Kangaroo K8805 User manual

SEW IN COMFORT. SEW LONGER.™
ASSEMBLY INSTRUCTIONS
Kangaroo
ITEM NO.: K8805 Teak
K8807 Gray
K8811 Ash White

Assembly InstructionsKangaroo 2
1. Read the instructions carefully before beginning the assembly process to ensure proper assembly
of this product. Please open and inspect the contents of box(es) to see that all parts and hardware
are included.
2. Tools Required
180°
Screw cam bolts flush as
illustrated.
Press cam into hole until flush with
surface. The arrow direction must
be in the direction of the hole.
Insert bolt through pre-drilled
hole in edge of panel.
Turn clockwise to lock cam with bolt.
General Assembly Guidelines
3. Understanding How the Cam Fastener Works
Tip: place a small bit of WD-40 or similar
lubricant into the pre-installed cam bolt
holes to help the cam bolts screw in better.
4. Glue provided is to secure wood dowels in place and is optional. If glue is used during assembly,
locate the appropriate hole for the dowel, place a small amount of glue in the hole and insert the
dowel. Wipe away excess glue immediately. It is not necessary to glue the other end of the dowel
when attaching to other parts.
Use and Care Your cabinet normally requires a minimum amount of maintenance; however, the
following points are worth noting:
Cleaning – To remove marks and enhance the surface, wipe with a gentle all-purpose cleanser. DO NOT
use ammonia-based, harsh chemicals or abrasive cleaning agents. Wipe dry immediately.
Electrical and Hydraulic Lifts – Require annual lubrication with WD-40 or similar lubricant.
Phillips Screwdriver Hammer Electric Screwdriver
Torque set to 3-5

Assembly InstructionsKangaroo 3
K
Z
A
A3
A2
A1
O1
O4
O3
O2
D
A4
A5
O
G
X
Y
L3
L1
L4
L
L2
Parts List: Panels
ITEM DESCRIPTION QT Y. PACK.
DBack Panel 1 2 of 3
LDrawer Front 1 2 of 3
ATop Panel 3 of 3
A3 Support Panel 1 2 of 3
A4 Platform Cover 1 3 of 3
A4 Platform Cover 1 3 of 3
GBottom Panel 1 3 of 3
A5 Right Leaf Panel 1 3 of 3
03 Front Right Leaf Support Panel 1 3 of 3
04 Rear Right Leaf Support Panel 1 3 of 3
Parts Box 1 1 of 3
ITEM DESCRIPTION QTY. PACK
XLeft side panel 1 1 of 3
ZRight side panel 1 1 of 3
YPartition 1 1 of 3
OInsert Holder 1 1 of 3
O1 Right Gate Leg 1 1 of 3
O2 Left Gate Leg 1 1 of 3
KFalse Drawer Front Panel 1 1 of 3
LDrawer Front 1 1 of 3
L1 Left Drawer Side 1 1 of 3
L2 Right Drawer Side 1 1 of 3
L3 Drawer Back 1 1 of 3
L4 Drawer Bottom 1 1 of 3
A1 Quilt Extension Panel 1 2 of 3
A2 Platform 1 2 of 3

Assembly InstructionsKangaroo 4
6x35 Cam Bolt x30
3.5x14 Screw x108
Allen Wrench x1
Knob x2
14mm Wrench x1
Cam
5⁄8“ Cam Cover x30 Alignment Pin x4
Caster x2 Plate Caster x5Butt Hinge x14
Ball Catch x2
Magnet x5
8x16 Fix Bolt x20 4x20 Fix Bolt x2
Pre-installed parts
s4
b2
r3
h2
b3
m
t1
t2
Drawer RunnersCaster Bracket
8x30 Dowel Pin x26
d1
3.5x35 Screw x4
c1
b1
s1
a
c2
c5
s3
h1
Parts List: Hardware
TIP: Keep all the parts in their individually labeled bags. This will make finding parts easier as you assemble your cabinet.
3x14 Screw x14
s2
Threaded Dowel Pin x3
p1

Assembly InstructionsKangaroo 5
Part 1: Cabinet Shell
We can’t wait to get your brand new Kangaroo Sewing Cabient up and running. Please contact our Customer Service Team at
1-800-533-7347, ext. 1 during normal business hours with any assembly related questions.
Plate Caster x5
8x16 Fix Bolt x20
Allen Wrench x1
t2
b1
a
Attach t2 Plate Casters to underside of Panel G using b1 Fix Bolts. Tighten
with a Allen Wrench. Lock Casters and flip Panel G over.
6x35 Cam Bolt x12
c1
8x30 Dowel Pin x2
d1
Insert 12 c1 Cam Bolts into the top side of
Panel G.
Insert 2 d1 Dowel Pins into the edge of
Panel O.
Attach Panel O to Panel G as shown. Tighten
Cam Locks and apply Cam Covers.
Set Panel G aside.
5⁄8“ Cam Cover x2
c2
G
O
G
180°
c5
O

Assembly InstructionsKangaroo 6
Part 1: Cabinet Shell
D
X
8x30 Dowel Pin x16
6x35 Cam Bolt x2
c1
d1
Insert 12 d1 Dowel Pins into the edges of Panel D.
Insert 4 d1 Dowel Pins into the edges of Panel X.
Insert 2 c1 Cam Bolts into Panel X.

Assembly InstructionsKangaroo 7
Part 1: Cabinet Shell
Z
Insert 4 d1 Dowel Pins into the edges of Panel Z.
Insert 2 c1 Cam Bolts into Panel Z.
Attach b3 Ball Catch with s1 Screws to front edge of Panel Z. Set aside the other parts of
the ball catch to use later.
s1
b3
Y
s1
b3
Insert 4 d1 Dowel Pins into the edges of Panel Y.
Attach b3 Ball Catch with s1 Screws to front edge of Panel Y. Set aside the other parts of
the ball catch to use later.
8x30 Dowel Pin x8
d1
Ball Catch x2
b3
6x35 Cam Bolt x2
c1
3.5x14 Screw x4
s1

Assembly InstructionsKangaroo 8
Part 1: Cabinet Shell
Lift Rail (Right) x1 Lift Rail (Left) x1
3.5x14 Screw x6
s1
Attach Lift Rail (Right) to Panel
Z with s1 Screws following pre-
drilled holes.
Attach Lift Rail (Left) to Panel Y with
s1 Screws following predrilled holes.
s1
TIP: Spray a small amount of
WD-40 or similar lubricant onto a
paper towel and wipe the newly
installed rails. This will make lift
installation and operation easier.
Y
Z

Assembly InstructionsKangaroo 9
Z
D
X
c5
5⁄8“ Cam Cover x4
c2
Insert c1 Cam Bolts on Panels X and Z into
cams on Panel D. Tighten cams and apply c2
Cam Covers.
NOTE: The above illustration shows panels
upside down and from the back. This is im-
portant for the next step, attaching the base
(Panel G).
Part 1: Cabinet Shell
180°
G
Z
D
c5
5⁄8“ Cam Cover x8
c2
Attach Panel G to Panels
D, X and Z as shown.
Tighten cam locks and
apply c2 Cam Covers.
Make sure the casters are
locked and turn the cabi-
net over onto its wheels.
NOTE: You may need a
friend to help you, but it
is not required.
X

Assembly InstructionsKangaroo 10
Part 1: Cabinet Shell
180°
G
Y
c5
5⁄8“ Cam Cover x2
c2
Insert c1 Cam Bolts on Panel G into
cams on Panel Y. Tighten and apply
c2 Cam Covers.
LIFT INSTALLATION WARNING:
DO NOT remove the small wooden block from the Lift until assembly is complete. If the block is removed or falls out
before lift assembly is complete, the cables will retract, making installation difficult. If the
block falls out before complete assembly, Call Customer Service at 1-800-533-7347, ext. 1
for assistance, or visit www.arrowcabinets.com/assembly-videos and find the
“Alternate Airlift Attachment Steps” video.
This illustration shows the back view of the Lift. Notice the
wooden block and zip tie; the wooden block holds the piston
in place so that the cables can be easily handled and inserted
into the Lift Rails installed on your cabinet.

Assembly InstructionsKangaroo 11
Part 2: Lift Panel
3.5x14 Screw x4
s1
A2
Attach the Lift to Panel A2 using s1 Screws.
Guide Lift onto Lift Rails using plastic guides. Insert ends of cable into rail tabs; make sure the cable is hooked into the rail
tabs on both sides.
NOTE: See Page 10 for close-up illustrations of Lift Panel assembly.
Cut the zip tie on the wooden block, but DO NOT remove the block yet.
Lower the Lift to first lock position and remove the
wooden block. DO NOT ADJUST LIFT POSITION until the
top is installed, or you risk the Lift
coming out and cables becoming
disengaged.

Assembly InstructionsKangaroo 12
Part 2: Lift Panel
Plastic guides
Lift rail
Cable
Lift rail
Rail tabs
REMINDER: Our Customer Service Agents are ready to help if you run into trouble! Please call us at 1-800-533-7347, ext. 1

Assembly InstructionsKangaroo 13
Part 3: Top, Support Leaf and Quilt Panel
A
6x35 Cam Bolt x10
c1
Insert c1 Cam Bolts into Panel A.
180°
c5
Lower Panel A, inserting cam bolts on Panel A onto cams on Panels X, D, Y and Z. Tighten
cam locks and apply c2 Cam Covers.
5⁄8“ Cam Cover x10
c2

Assembly InstructionsKangaroo 14
Part 3: Top, Support Leaf and Quilt Panel
O1
O2
t1
s4
s1
h2
m
s2
h2
3.5x14 Screw x12
Hinge x4
s1
Magnet Catch
Plate x2
m
Alignment Pin x2
s4
14mm Wrench x1
Caster x2
r3
t2
Attach h2 Butt Hinges to Panels O1 and O2 using s1 Screws.
Attach m Magnet Catch Plates to underside of Panels O1 and O2 using s2 Screws.
Screw s4 Alignment Pins into the pre-drilled hole in the top of Panels O1 and O2.
Screw t1 Casters into the bottom of Panels O1 and O2. Tighten with r3 Wrench.
3x14 Screw x4
s2

Assembly InstructionsKangaroo 15
h2
3.5x14 Screw x12
Hinge x4
s1
Magnet Catch
Plate x2
m
Alignment Pin x2
s4
Part 3: Top, Support Leaf and Quilt Panel
Attach h2 Butt Hinges to Panels O3 and O4 using s1 Screws.
Attach m Magnet Catch Plates to the underside of Panels O3 and O4 using s2 Screws.
Screw s4 Alignment Pins into the pre-drilled hole in the top of Panels O3 and O4.
3x14 Screw x4
s2
s4
s1
h2
O4
O3
m
s2

Assembly InstructionsKangaroo 16
Part 3: Top, Support Leaf and Quilt Panel
O1
O2
D
s1
h2
3.5x14 Screw x24
s1
Z
O4
O3
Attach Panels O1 and O2 to
Panel D using s1 Screws.
Attach Panels O3 and O4 to
Panel Z using s1 Screws.

Assembly InstructionsKangaroo 17
Part 3: Top, Support Leaf and Quilt Panel
s1
h2
A1
m
s1
Attach m Magnets to Panel A1 using s1
Screws as shown.
Attach h2 Butt Hinges to Panel A1 using
s1 Screws as shown.
Attach m Magnets using s1 Screws to
Panel A5 as shown.
Attach h2 Butt Hinges using s1 Screws
to Panel A5 as shown.
Magnet x4
m
3.5x14 Screw x26
s1
h2
Hinge x6
A5

Assembly InstructionsKangaroo 18
Part 3: Top, Support Leaf and Quilt Panel
A5
A1
Z
D
s1
h2
3.5x14 Screw x18
s1
Extend Gate Leg Panels O1 and O2. Balance Panel A1 on gate legs and attach h1 Hinges to Panel A
(top) using s1 Screws.
Extend Support Panels O3 and O4. Balance Panel A5 on support panels and attach h1 Hinges to
Panel A (top) using s1 Screws.
O3
O4
O1
O2

Assembly InstructionsKangaroo 19
Part 4: Drawer Unit and Front Panel
s2
m
b2
h1
L
6x35 Cam Bolt x4
c1
Magnet Catch
Plate x1
m
Knob x2
4x20 Fix Bolt x2
h1
b2
Attach c1 Cam Bolts to Panel L.
Attach m Magnet Catch Plate with s2 Screws.
Attach h1 Knobs with b2 Fix Bolts.
K
s1
b3
Attach remaining b3 Ball Catch parts
with s1 Screws to Panel K.
Set Panel K aside while you assemble
the drawer.
Ball Catch x2
b3
3x14 Screw x6
s2

Assembly InstructionsKangaroo 20
L
L1
L2
Part 4: Drawer Unit and Front Panel
L1
L2
L2
L1
L4
L3
s3
Slide Panel L4 into grooves on Panels L, L1 and L2. Connect Panel L3 to Panels L1 and L2 using s3 Screws.
L
L1
L2
Insert c1 Cam
Bolts on
Panel L into
cam locks
on Panels
L1 and L2.
Tighten cams
and apply c2
Cam Covers.
5⁄8“ Cam Cover x4
c2
3.5x35 Screw x4
s3
To reach the pre-drilled screw holes
on the sides of Panels L1 and L2,
you will need to tilt the drawer
runners.
Remove the front and back screws
on the drawer runners, leaving the
middle screw installed. Pivot the
drawer runners to access screw holes
as shown here.
