K-Line CROP CADET SG60T Instruction Manual

1023 W 9th St | PO Box 248, Grafton, ND 58237 | USA
74 Young Rd | PO Box 340 ,Cowra, NSW 2794 | AUS © K-Line Ag 2020
OPERATOR &OPERATOR &
SAFETY MANUALSAFETY MANUAL
SG60T SEEDER
CROP CADET

Would you like a copy of
this manual emailed to you?
Send your request to [e-mail] or scan here:

Dear Customer
Thank you for purchasing a SG60T Seeder® made by K-Line Industries. We would like to assure you that
you have made a good choice, and will be able to rely on this high quality piece of equipment. We ask you
to follow the user’s instructions closely, as this will ensure that you experience the benefits of using the
machine without experiencing the unnecessary down time caused by misuse.
When you receive the machine, make sure that it has not been damaged during transportation and that
no parts are missing. Contact your dealer immediately if any parts are missing. Ensure that all
components are correctly adjusted.
The return of the Warranty Registration Form Page 44 will enable a prompt and efficient identification of
your Seeder and attention to any concern you may have.
Before operating PLEASE TAKE THE TIME TO LEARN the process of operation. Do not take the unit for
granted; ease into becoming familiar with your new equipment. The operator should be a responsible
adult familiar with farm machinery and trained for this purpose. Do NOT allow persons to operate or
assemble the unit until they have read this manual and understand how to use this machine, and observe
the safety precautions.
Never exceed the limits of this machine. If its ability to do a job, or to do so safely, is in question - DO NOT
TRY IT.
DO NOT attempt to operate this equipment under the influence of drugs or alcohol.
Remember - Your best assurance against accidents is a careful and responsible operator.
If you have any questions not answered in this manual or require additional copies or the manual is
damaged, please contact your dealer or be free to phone us on our free call number:
USA - 1800 445 6882
AUS - 1800 194 131
The team here at K-Line Agriculture trust you enjoy a good season and prove the benefits of owning and
operating a quality machine that is built to perform.
Signed:
James Larsen
General Manager

SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
4
LEGAL DISCLAIMER
LAST UPDATED: 11/04/20
The information contained in the K-Line Industries Pty Ltd (also trading as “K-Line Ag”
and “K-Line Agriculture”) manual is for general information purposes only. K-Line
Industries Pty Ltd assumes no responsibility for errors or omissions in the contents of the
book.
In no event shall K-Line Industries Pty Ltd be liable for any special, direct, indirect,
consequential, or incidental damages or any damages whatsoever, whether in an action
of contract, negligence with the use of the Service or the contents of the Service. K-Line
Industries Pty Ltd reserves the right to make additions, deletions, or modification to the
contents of this manual at any time without prior notice.

5
SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
OP & SAFETY
MANUAL
Table Of Contents
CUSTOMER LETTER 3
LEGAL DISCLAIMER 4
SPECIFICATIONS 6
INTRODUCTION 7
Identifying The Machine 7
Tractor Requirements 7
Definitions Used In This Manual 7
Availability Of Genuine Parts 7
RISK MANAGEMENT 8-10
Identifying Hazards 8
Monitor & Review Control Measures 8
Risk Assessment 8
Risk Control 8
Risk Assessment Score Chart 9
Risk Assessment Table 10
SAFETY 11-28
Safety Precautions 11
Important Notice (MUST READ) 12
Safety Alert Symbol 13
Signal Words 13
Safety Decal Placement & Quantities 14
Safety Decals 15-17
Logo Stickers & Quantities 18
Safety Sign Care 19
Instruction For Safe Operation 20
Tyre Pressure & Safety 21
Hydraulic Operation & Safety 22
Hydraulic Hose Hook-Up 22
Hydraulic Hose Colour-Codes 22
Priming Hydraulic System 23
Hydraulic System Failure 24
Electrical Connection Hook-Up 24
Hooking/Unhooking To Tractor 25
Transporting/Roading 26
Safe Operation In Field/Transport 26
Folding/Unfolding Machine 27
Wing Wheel Lock-Out 27
Transporting/Roading 2nd Part 28
FIELD OPERATION 29-33
Seeder Start-Up Tips 29
Performing Maintenance 30
Starting Work 30
Ram Stop Combinations 31
Maintenance & Safe Procedures 32
After Delivery Check-List 33
Wheel Bearings 33
Seeder Tine Assrmbly 34
Hydraulic Cylinder Layout 35
Bolt Torque Tables 36-37
TESTIMONIAL PERMISSION FORM 38-39
WARRANTY 42-46
Warranty Letter 42
Warranty Registration Form 44
Warranty Request From 46
END OF DOCUMENT 48

SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
6
Figure 1
CROP CADET SPECIFICATIONS
FOLDING WINGS 5” 125MM 6” 150MM 8” 200M 10” 250MM 12” 300MM
32MM COIL TINE
SPRING RELEASE TINE
OPERATING WIDTH
6125MM 6150MM 6200MM 6000MM 6000MM
TiNE SPACING
5” 6” 8” 10” 12”
TRACTOR POWER
295-390HP
220-245KW
245-330HP
185-245KW
185-250HP
140-185KW
145-190HP
110-145KW
120-160HP
90-120KW
NO. TYNES
49 41 31 24 20
WHEEL EQUIPMENT
6 X 11.5”/ 80 R15.3
TRANSPORT HEIGHT
3.8M
TRANSPORT WIDTH
3.5M
WEIGHT
3800KG - FRAME ONLY (NO TINES, NO SEED BIN)
ADD 50KG PER TINE
TRACTOR HYDRAULIC REQUIREMENTS
HYDRAULIC REMOTES
2 X DOUBLE SPOOL FOR FRAME
+ QTY REQUIRED TO SUIT BIN OPTION
HYDRAULIC PRESSURE
2800 PSI (190 BAR) (19000 KPA)
HYDRAULIC FLOW
CAPACITY
FRAME REQUIREMENTS: MAX FLOW 10GPM (38 LITRES/MIN)
FLOW ADJUSTABLE
IF SEED BIN REQUIREMENTS GREATER THAN FRAME REQUIREMENTS, ADHERE TO
SEED BIN REQUIREMENTS

7
SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
Figure 2
When you receive the machine, make sure that it has not been damaged during transportation and that no
parts are missing. Only by giving us immediate advice can the necessary replacement parts be obtained.
Ensure that all components are correctly adjusted.
GENUINE PARTS
K-Line spare parts and accessories have been specifically designed and developed for the machines
produced. We would call your attention to the fact that non-genuine parts and accessories are not
recommended by K-Line. The use of such replacement parts frees K-Line from all liability and makes the
warranty void. The installation and/or use of non-genuine parts may, because of technical characteristics
of construction, modify or influence the performance of the machine negatively.
IDENTIFYING THE MACHINE FOR REQUESTING SPARE PARTS
The machine is identified by the serial number on the metal plate on the machine. When requesting
spare parts or maintenance service, please indicate the model and number of your equipment to ensure
prompt and efficient attention.
TRACTOR REQUIREMENTS
6-8 Horsepower x no. of tines in machine
4.5 - 6 Kilowatts x no. of tines on machine
Tractor weight must be same as or greater than the towed unit.
Hydraulic valves 2 x double spool (plus qty required for seed bin)
Hydraulic operating pressure 2800 PSI approximately
DEFINITIONS USED IN THIS MANUAL
AFTER DELIVERY

SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
8
Risk management is the process of finding out what may cause an injury, deciding what may happen as
a result, and doing something about it.
The steps of risk management are:
• Identify the hazards to workplace health and safety arising from work activities
• Assess the risks
• Determine and implement control measures to reduce risk
• Monitor and review the effectiveness of the control measures
IDENTIFYING HAZARDS
Prior to commencing work, all hazards related to the work tasks should be identified. The selection of
the appropriate work procedure(s) will depend on the type of work procedure(s) and hazards involved.
Regular safety inspections will also identify hazards and ensure that control measures are in place.
RISK ASSESSMENT
Risk assessment allows appropriate control measures to be developed. Once hazards have been
identified, they should be assessed in terms of their potential to do harm. To assess risk, consideration
should be given to probability and consequences. (SEE RISK ASSESSMENT SCORE CHART - Pg 9).
RISK CONTROL
Risk control is the process of eliminating or reducing risk factors. Control measures should be chosen
and implemented to eliminate or reduce risk as far as practicable. When deciding on the most appro-
priate measures to use, practicality and acceptance of the control measures should be considered. Safe
Working Procedures will be developed for all high – medium risk hazards.
MONITOR AND REVIEW CONTROL MEASURES
The risk identification, assessment and control process requires regular monitoring to ensure the
implemented control measures perform as originally intended and continue to prevent or adequately
control the risk of injury or incident. Control measures should also be checked carefully to ensure that
new hazards are not created, directly or indirectly, by the original control measures.
RISK MANAGEMENT

9
SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
Figure 3
AT ALL TIMES COMPLY WITH RECOMMENDATIONS
AND REQUIREMENTS OF THE MANUFACTURER AND
THE ENVIRONMENTAL PROTECTION AUTHORITY
RISK ASSESSMENT SCORE CHART

SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
10
RISK ASSESSMENT CONTINUEDCONTINUED
CODE HAZARDS RISK
SCORE CONTROL REVISED RISK SCORE
1(A).
CRUSHING - WHEN
ADJUSTING AND CLEANING,
AS MACHINE MAY DROP
WITHOUT WARNING
1
ADJUSTING & CLEANING MUST ONLY BE
DONE WHEN MACHINE IS LOWERED
OR IN TRANSPORT POSITION AND ONLY
AFTER ALL CHAINS AND BOLTS HAVE BEEN
CHECKED FOR TIGHTNESS & WEAR IN THE
LOWER POSITION
5
1(B). CRUSHING - IMPROPER
USE OF JACK 1
ENSURE JACK IS INSTALLED CORRECTLY &
JACK RECEIVES REGULAR MAINTENANCE.
KEEP FEET AND BODY CLEAR WHEN
OPERATING
5
1(C). CRUSHING - WHEN
HITCHING TRACTOR 2
ENSURE NO PERSONNEL ARE BETWEEN
TRACTOR & HARROW BAR WHEN HITCH-
ING TRACTOR
5
1(D).
CRUSHING - PRIOR TO
PRIMING HYDRAULIC
SYSTEM, AS MACHINE MAY
DROP WITHOUT WARNING
1
MACHINE MUST BE LOWERED INTO
WORKING POSITION USING SUITABLE
LIFTING EQUIPMENT BEFORE PRIMING
IS EFFECTED BY SLIGHTLY LOOSENING
FITTING/S INTO CYLINDERS AND
OPERATING TRACTOR HYDRAULICS TO
ACHIEVE FULL UNINTERRUPTED TRAVEL
OF CYLINDER SEVERAL TIMES. THEN
RE-TIGHTEN HYDRAULIC TINE FITTINGS
5
1(E).
SUDDEN LIFT OF DRAWBAR
CAUSING SEVERE INJURY,
IF MACHINE BECOMES
UNHITCHED
1
ENSURE ALL THREE JACKS ARE CORRECTLY
POSITIONED AND TAKING WEIGHT BEFORE
REMOVING DRAWBAR PIN. STICKERS WARN
OPERATOR
5
2(A).
PENETRATION OF
OIL - BROKEN OR BADLY
MAINTAINED HYDRAULIC
LINES
2
MAINTAIN REGULAR CHECKS ON
HYDRAULIC SYSTEM FOR WEAR & CHECK
ALL FITTINGS ARE SECURE
5
2(B).
RUPTURE OF OIL LINES BY
OVER PRESSURE WHEN
MACHINE COMES TO
SUDDEN STOP BEFORE
FULLY LOWERED TO
WORKING POSITION
2
ENSURE TRACTOR OIL FLOW IS LIMITED
TO REDUCE FALLING SPEED OR DO NOT
INTERRUPT MACHINE FALLING UNTIL
MACHINE IS FULLY IN LOWERED POSITION
5
3.
COLLISION - HYDRAULICS
ACCIDENTALLY LOWERED
WHEN MACHINE IS BEING
OPERATED IN TRANSPORT
1
SAFETY PINS MUST BE PUT IN PLACE AS
SOON AS MACHINE IS PUT IN TRANSPORT
POSITION AND IF TRAVELLING ON PUBLIC
ROADS TO DISCONNECT HYDRAULICS
FROM TRACTOR
5
ALL HAZARDS & RISKS ARE CONTROLLED THROUGH SAFE WORKING
PROCEDURES & ADEQUATE SIGNAGE
Figure 4

11
SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
WARNING!!!
SAFETY PRECAUTIONS
FAILURE TO OBSERVE THE FOLLOWING
INSTRUCTIONS COULD RESULT IN SERIOUS
INJURY OR DEATH
It is the responsibility of the purchaser to:
• Maintain in as new condition all warning and safety signs and devices at all time.
• Consult electricity authorities and all relevent energy companies to determine safe working
distances from overhead power lines etc BEFORE operation of the machine. POWER LINES CAN
ARC AND ELECTROCUTE WITHOUT COMING IN CONTACT!!!
• Ensure all operators are familiar with this manual and all safety devices and features of the machine.
• Take every reasonable precaution as is commonly expected in this industry and in the operation of
the machine.
• Maintain the machine at all times in a condition that is safe to operate, and ensure strength and
balance of machine is adequate to accommodate the K-Line products you have purchased.
• Conduct a risk assessment, taking all risks into consideration before comissioning machine for
use.

SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
12
It is the responsibility of the operators to:
Read and understand your manual.
Take time to familiarize yourself with the
operation of this machine, particularly
the safety signs and devices fitted to this
machine.
USE OF MACHINE BEYOND ITS LIMITS OR
INTENT OF OPERATION WILL VOID WARRANTY.
Slow down in terrain such as rocks, or other difficult
operating conditions.
• Safe work procedure analysis must be performed
before attempting to assemble this machine.
• Do not attempt to operate this equipment under the
influence of Drugs & Alcohol.
• K-Line Ag can not be held responsible for any injury,
death or property damage in the process of
assembling this machine.
• Ensure hydraulic system is fully primed, pg 23.
IMPORTANT
NOTICE
For further information
please contact :
US: 1800 445 6882
AU: 1800 194 131

13
SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
When you see this symbol, you must be
alert to the possibility of injury or death.
SAFETY ALERT SYMBOL
SAFETY ALERT!!
SAFETY...YOU CAN LIVE WITH IT
SIGNAL WORDS
Indicates potentially
hazardous situation that,
if not avoided MAY result
in serious injury or death
if proper safety measures
are not taken.
Indicates a potentially
hazardous situation that, if
not avoided COULD result
in serious injury or death if
proper safety measures are
not taken.
The use of signal words, DANGER, WARNING
AND CAUTION relate to the safety messages.
The appropriate signal word is selected when
using the following guidelines.
Indicates an imminently
hazardous situation that if
not avoided, WILL result
in serious injury or death if
proper safety measures are
not taken.
YOUR SAFETY AND THE SAFETY OF OTHERS IS IMPORTANT
• BE PREPARED!
• BE SAFE!
• BE AWARE!
• BE SEEN!
ALL OPERATORS MUST UNDERSTAND AND ABIDE BY MAINTENANCE SAFETY
PROCEDURES SET OUT IN THIS BOOK.
IT IS THE RESPONSIBILITY OF THE ASSEMBLER TO ATTACH ALL SAFETY SIGNS AND
DEVICES TO THIS MACHINE. FAILURE TO OBSERVE THE INSTRUCTIONS OF THIS BOOKLET
COULD RESULT IN SERIOUS INJURY OR DEATH.

SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
14
IMPORTANT
If safety signs have been damaged, removed, become illegible or parts replaced
without decals, new decals must be applied. New decals are available from your
authorized dealer or direct from factory.
Figure 6
SAFETY DECAL PLACEMENT
Decals & quantities shown in table below:
QTY
DECALS ON MACHINE
A B C D E G H J K L M N P R
1 6 1 1 4 1 1 1 1 1 4 2 4 1
Figure 5

15
SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
A. 9WD-W022
B. 9WD-C023
C. 9WD-W05
SAFETY DECALS
D. 9WD-D04
E. 9WD-D01V
F. 9WD-D01H
G. 9WD-W021
H. 9WD-C04
I. 9WD-I01

SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
16
J. 9WDW-T5
K. 9WDD-T3
L. 9WD-W024
M. 9WD-W10
N. 9WD-W01
UPTHRUST FORCE ON DRAWBAR
ـTractor weight must equal machine weight
ـDrawbar pin must be firmly secured
ـSafety chains attached correctly
Failure to comply will result in serious injury or death
0. 9WD-D01
R. AUS SPEED STICKER MAX 32KPH/20MPH
SAFETY DECALS CONTINUEDCONTINUED
T. HYDRAULIC COLOUR
S. 9WD-W02

17
SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
U. 9WD-I02
W. FOLDING INSTRUCTION
Y. WHEEL DEPTH
SAFETY DECALS CONTINUEDCONTINUED
*NOTE:
WHEEL DEPTH STICKER:
WHITE WITH CUT OUTS
(SHOWN AS BLACK)
P. 9WD-R01
Q. 9WD.F01

SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
18
LOGO STICKERS
CROP CADET:
760 X 80MM
(2 x sides of drawbar)
(2 x sides of centre frame)
K-LINE AGRICULTURE STICKER:
350 X 110MM
(2 x back of centre frame)
Figure 8
Figure 9
Figure 7
Figure 10
CROP COMMANDER DECAL ON BOTH SIDES OF RHS
K-LINE AG DECAL ON BOTH SIDES OF CENTER FRAME

19
SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
SAFETY SIGN CARE
• Keep safety signs clean and legible at all times.
• Replace safety signs that are missing or have become illegible.
• Replaced parts that displayed a safety sign should also display the current sign.
TO ORDER SAFETY DECALS CONTACT:
USA: K-Line Agriculture
PO Box 248
1023 W 9th St
Grafton ND 58237
Email: [email protected]
Free-call: 1800 445 6882
HOW TO INSTALL SAFETY SIGNS:
• Be sure that the installation area is clean and dry.
• Decide on the exact position before you remove the backing paper.
• Remove the smallest portion of the split backing paper.
• Align the decal over the specified area and carefully press the small portion with the exposed sticky
backing in place.
• Slowly peel back the remaining paper and carefully smooth the remaining portion of the decal in
place.
• Failure to comply could result in serious injury or death.
Australia: K-Line Agriculture
PO Box 340
74 Young Rd
Cowra NSW 2794
Email: [email protected]
Free-call: 1800 194 131
Locate where necessary. (Refer to safety decal placement, Pg 14)Figure 11

SG60 SEEDER CROP CADET OPERATOR & SAFETY MANUAL
20
INSTRUCTIONS FOR SAFE OPERATION
The machine should not be driven, maintained or repaired by people who are not aware of the contents
of this user manual.
This User’s Manual should be read and understood by all those who use, adjust or control the machine.
These safety instructions should be passed onto other users.
1. BE SURE tractor drawbar pin is locked securely in place.
2. Make SURE all personnel are clear of machine when folding/unfolding & when in operation.
3. DO NOT operate unit while people are within 20 metres.
4. KEEP CLEAR of machine when in working & lifted position - AT ALL TIMES.
5. Hydraulic lines & hoses operate under extremely high pressure & if damaged or worn MUST be repaired
IMMEDIATELY.
6. Keep HANDS & BODY CLEAR of any oil leakage as high pressure oil can penetrate the skin.
7. All bolts, nuts & pins MUST be well secured.
8. DO NOT stand on or ride on machine.
9. NEVER get under or on top of machine when it is supported by jack and KEEP TO LEFT OF MACHINE
& KEEP BODY CLEAR when operating jack.
10. NEVER alter the depth control or change to or from transport position, while another person adjusts
safety pins.
11. This machine has not been designed or built for road use. Please consult State Police, Roads & Traffic
Authority and any other relevant authorities regarding the roads concerned when in transit.
12. DO NOT operate if any part of this machine is within 10 metres of overhead power lines.
13. SPEED LIMIT - Subject to permit regulations, local government Authorities, road surface conditions &
prime mover towing recommendations. Maximum towing speed is 32km/hr. DO NOT EXCEED AT ANY
TIME.
14. TYRE PRESSURE - Consult recommended tyre pressure table.
15. Before operation, all hydraulic cylinders must be primed.
IIMPORTANTMPORTANT
K-LINE AG Spare parts and accessories have been specifically designed and developed for the machines
produced. We call your attention to the fact that non genuine parts and accessories are not recommended
by K-LINE AG. The use of such replacement parts frees K-LINE AG from all liability and makes the warranty
void. The installation and/or use of non genuine parts may, because of the technical characteristics of
construction, modify or influence the performance of the machine negatively.
REMEMBER AN IMPLEMENT WITH NO BRAKES REQUIRES
CAUTION & COMPETENCE
