Kambrook KFA423 User manual

Due to continual improvement in design or otherwise, the product you
purchase may differ slightly from the illustration in this book. Issue A12
Kambrook - Australia
Building 2, Port Air Industrial Estate
1A Hale Street
Botany NSW 2019
Australia
Customer Service Line 1300 139 798
Customer Service Fax [phone]
www.kambrook.com.au
Kambrook - New Zealand
Private Bag 94411
Botany, Manukau
Auckland 2163
New Zealand
Customer Service Line/
Spare Parts 0800 273 845
Customer Service Fax [phone]
www.kambrook.co.nz

Instruction Booklet
Arctic HV
40cm
Pedestal Fan
KFA423

Important
Please retain your instruction
book for future use.
In the event that you need some assistance with your
Kambrook appliance, please contact our Customer Service
Department on 1300 139 798 (Australia) or 0800 273 845
(New Zealand). Alternatively, visit us on our website at
www.kambrook.com.au or www.kambrook.co.nz

3
Contents
Kambrook Recommends p4
Safety First
Your Kambrook Arctic HV p6
Pedestal Fan
Using Your Kambrook p7
Pedestal Fan
Care and Maintenance p9

4
Kambrook Recommends Safety First
IMPORTANT: Please retain your
instruction book for future use.
At Kambrook, we believe that safe performance is the first priority in any
consumer product, so that you, our valued customer can confidently
use and trust our products. We ask that any electrical appliance that
you use be operated in a sensible fashion with due care and attention
placed on the following important operating instructions.
Important Safeguards For Your Kambrook
Arctic HV Pedestal Fan
• Carefully read all instructions before operating
the Kambrook Pedestal Fan for the first time
and save for future reference.
• Remove and safely discard any packaging
material and promotional labels before
using the fan for the first time.
• To eliminate a choking hazard for young
children, remove and safely discard the
protective cover fitted to the power plug
of this fan.
• Ensure that the surface is level, clean
and free of water and other substances.
• Always ensure the fan is properly assembled
before use. Follow the instructions provided
in this book.
• Keep the fan clean. Follow the cleaning
instructions provided in this book.
• Do not leave the fan unattended when in use.
• Do not place anything, on top of the fan when
assembled, when in use and when stored.
• This fan is not intended for commercial
or industrial use.
• Avoid touching mobile parts of the fan.
• Never insert fingers, pencils or any other
objects through the guards whenever the
power plug is connected, in particular
while the fan is switched on.
• Do not operate in the presence of explosives
and/or flammable fumes or liquids.
• Do not unplug the fan by pulling on the cord.
• Never carry the fan by the cord or yank
to disconnect from an outlet; instead grasp
the cord at the plug and pull to disconnect.
Do not pull the cord around sharp edges
or corners.
• The fan must not be used if the grilles are
not fastened correctly and the pedestal
stand and base correctly fitted as per
the instructions provided in this book.
• When unpacking the fan, check to see
you have received all the items listed in the
parts list before discarding the packaging.
• To avoid electrical circuit overload, it is
recommended that no other appliances
are plugged into the same circuit as your
fan when it is in use.
• Disconnect the power plug before dismantling,
assem
bling or before cleaning and when the
fan is not in use.

5
Important Safeguards For All
Electrical Appliances
• Fully unwind the power cord before use.
• Connect only to a 230V or 240V power outlet.
• Do not let the power cord hang over the
edge of a bench or table, touch hot
surfaces or become knotted.
• To protect against electric shock, do
not immerse the power cord, power
plug or appliance in water or any other
liquid, unless it is recommended in the
cleaning instructions.
• The appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance,
by a person responsible for their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• It is recommended to inspect the appliance
regularly. Do not use the appliance if the
power supply cord, plug, connector or
appliance becomes damaged in anyway.
Return the entire appliance to the nearest
authorised Kambrook Service Centre for
examination and/or repair.
• Any maintenance other than cleaning
should be performed at an authorized
Kambrook Service Centre.
• This appliance is for household use only.
Do not use this appliance for other than
its intended use. Do not use in moving
vehicles or boats. Do not use outdoors.
Misuse may cause injury.
• The installation of a residual current device
(safety switch) is recommended to provide
additional safety protection when using
electrical appliances. It is advisable that a
safety switch with a rated residual operating
current not exceeding 30mA be installed in
the electrical circuit supplying the appliance.
See your electrician for professional advice
• Always turn the appliance to the OFF
position, switch off at the power outlet
and unplug at the power outlet when the
appliance is not in use.
• Before cleaning, always turn the appliance
to the OFF position, switch off at the power
outlet, unplug at the power outlet and
remove the power cord, if detachable, from
the appliance and allow all parts to cool.
• Do not place this appliance on or near
a heat source, such as hot plate, oven
or heaters.
• Position the appliance at a minimum
distance of 20cm away from walls, curtains
and other heat or steam sensitive materials
and provide adequate space above and
on all sides for air circulation.

6
Your Kambrook Arctic HV Pedestal Fan
HIGH
MED
LOW
OFF
1. Fan head with metal front/back
grilles, metal fan blades, and tilt
adjustment knobs
2. Fan blade size: 40cm
3. Manually adjustable head moves
up and down or left and right
4. Height adjustable pedestal
extension with knob
5. Dial controller with 3 speed settings
6. Carry handle for portability
(not shown)
7. Solid, anti-topple base for stability
Parts List
1. Fan head
7. Base
8. Tilt adjustment knobs (2)
9. Fan Head Screws
10. Height adjustment knob
11. Inner extension tube
12. Outer extension tube
13. Fixing Tube
14. Stability plate
15. Washer
16. Locking screw

7
Using Your Kambrook Pedestal Fan
Before First Use
Remove any promotional material from
the fan.
IMPORTANT:
When unpacking the fan,
check to see you have
received all the items
listed in the Parts List before
discarding the packaging.
Assembling Your Kambrook
Arctic HV Pedestal Fan
Base and Extension Tube
Assembly
1. Place the Fixing Tube into the hole
of the Stability Plate (Fig. 1) then
place both under the Base. Place
the Washer on to the Locking Screw
and fit through the hole at the
bottom of the Stability Plate (Fig. 2).
Fig. 1
NOTE: The Washer fits into the
groove on the bottom of the
Stability Plate and is correctly
fitted if the Locking Screw
protrudes from the other side
of the Base leaving enough
thread to screw onto the
Outer Extension Tube.
2. Fit the Outer Extension Tube on to
the Locking Screw and tighten the
Locking Screw firmly. (Fig. 3).
Fig. 3
3. Unscrew the Height Adjustment Knob
and pull up on the Inner Extension
Tube to adjust the height, ensuring
that the Height Adjustment Knob is
fully tightened to hold in place before
assembling the Fan Head. (Fig. 4).
Fig. 4
Fig. 2
g

8
NOTE: The Inner Extension Tube is
inside the Outer Extension Tube.
4. Mount the pre-assembled Fan Head to
the Inner Extension Tube and tighten
the Fan Head Screw until it is tight (Fig. 5).
Fig. 5
IMPORTANT: The prongs
on the pre-assembled fan
head assembly may
need to be pried apart
slightly to more easily fit
on to the top of the
extension tube. Do not
force the pre-assembled
fan head onto the
extension tube.
5. Press the two Tilt Adjustment Knobs
firmly on to the bolts located on
either side of the fan head. (Fig. 6)
Fig. 6
To Operate the Kambrook
Arctic HV Pedestal Fan
Plug the cord into a 230V or 240V power
point and switch on.
The fan has 3 speeds. To adjust the flow of
air, turn the fan speed dial located at the
back of the fan to the preferred speed -
LOW, MED or HIGH. To turn Off, turn the fan
speed dial to the OFF position.
NOTE: To avoid an electrical
circuit overload, it is
recommended that no other
appliances are plugged into the
same circuit as your fan when it
is in use.
Adjusting Air Flow Direction
To adjust the flow of air left or right, manually
swivel the fan to the desired position.
To adjust the flow of air up or down,
slightly loosen the two tilt adjustment
knobs located on either side of the
fan and tilt the fan either upwards or
downwards to suit. Once the fan is in
the desired position, re-tighten the
two knobs to hold in place.
Adjustable Height
The fan height can be manually adjusted.
Simply loosen the Height Adjustment Knob
on the Extension Tube of the fan, then adjust
to the required height. Re-tighten the Height
Adjustment Knob when the desired height
has been reached (Fig. 6).
Fig. 6
Using Your Kambrook Pedestal Fan continued -

9
Always turn the fan to the OFF position,
switch off at the power outlet and unplug
at the power outlet before cleaning.
To clean the fan, remove dust that
may have accumulated with a soft
cloth or a vacuum cleaner using the
brush attachment. Wipe the exterior
of the fan with a soft, damp cloth.
Never use an abrasive cleaner. When not
in use, store the fan in a cool, clean and
dry location.
Care and Maintenance
