Kambrook Arctic KFA413 User manual

Instruction Booklet
Arctic
40cm
Pedestal Fan
KFA413

Contents
Kambrook Recommends p3
Safety First
Your Kambrook Arctic p5
Pedestal Fan
Using Your Kambrook p6
Arctic Pedestal Fan
Care and Maintenance p7
Warranty p8
Important
Please retain your instruction
book for future use.
In the event that you need some assistance with your
Kambrook appliance, please contact our Customer Service
Department on 1300 139 798 (Australia) or 09 271 3980 (New
Zealand). Alternatively, visit us on our website at
www.kambrook.com.au

3
Kambrook Recommends Safety First
IMPORTANT: Please retain your
instruction book for future use.
At Kambrook, we believe that safe performance is the first priority in any
consumer product, so that you, our valued customer can confidently
use and trust our products. We ask that any electrical appliance that
you use be operated in a sensible fashion with due care and attention
placed on the following important operating instructions.
Important Safeguards For Your Kambrook
Arctic Pedestal Fan
• Carefully read all instructions before
operating the Kambrook Arctic
Pedestal Fan for the first time and save
for future reference.
• To protect against electric shock, do no
immerse the fan, cord or plug in water
or any other liquid
• This fan is intended for household
use only and not for commercial or
industrial use. Disconnect the power
plug before dismantling, assembling or
before cleaning and when the fan is
not in use.
• Avoid touching mobile parts of the fan.
• Ensure the fan is on a dry and
even surface.
• Never insert fingers, pencils or any other
objects through the guards whenever
the power plug is connected, in
particular while the fan is switched on.
• The fan must not be used if the guards
are not fastened correctly, according
to these instructions.
• Do not operate in the presence of
explosives and/or flammable fumes
or liquids.
• Do not unplug the fan by pulling on
the cord.
• Never leave the fan unattended when
in use.
• Never carry the fan by the cord or yank
to disconnect from an outlet; instead,
grasp the cord and pull to disconnect.
Do not pull the cord around sharp
edges or corners.

4
Important Safeguards For All
Electrical Appliances
• Fully unwind the power cord before use.
• Do not let the power cord hang over
the edge of a bench or table, touch
hot surfaces or become knotted.
• To protect against electric shock do not
immerse the power cord, power plug or
housing in water or any other liquid.
• The appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised
to ensure that they do not play with
the appliance.
• It is recommended to regularly inspect
the appliance. To avoid a hazard do
not use the appliance if power cord,
power plug or appliance becomes
damaged in any way. Return the
entire appliance to the nearest
authorised Kambrook Service Centre
for examination and/or repair.
• Any maintenance other than cleaning
should be performed at an authorised
Kambrook Service Centre.
• This appliance is for household use only.
Do not use this appliance for anything
other than its intended use. Do not use
in moving vehicles or boats. Do not use
outdoors. Misuse may cause injury.
• The installation of a residual current
device (safety switch) is recommended
to provide additional safety protection
when using electrical appliances. It
is advisable that a safety switch with
a rated residual operating current
not exceeding 30mA be installed in
the electrical circuit supplying the
appliance. See your electrician for
professional advice.

5
Your Kambrook Arctic Pedestal Fan
1. Fan blade size: 40cm
2. Choice of 3 speed settings
3. 80° oscillation to disperse the air
throughout the room
4. Easy twist controller switch
5. Height adjustable for
comfort control
6. Tilt adjustable head to control the
direction of the air
7. Metal grille and plastic blades
8. Convenient carry handle for
easy portability
Parts List
9. Front grille with securing clips
and screw
10. Rear grille
11. Blade cap and guard locking nut
12. Plastic fan blade
13. Motor head and stand
14. Pedestal extension tube
15. Height adjustment ring
16. 2 piece criss-cross base

6
Using Your Kambrook Arctic Pedestal Fan
Before First Use
Remove any promotional material from
the fan.
IMPORTANT: When
unpacking the fan, check
to see you have received
all the items listed in the
Parts List, before discarding
the packaging.
Assembling Your Arctic
Pedestal Fan
Base and Pedestal Tube Assembly
1. Remove the four screws from the
criss-cross bars, and align these
four holes with those on the flange.
Secure the flange to the criss-cross
bars with the four screws. This might
require a bit of force.
Fig. 1
2. Loosen the Height Adjustable Ring
and extend the support tube. A bit
of force may be required to grasp
the support tube, located inside the
Pedestal Extension Tube. Retighten
the Height Adjustment Ring to
prevent slipping.
3. Place the motor head housing onto
the Pedestal Extension Tube.
4. Tighten the screw to secure the
Pedestal Extension Tube to the
motor head housing.
Fan Head Assembly
1. Remove the Blade Cap from the
Motor shaft by turning it clockwise,
and then remove the Guard Locking
Nut by turning it anti-clockwise.
2. Thread the Motor shaft through
the centre hole of the Rear Grille,
placing the Rear Grille into position.
Make sure that the carry handle, on
the back of the Rear Grille is located
above the motor housing. Ensure
the Rear Grille is aligned with the
locating pins and fix the grille into
position by replacing the Guard
Locking Nut. Make sure that the Rear
Grille has not slipped off the locating
pins before tightening. This should be
done by hand. Do not force.
NOTE: When positioning the
Rear Grille on the Motor shaft,
always ensure the carry handle
on the grille is positioned in the
upright position.
3. Insert the Plastic Blade onto the
Motor shaft, and match the pin slots
in the blade with the Motor shaft pin.
4. Fix the blade into place by
tightening the Blade Cap onto the
Motor shaft in an anti-clockwise
direction. This should be done by
hand. Do not force.
5. Unlatch the Securing Clips on the
Front Grille and unscrew the small
screw located at the bottom of the
front guard.
6. Press together the Front and Rear
Grille, and secure by snapping shut
the Securing Clips over edges of
both grilles. Make sure that the small
holes at the bottom of both grilles
are aligned. Tighten the Securing
Clips by hand.
7. Thread the screw through the
small holes of both the front and
back grilles, and tighten using the
nut provided.

7
Fig. 2
To Operate the Arctic
Pedestal Fan
Plug the cord into a 230V or 240V power
point and switch on.
NOTE: To avoid an electrical
circuit overload, it is
recommended that no other
appliances are plugged into the
same circuit as your fan when it
is in use.
Use the Twist Controller Switch to select
the desired air flow speed setting.
0 – The fan is in the ‘OFF’ position
1 – Low
2 – Medium
3 – High
Fig. 3
Setting the Oscillation
The oscillation function works in all air
flow settings.
Press down the Oscillation switch to
activate. The fan will begin to oscillate
from side to side.
Lift the Oscillation switch to stop the fan
from oscillating.
NOTE: The Oscillation switch is
located behind the Rear Grille,
on the Motor head housing.
Adjustable Tilting Head
The Arctic Pedestal Fan incorporates
an Adjustable Tilt Head for greater
air coverage.
To adjust the angle of the head, while
securely holding the shaft of the
pedestal tube, simply lift or lower the
Motor head housing, the head will click
as it is being adjusted.
Adjustable Height
The Arctic Pedestal Fan height can be
adjusted.
Simply loosen the Height Adjustable Ring
on the Pedestal Tube of the fan. Then
adjust to the required height. Re-tighten
the Height Adjustable Ring when the
desired height has been reached.
Care and Maintenance
Always switch the Arctic Pedestal Fan
off, prior to cleaning the housing, base,
grilles and blades.
To clean the outside of the fan, wipe
the exterior with a soft, damp cloth.
Never use an abrasive cleaner.
When not in use, store the fan
(preferably in its original box) in a cool,
clean and dry location.

In Australia, this Kambrook Replacement
Warranty does not affect the mandatory
statutory rights implied under the Trade Practices
Act 1974 and other similar State and Territory
legislation relating to the appliance. It applies
in addition to the conditions and warranties
implied by that legislation.
In New Zealand, this Kambrook Replacement
Warranty does not affect your mandatory
statutory rights implied under the Consumer
Guarantees Act 1993 in relation to the appliance.
It applies in addition to the conditions and
guarantees implied by that legislation.
This Kambrook Replacement Warranty is valid only
in the country of purchase, but other statutory
warranties may still apply.
This Warranty card and the purchase receipt
for this product are to be retained as proof of
purchase and must be presented if making
a claim under the Kambrook Replacement
Warranty. Please note that under any applicable
statutory warranty you are not required to
produce these documents, but may be required
to provide a proof of purchase.
Kambrook warrants the purchaser against defects
in workmanship and material for a period of 12
months domestic use from the date of purchase
(or 3 months commercial use).
The Kambrook Replacement Warranty does not
apply to any defect, deterioration, loss, injury or
damage occasioned by, or as a result of, misuse
or abuse, negligent handling or if the product
has been used other than in accordance with
the instructions. The Kambrook Replacement
Warranty excludes breakables such as glass and
ceramic items, consumable items and normal
wear and tear.
This Kambrook Replacement Warranty is void if
there is evidence of the product being tampered
with by unauthorised persons.
If the product includes one or a number of
accessories only the defective accessory or
product will be replaced. Subject to your statutory
rights, in the event of Kambrook choosing
to replace the appliance, the Kambrook
Replacement Warranty will expire at the original
date, i.e. 12 months from the original date of
purchase.
In the event that you need some assistance
with your Kambrook appliance, please contact
our Customer Service Department on 1300 139
798 (Australia) or 09 271 3980 (New Zealand).
Alternatively, visit us on the website at
www.kambrook.com.au
Kambrook 12 Month Replacement Warranty
Your Purchase Record (Please Complete)
Date Of Purchase ________________________________
Model Number ___________________________________
Serial Number ____________________________________
Purchased From __________________________________
Attach a copy of the purchase receipt here.
(Please don’t return purchase record
until you are making a claim)
Register your warranty at www.kambrook.com.au/service.asp
Kambrook - Australia
Building 2, Port Air Industrial Estate
1A Hale Street
Botany NSW 2019
Australia
Customer Service Line 1300 139 798
Customer Service Fax [phone]
Kambrook - New Zealand
Private Bag 94411
Botany, Manukau
Auckland 2141
New Zealand
Customer Service Line/Spare Parts
0800 273 845 or 09 271 3980
Customer Service Fax [phone]
Due to continual improvement in design or otherwise, the product you
purchase may differ slightly from the illustration in this book. Issue A10
Kambrook 12 Month Replacement Warranty
