
extended period of time, unplug the power cord from the
wall outlet.
If anything goes wrong, unplug the power cord and consult
your dealer.
Supplied accessories
Check to be sure that you have all the following items.
• FM antenna (×1)
• Composite video cord (×1)
• System cable (×1)
• Remote control (×1)
• Batteries (×2)
• Stand (×1)
• Core filter (×1)
If any items are missing, consult your dealer
immediately.
EN_NX-T5[B].indb 1EN_NX-T5[B].indb 1 10.3.19 5:25:57 PM10.3.19 5:25:57 PM

2
Introduction............................................................ 1
Precautions........................................................................... 1
How to Read This Manual ................................................. 1
Playable Disc/File Types..................................................... 3
Preparations ........................................................... 4
Placing the Main Unit Vertically or Horizontally .......... 4
Connections ......................................................................... 5
When Placing the Main Unit Vertically........................... 9
When Installing the Main Unit on a Wall ....................... 10
Preparing the Remote Control .......................................... 12
Changing the Scanning Mode ........................................... 13
Display Indicators .................................................... 14
Daily Operations—Playback .................................... 15
Listening to the FM Radio.................................................. 16
Playing Back a Disc/USB Mass Storage Class Device..... 17
Playing Back Other Equipment......................................... 19
Daily Operations—Sound & Other Adjustments......... 20
Turning Off the Sound in a Moment................................ 20
Adjusting the Sound............................................................ 20
Changing the Display Brightness ...................................... 21
Changing the Display Information................................... 21
Turning Off the Power Automatically.............................. 21
Advanced Radio Operations...................................... 22
Receiving FM Stations with Radio Data System ............. 22
Searching for a Program by PTY Codes........................... 22
Unique Video Disc/File Operations............................. 23
Selecting the Audio Track .................................................. 23
Selecting the Subtitle Language ......................................... 24
Selecting the View Angle.................................................... 24
Special Effect Playback........................................................ 25
Advanced Disc/File Playback Operations.................... 26
Programming the Playing Order—Program Play........... 26
Playing at Random—Random Play .................................. 27
Playing Repeatedly .............................................................. 27
Prohibiting Disc Ejection—Child Lock............................ 28
On-Screen Operations .............................................. 29
On-Screen Bar Operations................................................. 29
Control Screen Operations ................................................ 30
Setup Menu Operations............................................ 32
Setting Up Playback of Discs/USB Devices ..................... 32
Setting Up the Sound and HDMI Functions................... 34
Additional Information............................................ 36
Learning More about This System ................................... 36
Maintenance......................................................................... 38
Troubleshooting .................................................................. 38
Specifications........................................................................ 40
Parts Index ............................................................. 44
Contents
EN_NX-T5[B].indb 2EN_NX-T5[B].indb 2 10.3.19 5:25:58 PM10.3.19 5:25:58 PM

3
Playable Disc/File Types
DIGITAL VIDEO
SUPER VIDEO
COMPACT
DIGITAL AUDIO
• CD-R/-RW: Recorded in the Audio CD, Video CD,
and SVCD formats. MP3, JPEG, MPEG-1, MPEG-2,
and DivX files written in accordance with the “ISO
9660” format can also be played.
• DVD-R/-RW: Recorded in the DVD Video format and
DVD Video Recording (VR) format.
MP3, JPEG, MPEG-1, MPEG-2, and DivX files written
in the UDF-Bridge format can also be played.
• +R/+RW (finalized): Recorded in the DVD Video
format. MP3, JPEG, MPEG-1, MPEG-2, and DivX files
written in the UDF-Bridge format can also be played.
• USB mass storage class device: MP3, JPEG, MPEG-1,
MPEG-2, and DivX*files.
In addition to the above discs/files, this System can play
back audio data recorded on CD-Extra.
• The following discs cannot be played back:
– DVD-RAM, CD-I (CD-I Ready), CD-ROM, and Photo
CD
Playing back these discs will generate noise and damage
the speakers.
– 8 cm discs
• CD Text and DVD Text can be played, but Text
information will not be shown on the display.
• In this manual, “file” and “track” are used
interchangeably.
• It is possible to play back finalized +R/+RW (DVD Video
format only) discs. DVD indicator lights on the TV
screen when a +R/+RW disc is loaded.
• “DVD Logo” is a trademark of DVD Format/Logo
Licensing Corporation.
• This System can play back Everio files (see page 37)
recorded on DVD, CD*, and USB mass storage class
device*.
* Only when the maximum bit rate is less than 2 Mbps.
About color system
This System can play back discs recorded in both PAL and
NTSC video format. When you play back an NTSC disc,
the NTSC video signal is converted into the PAL video
signal and emitted.
Note on Region Code
DVD players and DVDs have their own Region Code
numbers. This System can play back only DVDs with an
appropriate Region Code number.
• “WRONG REGION” appears on the TV if DVD with
another Region Code is loaded.
Ex.:
Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Digital Audio” standard. Therefore,
the use of the Non-DVD side of a DualDisc in this product
may not be recommended.
IMPORTANT: Before playing a disc/file, make sure of the
following...
• Turn on the TV and select an appropriate input mode
on the TV to view the pictures or on-screen displays.
• For disc/file playback, you can change the initial setting
to your preference. See “Setup Menu Operations” on
page 32.
If “INVALID KEY” appears on the TV screen when
you press a button, the disc/file cannot perform the
operation you have tried to do.
EN_NX-T5[B].indb 3EN_NX-T5[B].indb 3 10.3.19 5:25:58 PM10.3.19 5:25:58 PM

4
When placing the main unit horizontally
Set the DISPLAY MODE switch to “H” (horizontal).
Preparations
When placing the main unit vertically
Set the DISPLAY MODE switch to “V” (vertical) and
attach the supplied stand to the main unit (see page 9).
• When installing the main unit on a wall (see page 10),
also set the DISPLAY MODE switch to “V.”
• When placing the main unit vertically, attach the
supplied stand firmly to the back of the main unit after
connections have been completed (see page 9).
Placing the Main Unit Vertically or Horizontally
You can place the main unit either vertically or horizontally. Set the DISPLAY MODE switch according to the way the
main unit is placed.
• The position of the remote sensor also changes according to the setting of the DISPLAY MODE switch (see page 12).
This manual explains operations using
the illustrations of the main unit placed
vertically as examples.
Buttons and operations when the main
unit is placed horizontally are the same
as when it is placed vertically.
Buttons and display indications with the DISPLAY
MODE switch set to “V”
Buttons and display indications with the DISPLAY
MODE switch set to “H”
EN_NX-T5[B].indb 4EN_NX-T5[B].indb 4 10.3.19 5:25:59 PM10.3.19 5:25:59 PM

5
Connections
INFO
Do not connect the power cord until all other connections have been made.
Detach the connector cover from the main unit and
connect the cords by passing them through the hole of
the connector cover.
Rear panel of the main unit
@TO SP-NXT5W
From the subwoofer (with the supplied
system cable)
See page 7.
~VIDEO OUT
From the input of a TV/monitor
See page 6.
~HDMI OUT
From the input of a TV/monitor
See page 6.
When placing the main unit horizontally
!FM. ANT
From the FM antenna
See page 6.
⁄AUDIO IN
From the output of an analog audio device
See page 7.
How to detach the connector
cover
Cords
Cords
When placing the main unit vertically
ŸDIGITAL IN (OPTICAL)
From the output of a Blu-ray device or a
Digital Set Top Box
See page 6.
• Use the same hole as illustrated above when installing the
main unit on a wall (see page 10).
• Attach the connector cover again to the main unit after connections have been completed.
EN_NX-T5[B].indb 5EN_NX-T5[B].indb 5 10.3.19 5:25:59 PM10.3.19 5:25:59 PM

6
~TV/monitor
Connect an HDMI cable or a composite video cord.
• To select progressive scanning mode (see page 13), use
the HDMI OUT terminal.
When connecting your TV
Connect your TV directly to the System. Connecting the
System to a TV via other device, such as a VCR or an
HDD/DVD recorder, may interfere with your viewing.
Connecting an integrated TV/VCR system to the System
may also interfere with your viewing.
• When connecting a TV with an HDMI cable, select the
appropriate video signal output according to the TV. See
page 13.
• When you use an HDMI cable, make appropriate settings
in the Setup menu (see pages 32 – 34).
• This System is compatible with some basic functions of
HDMI CEC. For details, see page 35.
• Playback sound may be interrupted when operating the
TV connected with the HDMI cable.
HDMI cable (not supplied)
Use an HDMI cable of less than
2 m.
• Connect the HDMI cable
straight not to cause damage
to the HDMI terminal.
Composite video cord
(supplied)
ŸBlu-ray device or Digital Set Top Box
When connecting a Blu-ray device or a Digital Set Top Box
• When connecting the digital audio output of the device
to the DIGITAL IN (OPTICAL) terminal, set the digital
audio output setting of the device properly.
For details, refer to the manual of the device.
– Following signals can be reproduced on the System:
Dolby Digital, DTS, Linear PCM.
!FM antenna
Extend it so that you can obtain the best reception.
For better FM reception
Disconnect the supplied FM antenna, and connect to an
outdoor FM antenna using a 75 Ωwire with coaxial type
connector (IEC or DIN45325).
This System cannot receive the AM (LW/MW) band.
Optical digital cord
(not supplied)
Protective
cap
FM antenna (supplied)
FM outdoor antenna
(not supplied)
EN_NX-T5[B].indb 6EN_NX-T5[B].indb 6 10.3.19 5:25:59 PM10.3.19 5:25:59 PM

7
⁄Analog audio device
Audio cord (not supplied)
Red
White
@System cable
Connect the system cable with the arrow side facing up.
System cable (supplied)
From the subwoofer
Arrow
Rear panel of the subwoofer
¤SPEAKERS
From the speakers
See below.
‹To a wall outlet
Plug in the power cord only after all
connections have been completed.
See page 8.
#TO CA-NXT5
From the main unit
See page 8.
¤Speakers
Connect the speakers to the subwoofer by connecting the
colored connectors to the same color terminals on the rear
of the subwoofer.
White
Red
From the right
speaker
From the left
speaker
CAUTION:
• The supplied speakers are manufactured exclusively
for use with the NX-T5 System. Do not connect
the supplied speakers to any devices other than the
subwoofer of the System (SP-NXT5W). Doing so may
damage the speakers.
• Do not connect external speakers together with the
supplied speakers. The change in impedance may
damage the System.
IMPORTANT
• Improper speaker cable connection reduces the sound
quality.
• The supplied speakers and subwoofer are not
magnetically shielded, so do not place the speakers and
subwoofer close to a TV as the colors on the screen
could be affected. Similarly, do not place watches,
credit cards or other cards with magnetic strips, MDs,
floppy discs, audio or video tapes close to the speakers
and subwoofer.
After connections on the rear of the main unit have been completed, connect speakers and the system cable to the
subwoofer. See below and page 8.
EN_NX-T5[B].indb 7EN_NX-T5[B].indb 7 10.3.19 5:26:00 PM10.3.19 5:26:00 PM

8
Speaker layout
This System is designed to provide virtual surround sound
using Dolby Virtual Speaker.
Position the speakers as illustrated above.
• When it is difficult to place the speakers as illustrated
above, you can select the surround mode to have a better
sound effect. See page 20.
Information of Dolby Virtual Speaker
Dolby Virtual Speaker is an audio virtualization system
which gives the impression of 5.1 channel surround sound
using only two speakers.
Main unit
Subwoofer
Right speakerLeft speaker
lamp
#System cable
Connect the system cable with the arrow side facing up.
How to attach the core filter
Attach the provided core filter to the system cable, then the
core filter reduces interference.
1Release the stopper of the core filter.
2Run the system cable through the core filter, and place
the core filter at the root of the connector connected
to the subwoofer.
3Close the core filter until it clicks shut.
‹Power cord
Connect the power cord of the subwoofer after other
connections have been completed.
The lamp on the main unit and the POWER ON/
STANDBY lamp on the subwoofer light red.
System cable (supplied)
Arrow
From the main unit
Core filter (supplied)
EN_NX-T5[B].indb 8EN_NX-T5[B].indb 8 10.3.19 5:26:00 PM10.3.19 5:26:00 PM

9
Stand (supplied)
When Placing the Main Unit
Vertically
Make sure to attach the supplied stand to the main unit.
Attach the supplied stand firmly to the back of the main
unit after connections have been completed.
CAUTION:
Detach the stand before carrying the main unit.
Side panel of the main unit
From a USB mass storage class
device
When connecting a USB mass storage class device
• When connecting with a USB cable, use the USB 2.0 cable
whose length is less than 1 m.
• You can connect a USB mass storage class device such as
a USB flash memory device, hard disk drive, multimedia
card reader, etc. to this System.
• You cannot connect a computer or JVC Everio
camcorder to the USB MEMORY PLAY terminal ( )
of the System.
• Electrostatic shock at connecting a USB device may cause
abnormal playback of the device. In this case, disconnect
the USB device then reset this System and the USB
device.
EN_NX-T5[B].indb 9EN_NX-T5[B].indb 9 10.3.19 5:26:02 PM10.3.19 5:26:02 PM

10
When Installing the Main Unit
on a Wall
You can install the main unit on a wall.
CAUTION:
• Be sure to have the main unit installed by qualified
personnel.
• DO NOT install the main unit on the wall by yourself
to avoid unexpected damage from them falling off the
wall due to incorrect installation or weakness in wall
structure.
• Care must be taken in selecting a location for
installation on a wall. Injury to personnel or damage to
devices may result if the main unit installed on a wall
interfere with daily activities.
• The main unit weighs approximately 2.3 kg. Sufficient
care must be taken when installing the main unit on a
wall to prevent any accidents caused by the main unit
falling off.
• Before installing the main unit on a wall, check the wall
(or other related aspects) to install, and verify whether
the strength of the wall will be sufficient to support the
weight of the main unit.
• Do not install the main unit to a plywood or
plasterboard wall. The main unit will fall and sustain
damage as a result.
• The screws needed for attachment are not supplied.
Use screws which are compatible with the strength and
material of the pillar or wall.
• When installing the main unit, the screws must
be secured tightly in all three locations. Failure in
installing the main unit to the wall using all three holes
on the back of the main unit makes for an unstable
installation and it constitutes a safety hazard as the
main unit may fall down.
Example of attachment
The procedure below is an example of how to attach the
main unit to a wall.
It does not make any guarantee for safety while using the
main unit on the wall. Take into account such factors as the
material, strength, and the status of the wall as well as the
reinforcing material, and the possible changes that will take
place over time.
• You need to connect the cords to the main unit before
attaching it to the wall.
• DO NOT plug the power cord into an AC outlet before
installing the main unit on the wall.
1Select the place (wooden wall) where the main unit is
to be attached.
Avoid a plywood or plasterboard wall.
2For reinforcement purposes, prepare the wooden
board which will be used to install the main unit on
the wall.
Before proceeding, check the position of the supports
inside the wall.
Use a sturdy board sized as below:
A
Board
B
C
Supports inside the wall
A (Height): Higher than the main unit
B (Width): Wider than the distance between the two
supports inside the wall
C (Thickness): 9 mm to 15 mm
Continued on the next page
EN_NX-T5[B].indb 10EN_NX-T5[B].indb 10 10.3.19 5:26:02 PM10.3.19 5:26:02 PM

11
5Hook the main unit onto the mounted screws and
slide the main unit down.
Make sure that the main unit is installed securely.
• Adjust the screws if the main unit is not installed
securely.
Slide down.
3Attach the board to the wall.
Anchor the board securely in at least four places to the
supports inside the wall.
The diameter of the screws must be more than 4
mm and their length must be 3 times longer than the
thickness of the board mounted on the wall (also take
the thickness of the wall into account).
4Mount three screws (not supplied) to the board which
has been attached on the wall.
Attach the screws to the board as illustrated below.
D
Screws (not
supplied)
FF
E
D: 240 mm
E: 78 mm
F: 120 mm
Board
G
J
K
G: Keep the space of 6 to 7 mm.
H: 10.5 to 12 mm
I: Within 3.5 mm
J: 12 to 19 mm (According to
the thickness of the board)
K: 5 mm
H
I
EN_NX-T5[B].indb 11EN_NX-T5[B].indb 11 10.3.19 5:26:02 PM10.3.19 5:26:02 PM

12
• Do not place anything on top of the main unit. Doing so
may cause the main unit to fall down, and cause injury to
the persons around.
• Do not climb onto the main unit or hang from it. Doing
so may damage the main unit and/or cause injury to the
person.
Take care specially when there are small children at the
home.
• Avoid sandwiching the cords between the main unit and
wall. This may upset the balance of the main unit and
cause the main unit to fall down.
• Make sure that the connected cords will not interfere
with daily activities and that the users will not be caught
in the cords.
• Do not pull the connected cords with excessive force.
• Check regularly that none of the screws are loose.
• In the event that the main unit has fallen, turn off the
power, disconnect the power cord from the AC outlet.
Then, contact your dealer for an inspection and repairs.
Using the main unit in this state may cause a fire or
electrical shock.
• Do not place valuables (breakables) underneath the
location where the main unit is installed. They will be
damaged if the main unit should fall.
JVC bears no responsibility for any accidents or damage
resulting from inadequate assembly or mounting,
insufficient strength of attachment, misuse or abuse, or
natural disasters.
Preparing the Remote Control
Insert the battery into the remote control by matching the
polarity (+ and –) correctly.
• If the range or effectiveness of the remote control
decreases, replace both batteries.
When using the remote control
Point the top of the remote control towards the remote
sensor as directly as possible. If you operate it from a
diagonal position, the operating range (approx. 5 m) may
be shorter.
When placing the main unit vertically (with the DISPLAY MODE
switch set to “V”)
When placing the main unit horizontally (with the DISPLAY
MODE switch set to “H”)
R03/LR03/AAA
Remote sensor
Remote sensor
EN_NX-T5[B].indb 12EN_NX-T5[B].indb 12 10.3.19 5:26:03 PM10.3.19 5:26:03 PM

13
Changing the Scanning Mode
INFO
Select the video signal output according to
the type of your TV after connecting the main
unit to the TV with an HDMI cable.
• Turn on the System before setting the scanning mode.
See page 15.
• You don’t need to make this setting when you connect
the TV with a composite video cord.
1Select DVD/CD as the source.
2Enter the scanning mode setting.
• Finish the following process while the setting item is
flashing.
Remote
ONLY
AUTO
576P
720P
1080P
1080I
3Select the scanning mode.
AUTO Normally select this.
576P
720P
1080I
1080P
Select a scanning mode when it is
needed.
• Available settings vary according
to the available resolutions of the
connected TV.
4Store the setting.
EN_NX-T5[B].indb 13EN_NX-T5[B].indb 13 10.3.19 5:26:03 PM10.3.19 5:26:03 PM

14
Display Indicators
The indications on the display tell you a lot of things while you are operating the System.
Before operating the System, be familiar with when and how the indicators light on the display.
pUSB indicator
• Lights when “USB” is selected as the source and a USB
mass storage class device is connected.
qPROGRESSIVE (progressive) indicator
• Lights when the progressive scanning mode is
selected.
wHD (High Definition) indicator
• Lights when a High Definition (720p/1080i/1080p)
video signal is emitted from the HDMI OUT terminal.
eMain display
• While listening to FM: band (or preset number) and
station frequency appear.
• While “DGTL (DIGITAL) IN,” or “AUDIO IN”
is selected as the source: the current source name
appears.
• While playing a disc or file: current status appears.
1FM reception indicators
• ST (stereo): lights while an FM stereo station with
sufficient signal strength is tuned in.
• MONO (monaural): lights while receiving an FM
station in monaural.
2Digital audio signal format indicators
3HDMI indicator
• Lights when an HDMI video signal is output.
4FM indicator
• Lights when FM is selected as the source.
5CHAP. (chapter) indicator
• Lights to indicate the chapter number.
6TRK (track) indicator
• Lights to indicate the track number.
7PG (program) indicator
• Lights when an Original Program on DVD-VR is
played.
8PL (Play List) indicator
• Lights when a Play List on DVD-VR is played.
9Playback mode indicators
• PRG: lights when Program Play is activated.
• RND: lights when Random Play is activated.
• Repeat Mode indicators:
– : lights when One Track/File/Chapter Repeat is
activated.
– : lights when One Group/Title/Original
Program/Play List Repeat is activated.
– : lights when All Track/File/Title/Original
Program Repeat is activated.
– : lights when A-B Repeat is activated.
EN_NX-T5[B].indb 14EN_NX-T5[B].indb 14 10.3.19 5:26:03 PM10.3.19 5:26:03 PM

15
Daily Operations—Playback
In this manual, operations using the remote control
are mainly explained; however, you can use the buttons
and controls on the main unit if they have the same (or
similar) name and marks.
1Turn on the power.
The lamp on the main unit lights blue.
• The POWER ON/STANDBY lamp on the
subwoofer also lights blue.
• Instead of pressing , the System is turned on by
pressing one of the following buttons:
– DVD/CD, USB, FM, AUDIO IN, SOURCE, 3, 0
2Select the source.
From the remote control
• For disc: Press DVD/CD. See page 17.
• For FM: Press FM. See page 16.
• For USB: Press USB. See page 17.
• For DIGITAL IN/AUDIO IN:
Press AUDIO IN repeatedly to select “DGTL IN” or
“AUDIO IN.” See page 19.
On the main unit
Pressing SOURCE repeatedly changes the source as
follows:
• You can change the display information by pressing
DISPLAY. For details, see page 21.
3Adjust the volume.
You can adjust the volume level from “VOL MIN”
(level 0) to “VOL MAX” (level 50).
To turn off (standby) the System
The lamp on the main unit lights red.
• The POWER ON/STANDBY lamp on
the subwoofer also lights red.
• A small amount of power is always
consumed even while on standby.
DO NOT turn off (standby) the System with
the volume set at an extremely high level;
otherwise, the sudden blast of sound may
damage your hearing and speakers when you
turn on the System or start playback.
Remote control
Number
buttons
Main unit
or
or
or
EN_NX-T5[B].indb 15EN_NX-T5[B].indb 15 10.3.19 5:26:04 PM10.3.19 5:26:04 PM

16
How to select a number
Press the number buttons to enter the number, then
press ENTER.
Some items are automatically selected without pressing
ENTER.
Examples:
To select number 7, press 7, then ENTER.
To select number 14, press 1, 4, then ENTER.
To select number 78, press 7, 8, then ENTER.
To select number 104, press 1, 0, 4, then ENTER.
Listening to the FM Radio
INFO
• This System cannot receive the AM (LW/MW) band.
To tune in to a station
Remote
ONLY
While FM is selected...
Frequency starts changing on the display.
When a station (frequency) with sufficient signal strength
is tuned in, the frequency stops changing.
• When you repeatedly press the button, the frequency
changes step by step.
To manually stop the search, press either button.
If the FM reception is poor
Remote
ONLY
The MONO (monaural) indicator lights on the display.
Reception will improve though stereo effect is lost—
Monaural reception.
To restore the stereo effect, press the button again. The ST
(stereo) indicator lights on the display when an FM stereo
broadcast with sufficient signal strength is received.
To preset the stations
Remote
ONLY
You can preset 30 FM stations.
1Tune in to a station you want to preset.
2Activate the preset number entry mode.
• Finish the following process while the preset number
is flashing.
3Select a preset number for the station you store.
• To select a number with the number buttons, see
“How to select a number” on the left column.
4Store the station.
To tune in to a preset station
Remote
ONLY
While FM is selected...
Select the preset number for the station you stored.
• To select a number with the number buttons, see
“How to select a number” on the left column.
or
or
EN_NX-T5[B].indb 16EN_NX-T5[B].indb 16 10.3.19 5:26:04 PM10.3.19 5:26:04 PM

17
Playing Back a Disc/USB Mass Storage Class
Device
INFO
To insert a disc
The disc player panel is automatically closed and the
System starts reading the disc.
To close the disc player panel manually, press 0.
• For some discs, playback automatically starts after the
System finishes reading the disc.
To connect a USB mass storage class device
• For connecting a USB mass storage class device, see page
9.
• Always set the volume level to the minimum when
connecting or disconnecting a USB mass storage class
device.
• To disconnect a USB mass storage class device safely,
turn off the System before disconnecting the device.
To play back a disc/USB mass storage class device
While DVD/CD or USB is selected...
To start:
To pause: To stop:
To release, press 3.
If different types of playable files (audio/still
picture/moving picture) are recorded
Select a file type on the control screen (on the TV).
• For still/moving picture files, it appears while playback is
stopped. For details, see page 31.
1
Control screen appears on the TV.
1Audio
2Still picture
3Moving picture
2Select a file type.
When the sound of DVD Video or DVD-VR is not loud enough
DVD sound is sometimes recorded at a lower level than
other discs and sources. You can set the increase level for
the currently loaded DVD (without changing the volume
level). To set the increase level, see page 34.
Resume play
The System can store the stop point of playback. When you
start playback again by pressing 3, playback starts from the
position where you have stopped.
To stop completely, press 7twice.
• The following operations also erase the memory of the
stop point:
– Pressing 0to open the disc player panel
– Pressing to turn on the System when the System is
turned off (standby).
Auto Standby
While DVD/CD or USB is selected...
The System turns off (standby) automatically if no
operation is done for about 30 minutes after playback is
stopped.
Label side
123
Remote
ONLY
Current file type to play
EN_NX-T5[B].indb 17EN_NX-T5[B].indb 17 10.3.19 5:26:05 PM10.3.19 5:26:05 PM
