Instruction Manual
• Operator
blueplanet
XP10U-H4 / H6
XP10U-H4 / H6 PSD

Operator Instructions blueplanet XPU H / H and XPU H / H PSD Page 
 General Notes............................................ 
. About this documentation .................................
. Design features .......................................................
 Safety .........................................................
. Intended use............................................................
. Protection features ................................................ 
. Standards and regulations.................................. 
 Conguration and Operation ..................
. Controls......................................................................
. Initial start-up ......................................................... 
. Menu structure....................................................... 
. Monitoring the inverter ......................................
. Performing a software update.........................
Operating Instructions
Contents

General Notes
Page  Operator Instructions blueplanet XPU H / H and XPU H / H PSD
 General Notes
. About this documentation
WARNING
Improper handling of the inverter can be hazardous
›IMPORTANT SAFETY INSTRUCTIONS.
›You must read and understand the operating instructions before you can install and use the inverter
safely.
This manual is intended for inverter model blueplanet XPU-H and shall be followed during installation and mainte-
nance of this inverter model.
.. Other Applicable Documents
During installation, observe all assembly and installation instructions for components and other parts of the system.
These instructions are delivered together with the respective components and other parts of the system.
Some of the documents which are required for registering and approving your photovoltaic (PV) system are included
with the operating instructions.
.. Retention of documents
SAVE THESE INSTRUCTIONS. These instructions and other documents must be stored near the system and be available
whenever they are needed.
. Design features
.. Symbols used in this document
General hazard symbol Risk of re or explosion
High voltage Risk of burns
Authorised electrician The tasks indicated with this symbol may only be carried out by an authorised
electrician.
.. Description of safety instructions
DANGER
Imminent danger
Failure to observe this warning will lead directly to serious bodily injury or death.
WARNING
Potential danger
Failure to observe this warning may lead to serious bodily injury or death.

General Notes
Operator Instructions blueplanet XPU H / H and XPU H / H PSD Page 
CAUTION
Low-risk hazard
Failure to observe this warning will lead to minor or moderate bodily injury.
CAUTION
Hazard with risk of property damage
Failure to observe this warning will lead to property damage.
.. Description of additional information
NOTICE
Useful information and notes
.. Description of action instructions
a) One-step actions or actions that can be carried out in any sequence:
Action instructions
↻Prerequisite(s) for your action(s) (optional)
Carry out action.
(Additional actions, if applicable)
» Result of your action(s) (optional)
b) Multi-step action instructions that must be carried out in a xed sequence:
Action instructions
↻Prerequisite(s) for your actions (optional)
. Carry out action.
. Carry out action.
. (Additional actions, if applicable)
» Result of your actions (optional)

Safety
Page  Operator Instructions blueplanet XPU H / H and XPU H / H PSD
 Safety
DANGER
Lethal voltages are still present in the terminals and leads of the inverter even after the inverter has
been switched o and disconnected.
Severe injuries or death if the leads and/or terminals in the inverter are touched.
Only authorised electricians who are approved by the supply grid operator may open, install and maintain
the inverter.
›Keep the inverter closed when the unit is in operation.
›Do not touch the leads and/or terminals when switching the unit on and o.
›Do not make any modications to the inverter.
The electrician is responsible for observing all existing standards and regulations.
• Keep unauthorized persons away from the inverter and PV system.
• Be sure to observe IEC --: (“Requirements for special installations or locations – solar photovoltaic (PV)
power supply systems”) in particular.
• Ensure operational safety by providing proper grounding, conductor dimensioning and appropriate protection against
short circuiting.
• Observe the safety instructions on the inverter and in these operating instructions.
• Switch o all voltage sources and secure them against being inadvertently switched back on before performing visual
inspections and maintenance.
• When taking measurements while the inverter is live:
–Do not touch the electrical connections.
–Remove all jewellery from your wrists and ngers.
–Ensure that the testing equipment is in safe operating condition.
• Stand on an insulated surface when working on the inverter while it is switched on.
• Modications to the surroundings of the inverter must comply with the applicable national and local standards.
• When working on the PV array, it is also necessary to switch o the DC voltage with the DC disconnector in addition to
disconnecting the PV array from the grid.
. Intended use
The XPU converts clean renewable DC energy into AC energy for export into the utility.
The XPU-H was designed in accordance with UL , CSA-C. No. .. and the NFPA .
The XPU-H was designed in accordance with CSA-C. No. .. and the NFPA .
Authorized personnel who are qualied for the VAC and VDC voltage ratings are the only people who should install or
maintain this equipment. Lethal hazards exist which may result in serious injury.
Operate the inverter only with a permanent connection to the public power grid.
Any other or additional use is not considered the intended use. This includes:
• Mobile use
• Use in rooms where there is a risk of explosion
• Use in rooms where the humidity is higher than %
• Operation outside of the specication intended by the manufacturer
• Standalone operation.

Safety
Operator Instructions blueplanet XPU H / H and XPU H / H PSD Page 
. Protection features
For your safety, the following monitoring and protective functions are integrated into the XPU inverter:
• Overvoltage conductors/varistors to protect the power semiconductors from high-energy transients on the
grid and PV array side
• Temperature monitoring of the heat sink
• EMC lters to protect the inverter from high-frequency grid interference
• Grid-side grounded varistors to protect the inverter against surge pulses
• Islanding detection according to VDE -- and IEEE 
. Standards and regulations
Electrical conformity according to U.S., Canadian and international safety operating standards and code
requirements:
XP10U-H4 XP10U-H6
UL 1741-1:1999 Rev. May 2007 X -
CSA 22.2 No. 107-1:2001 Rev 2006 X X
IEEE Std. 1547-2003 X X
IEEE Std. 1547.1-2005 X X
FCC Part 15 Class B X X
NFPA 70 X X
Directive concerning Electromagnetic
Compatibility with Class B (Council Directive
2004/108/EC)
XX
Low Voltage Directive (Council Directive
2006/95/EC)
XX
The blueplanet inverter has complete on-board overcurrent, over-temperature and anti-islanding protection.

Configuration and Operation
Page  Operator Instructions blueplanet XPU H / H and XPU H / H PSD
 Conguration and Operation
. Controls
The inverter has a backlit LCD as well as three status LEDs. The inverter is operated using six keys.
1
2
3
4
5
6
7
Figure 18: Control panel
Key
1 “Operating” LED 5 4-way key
2 “Feed-in” LED 6 “Enter” key
3 “Fault” LED 7 “ESC” key
4LCD
.. LED indicators
The three LEDs on the front of the inverter show the dierent operating states.
The LEDs can take on the following states:
LED illuminated LED ashing LED not illuminated
The LED indicators show the following operating states:
Operating state LEDs Display Description
Start The green “Operating” LED is illuminated
if an AC voltage is present,
independently of the DC voltage.
Feed-in start Power fed into the grid
or measured values
The green “Operating” LED is illuminated.
The green “Feed-in” LED is illuminated after the
country-specic waiting period*.
The inverter is ready to feed in, i.e. is on the grid.
You can hear the line relay switch on.
* The waiting period ensures that the PV array voltage continuously remains above the power delivery limit of V.

Configuration and Operation
Operator Instructions blueplanet XPU H / H and XPU H / H PSD Page 
Operating state LEDs Display Description
Feed-in operation Power fed into the grid
or measured values
The green “Operating” LED is illuminated.
The green “Feed-in” LED is illuminated.
The “Feed-in” icon appears on the desktop.
The inverter feeds into the grid.
Non-feed-in
operation
Status message The display shows the corresponding message.
Voltage Fault message The display shows the corresponding message.
The red “Fault” LED is illuminated.
.. Graphical display
The graphical display shows measured values and data and allows the conguration of the inverter using a graphical
menu. In normal operation, the backlighting is switched o. As soon as you press one of the control keys, the backlight is
activated. If no key is pressed for an adjustable period of time, it switches o again. You can also permanently activate or
deactivate the backlighting. In sleep mode, the inverter deactivates the display regardless of the selected setting.
NOTICE
Depending on the tolerances of the measuring elements, the measured and displayed values
are not always the actual values. However, the measuring elements ensure maximum solar yield.
Due to these tolerances, the daily yields shown on the display may deviate from the values on the grid
operator’s feed-in meter by up to %.
After being switched on and after the initial start-up is complete, the inverter displays the start screen (the desktop). If
you are in the menu and do not touch the control keys for two minutes, the inverter returns to the desktop.
For information about initial start-up, see section . on page page .
1
2
3
4
5
6
7
8
Figure 19: Desktop
Key
1 Current date 6 Status bar
2 Current power 7 Current time
3 Menu indicator 8 Feed-in indicator
4Dailyyield
5 Annual yield

Configuration and Operation
Page  Operator Instructions blueplanet XPU H / H and XPU H / H PSD
.. Control keys
You operate the inverter using the -way key and the OK and ESC control keys.
... Desktop
Opening the menu
↻The inverter is operating.
↻The LCD is showing the desktop.
Press the right arrow key.
» The menu opens up over the desktop from left to right.
Displaying the daily output
↻The inverter is operating.
↻The LCD is showing the desktop.
Press the down arrow key.
» The LCD displays the daily yield in a diagram.
To return to the desktop, press any key.
... Inverter menu
Selecting a menu item
↻You have left the desktop. The inverter displays the menu.
Use the up and down arrow keys.
Opening a menu item or a setting
Use the right arrow key and the OK key.
Jump to the next higher menu level/discard changes
Press the left arrow key or the ESC key.
Selecting an option
Use the right and left arrow keys.
Changing an option/the value of an input eld
Use the keys with the up and down arrows.
