Kambrook Arctic KFA715 User manual

Due to continual improvement in design or otherwise, the product you
purchase may differ slightly from the illustration in this book. Issue A13
Kambrook - Australia
Building 2, Port Air Industrial Estate
1A Hale Street
Botany NSW 2019
Australia
Customer Service Line 1300 139 798
Customer Service Fax [phone]
www.kambrook.com.au
Kambrook - New Zealand
Private Bag 94411
Botany, Manukau
Auckland 2163
New Zealand
Customer Service Line/
Spare Parts 0800 273 845
Customer Service Fax [phone]
www.kambrook.co.nz

Instruction Booklet
Arctic
Tower Fan
KFA715

Important
Please retain your instruction
book for future use.
In the event that you need some assistance with your
Kambrook appliance, please contact our Customer Service
Department on 1300 139 798 (Australia) or 0800 273 845
(New Zealand). Alternatively, visit us on our website at
www.kambrook.com.au or www.kambrook.co.nz

Contents
Kambrook Recommends p4
Safety First
Your Kambrook Arctic p6
Tower Fan
Using Your Kambrook p7
Tower Fan
Care, Cleaning and Storage p10

4
Kambrook Recommends Safety First
IMPORTANT: Please retain your
instruction book for future use.
At Kambrook, we believe that safe performance is the first priority in any
consumer product, so that you, our valued customer can confidently
use and trust our products. We ask that any electrical appliance that
you use be operated in a sensible fashion with due care and attention
placed on the following important operating instructions.
Important Safeguards For Your Kambrook
Arctic Tower Fan
• Carefully read all instructions before
operating the tower fan for the first time
and save for future reference.
• Remove and safely discard any
packaging material and promotional
labels before using the tower fan for the
first time.
• To eliminate a choking hazard for
young children remove and safely
discard the protective cover fitted to
the power plug of this tower fan.
• This tower fan is intended for household
use only and not for commercial or
industrial use.
• Switch off the tower fan and unplug at
the power outlet, prior to assembling,
cleaning and storing the tower fan.
• Avoid touching mobile parts of the
tower fan.
• Do not place the tower fan on a bench
or table. Ensure that the surface is level,
clean and free of water and other
substances.
• Always ensure the tower fan is properly
assembled before use. Follow the
instructions provided in this book.
• Do not leave the tower fan unattended
when in use.
• Do not place anything, on top of the
tower fan when assembled, when in
use and when stored.
• Never insert fingers, pencils or any
other objects through the guards
whenever the power plug is connected,
in particular while the tower fan is
switched on.
• The tower fan must not be used if
the base is not fastened correctly,
according to the instructions.
• Do not operate in the presence of
explosives and/or flammable fumes
or liquids.
• Do not unplug the tower fan by pulling
on the cord.
• Never carry the tower fan by the cord
or yank to disconnect from an outlet;
instead, grasp the plug and pull to
disconnect.
• Do not pull the cord around sharp
edges or corners.
• When unpacking the tower fan, check
to see you have received all the items
listed in the parts list, before discarding
the packaging.
• Keep the tower fan clean. Follow
the cleaning instructions provided
in this book.
• Do not operate without the base
stand fitted.

5
Important Safeguards For All
Electrical Appliances
• Fully unwind the power cord before use.
• Connect only to a 230V or 240V
power outlet.
• Do not let the power cord hang over
the edge of a bench or table, touch
hot surfaces or become knotted.
• To protect against electric shock,
do not immerse the power cord,
power plug or appliance in water or
any other liquid or allow moisture to
come in contact with the part, unless
it is recommended in the cleaning
instructions.
• The appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by
a person responsible for their safety.
• Children should be supervised to
ensure that they do not play with
the appliance.
• It is recommended to regularly
inspect the appliance. To avoid a
hazard, do not use the appliance if
power cord, power plug or appliance
becomes damaged in any way.
Return the entire appliance to the
nearest authorised Kambrook service
centre for examination and/or repair.
• Any maintenance other than cleaning
should be performed at an authorised
Kambrook Service Centre.
• This appliance is for household use only.
Do not use this appliance for anything
other than its intended use. Do not use
in moving vehicles or boats. Do not use
outdoors. Misuse may cause injury.
• The installation of a residual current
device (safety switch) is recommended
to provide additional safety protection
when using electrical appliances. It
is advisable that a safety switch with
a rated residual operating current
not exceeding 30mA be installed in
the electrical circuit supplying the
appliance. See your electrician for
professional advice.
• Always turn the appliance to the OFF
position, switch off at the power outlet
and unplug at the power outlet when
the appliance is not in use.
• Before cleaning, always turn the
appliance to the OFF position, switch
off at the power outlet, unplug at
the power outlet and remove the
power cord, if detachable, from the
appliance and allow all parts to cool.
• Do not place this appliance on or near
a heat source, such as hot plate, oven
or heaters.
• Position the appliance at a minimum
distance of 20cm away from walls,
curtains and other heat or steam
sensitive materials and provide
adequate space above and on all
sides for air circulation.

6
Your Kambrook Arctic Tower Fan
1. 78cm tower fan
2. Oscillating body to circulate air
throughout the room
3. Control panel featuring;
•PowerOFFbutton
•Fanspeedsettings;LOW,
MEDIUM and HIGH
•Twohourauto-off
control TIMER
•SWINGbuttontoturn
oscillation on and off
4. Base stand (two fitted pieces)
Not Shown
• Connection ring to secure fan to
base stand
• Convenient carry handle for
easy portability

7
Using Your Kambrook Tower Fan
Before First Use
Remove your tower fan from its carton
and associated protective wrapping.
Ensure that all parts listed are
accounted for before discarding
the packaging.
Unwind the cord to its full length and
remove any promotional labels and
or packaging materials from the
tower fan.
Place the tower fan on a firm, level
surface in a stable position. Visually
inspect the air inlet and outlets to
ensure no foreign materials are
blocking these areas.
Assembling Your Arctic
Tower Fan
To assemble the base stand:
1. The tower fan base stand comes
in two separate pieces; piece (a)
andpiece(b)-thatmustbexed
together before being fitted to the
fan body (see Fig.1).
2. To assemble the base stand, first
carefully place the tower fan
body on its side and unscrew the
plastic connection ring screwed
onto the stem on the base of the
fan. Holding base stand piece (a),
align the four locating posts on
piece (b) with the corresponding
slots found in base stand piece (a)
and firmly push downwards until
the base stand is securely fixed
together (see Fig. 2).
Fig. 1
Fig. 2
Fig. 3
(a) (b)
3. Align the base stand with the
tower fan body being sure that
the power cord is situated to sit
on top of the groove found in
base stand piece (a) (see Fig. 3).
Top view
(b)
(b)
(a)
(a)
Bottom View
Cord
Groove

8
Using Your Kambrook Tower Fan continued
Fit the base stand on to the
stem located on the base of the
tower fan and using the plastic
connection ring supplied, screw
the base stand to the tower fan
body. Fasten until tightened
(see Fig. 4).
Fig. 4
NOTE: Ensure power cord is sitting
above tower fan base.
4. Return the tower fan to its upright
position. It is now ready for use.
WARNING: Do not operate
the tower fan without the
base stand fitted.
Operating Your Tower Fan
To operate the tower fan, plug the
power cord into a 230V or 240V
electrical outlet and switch on.
Be sure that the plug fits tightly as a
loose fit will cause overheating
and damage the plug.
NOTE: To avoid an electrical circuit
overload, it is recommended that
no other appliances are plugged
into the same circuit as your fan,
when it is in use.
The tower fan operates in two ways.
1) It will operate when the TIMER dial
is set to ON or 2) by using the 2 hour
auto-offtimer.Forboth,afanspeed
setting MUST be chosen.
Fan Speed Settings
The tower fan has 3 speed settings,
LOW,MEDIUMandHIGH.Pressthe
desired fan speed button on the
control panel. Fan speed can be
adjusted during operation by simply
switching to another setting.
To Turn The Tower Fan On
To turn the tower fan ON, set the timer
dial to the ON setting then choose a
fan speed.
To turn the tower fan OFF temporarily,
press the Off button located on the
control panel. To turn the tower fan
OFF completely, press the Off button
and move the timer dial to the OFF
position, switch off at the power
outlet and unplug the tower fan
from the outlet.
Setting the Auto-Off Timer
Alternatively,the2hourauto-offtimer
located on the control panel can also
be utilised to turn the tower fan ON
and OFF.
First select the desired fan speed
setting;LOW,MEDIUMorHIGH.Then
turn the timer dial clockwise to the
desired position up to 120 minutes (2
hours) to activate the timer and turn
the fan ON.

9
The two hour timer will count down
and turn the tower fan OFF after the
selected preset time has elapsed.
Once OFF, switch the tower fan Off at
the power outlet and unplug from the
outlet.
NOTE: The tower fan will only
operate with the timer dial set to
ON or by using the 2 hour TIMER.
Setting the Oscillation
The oscillation function works in all
fan speed setting modes.
With the tower fan turned on,
pressing the ‘SWING’ button will allow
the tower fan to oscillate back and
forth. To stop the unit oscillating, press
the ‘SWING’ button once more.
Fig. 5

10
Care, Cleaning and Storage
1. Ensure that the tower fan is
switched OFF and disconnected
from the power outlet before
cleaning.
2. Use a clean, dry cloth to clean
the external surfaces of the tower
fan. If the tower fan has collected
dirt inside the unit, have the unit
cleaned by a qualified service
agent. Do not operate the tower
fan in this condition.
3. Do not attempt to open the case
of the tower fan at any time as
there are no customer serviceable
parts inside.
4. When not in use, remove the base
stand and screw connection ring
to the stem on the base. Store the
tower fan (preferably in its original
box) in a cool, clean and dry
location.

11
Notes
