Kaco blueplanet 87.0 TL3 User manual

Manual
nEnglish translation of German original
KACO blueplanet 87.0 TL3
KACO blueplanet 92.0 TL3
KACO blueplanet 105 TL3
KACO blueplanet 110 TL3
KACO blueplanet 125 TL3
KACO blueplanet 137 TL3
KACO blueplanet 150 TL3
KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
These instructions form part of the product and must be carefully read, observed and stored in a place which is freely accessible at all
times.
Authorised electrician
Important safety instructions

Legal provisions
The information contained in this document is the property of KACO new energy GmbH. Publication, in whole
or in part, requires the written permission of KACO new energy GmbH.
KACO warranty
For current warranty conditions contact your system integrator. http://www.kaco-newenergy.com
Definitions on product designations
In these operating instructions, the product "Photovoltaic feed-in inverter" is referred to as "device" for ease of
reading.
Trademarks
All trademarks are recognised, even if not explicitly identified as such. A lack of identification does not mean
that a product or designation/logo is free of trademarks.
Software
This device contains open source software developed by third parties and in some cases licensed under GPL
and/or LGPL.
More details on this topic and a list of the open source software used, as well as the corresponding licence
texts, can be found in the web interface information display under "Licence List".
| Legal provisions Manual
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
Page 2
EN

Contents
1General information.................................................... 4
1.1 About this document............................................. 4
1.2 More information.................................................. 4
1.3 Layout of Instructions............................................ 5
1.4 Identification ......................................................... 6
1.5 Warnings on the device......................................... 6
1.6 Target group.......................................................... 6
2Safety.......................................................................... 7
2.1 Proper use ............................................................. 7
2.2 Protection features................................................ 8
3Description of the device............................................. 9
3.1 Mode of operation ................................................ 9
3.2 Device diagram...................................................... 9
3.3 System layout ........................................................ 10
4Technical data ............................................................. 12
4.1 Electrical data ........................................................ 12
4.2 General Data.......................................................... 14
4.3 Environmental data ............................................... 15
4.4 Accessories ............................................................ 16
5Transportation and Delivery........................................ 18
5.1 Scope of delivery ................................................... 18
5.2 Transporting the device......................................... 18
5.3 Installation tool ..................................................... 18
6Assembly and preparation .......................................... 19
6.1 Choosing the installation location ......................... 19
6.2 Unpacking the device ............................................ 20
6.3 Fastening the mount ............................................. 21
6.4 Installing and securing the device ......................... 22
7Installation.................................................................. 24
7.1 General information .............................................. 24
7.2 Opening the device................................................ 24
7.3 Surveying the connection area.............................. 24
7.4 Making the electrical connection .......................... 25
7.5 Connecting the device to the power grid .............. 26
7.6 Connect PV generator to device............................ 27
7.7 Inserting the overvoltage protection .................... 31
7.8 Creating equipotential bonding............................. 32
7.9 Connecting the interfaces ..................................... 33
7.10 Sealing the connection area .................................. 36
8Commissioning............................................................. 37
8.1 Requirements ........................................................ 37
8.2 Preconditions relating to standards....................... 37
8.3 Network topologies ............................................... 38
8.4 Start-up options ..................................................... 39
9Configuration and operation ........................................ 44
9.1 Initial start-up ........................................................ 44
9.2 Controls.................................................................. 46
9.3 User interface ........................................................ 47
9.4 Menu structure...................................................... 50
9.5 Monitoring the device ........................................... 69
9.6 Performing a firmware update .............................. 69
9.7 Access via Modbus................................................. 70
9.8 Multi-function button ............................................ 70
10 Specifications ............................................................... 74
10.1 Reactive power control.......................................... 74
10.2 Active power regulation......................................... 80
10.3 FRT ......................................................................... 86
10.4 Other grid-supporting functions that are effect-
ive in the case of active power ..............................
89
10.5 Advanced islanding detection................................ 92
10.6 Behavior in case of communication failure ........... 92
11 Maintenance and troubleshooting ............................... 93
11.1 Visual inspection .................................................... 93
11.2 Cleaning ................................................................. 93
11.3 Replacing the fan ................................................... 93
11.4 Replacing overvoltage protection.......................... 95
11.5 Shutting down for maintenance / troubleshoot-
ing ..........................................................................
95
11.6 Faults...................................................................... 95
11.7 Fault messages....................................................... 97
11.8 Troubleshooting..................................................... 97
12 Decommissioning and dismantling ...............................110
12.1 Switching off the device.........................................110
12.2 Disconnecting connections .................................... 110
12.3 Uninstalling the device...........................................111
12.4 Disassembling the device.......................................111
12.5 Packaging the device.............................................. 111
12.6 Storing the device .................................................. 111
13 Disposal .......................................................................112
14 Service and warranty....................................................113
Manual Contents
MNL_BP_87.0-165_TL3_en iii
Photovoltaic feed-in inverter
EN

1 General information
1.1 About this document
WARNING
Improper handling of the device can be hazardous!
1. You must read and understand the operating instructions in order to install and use the device safely!
Other applicable documents
During installation, observe all assembly and installation instructions for components and other parts of the system.
These instructions also apply to the equipment, related components and other parts of the system.
Some of the documents which are required to register your system and have it approved are included with the operating
instructions.
Storing the documents
These instructions and other documents must be stored near the system and be available at all times.
– The current version of the operating Instructions can be downloaded from www.kaco-newenergy.com.
English translation of German original
This document has been produced in several languages. The German-language version is the original version. All other
language versions are translations of the original version.
This document is valid for the following types of device from firmware version V2.2x onwards
Modules
[KACO art. no.]
KACO blueplanet 87.0 TL3 M1 WM OD IIF0 /
KACO blueplanet 87.0 TL3 M1 WM OD IIFX
[ 1001784 / 1001897 ]
KACO blueplanet 92.0 TL3 M1 WM OD IIG0 /
KACO blueplanet 92.0 TL3 M1 WM OD IIGX
[ 1001785 / 1001898 ]
KACO blueplanet 105TL3 M1 WM OD IIG0/
KACO blueplanet 105TL3 M1 WM OD IIGX
[ 1001941 / 1001951 ]
KACO blueplanet 110 TL3 M1 WM OD IIK0 /
KACO blueplanet 110 TL3 M1 WM OD IIKX
[ 1001786 / 1001892 ]
KACO blueplanet 125 TL3 M1 WM OD IIP0 /
KACO blueplanet 125 TL3 M1 WM OD IIPX
[ 1001623 / 1001894 ]
KACO blueplanet 125TL3 M1 WM OD IIK0/
KACO blueplanet 125TL3 M1 WM OD IIKX
[ 1001942 / 1001952 ]
KACO blueplanet 137 TL3 M1 WM OD IIP0 /
KACO blueplanet 137 TL3 M1 WM OD IIPX
[ 1001787 / 1001895 ]
KACO blueplanet 150 TL3 M1 WM OD IIQ0 /
KACO blueplanet 150 TL3 M1 WM OD IIQX
[ 1001783 / 1001896 ]
KACO blueplanet 155TL3 M1 WM OD IIP0/
KACO blueplanet 155TL3 M1 WM OD IIPX
[ 1001943 / 1001953 ]
KACO blueplanet 165TL3 M1 WM OD IIP0/
KACO blueplanet 165TL3 M1 WM OD IIPX
[ 1001944 / 1001954 ]
1.2 More information
Links to more detailed information can be found at www.kaco-newenergy.com
Document title Document type
Technical data sheet Product flyer
Modbus protocol
RS485 protocol reactive power control
Application note
1 | General information Manual
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
Page 4
EN

Document title Document type
SunSpec Information Model Reference
SunSpec Information Model Reference KACO
Excel files for software version with application note “Mod-
bus protocol” under https://kaco-newenergy.com/
downloads/
Software package Files for current software
EU Declaration of Conformity
Country-specific certificates
Certification for specific subassembly
Certificates
1.3 Layout of Instructions
1.3.1 Symbols used
General hazard Fire and risk of explosion
Electrical voltage Risk of burns
Earthing - ground conductor
1.3.2 Safety warnings symbols guide
DANGER
High risk
Failure to observe this warning will lead directly to serious bodily injury or death.
WARNING
Potential risk
Failure to observe this warning may lead to serious bodily injury or death.
CAUTION
Low-risk hazard
Failure to observe this warning will lead to minor or moderate bodily injury.
CAUTION
Risk of damage to property
Failure to observe this warning will lead to property damage.
1.3.3 Additional information symbols
NOTE
Useful information and notes
Information that is important for a specific topic or objective, but that is not safety-relevant.
1.3.4 Symbols for instructions
↻Prerequisite for use
Manual General information | 1
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3 KACO
blueplanet 165 TL3
Page 5
EN

1. Carry out the next step
2. Additional action sequence
ðInterim result of the action
ðEnd result
1.4 Identification
You will find the name plate with the following data for service and other require-
ments specific to installation on the right side panel of the product:
– Product name
– Part no.
– Serial number
– Date of manufacture
– Technical data
– Disposal information
– Certification marking, CE marking.
KACO new energy
Carl-Zeiss-Straße 1
74172 Neckarsulm
Made in Germany
KACO blueplanet 125 TL3 M1 WM OD IIP0
Part number 1001623
Serial number 125TL01654321 Year Q4 / 18
Input Vmax PV / lsc PV (max) / Inom PV 1500 V / 300 A / 160 A
V-MPP at Pnom / V- range 875V - 1300V / 875V - 1450V
Output
Nominal voltage
600 V (3P+PE)
Voltage range continuous operation 480 V - 760 V (Ph-Ph)
Current (maximum continuous) 3 x 132,3 A
Frequency range 45 Hz - 65 Hz
Output
Power
Snom at 600 V Unom 125 000 VA
Smax at 600 V Unom 137 500 VA
Reactive power cos phi 0,3-1 ind/cap
Environ-
ment Temperature range - 25...+60°C / -13...+140 °F
Protection class / Ingress protection I / IP66 / NEMA 4X
ARC fault circuit protection none
Interface protection according to country specific requirements, details see manual
Grid Support Interactive Inverter
Max. Backfeed Current 0 A
Conf. to UL 1741 & UL 62109-1
Cert. to CSA C22.2 No. 107.1 &
CAN/CSA Std. C22.2 No. 62019-1
CAN/CSA Std. C22.2 No. 62109-2
No galvanic separation / Ungrounded Arrays Only
Fig.1: Name plate
1.5 Warnings on the device
A warning sticker is affixed to the device. Read the warnings carefully.
Do not remove the sticker. If the sticker is missing or is illegible, please contact a
KACO representative or distributor.
– Article number: 3013153
Fig.2: Warning sticker
1.6 Target group
All activities described in the document may only be carried out by specially trained personnel with the follow-
ing qualifications:
– Knowledge about how an inverter functions and operates
– Training in the handling of hazards and risks during the installation and operation of electrical units and
plants.
– Education concerning the installation and start-up of electrical devices and systems.
– Knowledge of applicable standards and directives.
– Knowledge and adherence to this document with all safety notices.
1 | General information Manual
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
Page 6
EN

2 Safety
Before using the product for the first time, please read through the safety instructions carefully.
DANGER
Lethal voltages are still present in the connections and cables of the device even after the device
has been switched off and disconnected!
Severe injuries or death may occur if the cables and/or terminals/busbars in the device are touched.
1. Comply with all safety regulations and current technical connection specifications of the responsible power
supply company.
2. The device is only permitted to be opened or serviced by a qualified electrician.
3. Switch off the grid voltage by turning off the external circuit breakers.
4. Do not touch the cables and/or terminals/busbars when switching the device on and off.
5. Keep the device closed when in operation.
The electrician is responsible for observing all existing standards and regulations. The following applies:
– Keep unauthorised persons away from the device and/or system.
– In particular, making sure that the locally applicable version of the standard 1 "Requirements for special installations
or locations – solar photovoltaic (PV) power supply systems" is observed.
– Ensure operational safety by providing proper grounding, conductor dimensioning and appropriate protection against
short circuiting.
– Observe all safety instructions on the product and in these operating instructions.
– Switch off all voltage sources and secure them against being inadvertently switched back on before performing visual
inspections and maintenance.
– When taking measurements on the live device:
– Do not touch the electrical connections
– Remove all jewellery from wrists and fingers
– Ensure that the testing equipment is in safe operating condition.
– Modifications to the surroundings of the device must comply with the applicable national and local standards.
– When working on the PV generator, it is also necessary to switch off the DC voltage with the external DC isolator
switch (e.g. at the string combiner or the KACO DC switchbox) in addition to disconnecting the PV generator from the
grid.
2.1 Proper use
The device is a transformerless PV inverter which converts the direct current of the PV generator into grid-com-
patible three-phase alternating current and then feeds the three-phase alternating current into the public
power grid.
The device is built using state-of-the-art technology and in accordance with the recognized safety rules. Never-
theless, improper use may cause lethal hazards for the operator or third parties, or may result in damage to the
product and other property.
1Country Standard
EU Harmonised document - HD 60364-7-712 (European
implementation of the IEC standard)
USA PV section of NEC 690 and sections in article 100,
690.4, 690.6 and 705.10
Tab.1: Examples of standards specific to business premises
Manual Safety | 2
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3 KACO
blueplanet 165 TL3
Page 7
EN

The device is intended for indoor and outdoor applications and may only be used in countries for which it has
been approved or for which it has been released by KACO new energy and the grid operator. 2
Operate the device only with a permanent connection to the public power grid. The country and grid type se-
lection must be commensurate with the respective location and grid type.
The requirements of the grid operator must be met for grid connection to take place. The permission of the rel-
evant authorities may also be required in order to secure authorisation to connection to the grid.
The enclosed documentation is an integral part of the product. The documentation must be read, observed and
stored in a place which is freely accessible at all times.
The name plate must be permanently attached to the product.
Any other or additional use of the device shall be regarded as improper.
This includes:
– Use of a distribution system that is not described (grid type)
– Use of sources other than PV-strings.
– Mobile use
– Use in rooms where there is a risk of explosion
– Use in direct sunlight, rain or a storm or other harsh environmental conditions
– Outdoor use in environmental conditions that exceed the limits stated in the technical specifications >En-
vironmental data.
– Operation outside the specification intended by the manufacturer
– Overvoltage on the DC connection of over 1,500 V
– Modifying the device
– Standalone mode
2.2 Protection features
The following monitoring and protection functions are built-in:
– RCMU (Residual Current Monitoring Unit)
– Overvoltage conductor / varistor to protect the power semiconductors from high-energy transients on the
grid and generator sides.
– Device temperature monitoring system
– EMC filter to protect the inverter from high-frequency grid interference
– Grid-side varistors grounded to earth to protect the product against burst and surge pulses
– Anti-islanding detection according to the current standards.
– Isolation detection / residual current monitoring and disconnection function to detect isolation faults
NOTE
If the device is connected, the overvoltage conductors / varistors contained in the device have an impact on the
electrical system insulation resistance test as per HD 60364-6 / IEC 60364-6 Low-voltage installations- Part 6:
Verification.
IEC 60364-6 6.4.3.3 describes two options for this case. The first option is to disconnect devices with an over-
voltage conductor or, if this is not practicable, then the test voltage can be reduced to 250V.
2WARNING!The device is not intended for use in residential areas and cannot ensure adequate
protection of radio reception in such environments.
2 | Safety Manual
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
Page 8
EN

3 Description of the device
3.1 Mode of operation
The device converts the DC voltage generated by the PV-modules into AC voltage and feeds this into the power
grid. The starting procedure begins when there is sufficient sunlight and a specific minimum voltage is present
in the device. The feed-in process begins once the PV generator has passed the insulation test and the grid
parameters are within the requirements imposed by the grid operator for a specific monitoring time. If, as it
gets dark, the voltage drops below the minimum voltage value, feed-in mode ends and the device switches off.
3.2 Device diagram
1
2
5
6
87
34
Fig.3: Device diagram - S version
1
2
6
87
34
9
5
Fig.4: Device diagram - XL version
Key
1 Housing 6 Interface / cable feed-through
2 Cover 7 Communication - button / USB port
3 Status indicator 8 DC connection / cable feed-through
4 Upper cover 9 DC isolator switch (not present in S version)
5 AC connection / cable feed-through
3.2.1 Mechanische Komponenten
DC isolator switch (not present in S version)
The DC isolator switch is located on the housing door. of the device. The DC isolator switch is used to discon-
nect the inverter from the PV generator in order to carry out service.
Disconnecting the device from the PV generator
FSwitch the DC isolator switches from 1 (ON) to 0 (OFF).
Connecting the device to the PV generator
FSwitch the DC isolator switches from 0 (OFF) to 1 (ON).
ON
OFF
Fig.5: DC isolator switch
3.2.2 Electrical functions
A potential-free relay contact is integrated into the device. Use this contact for one of the following functions:
Potential-free relay
The potential-free relay contact closes as soon as there is a fault during operation. You use this function, for ex-
ample, to signal a fault visually or acoustically.
Manual Description of the device | 3
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3 KACO
blueplanet 165 TL3
Page 9
EN

3.2.3 Interfaces
You can configure the interfaces and the web server in the Settings menu. The device has the following inter-
faces for communication and remote monitoring.
Ethernet interface
The device features two switched Ethernet ports to enable the user to, for example, connect several devices in
series if the user prefers a linear topology.
RS485 interface
The device features two RS485-Interfaces. One RS485-Interface is earmarked for communication with a string-
combiner-box. This can be controlled using the Modbus RTU protocol. Data loggers that cannot be connected
via Ethernet can be connected to the other RS485-Interface. The Sunspec and KACO protocol are supported in
this case.
USB interface
The USB connection of the device is a type A socket. It is located on the communication circuit board. The USB
connection is specified to draw 500mA of current.
Use the USB interface to read out stored operating data, load software updates or device configurations using a
FAT32-formatted USB stick.
It is possible to establish a connection to the webserver integrated into the device by connecting a USB-WiFi
stick. In addition to starting up the device, the web interface can be used for service information purposes,
software updates and for carrying out extensive configuration.
„Inverter Off“ Eingang / DRM0 for Australia
In addition to the safety functions, the internal interface switches can also be actuated via the "Inverter Off" in-
put.
The Powador-protect or a protective device from another manufacturer can be used for this purpose.
If a Powador-protect is used as the central interface protection, the fail-safe disconnection of suitable KACO in-
verters from the public grid can be carried out by the internal interface switches instead of separate interface
switches. This requires the inverters in the photovoltaic system to be connected to the Powador-protect.
Information on installation and use can be found in this manual, in the Powador protect manual and in the in-
structions for use of the Powador protect on the KACO web site.
On the "Inverter Off" input, instead of the Powador-protect an interface protection device from another sup-
plier an also be connected to actuate the internal interface switches.
3.3 System layout
Inverter
with circuit-breaker
String combiner with DC isolator switch
*Switch box
Inverter
with circuit-breaker
AC
AC
String combiner with DC isolator switch
RS485
PV generator PV generator
Fig.6: Circuit diagram with a short or long supply cable to the inverter
3 | Description of the device Manual
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
Page 10
EN

Grid connection point
PTransf.
Inverter
with circuit-breaker
S
XFMR MV/LV
Equivalent mains
impedance up to 25%
Fig.7: Circuit diagram from the grid connection point to the inverter
Key Definition / information on the connection
PV generator The PV generator converts the radiant energy of sunlight
into electrical energy.
String combiner A string combiner can be coupled to the KACO device so
that the DC lines can be combined.
*) If the supply cable from the PV generator to the device is
long, the string combiner can also be installed in the vicinity
of the PV generator.
An integrated DC isolator switch enables disconnection on
the DC-side.
Switch box A switch box with integrated DC isolator switch enables dis-
connection from the inverter on the DC-side.
Inverter with circuit-breaker The PV generator is connected to the device's DC connec-
tion.
Transformer All three phases need to be set up on the medium-voltage
transformer or medium-voltage/high-voltage transformer.
In this case, the total impedance of the transformer stations
must be below 25%.
Grid connection point The clean PV-current is made available at the grid connec-
tion point.
Manual Description of the device | 3
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3 KACO
blueplanet 165 TL3
Page 11
EN

4 Technical data
4.1 Electrical data
KACO blue-
planet
87.0TL3
KACO blue-
planet
92.0TL3
KACO blue-
planet 110TL3
KACO blue-
planet 125TL3
KACO blue-
planet 137TL3
KACO blue-
planet 150TL3
DC Input levels Input levels (DC)
Maximum recommended PV
generator power 130.5 kW 138 kW 165 kW 187.5 kW 205.5 kW 225 kW
MPPrange@Pnom 563 V - 1300
V591 V-1,300 V 705 V-1,300 V 875 V-1,300 V 875 V -1,300 V960 V-1,300 V
Working range 563 V - 1450
V591 V-1,450 V 705 V-1,450 V 875 V-1,450 V 875 V -1,450 V960 V-1,450 V
Rated voltage 600 V 620 V 730 V 900 V 1,000 V
Starting voltage 645 V 675 V 805 V 1,000 V 1,100 V
Open circuit voltage 31,500 V
Max. input current 4160 A
Number of strings 1-2
Number of MPP controls 1
Max. short-circuit current (ISC
max.) 300 A
Input source feedback current 0 A
Polarity safeguard no
String fuse no
DC overvoltage protection Yes
KACO blueplanet
105TL3
KACO blueplanet 125
TL3 US
KACO blueplanet
155TL3
KACO blueplanet
165TL3
Maximum recommended PV
generator power 157.5 kW 187.5 kW 232.5 kW 247.5 kW
MPPrange@Pnom 580 - 1300 V 700 - 1300 V 875 - 1300 V 950 - 1300 V
Working range 591 V-1,450 V 705 V-1,450 V 875 V-1,450 V 960 V-1,450 V
Rated voltage 620 V 730 V 900 V 1,000 V
Starting voltage 673 V 804 V 1,000 V 1,098 V
Open circuit voltage 31,500 V
Max. input current 4183 A
Number of strings 1-2
Number of MPP controls 1
Max. short-circuit current (ISC
max.) 300 A
3A brief open circuit voltage of up to 1600 Vdc (max. 15 hours a year) is admissible for the device.
Due to the brief open circuit voltage exceedance, there is no guarantee that the integrated overvoltage pro-
tection will work correctly if the ambient temperature is > 40°C.
4The "Max. input current" is the maximal theoretical value for operation with full power when the feed-in
power is low. The device is limited to the maximum AC power.
The "Max. short-circuit current (ISCmax.)" defines together with open circuit voltage (Uocmax) the character-
istic of the connected PV generator. This is the relevant value for string sizing and is the absolute maximal limit
for inverter protection. The connected PV-Generator must be designed, that the max short circuit current is
below or equal to ISCmax of the inverter under all foreseeable conditions. In no condition the design may res-
ult in a greater short circuit current than ISCmax of the inverter [See section7.6.2}Page28].
4 | Technical data Manual
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
Page 12
EN

KACO blueplanet
105TL3
KACO blueplanet 125
TL3 US
KACO blueplanet
155TL3
KACO blueplanet
165TL3
Input source feedback current 0 A
Polarity safeguard no
String fuse no
DC overvoltage protection Yes
KACO blue-
planet
87.0TL3
KACO blue-
planet
92.0TL3
KACO blue-
planet
110TL3
KACO blue-
planet
125TL3
KACO blue-
planet 137TL3
KACO blue-
planet
150TL3
AC Output levels Output levels (AC)
Nominal power 87 kVA 92 kVA 110 kVA 125 kVA 137 kVA 150 kVA
Rated voltage 380 V (3P+PE) 400 V (3P+PE) 480 V (3P+PE) 600 V [3P+PE] 660 V (3P+PE)
Voltage range: continuous op-
eration 300 V - 437 V 300 V - 460 V 300 V - 552 V 480 V - 690 V 480 V - 760 V
Rated current 3 x 132.3 A 3 x 132.3 A 3 x 132.3 A 3 x 120.3 A 3 x 132.3 A 3 x 131.2 A
Max. continuous current 3 x 132.3 A
Contribution to peak short-cir-
cuit current ip 193 A
Initial short-circuit alternating
current (Ik" first single period
effective value)
137 A
Short circuit current continu-
ous [ms] (max output fault
current)
134 A
Inrush current 5 A [RMS (20ms)]
Rated frequency 50/60 Hz
Frequency range 45 - 65 Hz
Reactive power 0-100 % Snom
cos phi 0.3 - 1 ind/cap
Number of feed-in phases 3
Distortion factor (THD) < 3 %
Max. voltage range (up to 100
s) 475 V 500 V 600 V 750 V 825 V
AC overvoltage protection Base
KACO blueplanet
105TL3
KACO blueplanet 125
TL3 US
KACO blueplanet
155TL3
KACO blueplanet
165TL3
AC Output levels Output levels (AC)
Nominal power 99.9 kVA 125 kVA 155 kVA 165 kVA
Rated voltage
380 V [3P+PE] ;
400 V [3P+PE];
415 V [3P+PE]
480 V (3P+PE) 600 V [3P+PE] 660 V (3P+PE)
Voltage range: continuous op-
eration 300 V - 478 V 300 V - 552 V 480 V - 690 V 480 V - 760 V
Rated current 3 x 144.5 A 3 x 150.5 A 3 x 149.5 A 3 x 144.5 A
Max. continuous current 3 x 152 A 3 x 145 A
Contribution to peak short-cir-
cuit current ip 260.8 A
Initial short-circuit alternating
current (Ik" first single period
effective value)
150.8 A
Manual Technical data | 4
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3 KACO
blueplanet 165 TL3
Page 13
EN

KACO blueplanet
105TL3
KACO blueplanet 125
TL3 US
KACO blueplanet
155TL3
KACO blueplanet
165TL3
Short circuit current continu-
ous [ms] (max output fault cur-
rent)
150 A
Inrush current 5 A [RMS (20ms)]
Rated frequency 50/60 Hz
Frequency range 45 - 65 Hz
Reactive power 0-100 % Snom
cos phi 0.3 - 1 ind/cap
Number of feed-in phases 3
Distortion factor (THD) < 3 %
Max. voltage range (up to 100
s) 519 V 600 V 750 V 825 V
AC overvoltage protection Base
4.2 General Data
KACO blue-
planet
87.0TL3
KACO blue-
planet
92.0TL3
KACO blue-
planet
110TL3
KACO blue-
planet
125TL3
KACO blue-
planet 137TL3
KACO blue-
planet
150TL3
General electrical data
Max. efficiency 98.9 % 99.1 % 99.2 %
European efficiency 98.6 % 98.8 % 99.0 %
Self consumption: Standby < 10 W
Feed-in from > 200 W
Transformer unit no
Protection class / over voltage
category I / III
Grid monitoring Country-specific
Distribution system TN-C system, TT system, Solid grounded wye
KACO blueplanet
105TL3
KACO blueplanet 125
TL3 US
KACO blueplanet
155TL3
KACO blueplanet
165TL3
General electrical data
Max. efficiency 98.89 % 98.98 % 99.10 % 99.14 %
European efficiency 98.56 % 98.73 % 98.89 % 98.96 %
Self consumption: Standby < 10 W
Feed-in from > 200 W
Transformer unit no
Protection class / over voltage
category I / III
Grid monitoring Country-specific
Distribution system TN-C system, TT system, Solid grounded wye
KACO blue-
planet
87.0TL3
KACO blue-
planet
92.0TL3
KACO blue-
planet 110TL3
KACO blue-
planet
125TL3
KACO blue-
planet 137TL3
KACO blue-
planet
150TL3
General Data
Display LEDs
Controls Button / web server
Menu languages EN; DE; FR; IT; ES; PL; NL; PT; CZ; HU; SL; TR; RO
4 | Technical data Manual
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
Page 14
EN

KACO blue-
planet
87.0TL3
KACO blue-
planet
92.0TL3
KACO blue-
planet 110TL3
KACO blue-
planet
125TL3
KACO blue-
planet 137TL3
KACO blue-
planet
150TL3
Interfaces 2 x Ethernet, USB, 2x RS485 (1x reserved for string combiner com.), optional
Communication TCP/IP, Modbus TCP, Sunspec
Potential-free relay yes (integrated switch)
DC isolator switch no / yes (XL version)
AC isolator switch no
Cooling temp. regulated fan, max air throughput 364 m³/h
Number of fans 3x outside, 1x inside
Noise emission <60 db(A)
Housing material AL
HxWxD 719 mm x 699 mm x 460 mm
Weight 78.2 kg
Safety EN 62109-1, EN 62109-2
Interference immunity/inter-
ference emission/grid feed-
back
EN 61000-6-1, EN 61000-6-2, EN 62920 - Class A /
EN 61000-6-4, EN 62920 - Class A, EN 55011 - group 1 Class A /
EN 61000-3-11, EN 61000-3-12
Certifications Overview: see homepage, download area
KACO blueplanet
105TL3
KACO blueplanet 125
TL3 US
KACO blueplanet
155TL3
KACO blueplanet
165TL3
General Data
Display LEDs
Controls Button / web server
Menu languages EN; DE; FR; IT; ES; PL; NL; PT; CZ; HU; SL; TR; RO
Interfaces 2 x Ethernet, USB, 2x RS485 (1x reserved for string combiner com.), optional
Communication TCP/IP, Modbus TCP, Sunspec
Potential-free relay yes (integrated switch)
DC isolator switch no / yes (XL version)
AC isolator switch no
Cooling temp. regulated fan, max air throughput 364 m³/h
Number of fans 3x outside, 1x inside
Noise emission <60 db(A)
Housing material AL
HxWxD 719 mm x 699 mm x 460 mm
Weight 78.2 kg
Safety EN 62109-1, EN 62109-2
Interference immunity/inter-
ference emission/grid feed-
back
EN 61000-6-1, EN 61000-6-2, EN 62920 - Class A /
EN 61000-6-4, EN 62920 - Class A, EN 55011 - group 1 Class A /
EN 61000-3-11, EN 61000-3-12
Certifications Overview: see homepage, download area
4.3 Environmental data
KACO blue-
planet
87.0TL3
KACO blue-
planet
92.0TL3
KACO blue-
planet 110TL3
KACO blue-
planet
125TL3
KACO blue-
planet
137TL3
KACO blue-
planet 150TL3
Installation height 3000m (derating from 2000m)
Installation distance from
coast > 500 m
Manual Technical data | 4
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3 KACO
blueplanet 165 TL3
Page 15
EN

KACO blue-
planet
87.0TL3
KACO blue-
planet
92.0TL3
KACO blue-
planet 110TL3
KACO blue-
planet
125TL3
KACO blue-
planet
137TL3
KACO blue-
planet 150TL3
Ambient temperature -25 °C - +60 °C
Ambient temperature (stor-
age) -25 °C - +60 °C
Power derating from > 45 °C
Protection rating (KACO in-
stallation location) IP66 /NEMA 4X
Humidity range (non-condens-
ing) [%] 100%
Item number 1001784 /
1001897
1001785 /
1001930 //
1001898
1001786 /
1001892
1001623 /
1001893
1001787 /
1001934 //
1001895 /
1001936
1001783 /
1001935 //
1001896 /
1001937
Name on nameplate
KACO blue-
planet 87.0
TL3 M1 WM
OD IIF0 /
KACO blue-
planet 87.0
TL3 M1 WM
OD IIFX
KACO blue-
planet 92.0
TL3 M1 WM
OD IIG0 /
KACO blue-
planet 92.0
TL3 M1 WM
OD IIGX
KACO blue-
planet 110
TL3 M1 WM
OD IIK0 /
KACO blue-
planet 110
TL3 M1 WM
OD IIKX
KACO blue-
planet 125
TL3 M1 WM
OD IIP0 /
KACO blue-
planet 125
TL3 M1 WM
OD IIPX
KACO blue-
planet 137
TL3 M1 WM
OD IIP0 /
KACO blue-
planet 137
TL3 M1 WM
OD IIPX
KACO blue-
planet 150
TL3 M1 WM
OD IIQ0 /
KACO blue-
planet 150
TL3 M1 WM
OD IIQX
KACO blueplanet
105TL3
KACO blueplanet 125
TL3 US
KACO blueplanet
155TL3
KACO blueplanet
165TL3
Installation height 3000m (derating from 2000m)
Installation distance from
coast > 500 m
Ambient temperature -25 °C - +60 °C
Ambient temperature (stor-
age) -25 °C - +60 °C
Power derating from > 35 °C
Protection rating (KACO in-
stallation location) IP66 /NEMA 4X
Humidity range (non-condens-
ing) [%] 100%
Item number 1001941 / 1001951 1001942 / 1001952 1001943 / 1001953 1001944 / 1001954
Name on nameplate
KACO blueplanet
105TL3 M1 WM OD
IIG0/KACO blue-
planet 105TL3 M1
WM OD IIGX
KACO blueplanet
125TL3 M1 WM OD
IIK0/KACO blueplanet
125TL3 M1 WM OD
IIKX
KACO blueplanet
155TL3 M1 WM OD
IIP0/KACO blueplanet
155TL3 M1 WM OD
IIPX
KACO blueplanet
165TL3 M1 WM OD
IIP0/KACO blueplanet
165TL3 M1 WM OD
IIPX
4.4 Accessories
Accessory articles KACO order no.
Bending box 1001917
AC inverter input plate kit 1001882 (double row) / 1001906 (M63/32)
AC inverter overvoltage pro-
tection kit 1001884
AC inverter overvoltage pro-
tection kit 1001884
4 | Technical data Manual
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
Page 16
EN

Accessory articles KACO order no.
DC inverter overvoltage pro-
tection kit 1001885
LAN inverter overvoltage pro-
tection kit 1001886
RS485 inverter overvoltage
protection kit 1001887
PID connection set 1001888
WLAN adapter, Digitus 150N
micro 3013222
Accessory articles KACO order no.
Replacement fuses (10x85mm
1500V 5A PID) 1001883
Manual Technical data | 4
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3 KACO
blueplanet 165 TL3
Page 17
EN

5 Transportation and Delivery
Every product leaves our factory in perfect electrical and mechanical condition. Special packaging ensures that
the devices are transported safely. The shipping company is responsible for any transport damage that occurs.
5.1 Scope of delivery
– Inverter
– Mount
– Installation kit
– Manual [online] / operating instructions [multi-language]
Check the equipment included
1. Inspect the device thoroughly.
2. Immediately notify the shipping company in case of the following:
– Damage to the packaging that indicates that the device may have been damaged.
– Obvious damage to the device.
3. Send a damage report to the shipping company immediately.
4. The damage report must be received by the shipping company in writing within six days following receipt
of the device. We will be glad to help you if necessary.
5.2 Transporting the device
CAUTION
Hazard due to impact; risk of breakage to the device!
1. Pack the device securely for transport.
2. Transport the device using the intended carrying handles of the packaging box.
3. Do not expose the device to any shocks.
For safe transportation of the product, use the hand recesses in the carton.
Packaging Folding cardboard box
Height x width x depth 790x760x550 mm
Total weight 83 kg
Fig.8: Transporting the device
5.3 Installation tool
The codes given in the table below are used in all usage instructions for assembly/installation/maintenance and
disassembly for the tools and tightening torques being used.
Code (s) Shape of the
connector
W External hexagon
A Internal hexagon
T Torx
S Slot
Tab.2: Key and description of tool codes
Outer contour
Tightening torque
Spanner size or number
Nm
Fig.9: Form pattern
5 | Transportation and Delivery Manual
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
Page 18
EN

6 Assembly and preparation
6.1 Choosing the installation location
DANGER
Risk of fatal injury due to fire or explosions!
Fire caused by flammable or explosive materials in the vicinity of the device can lead to serious injuries.
1. Do not mount the inverter in potentially explosive atmospheres or in the vicinity of highly flammable ma-
terials.
CAUTION
Property damage due to gases that have an abrasive effect on surfaces when they come into contact with
ambient humidity caused by weather conditions.
The device housing can be seriously damaged due to gases in combination with air humidity resulting from weather con-
ditions (e.g. ammonia, sulphur).
1. If the device is exposed to gases, the installation must be carried out at observable locations.
2. Perform regular visual inspections.
3. Immediately remove any moisture from the housing.
4. Ensure adequate ventilation at the installation location.
5. Immediately remove dirt, especially on vents.
6. Failure to observe these warnings may lead to device damage which is not covered by the manufacturer warranty.
NOTE
Access by maintenance personnel for service
Any additional costs arising from unfavourable structural or mounting conditions shall be billed to the cus-
tomer.
Installation space
– As dry as possible, climate-controlled, the waste heat must be dissipated away from the device.
– Unobstructed air circulation.
– Close to the ground, accessible from the front and sides without requiring additional resources
– Protected on all sides against direct weather exposure and sunlight (thermal heating) in outdoor areas. Implementa-
tion where necessary via constructional measures, e.g. wind breaks.
Installation surface
– Must have adequate load-bearing capacity
– Must be accessible for installation and maintenance
– Must be made out of heat-resistant material (up to 90 °C )
– Must be flame resistant
– Minimum clearances to be observed during installation: [See figure 17 [}Page21]
Manual Assembly and preparation | 6
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3 KACO
blueplanet 165 TL3
Page 19
EN

Fig.10: Device for outdoor installation
10-90°
Fig.11: Permissible installation location
Fig.12: Free-standing mounting under PV system
300 mm
Fig.13: Mounting instruction under PV system
6.2 Unpacking the device
CAUTION
Risk of injury caused by excessive physical strain.
Lifting the device, for transport, relocation and assembly, can result in injuries (e.g. back injuries).
1. Only lift the device using the openings provided.
2. The device must be transported and installed by at least 2 persons.
DETAIL Z4:1
Z
2
1
3
4
5
6
Fig.14: Open the package Fig.15: Setting the device upright
6 | Assembly and preparation Manual
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
Page 20
EN
