Kangaroo Bandicoot II K8205 User manual

SEW IN COMFORT. SEW LONGER.™
ASSEMBLY INSTRUCTIONS
Bandicoot II
ITEM NO.: K8205 Teak
K8211 Ash White

2
Bandicoot II Assembly Instructions
Read the instructions carefully before starting. Please open and inspect the contents of boxes to
see that all parts are included. You will need a Phillips head and a flat head screwdriver. A power
screwdriver or cordless drill is preferable. Ensure that the Phillips head fits neatly and fully engages
the screw to avoid damage to the screws. Make sure that you tighten all screws securely and tap
wooden dowels all the way in.
Use and Care
Your cabinet normally requires a minimum amount of maintenance; however, the following points are
worth noting:
Cleaning – To remove marks and enhance the surface, wipe with general purpose cleaner.
Caution – Do not use ammonia-based cleaning agents. Do not use harsh chemicals or abrasive
cleansers. The surface can be wiped with a damp cloth but should be dried quickly.
Electrical and Hydraulic Lifts – Require annual lubrication.
180°
Screw cam bolts flush as
illustrated.
Press cam Into hole until flush with
surface. The arrow direction must
be in the direction of the hole!
Insert bolt through pre-drilled
hole in edge of panel.
Understanding How the Cam Fastener Works
Turn clockwise to lock cam with bolt.

3
Bandicoot II Assembly Instructions
Parts List
ITEM DESCRIPTION QT Y. PACK.
ATop Panel 1 1 of 2
BRight Leaf 1 1 of 2
CLeft Leaf 1 1 of 2
A4 Cover 1 1 of 2
GBottom Panel 1 1 of 2
DBack Panel 1 2 of 2
XLeft Side Panel 1 2 of 2
ZRight Side Panel 1 2 of 2
YPartition 1 2 of 2
FFixed Shelf 1 2 of 2
V1 Left Door Panel 1 2 of 2
ITEM DESCRIPTION QT Y. PACK.
V2 Right Door Panel 1 2 of 2
O1 Left Door Edge Panel 1 2 of 2
O2 Right Door Edge Panel 1 2 of 2
F1 Door Shelf 4 2 of 2
LDoor Bin Front 2 2 of 2
L1 Door Bin Side 4 2 of 2
L2 Door Bin Bottom 2 2 of 2
A3 Platform 1 2 of 2
Hardware Box 1 2 of 2
Lift & Rails 1 3 of 3
V2
Z
A
C
B
A3
O1
O2
D
A4
G
X
V1
F
F1
F1
F1
F1
Y
L1
L1
L1
L1
L
L
L2
L2

4
Bandicoot II Assembly Instructions
Parts List
6x35 Cam Bolt x30
3.5x14 Screw x14
3x14 Screw x28 Handle x2
Cam
6x25 Cam Bolt x36
5⁄8“ Cam Cover x66
6x50 Dowel Pin x20
Locking Plate Caster x4
Flush Hinge x6 Magnet x2
Catch plate x2
8x16 Fix Bolt x16 4x20 Fix Bolt x4
Pre-installed parts
ITEM DESCRIPTION QT Y.
c1 6x35 Cam Bolt 30
c3 6x25 Cam Bolt 36
d1 8x30 Dowel Pin 28
d2 6x50 Dowel Pin 20
c2 5⁄8“ Cam Cover 66
t2 Caster 4
aWrench 1
8x30 Dowel Pin x28
ITEM DESCRIPTION QT Y.
s2 3x14 Screw 28
hHandle 2
h2 Flush Hinge 6
b2 4x20 Fix Bolt 4
b1 8x16 Fix Bolt 16
s1 3.5x14 Screw 14
mMagnet, Catch Plate 2
Door Hook x2
Wrench x1
c1
c3
b1
s1
c2
c5
a
d2
b2
d1
h2
s2
h
m
t2
d

Bandicoot II 5Assembly Instructions
3.5x14 Screw x4
8x30 Dowel Pin x20
Magnet x2
m
Step 1. Preparation Panels A, D, X, Z, Y.
1. Insert cams bolts c1 into panels A,X and Z.
2. Insert dowel pins d1 to panels X, Z,Y and D.
3. Attach the door magnet mto Top Panel A using s1 screws.
6x35 Cam Bolt x14
c1
c1
s1
s1
Z
A
Y
X
D
m
c1
d1
d1
d1
d1

Bandicoot II 6Assembly Instructions
8x30 Dowel Pin x8
Catch Plate x2
Step 2. Preparation Panels V1, V2, Lx2, L1x4, F, F1x4, 01 and 02.
1. Insert cams bolts c1 into panels V1 and V2.
2. Insert dowel pins d1 to panels O1, O2, and F.
3. Insert cam bolt c3 into panels V1, V2,L and L1.
4. Insert Door Hook dto panels V1 and V2 using a hammer.
5. Fix magnet catch plate mto door V1 and V2 using s2 screws.
6. Insert dowels d2 into F1 shelves.
6x35 Cam Bolt x6
6x50 Dowel Pin x20
d2
6x25 Cam Bolt x36
3x14 Screw x4
Door Hook x1
x2
x4
x4
c1
c1
c1
c3
c3
c3
c3
F
V2
V1
F1
L
L1
O1
O2
m
c3
s2
s2
d1
d1
d2
d
d1
d1
d
m

Bandicoot II 7Assembly Instructions
3.5x14 Screw x3
Step 3. Fix Lifter Rail (right) to Zpanel with s1 screws following predrilled holes as shown on the illustration below.
Step 4.
1. Fix Lifter Rail (Left) to Y panel with s1 screws following predrilled holes as shown on the illustration below.
2. Turn panel Y over and insert cam bolts c1.
Lifter Rail (Right) x1
Lifter Rail (Left) x1
3.5x14 Screw x3
6x35 Cam Bolt x2
s1
s1
s1
s1
Y
Y
Z
c1
c1
c1

Bandicoot II 8Assembly Instructions
Step 5. Panels D, X, Z assembly.
Insert cam bolts c1 on panels Xand Zinto cams on panel Dand tighten in a clockwise direction. Apply cam covers c2
over tightened cams.
Step 6. Panel F and Y assembly.
Insert cam bolts c1 on panels Xand Yinto cams on panel Fand tighten in a clockwise direction as illustrated below. Apply
cam covers c2 over tightened cams.
180°
180°
5⁄8“ Cam Cover x4
5⁄8“ Cam Cover x4
Z
Y
F
D
X
X
c2
c2
c5
c5

180°
Bandicoot II 9Assembly Instructions
Step 7. Panel G assembly.
1. Fix casters t2 to panel Gwith bolts b1 as illustrated below. Tighten with wrench a.
2. Turn panel over.
3. Install cam bolts c1 into panel Gas illustrated below.
Step 8. Panel G assembly.
2 people should carefully turn cabinet over supporting panel Y which is attached to F and X but not to back panel D.
1. Insert cam bolts c1 on panel G into cams on panels X, Z, Dand Y and tighten in a clockwise direction as illustrated
below. Apply cam covers c2 over tightened cams.
Locking Plate
Caster x4
8x16 Fix Bolt x16
6x35 Cam Bolt x8
Wrench x1
5⁄8“ Cam Cover x6
G
Y
X
Z
D
G
t2
t2
b1
b1
c1
a
G
c1
c2
c5

Bandicoot II 10 Assembly Instructions
Step 10. Lifter Panel assembly.
Fix Lifter to A3 panel with s1 screws following predrilled holes as shown on the illustration below.
Note: Remove cable ties (do not remove wooden block).
Step 9. Flip cabinet over.
3.5x14 Screw x4
Lifter x1
A3
s1
s1
