6 English
Geringe Förderleistung
1. Den Saugschlauch auf Dichtheit und Löcher unter-
suchen.
2. Die Flachdichtung zwischen Gerät und Saug-
schlauch prüfen.
3. Einen stabileren Saugschlauch verwenden.
4. Den Saugfilter komplett untertauchen.
5. Den Saugfilter säubern.
6. Die Pumpe näher zur Wasserquelle platzieren. Hö-
henunterschied zwischen Pumpe und Wasserober-
fläche verringern.
7. Kürzere Schläuche verwenden.
Garantie
In jedem Land gelten die von unserer zuständigen Ver-
triebsgesellschaft herausgegebenen Garantiebedin-
gungen. Etwaige Störungen an Ihrem Gerät beseitigen
wir innerhalb der Garantiefrist kostenlos, sofern ein Ma-
terial- oder Herstellungsfehler die Ursache sein sollte.
Im Garantiefall wenden Sie sich bitte mit Kaufbeleg an
Ihren Händler oder die nächste autorisierte Kunden-
dienststelle.
(Adresse siehe Rückseite)
Technische Daten
Technische Änderungen vorbehalten.
EU-Konformitätserklärung
Hiermit erklären wir, dass die nachfolgend bezeichnete
Maschine aufgrund ihrer Konzipierung und Bauart so-
wie in der von uns in Verkehr gebrachten Ausführung
den einschlägigen grundlegenden Sicherheits- und Ge-
sundheitsanforderungen der EU-Richtlinien entspricht.
Bei einer nicht mit uns abgestimmten Änderung der Ma-
schine verliert diese Erklärung ihre Gültigkeit.
Produkt: Schmutzwasserpumpe
Typ: 1.812-xxx
Einschlägige EU-Richtlinien
2006/42/EG (+2009/127/EG)
2014/30/EU
2011/65/EU
Angewandte harmonisierte Normen
EN 809: 1998: A1: 2009 + AC: 2010
EN 61000-6-3: 2007+A1: 2011+AC: 2010
EN 61000-6-1: 2007
Angewandtes Konformitätsbewertungsverfahren
2000/14/EG: Anhang V
Die Unterzeichnenden handeln im Auftrag und mit Voll-
macht des Vorstands.
Dokumentationsbevollmächtigter: S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Tel.: [phone]
Fax: [phone]
Winnenden, 2018/10/01
Contents
General notes
Read these original operating instruc-
tions and the enclosed safety instruc-
tions before using the device for the first
time. Proceed accordingly.
Keep both books for future reference or for future own-
ers.
Intended use
This waste water pump must not be operated in en-
closed spaces and is only approved for outdoor opera-
tion.
This waste water pump is not approved for use in the
food industry.
Only fresh water may be delivered using the pump.
Using the pump for inflammable substances such as
petrol, diesel or heating oil is prohibited due to the dan-
ger of fire and explosion.
Delivering salt water, acidic chemicals and other corro-
sive substances can damage the pump.
As delivered, this waste water pump is intended for use
at heights of up to 1500 m above sea level. It can be ad-
justed by an authorised Customer Service department
for use at higher elevations.
If a device that has been adjusted for use at higher ele-
vations is used below this height then this can result in
destruction of the motor through overheating.
Environmental protection
The packing materials can be recycled. Please
dispose of packaging in accordance with the en-
vironmental regulations.
Electrical and electronic appliances contain valu-
able, recyclable materials and often components
such as batteries, rechargeable batteries or oil,
which - if handled or disposed of incorrectly - can
pose a potential threat to human health and the environ-
ment. However, these components are required for the
correct operation of the appliance. Appliances marked
by this symbol are not allowed to be disposed of togeth-
er with the household rubbish.
Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.com/REACH
Accessories and spare parts
Only use original accessories and original spare parts.
They ensure that the appliance will run fault-free and
safely.
Information on accessories and spare parts can be
found at www.kaercher.com.
Scope of delivery
Check the contents for completeness when unpacking.
If any accessories are missing or in the event of any
shipping damage, please notify your dealer.
Safety instructions
Hazard levels
DANGER
● Indication of an imminent
threat of danger that will lead
to severe injuries or even
death.
WARNING
● Indication of a potentially dan-
gerous situation that may lead
to severe injuries or even
death.
CAUTION
● Indication of a potentially dan-
gerous situation that may lead
to minor injuries.
WWP 45
Pumpe
Nennweite“ 3
Fördermenge maximal l/h 45000
Ansaughöhe (max.) m7
Förderhöhe (max.) m 25
Verbrennungsmotor
Motortyp Einzylinder
Bauart 4-takt
Kühlart luftgekühlt
Hubraum cm3196
Motorleistung kW/PS 5,1/6,9
Kraftstoffart Benzin, min. 88 Oktan
Inhalt Kraftstofftank l 3,6
Einsatzdauer bei vollem Tank h 2,1
Motorölmenge l 0,5
Ölsorte 10 W-30
15 W-40
Zündkerzentyp F5T, F6TJC, F7TJC
Maße und Gewichte
Länge mm 580
Breite mm 440
Höhe mm 450
Gewicht ohne Kraftstoff kg 36
CO2-Emissionen gemäß dem Messverfahren der EU-Verordnung 2016/1628 Euro V
Motor g/kWh 790
General notes ..................................................... 6
Intended use ....................................................... 6
Environmental protection .................................... 6
Accessories and spare parts............................... 6
Scope of delivery ................................................ 6
Safety instructions............................................... 6
Device description............................................... 7
Initial start-up ...................................................... 8
Chairman of the Board of Management
Director Regulatory Affairs & Certification
H. Jenner S. Reiser
Initial startup........................................................ 8
Operation ............................................................ 8
Transport............................................................. 8
Storage ............................................................... 8
Care and service................................................. 8
Troubleshooting guide......................................... 9
Warranty.............................................................. 9
Technical data ..................................................... 9
EU Declaration of Conformity ............................. 9

English 7
ATTENTION
● Indication of a potentially dan-
gerous situation that may lead
to damage to property.
Safety instructions
DANGER
● Danger of injury.
The device is not intended for
use by persons with restricted
physical, sensory or mental
abilities or those lacking in ex-
perience and / or lacking in
knowledge.
Children must be supervised
to prevent them from playing
with the device.
Children and minors must not
use the device.
● Danger of explosion.
Never operate the device in
potentially explosive environ-
ments.
Observe the corresponding
safety instructions when oper-
ating the device in hazard
zones (e.g. a petrol station).
Only fill the fuel specified in
the operating instructions.
Only refuel with the engine
switched off.
 Do not refuel in confined spaces.
Smoking and open flames are
prohibited.
Ensure that no fuel gets on hot
surfaces during refuelling.
Close the fuel tank cap after
refuelling.
Do not operate the device if
fuel has been spilt. Move the
device to another location and
avoid generating sparks.
Store fuel only in approved
containers.
 Do not store fuel in the vicinity
of open flames or devices hav-
ing an ignition flame or that gen-
erate sparks (e.g. oven, heating
boiler or water heater).
Do not spray start spray into
the air filter.
● Danger of fire.
Maintain a minimum distance
of 2 m between inflammable
objects and the muffler.
Do not operate the device in
forests, bushy or grassy areas
unless the exhaust pipe has
been equipped with a spark
catcher.
Keep grass and other soiling
substances away from the
cooling fins.
Do not operate the device if
the fuel system is damaged or
leaking. Check the fuel sys-
tem regularly.
Allow the device to cool down
before storing in closed
rooms.
Danger of electric shock
Do not touch the spark plug or
ignition lead when the device
is in operation.
WARNING
● Health risk
Exhaust gases are toxic. Nev-
er breathe in the exhaust gas-
es. Never operate the device
in confined spaces. Ensure
sufficient ventilation and ex-
traction of the exhaust gases.
Make sure that no exhaust
gases are emitted close to air
vents.
Avoid repeated or prolonged
contact with fuel or engine oil
and do not inhale the fuel va-
pours.
CAUTION
● Danger of burns
Do not touch any hot parts
such as the muffler, cylinder or
cooling fins.
Danger of hearing damage
Do not operate the device
without a muffler. Check the
muffler regularly and have a
damaged muffler replaced.
ATTENTION
● Risk of damage
Use only spare parts from the
original manufacturer.
Old fuel can lead to deposits
in the carburettor and impair
the engine performance. Use
only new fuel.
Do not adjust any control
springs or linkages that might
increase the speed of the en-
gine.
Do not operate the device with
the air filter removed.
Do not pull the starter cord
while the device is running.
Ensure adequate ventilation
so that the device does not
overheat.
Drain all water from the pump
if there is a danger of frost.
Symbols on the device
WARNING
Danger of explosion, risk of fire.
Petrol can cause fires or explosions if handled incorrect-
ly.
Read these operating instructions before using the de-
vice.
Do not operate the device in confined spaces or partially
enclosed areas.
Shut the motor down prior to refuelling.
Fill the tank only up to 16 mm below the upper edge of
the tank to allow room for expansion of the fuel.
CAUTION
Hot surface
The exhaust pipe of the device be-
comes very hot during operation and
can cause burns.
Avoid touching the exhaust pipe.
WARNING
Risk of eye injuries and hearing dam-
age.
Wear safety goggles and hearing pro-
tection when operating the device.

Device description
See cover page for pictures
Illustration A
1Power switch
2Starter cord
3Air filter
4Filling hole
5Fuel tank cap
6Fuel tank
7Oil dipstick
8Oil drain plug
9Output
10 Suction hose port
11 Water drain screw
12 Type plate
13 Fuel cock
14 Choke lever
15 Accelerator lever
Symbols on the device
Clean the air filter every 50 operating hours or every 10
operating hours in the case of dusty environments(see
"Care and maintenance/Cleaning the air filter").

8 English
Note on checking the oil level.
Choke lever
Accelerator lever
Initial start-up
Fill with oil
1. Position the device on a level surface.
2. Unscrew the oil dipstick.
3. Fill with engine oil.
Note: The engine oil is not included in the scope of
delivery. The filling quantity and oil type are speci-
fied in the section "Technical data".
4. Wipe off the oil dipstick.
5. Insert the oil dipstick as far as it will go, but do not
screw in.
6. Pull out the oil dipstick. The oil level must lie in the
marked section of the oil dipstick.
7. Top up the engine oil if the level is too low.
8. Screw in and tighten the oil dipstick.
Initial startup
Check the oil level
1. Position the device on a level surface.
2. Unscrew the oil dipstick.
3. Wipe off the oil dipstick.
4. Insert the oil dipstick as far as it will go, but do not
screw in.
5. Pull out the oil dipstick. The oil level must lie in the
marked section of the oil dipstick.
6. Top up the engine oil if the level is too low.
7. Screw in and tighten the oil dipstick.
Refuelling
1. Unscrew the fuel tank cap.
2. Fill fuel up a maximum of the lower edge of the filling
nozzle.
3. Fit the fuel tank cap and screw tight.
Positioning the pump
The delivery performance of the pump is heavily de-
pendent on the operating conditions. Adhering to the
following rules will ensure optimum performance.
Keep the height difference between the water sur-
face and the pump as small as possible.
Position the pump so that the suction hose is a short
as possible.
A long pressure hose is better than a long suction
hose.
Do not unnecessarily long hoses.
Connecting the hoses
1. Push the hose clip onto the suction hose.
Illustration B
1Suction hose (not in scope of delivery)
2Hose clip
3Hose nipple
4Union nut
5Flat seal
2. Slide the union nut onto the hose nipple.
3. Push the suction hose onto the hose nipple.
4. Position and tighten the hose clip.
5. Fit a flat seal between the suction nozzle and hose
nipple.
Note: A reinforced hose suitable for vacuum appli-
cations must be used for the suction hose.
6. Connect the suction hose to the suction nozzle and
tighten the union nut.
7. Fit the suction filter to the other end of the suction
hose.
Illustration C
1Suction hose (not in scope of delivery)
2Hose clip
3Suction filter
8. Fit a hose nipple, union nut and hose clip to the
pressure hose (not included in the scope of deliv-
ery).
9. Fit a flat seal between the hose nipple and outlet.
10. Connect the pressure hose to the outlet and tighten
the union nut.
Operation
Venting the pump
ATTENTION
Risk of damage
The seals will be damaged if the pump runs dry.
Vent the pump before starting. If the pump is accidentally
run dry then stop the engine immediately and allow the
pump to cool down before starting the venting procedure.
1. Unscrew the cap from the filler opening.
2. Fill the pump completely with water.
3. Screw the cap back into the filler opening and tighten.
Starting the device
1. Vent air from the pump.
2. Open the fuel cock.
3. Push the choke lever to the left.
4. Push the accelerator lever to approximately 1/3 of
the total range.
5. Set the power switch to "I".
6. Pull the starter cord slowly until a strong resistance
is discernible then pull strongly.
7. Slowly return the starter cord.
ATTENTION
Risk of damage
A rapidly returning starter cord damages the device.
Slowly return the starter cord.
8. Push the choke lever to the right once the engine
has started.
9. Push the accelerator lever to the left until reaching
the desired speed. The flow rate of the pump de-
pends on the engine speed.
10. Check the function of the pump. Dry running damag-
es the pump. Switch off the engine and repeat vent-
ing of the pump if the pump does not deliver water.
Switching the device off in an emergency
1. Set the power switch to "0".
Switching off the device
1. Push the accelerator lever all the way to the right.
2. Set the power switch to "0".
3. Close the fuel cock.
Draining the water
1. Unscrew the water drain screw.
2. Allow the water to drain from the pump.
3. Unscrew the cap from the filler opening.
4. Flush the pump with fresh water.
5. Allow the fresh water to drain away.
6. Screw the cap into the filler opening and tighten.
7. Screw in and tighten the water drain screw.
Transport
Set the power switch to "0" before transport.
Allow the engine to cool down for at least
15 minutes before loading.
Keep the device horizontal during transport to pre-
vent fuel from spilling out.
When transporting in vehicles, secure the device
against rolling away, slipping and tipping according
to the respectively applicable guidelines.
Be aware of the weight of the device during trans-
port.
Storage
CAUTION
Failure to observe the weight
Risk of injury and damage
Be aware of the weight of the device during storage.
ATTENTION
Risk of damage
Do not place any heavy objects on the device.
Store the device in a dry and dust-free place.
Cleaning the device
The device must be cleaned before storage.
1. Allow the device to cool down for a half-hour if it was
recently in operation.
2. Flush the pump with clear water.
3. Manually wash the exterior of the device with a
small amount of water.
4. Rub all accessible surfaces dry.
5. Unscrew the water drain screw and allow the water
to drain out.
6. Screw in and tighten the water drain screw.
7. Lightly oil rust-prone surfaces.
8. Spray the control elements with silicone spray.
Storage duration of 1...2 months
1. Add petrol stabiliser to the fuel tank.
2. Top up the fuel tank.
Storage duration of 2...12 months
Additionally:
1. Close the fuel cock.
2. Place a container under the carburettor.
Illustration D
1Carburettor
2Drain screw
3. Unscrew the drain screw.
4. Collect the fuel in the container.
5. Screw in and tighten the drain screw.
6. Empty the settling cup (see "Care and Maintenance/
Cleaning the settling cup").
Storage duration longer than 12 months
Additionally:
1. Unscrew the spark plug.
2. 5...10 cm3Add engine oil to the cylinder.
3. Slowly pull the starter cord several times to distrib-
ute the oil in the engine.
4. Screw in the spark plug.
5. Change the oil (see "Care and Maintenance/Chang-
ing the oil").
6. Pull the starter cord slowly until a strong resistance
is discernible.
Care and service
DANGER
Danger of injury from electric shock.
The device can start unintentionally. You can be injured
by moving parts.
Remove the spark plug connector before performing
any maintenance work.
CAUTION
Danger of burns.
Hot device components cause burns if touched.
Allow the device to cool down before working on it.
* See "Startup" for a description.
** See "Maintenance work" for a description.
Maintenance intervals
Each time before use
1. Check the device for correct condition and opera-
tional safety. Do not start up a damaged device.
2. Check the oil level. *
3. Check the air filter. **
Once after 1 month or 20 operating hours
1. Change the oil. **
Every 3 months or 50 operating hours
1. Clean the air filter. **
Perform cleaning more frequently in a dusty applica-
tion environment.
Every 6 months or 100 operating hours
1. Change the oil. **
2. Clean the settling cup. **
3. Check and clean the spark plug. **
4. Clean the spark catcher (not included in the scope
of delivery). **
Annually by the authorised Customer Service
department
1. Check and adjust the valve play.
2. Clean the fuel tank and fuel filter.
3. Replace the air filter insert.
4. Replace the spark plug.
5. Check/adjust the idling mixture speed.
6. Check/adjust the valve play.
7. Check the pump impeller.
8. Check the gap between the casing and impeller.
9. Check the pump inlet valve.
Every 2 years by the authorised Customer Service
department
1. Check the fuel line and replace if necessary.
2. Clean the engine combustion chamber.
Maintenance work
Check the air filter
1. Lift the strap and remove the cover.
Illustration E
1Cover
2Lap
3Air filter insert
2. Check the air filter insert for soiling. Clean the air fil-
ter if necessary or replace if damaged (see "Clean-
ing the air filter").
3. Fit the cover and latch into place.
Cleaning the air filter
ATTENTION
Risk of damage
Penetrating dust can destroy the engine if the air filter
insert is absent.
Do not operate the device without an air filter insert.
1. Open the air filter (see "Checking the air filter").
2. Remove the air filter insert.

English 9
3. Wash the air filter insert in warm water and house-
hold cleaner then rinse with clear water.
Note: Dispose of the oil contaminated washing solu-
tion in an environmentally friendly manner.
4. Allow the air filter insert to dry.
5. Saturate the air filter insert in clean engine oil and
press out the excess oil.
6. Fit the air filter insert back into place.
7. Fit the cover.
8. Close the latches.
Changing oil
Perform the oil change on a warm engine.
1. Unscrew the oil dipstick.
Illustration F
1Oil dipstick
2Oil drain plug
2. Unscrew the oil drain screw with seal and catch the
escaping oil.
3. Screw in and tighten the oil drain screw with seal.
4. Position the device on a level surface.
5. Measure the correct quantity of engine oil (for oil
type see "Technical data") and fill through the oil dip-
stick hole.
6. Check the oil level (see "Starting up").
7. Screw in and tighten the oil dipstick.
8. Dispose of the old oil in accordance with the envi-
ronmental regulations.
Cleaning the settling cup
The settling cup separates water from the petrol.
1. Close the fuel cock.
2. Unscrew the settling cup.
Illustration G
1Settling cup
2Screw
3. Remove the settling cup with O-ring.
4. Clean the settling cup and O-ring using a non-in-
flammable solvent and allow to dry.
5. Fit the settling cup and O-ring and screw tight.
6. Open the fuel cock.
7. Check the seal between the settling cup and carbu-
rettor.
8. Close the fuel cock.
Checking and cleaning the spark plug
1. Pull off the spark plug connector.
Illustration H
1Spark plug connector
2Spark plug
2. Clean the region around the spark plug to prevent
dirt from entering the engine when the spark plug is
removed.
3. Unscrew the spark plug.
4. Replace a spark plug that has worn electrodes or a
broken insulator.
5. Check the electrode gap of the spark plug. Target
value 0.7...0.8 mm.
6. Check the spark plug seal for damage.
ATTENTION
Risk of damage
A loose spark plug can overheat and damage the en-
gine. An overtightened spark plug can damage the
thread in the engine.
Observe the following instructions for tightening the
spark plug.
7. Carefully screw the spark plug in by hand. Do not
cross the thread.
8. Screw the spark plug all the way in using the plug
spanner and the tighten as follows.
a Tighten a used spark plug by an additional 1/
8...1/4 turn.
b Tighten a new spark plug by an additional 1/2 turn.
9. Plug on the spark plug connector.
Troubleshooting guide
Have all checks and work on electrical parts performed
by an expert.
In case of any malfunctions not mentioned in this chap-
ter, contact the authorised Customer Service.
The engine does not start.
1. Open the fuel cock.
2. Push the choke lever to the left.
3. Set the power switch to "I".
4. Fill the tank with fuel.
5. Check the oil level and top up if necessary.
6. Clean the fuel tank and carburettor. Refuel with
fresh fuel.
7. Check the spark plug (see"Care and maintenance/
Checking and cleaning the spark plug").
8. Allow a wet spark plug to dry. Then start the engine
with the accelerator lever at the full speed position.
9. Clean the settling cup (see "Care and Maintenance/
Cleaning the settling cup").
Low engine performance
1. Check the air filter.
2. Clean the fuel tank and carburettor. Refuel with
fresh fuel.
Pump does not deliver any water
1. Vent air from the pump.
2. Check the suction hose for leaks and holes.
3. Check the flat seal between the device and the suc-
tion hose.
4. Use a more sturdy suction hose.
5. Completely immerse the suction filter.
6. Clean the suction filter.
7. Position the pump closer to the water source. Re-
duce the height difference between the pump and
water surface.
8. Use shorter hoses.
Low delivery rate
1. Check the suction hose for leaks and holes.
2. Check the flat seal between the device and the suc-
tion hose.
3. Use a more sturdy suction hose.
4. Completely immerse the suction filter.
5. Clean the suction filter.
6. Position the pump closer to the water source. Re-
duce the height difference between the pump and
water surface.
7. Use shorter hoses.
Warranty
The warranty conditions issued by our relevant sales
company apply in all countries. We shall remedy possi-
ble malfunctions on your appliance within the warranty
period free of cost, provided that a material or manufac-
turing defect is the cause. In a warranty case, please
contact your dealer (with the purchase receipt) or the
next authorised customer service site.
(See overleaf for the address)
Technical data
Subject to technical modifications.
EU Declaration of Conformity
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements in the EU Directives, both in its basic design
and construction as well as in the version placed in cir-
culation by us. This declaration is invalidated by any
changes made to the machine that are not approved by
us.
Product: Waste water pump
Type: 1.812-xxx
Currently applicable EU Directives
2006/42/EC (+2009/127/EC)
2014/30/EU
2011/65/EU
Harmonised standards used
EN 809: 1998: A1: 2009 + AC: 2010
EN 61000-6-3: 2007+A1: 2011+AC: 2010
EN 61000-6-1: 2007
Conformity evaluation procedure used
2000/14/EC: Appendix V
The signatories act on behalf of and with the authority of
the company management.
Documentation supervisor: S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Ph.: [phone]
Fax: [phone]
Winnenden, 2018/10/01
WWP 45
Pump
Nominal width“ 3
Maximum flow rate l/h 45000
Suction height (max.) m7
Delivery height (max.) m 25
Internal combustion engine
Engine type Single-cylinder
Type 4-stroke
Cooling type Air-cooled
Engine capacity cm3196
Engine performance kW/PS 5,1/6,9
Fuel type Petrol, min. 88 octane
Fuel tank capacity l 3,6
Working time with a fully filled fuel tank h 2,1
Engine oil volume l 0,5
Oil type 10 W-30
15 W-40
Spark plug type F5T, F6TJC, F7TJC
Dimensions and weights
Length mm 580
Width mm 440
Height mm 450
Weight without fuel kg 36
CO2Emissions according to the measurement procedure of EU regulation 2016/1628 Euro V
Motor g/kWh 790
Chairman of the Board of Management
Director Regulatory Affairs & Certification
H. Jenner S. Reiser
