Kangaroo Kookaburra K3455 User manual

SEW IN COMFORT. SEW LONGER.™
ASSEMBLY INSTRUCTIONS
Kookaburra
ITEM NO.: K3455 Teak
K3451 Ash White

2
Kookaburra Assembly Instructions
Read the instructions carefully before starting. Please open and inspect the contents of boxes to
see that all parts are included. You will need a Phillips head and a flat head screwdriver. A power
screwdriver or cordless drill is preferable. Ensure that the Phillips head fits neatly and fully engages
the screw to avoid damage to the screws. Make sure that you tighten all screws securely and tap
wooden dowels all the way in.
Use and Care
Your cabinet normally requires a minimum amount of maintenance; however, the following points are
worth noting:
Cleaning – To remove marks and enhance the surface, wipe with general purpose cleaner.
Caution – Do not use ammonia-based cleaning agents. Do not use harsh chemicals or abrasive
cleansers. The surface can be wiped with a damp cloth but should be dried quickly.
Electrical and Hydraulic Lifts – Require annual lubrication.
180°
Screw cam bolts flush as
illustrated.
Press cam Into hole until flush with
surface. The arrow direction must
be in the direction of the hole!
Insert bolt through pre-drilled
hole in edge of panel.
Understanding How the Cam Fastener Works
Turn clockwise to lock cam with bolt.

3
Kookaburra Assembly Instructions
Parts List
ITEM DESCRIPTION QT Y. PACK.
YBack Panel 1 1 of 3
EShelf panel 3 1 of 3
L1 Drawer Left Side 4 1 of 3
L2 Drawer Right Side 4 1 of 3
L3 Drawer Back 4 1 of 3
L4 Drawer Bottom 4 1 of 3
A1 Top Leaf Panel 2 2 of 3
ATop Panel 1 2 of 3
GBottom 1 2 of 3
ITEM DESCRIPTION QT Y. PACK.
XLeft Side Panel 1 3 of 3
ZRight Side Panel 1 3 of 3
01 Left Gate Leg 2 3 of 3
O2 Right Gate Leg 2 3 of 3
Z
A
A1
A1
O1
O1
O2
O2
E
E
E
G
X
Y
L3
L1
L4
L
L2

4
Kookaburra Assembly Instructions
Parts List
6x35 Cam Bolt x40
3.5x14 Screw x92 3x14 Screw x8
Wrench x1 Handle x4 14mm Spanner x1
Cam
5⁄8“ Cam Cover x40
Alignment Pin x4
Caster x4 Locking Plate Caster x5
Butt Hinge x14 Peg x12
8x16 Fix Bolt x20
4x24 Fix Bolt x8
Pre-installed parts
ITEM DESCRIPTION QT Y.
c1 6x35 Cam Bolt 40
d1 8x30 Dowel Pin 30
c2 5⁄8“ Cam Cover 40
t1 Caster 4
t2 Locking Plate Caster 5
aWrench 1
r3 14mm Spanner 1
mMagnet, Catch Plate 4
ITEM DESCRIPTION QT Y.
h1 Butt hinge 14
hHandle 4
b2 4x24 Fix Bolt 8
b1 8x16 Fix Bolt 20
s1 3.5x14 Screw 92
s2 3x14 Screw 8
s3 3.5x30 Screw 16
s5 Alignment Pin 4
p1 Peg 12
Drawer RunnersCaster Bracket
8x30 Dowel Pin x30
3.5x30 Screw x16
Magnet x4
Catch plate x4
c1
b1
s1
a
c2
c5
s3
s5
b2
s2
h
r3
h1
p1
t1
t2
d1
m

Kookaburra 5Assembly Instructions
Step 1. Panel G assembly.
1. Fix casters t2 to panel Gwith bolts b1 as illustrated below using wrench ato tighten.
2. Turn panel over to side with care.
3. Install cam bolts c1 into panel Gas illustrated below.
Locking Plate
Caster x5
8x16 Fix Bolt x20
6x35 Cam Bolt x10
Wrench x1
Underside of Panel G
Top side of panel G
G
t2
t2
b1
b1
c1
c1
a
a
G

Kookaburra 6Assembly Instructions
8x30 Dowel Pin x16
d1
Step 2. Preparation Panels X and Z
1. Insert cams bolts c1 into panels X and Zas illustrated below.
2. Insert dowel pins d1 to panels Xand Zas illustrated below.
6x35 Cam Bolt x4
c1
Y
c1
X
c1
d1
d1
d1
d1

Kookaburra 7Assembly Instructions
14mm Spanner x1
Caster x4
Alignment Pin x4
Step 3. Preparation Panels A, A1, O1 and O2
1. Insert cams bolts c1 into panels A as illustrated below.
2. Locate the pilot holes in panels A, A1, 01 and 02 and install butt hinges h1 using s1 screws.
3. Attach magnet mon panels A1 using s1 screws.
4. Using spanner r3 screw caster t1 into bottom of panels 01 and 02 as shown below.
5. Screw in alignment pin s4 to panels 01 and 02 as illustrated below.
6. Attach magnet catch plate mto panels O1 and 02 using s2 screws.
3.5x14 Screw x60
Butt Hinge x14
x2
6x35 Cam Bolt x10
Magnet x4
Catch Plate x4
m
3x14 Screw x8
h1
O1
O2
t1
r3
s1
s1
h1
h1
s1
r3
t1
s5
s5
s2
m
A1
A1
A
c1
s2
s1
m

Kookaburra 8Assembly Instructions
8x30 Dowel Pin x16
d1
Step 4. Preparation Panels Y, L, L1 and L2
1. Insert cams bolts c1 into panels Las illustrated below.
2. Insert dowel pins d1 to panels Y,L1 and L2 as illustrated below.
3. Attach handle hto panel Lusing screws b2.
6x35 Cam Bolt x16
4x24 Fix Bolt x8
Handle x4
b2
h
x4
x4
c1
Y
c1
L
L2
L1
d1
d1
d1
h
b2

Kookaburra 9Assembly Instructions
Step 5. Panels Y, X, and Z assembly.
1. Insert cam bolts c1 on panels Xand Zinto cams on panel Yand tighten in a clockwise direction as illustrated below.
2. Apply cam covers c2 over tightened cams.
180°
5⁄8“ Cam Cover x4
5⁄8“ Cam Cover x10
Step 6. Panel G assembly.
1. Insert cam bolts c1 on panel G into cams on panels X, Yand Zand tighten in a clockwise direction.
2. Apply cam covers c2 over tightened cams.
180°
Z
Z
Y
G
X
X
Y
c2
c2
c5
c5

Kookaburra 10 Assembly Instructions
Step 8. Panels A and A1 assembly.
1. Insert cam bolts c1 on panel A into cams on panels X, Yand Zand tighten in a clockwise direction.
2. Apply cam covers c2 over tightened cams.
5⁄8“ Cam Cover x10
c2
180°
Step 7. Panels 01 and O2 assembly.
1. Locate the pilot holes on side panels Xand Zand attach butt hinges h1 found on gate leg panels O1 and O2 with 3
s1 screws per hinge to panels Xand Z.
3.5x14 Screw x24
A
A1
A1
c5
s1
s1
h1
Z
O1
O1
O2
O2
X

180°
c5
Kookaburra 11 Assembly Instructions
Step 9. Drawer(s) Panel L, L1, L2, L3 and L4 assembly.
1. Connect drawer panels L1, L2 and L3 with screws s3 as illustrated below. Screws will create the holes in panel L3 so
line up carefully.
2. Slide bottom L4 into L, L1, L2 and L3 grooves as illustrated.
3. Insert cam bolts c1 on panel Linto cam on panels L1 and L2. Tighten cams clockwise.
4. Apply cam covers c2 over tightened cams.
5⁄8“ Cam Cover x16
180°
3.5x30 Screw x16
x4
x4
c2
L3
L1
L1
L4
L
L2
L2
s3
s3
c5

Kookaburra 12 Assembly Instructions
Step 11. Moveable shelf assembly.
1. Press in p1 pegs with flat surface facing upwards at the same level.
2. Slide shelf Ewith cut in grooves (if available) downwards on top of p1 pegs.
Step 10. Drawers assembly.
Slide drawers into table aligning drawer runners.
Peg x12
E
E
E
L
L
L
L
p1
p1

SEW IN COMFORT. SEW LONGER.™
LIMITED LIFETIME WARRANTY
Kangaroo™ Sewing Furniture Limited Lifetime Warranty
WHAT THIS WARRANTY COVERS: Arrow Companies, LLC (Arrow) provides a Limited Lifetime Warranty
(warranty) to the original purchaser of this product against defects in materials or workmanship of furniture
components. As used in this Warranty, “defect” means imperfections in components which substantially
impair the utility of the product. This Warranty gives you specific legal rights, and you may also have other
rights which vary from state to state. Electrical and mechanical components of furniture are warrantied
for 5 years.
HOW TO GET SERVICE: Simply contact Arrow at 1-800-533-7347 or [e-mail]. When you
request warranty service, you must also present proof of purchase documentation, which includes the
date of purchase (detailed receipt), and photos of the product. Arrow will replace any defective part (at
its sole option), excluding labor. Replacement parts will be warranted for only the remaining period of
the original Warranty.
Replacement parts will be shipped freight prepaid on any initial warranty claim during first year of Warranty
only. Warranty applies only to defects confirmed by Arrow Companies, LLC and will be replaced or repaired
at Arrow’s option. In the event parts are no longer available for a warranty claim, customer may receive
brand new cabinet at a price equal to 60% off the MSRP of a current comparable model.
WHAT’S NOT COVERED: There is no warranty coverage for defects or conditions that result from the failure
to follow product assembly instructions, information or warnings, misuse or abuse, intentional damage,
fire, flood, alteration or modification of the product, or use of the product in a manner inconsistent with
its intended use, nor any condition resulting from incorrect or inadequate maintenance, cleaning, or care,
or neglect, cuts or scratches. Caster damage as a result of moving furniture fully loaded or with locked
casters. Damage resulting from electrical surge or lightning. Use in commercial or education environments.
Kangaroo Sewing Furniture is designed for residential use only.
ARROW SHALL HAVE NO LIABILITY for ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY KIND and
all such damages are EXCLUDED FROM THIS WARRANTY, such as loss of use, disassembly, transportation,
labor or damage to property on or near the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation or exclusion may not apply to you. The
Warranty cannot be transferred to subsequent owners or users of the product, and it shall be immediately
void in the event the product is resold, transferred, leased or rented to any third party or person other than
the original purchaser.
ADDITIONAL LIMITATIONS:
THERE ARE NO OTHER WARRANTIES APPLICABLE TO THIS PRODUCT. Under the laws of certain states,
there may be no implied warranties from Arrow and all implied warranties, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE are disclaimed where
allowed by law. TO THE EXTENT ANY IMPLIED WARRANTIES ARE APPLICABLE, ANY IMPLIED WARRANTIES,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
ARE LIMITED IN DURATION TO THE DURATION OF THIS EXPRESS WARRANTY or the minimum period
allowed by law, whichever is shorter. Some states do not allow limitations on how long an implied Warranty
lasts, so the above limitation may not apply to you. This limited warranty gives you specific legal rights.
This limited warranty does not, in any way, affect the rights given to you by law.
REGISTER YOUR PRODUCT: Original purchaser should register the purchase online at www.ArrowCabinets.com/warranty.
