Kärcher HD 3.0/30 Pb User manual

9.800-083.0
MODEL ORDER #
HD 3.0/30 Pb 1.575-152.0
HD 3.7/35 Pb 1.575-154.0
HD 3.0/40 Pb 1.575-155.0
OPERATOR’S MANUAL
R
To locate your local Kärcher Commercial Pressure Washer Dealer nearest you,
visit www.karchercommercial.com

9.800-083.0 • Rev. 01/13
OPERATOR’S MANUAL PRESSURE WASHER
14
“Thisproduct contains chemicalsknown to the State of
Californiato cause cancer andbirth defects or other
reproductiveharm. Operation ofThis EquipmentMay
CreateSparksThat Can Start Fires Around DryVegetation.
ASpark Arrestor May be Required. The Operator Should
ContactLocal Fire Agencies for Laws or Regulations
Relatingto Fire Prevention Requirements.”
WARNING
8.917-015.0
EXPLODED VIEW - 1.575-152.0,154.0,155.0
17
18
9
10
11
12
10
11
16 13
15
31
19
27
29
6
28
30
1
59
58
58
2
3
4
6
5
57
40
41
42
45
43
39
38
37
32
36
32
35
44
34
49
51
25
24
60
61
54
11
14
47
52
50
48
23
56
55
59
22
21
53
11 20
10
63
33
58
58
20
46
28
28
28
62
61
60 61
60
6
58
59
57
11
10
58
59
64
65
66
69
7
91
67
8
10
11
22
21
68
70
70
73
76
43
81
72
75 74
89
41
45
44
77
88
87
82
78
84
79
26
80
Pump
155.0
39
38
36
37
32
Pump
152.0
90
42

9.800-083.0 • Rev. 01/13
15
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW PARTS LIST - 1.575-152.0,154.0,155.0
ITEM PART NO. DESCRIPTION QTY
1 9.802-064.0 Grommet, Rubber, 5
Nozzle Holder
2 8.920-262.0 Handle, Grab, Chrome 1
3 9.800-723.0 Label, Cold Water Handle 1
4 9.803-126.0 Plate, Warning/Instruction, Black1
5 9.803-098.0 Hanger, Hose/Wand 1
6 9.802-706.0 Bolt, Carriage, 1/4"-20 x 1-3/4", 6
Zinc
7 9.800-110.0 Label Karcher Logo 1
8 9.802-778.0 Nut, 5/16" Whiz Loc Flange 2
9 8.920-261.0 Handle, Lower Grab, Chrome 1
10 9.197-003.0 Nut, 3/8" ESNA, NC 10
11 9.802-807.0 Washer, 3/8" SAE, Flat 14
12 9.803-114.0 Retainer Bracket, Handle, Black 2
13 9.802-728.0 Bolt, 3/8" x 2" NC, HH 4
14 9.802-727.0 Bolt, 3/8" x 1-3/4", Tap 4
15 9.802-817.0 Washer, 3/8" x 1", Steel 2
16 9.802-066.0 Pad, Soft Rubber 2
17 9.802-782.0 Collar, 5/8" Bore Shaft, 3010 2
18 9.802-271.0 Wheel & Tire Assy., 6" Steel 2
Rim w/Tube (152.0,154.0,155.0)
19 9.803-115.0 Frame Assy, Large, Black 1
(152.0,154.0,155.0)
20 9.802-712.0 Bolt, 5/16" x 1-3/4", NC, 4
Carriage, Zinc
21 9.802-776.0 Nut, 5/16", ESNA, NC 4
22 8.718-980.0 Washer, 5/16" Flat, SAE 4
23 8.911-226.0 Axle, 5/8" x 27" L 1
(152.0,154.0,155.0)
24 8.917-893.0 Assy Black, Slider Pump / Belt 1
Guard Mount (152.0,154.0,155.0)
25 8.917-886.0 Plate, Belt Guard Front Cover 1
26 Hose and Spray Gun, See Assy Page
27 9.803-118.0 Bracket, Take Up, CW, Black 1
28 9.802-700.0 Screw, 1/4" x 3/4" HH NC 8
29 9.802-809.0 Washer, 1/2", Flat, SAE 1
30 9.802-740.0 Bolt, 1/2" x 3-1/2" HEX 1
31 9.802-730.0 Bolt, 3/8" x 2-1/4", HH 2
32 6.390-126.0 Clamp, Hose, .46-54 ST 2
33 9.802-813.0 Washer, 5/16" Lock (152.0) 4
9.802-816.0 Washer, 7/16" Lock, Split 4
(154.0,155.0)
34 9.802-225.0 Injector Assy., Detergent, 1
Non-Adj, 3-5 GPM, 0.083
35 9.802-254.0 Hose, 1/4", Push-On, 1 ft.
Fuel Line (All except 155.0)
36 8.706-958.0 Barb, 1/4" Barb x 1/4" ML Pipe, 1
90°
ITEM PART NO. DESCRIPTION QTY
37 8.706-955 Hose Barb, 1/4" Barb x 1/8" 1
ML Pipe, 90°
8.706-940.0 Hose Barb, 1/4" Barb x 1/8" 1
ML Pipe
38 9.802-190.0 Valve, E-Z Start, 1
3/8" MPT x 1/8" FPT
9.804-065.0 Valve, E-Z Start, 1
1/4" MPT x 1/8" FPT (152.0)
39 8.706-207.0 Elbow, 3/8", Street 1
8.706-200.0 Elbow, 1/4", Street (152.0) 1
40 9.804-025.0 Pump Protector, 1/4" PTP 1
(All except 155.0)
41 Pump, See Specifications Pages
42 Unloader, See Specifications Pages
43 9.802-171.0 Nipple, 3/8" x 3/8" NPT ST Male 1
44 9.802-146.0 Swivel, 1/2" MP x 3/4" GHF 1
w/Strainer
45 9.802-163.0 Strainer, 1/2" PA, Inline Plastic 1
46 9.800-008.0 Label, Danger Cool Engine 1
47 Engine, See Specifications Pages
48 Engine Pulley, See Specifications Pages
49 Engine Bushing, See Specifications Pages
50 Belts, See Specifications Pages
51 Pump Bushing, See Specifications Pages
52 Pump Pulley, See Specifications Pages
53 8.920-263.0 Handle, Bumper, Chrome 1
54 9.800-006.0 Label, Hot/Caliente w/Arrows, 1
Warning
55 8.932-968.0 Label, Intended For Outdoor Use1
56 9.800-034.0 Label, Clear Lexan, 1
2-1/4" x 4-1/2"
57 8.712-337.0 Nozzle, 0003.5, Red (152.0) 1
8.712-338.0 Nozzle, SAQCMEG 1503.5, 1
Yellow (152.0)
8.712-339.0 Nozzle, SAQCMEG, 2503.5, 1
Green (152.0)
8.712-340.0 Nozzle, SAQCMEG 4003.5, 1
White (152.0)
8.712-350.0 Nozzle, SACQMEG, 0004.5, 1
Red (154.0)
8.712-360.0 Nozzle, SAQCMEG 1504.0, 1
Yellow (154.0)
8.712-370.0 Nozzle, SAQCMEG, 2504.0, 1
Green (154.0)
8.712-380.0 Nozzle, SAQCMEG 4004.0, 1
White (154.0)
8.712-331.0 Nozzle, SACQMEG, 0003 1
Red(155.0)
8.712-333.0 Nozzle, SAQCMEG 1503.0, 1
Yellow (155.0)
8.712-334.0 Nozzle, SAQCMEG, 2503.0, 1
Green (155.0)
8.712-335.0 Nozzle, SAQCMEG 4003.0, 1
White(155.0)

9.800-083.0 • Rev. 01/13
OPERATOR’S MANUAL PRESSURE WASHER
16
EXPLODED VIEW PARTS LIST - 1.575-152.0,154.0,155.0
ITEM PART NO. DESCRIPTION QTY
58 9.802-802.0 Washer, 1/4" Flat 10
59 9.802-773.0 Nut, 1/4" ESNA 8
60 8.718-980.0 Washer, 5/16" Flat 4
61 9.802-776.0 Nut, 5/16" ESNA 4
62 9.802-802.0 Washer, 1/4" Flat, SAE 6
63 9.802-741.0 Bolt, 8mm x 16mm Hex (152.0) 4
9.802-744.0 Bolt, 10mm x 20mm 4
(154.0,155.0)
64 8.706 -860.0 Tee, 1/2" Branch (155.0) 1
8.706-854.0 Tee, 1/4" Branch (152.0, 154.0) 1
65 8.706-984.0 Adapter, 1/2" x 1/2" (152.0) 1
66 9.800-049.0 Label, Manufacturer's Cleaning 1
Solution
67 9.802-959.0 Key, .247 Sqr. x 2.125" 1
68 9.802-311.0 Nozzle, Compl., Detergent 1
69 9.800-036.0 Label, Warning, Pictoral, Small 1
70 8.718-980.0 Washer, 5/16" Flat (152.0) 4
9.802-807.0 Washer, 3/8" Flat (155.0) 4
71 8.750-300.0 Unloader, VRT3 Ez Start (155.0) 1
72 9.802-870.0 Block, Unloader, 1
3/8" x 3/8" 1.25 Steel (155.0)
73 9.802-728.0 Bolt, 3/8" x 2", NC HH (155.0) 2
74 9.802-807.0 Washer, 3/8" SAE, Flat (155.0) 2
75 9.197-003.0 Nut, 3/8" ESNA NC (155.0) 2
76 8.705-974.0 Nipple, 3/8" Hex Steel (155.0) 1
77 9.802-129.0 Elbow, 3/8" x 1/2" JIC (155.0) 1
78 8.706-860.0 Street Tee, 1/2" (155.0) 1
79 9.802-128.0 Nipple, 1/2" x 1/2" JIC (155.0) 1
80 9.802-259.0 Hose, Push-on 1/2" (155.0) 15"
81 8.707-254.0 Pump Protector, 3/8" PTP 1
(155.0)
82 9.802-036.0 Nipple, 1/2" JIC, 3/8" Pipe 1
(155.0)
83 9.802-810.0 Washer, 5/8" Flat 2
84 9.802-151.0 Swivel, 1/2" JIC, Female, 2
Push-On (155.0)
85 9.802-959.0 Key, .247" Sqr. x 2.125" 1
86 9.800-036.0 Label, Warning, Pictoral, Small 1
87 9.802-039.0 Elbow, 1/2" JIC, 3/8", 90° 1
(155.0)
88 8.918-422.0 Hose, 3/8" x 20", 2 Wire, 1
Pressure Loop (155.0)
89 8.706-829.0 Elbow, 1/2"" Street, Brass 1
90 8.751-096.0 Label Regulation 4442.6 1
91 8.917-889.0 Plate, Belt Guard Back Cover 1
8.920-542.0 Black Plate Belt Guard (152.0) 1
▲Not Shown

9.800-083.0 • Rev. 01/13
17
PRESSURE WASHER
OPERATOR’S MANUAL
HOSE & SPRAY GUN ASSEMBLY PARTS LIST
HOSE & SPRAY GUN ASSEMBLY
ITEM PART NO. DESCRIPTION QTY
1 9.802-219.0 Wand Assy., Side Grip w/1/4" Coupler, 35-1/2" 1
2 8.710-384.0 Gun, St-1500, 5000 PSI, 10.4 Gpm 1
3 9.802-164.0 Coupler, 1/4” Female, Brass 1
4 Nozzle, See Breakdown for Part Numbers
5 8.739-125.0 Hose, 3/8" x 50', 1 Wire, Tuff-Flex, (150.0, 151.0, 152.0) 1
8.739-203.0 Hose, 3/8" x 50', 2 Wire,Tuff-Flex (154.0, 155.0) 1
6 9.802-166.0 Coupler, 3/8" Female, Brass 1
7 9.802-216.0 Injector, Chemical, Non-Adjust, 3-5 GPM, .083 1
8 6.390-126.0 Clamp, Hose 2
9 9.802-251.0 Tube, 1/4" x 1/2" Clear Vinyl 6 ft.
10 8.707-057.0 TStrainer, Plastic, 1/4" Hose Barb 1
11 9.802-170.0 Nipple 3/8 x 3/8 NPT Fem (155.0 Only) 1
12 9.802-169.0 Coupler 3/8" Male Brass (155.0 Only) 1
3
4
1
2
5
6
10
8
9
7
11
12

9.800-083.0 • Rev. 01/13
PRESSURE WASHER Specifications
18
SPECIFICATIONS
Model GPM
Pressure
(PSI)
Nozzle
Size Pump
Pump
Part No.
Unloader
Part No. Engine
Engine
Part No.
Pump
Pulley
Pump Pulley
Part No.
1.575-152.0 3.0 3000 3.5 KD3030 9.804-006.0 9.175-018.0 GX270 (270cc) 8.750-680.0 2BK80 9.802-389.0
1.575-154.0 3.7 3500 4.0 KM4035R.3 8.751-189.0 9.175-018.0 GX390 (390cc) 8.750-580.0 2BK90H 8.715-593.0
1.575-155.0 3.0 4000 3.0 KM3540R.3 8.751-186.0 8.750-300.0 GX390 (390cc) 8.750-580.0 2BK80H 9.802-389.0

9.800-083.0 • Rev. 01/13
19
PRESSURE WASHER Specifications
Model
Pump
Bushing
Bushing Part
No.
Engine
Pulley
Pulley
Part No.
Engine
Bushing
Bushing
Part No.
Belt
Size
Belt
Part No.
1.575-152.0 24MM 9.802-402.0 2BK40H 9.802-384.0 HX1" 9.802-398.0 BX38 (2) 9.802-417.0
1.575-154.0 24MM 9.802-402.0 2BK32H 9.802-381.0 HX1" 9.802-398.0 BX39 (2) 9.802-418.0
1.575-155.0 24MM 9.802-402.0 2BK40H 9.802-384.0 HX1" 9.802-398.0 BX38 (2) 9.802-417.0
SPECIFICATIONS

9.800-083.0 • Rev. 01/13
21
PRESSURE WASHER
OPERATOR’S MANUAL
UU1 UNLOADER EXPLODED VIEW
UU1 UNLOADER EXPLODED VIEW PARTS LIST
ITEM PART # DESCRIPTION KIT QTY
1 8.751-394.0 Piston Housing D 1
2 Piston C, D 1
3 Piston O-Ring Back Up A, D 1
4 8.749-796.0 Main Block 1
5 9.152-372.0 Piston Ring D 1
6 Ball Seat C, D 1
7 O-Ring 10.5 ID x 1.5 CS A,C,D 1
8 Plunger B 1
9 9.152-016.0 Plunger Housing 1
10 Bypass Spring C, D 1
11 9.149-001.0 Low Pressure Port 1
12 9.152-017.0 Sliding Connector, 30mm 1
8.762-005.0 Sliding Connector, 40mm, Long 1
13 9.149-002.0 Sliding Connector H 1/2" 1
9.149-005.0 Sliding Connector H 3/8" 1
14 9.196-011.0 Plug 5/8 -18 UNF D 1
15 O-Ring 12 ID x 2 CS A, D 2
16 O-Ring 6 ID X 2 CS A, D 1
ITEM PART # DESCRIPTION KIT QTY
17 9.149-006.0 Sliding Connector Guide 1
18 O-Ring Backup A, D 1
6 x 1.45 x 1.68
19 Ball Housing Assy C, D 1
20 O-Ring 6.75 x 1.78 BN80 A, D 1
21 Spring Seat C, D 2
22 Plunger Spring B 1
23 8.917-699.0 Banjo Bolt 1/2" Short 1
8.917-700.0 Banjo Bolt 1/2"-1/4" NPT Short 1
24 8.917-698.0 Banjo Bolt 3/8" Short 1
25 9.802-893.0 Seal Washer 3/8" 2
26 9.803-921.0 Seal Washer 1/2" 2
9.802-893.0 Seal Washer 3/8" 2
27 O-Ring 15 ID x 2CS A,B,D 3
28 8.706-865.0 Plug, 1/4" Countersunk 1
Kit A 9.104-038.0 O-Ring Repair Kit
Kit B 9.104-039.0 Outlet Kit
Kit C 9.104-040.0 Stem Basic Kit
Kit D 8.920-045.0 UU1 Complete Stem Kit
9.175-018.0
UU1 3500PSI, UNIVERSAL UNLOADER (SPARE)
21
2
3
20
16
18
5
15
19
6
7
25
4
8
22
27
9
15
12
17
11
27
23
13
26 26
24
25
27
1
10
14
21
28
23

9.800-083.0 • Rev. 01/13
OPERATOR’S MANUAL PRESSURE WASHER
24
KD.1 SERIES PUMP EXPLODED VIEW
KD.1 SERIES PUMP EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 9.803-938.0 Crankcase 1
2*
See Kits Below Plunger Oil Seal 3
3*
See Kits Below O-Ring Ø1.78 x 28.30 3
4*
See Kits Below Pressure Ring 15mm (3030) 3
See Kits Below Pressure Ring 18mm
(4020, 3025) 3
5*
See Kits Below U-Seal, 15mm (3030) 3
See Kits Below U-Seal, 18mm (4020, 3025) 3
6*
See Kits Below Intermediate Ring 15mm
(3030) 3
See Kits Below Intermediate 18mm
(4020, 3025) 3
7*
See Kits Below Intermed. Ring 15mm (3030) 3
See Kits Below Intermed. Ring 18mm
(4020, 3025) 3
8 9.802-926.0 Brass Plug 1/2" 1
9 9.803-199.0 Copper Washer 1/2" 1
10 9.803-946.0 Manifold Housing 1
ITEM PART NO. DESCRIPTION QTY
11* 9.803-947.0 O-Ring Ø1.78 x 15.54 6
12*
See Kits Below Valve Assembly 6
13* 9.803-948.0 O-Ring Ø2.62 x 18.77 6
14 9.803-949.0 Valve Plug 6
15 9.803-950.0 Copper Washer 1/4 1
16 9.803-951.0 Brass Plug G1/4 1
17 9.803-952.0 Manifold Stud Bolt 8
18 9.802-884.0 Washer 8
19 9.803-198.0 Copper Washer 3/8 1
20 9.802-925.0 Brass Plug 3/8 2
25 9.802-939.0 Screw 12
26 9.803-953.0 Bearing Cover 2
27 9.803-954.0 Bearing Seal 1
28 9.802-914.0 Snap Ring 1
29 9.803-955.0 Ball Bearing 2
30 9.803-956.0 Crankshaft 1
31 9.803-167.0 Crankshaft Key 1
32 9.803-957.0 Oil Dipstick 1
TORQUE
SPECS
Item # Ft.-lbs
14 65
17 18
25 7.6
34 7
44 13
9.803-417.0 KD 3025.1
9.804-006.0 KD 3030.1
9.804-019.0 KD 4020.1

9.800-083.0 • Rev. 01/13
25
PRESSURE WASHER
OPERATOR’S MANUAL
KD.1 SERIES PUMP EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
33 8.933-010.0 Crankshaft Seal 1
34*
See Kits Below Plunger Nut 3
35* See Kit Below Copper Spacer 3
36*
See Kits Below Plunger, 15mm (3030) 3
See Kits Below Plunger, 18mm
(4020, 3025) 3
37*
See Kits Below Copper Spacer 3
38*
See Kits Below O-Ring Ø1.78 x 5.28 3
39*
See Kits Below Teflon Ring 3
40* See Kits Below Plunger Rod 3
41 9.803-965.0 Connecting Rod Pin 3
42 9.803-966.0 Connecting Rod 3
43 9.803-218.0 Spring Washer 6
44 8.933-020.0 Connecting Rod Screw 6
45 9.803-202.0 Sight Glass 1
46 9.803-197.0 Gasket 1
47 9.803-968.0 Crankcase Cover 1
48 9.803-969.0 O-Ring Ø2.62 x 107.62
* Available in kit (See below)
REPAIR KIT
NUMBER 8.725-354.0 8.725-356.0 8.725-355.0 8.725-357.0 9.803-934.0 9.803-935.0 9.803-936.0 9.803-937.0
Kit Description Plunger
Seal 15mm
LD-3030
Plunger
Seal 18mm
LD-3025
LD-4020
Complete
Seal
Packing,
15mm
LD-3030
Complete
Seal Pack-
ing, 18mm
LD-3025
LD-4020
Plunger
15mm
LD-3030
Plunger
18mm
LD-3025
LD4020
Complete
Valve
Plunger Oil
Seals
ITEM NUM-
BERS IN-
CLUDED
3, 5, 7 3, 5, 7 3, 4, 5,
6, 7
3, 4, 5,
6, 7,
34, 35, 36,
37, 38
34, 35, 36,
37, 38 11, 12, 13 2
NUMBER OF
CYLINDERS KIT
WILL SERVICE
33111163

9.800-083.0 • Rev. 01/13
PRESSURE WASHER WARRANTY
®
LIMITED NEW PRODUCT
WARRANTY—COMMERCIAL
PRESSURE WASHERS
Phone: [phone]
Fax: [phone]
www.karchercommercial.com
WHAT THIS WARRANTY COVERS
All Kärcher commercial pressure washers are warranted by Kärcher to the original purchaser to be free from defects in materials and workmanship
under normal use, for the periods specified below. This Limited Warranty, subject to the exclusions shown below, is calculated from the date of the
original purchase, and applies to the original components only. Any parts replaced under this warranty will assume the remainder of the pressure
washer’s warranty period.
SEVEN YEAR PARTS AND ONE YEAR LABOR WARRANTY
Components manufactured by Kärcher, such as frames, handles, top and bottom wraps, float tanks, fuel tanks, and belt guards. Xpert Series cold water
pressure washer have a three-year frame warranty. Internal components on the oil-end of Kärcher Classic series, electric powered axial pumps have a 5 year
warranty. Period of warranty on gas-engine axial pumps shall be one year; Kärcher crankshaft pumps have a 7 year warranty on non-wear parts. Heating
coils have a five year warranty from date of original machine purchase; stainless steel coils have a 10 year warranty.
ONE YEAR PARTS AND ONE YEAR LABOR WARRANTY
All other components, excluding normal wear items as described below, will be warranted for one year on parts and labor. Parts and labor warranty on these
parts will be for one year regardless of the duration of the original component manufacturer’s part warranty.
WARRANTY PROVIDED BY OTHER MANUFACTURERS
Motors, generators, and engines, which are warranted by their respective manufacturers, are serviced through these manufacturers’ local authorized
service centers. Kärcher is not authorized and has no responsibility to provide warranty service for such components. Motors manufactured outside
of the United States will be warranted by Kärcher.
WHAT THIS WARRANTY DOES NOT COVER
This warranty does not cover the following items:
1. Normal wear items, such as nozzles, spray guns, discharge hoses, wands, quick couplers, seals, filters, gaskets, O-rings, packings, pistons, pump
valve assemblies, strainers, belts, brushes, rupture disks, fuses, pump protectors.
2. Any components or other devices incorporated into a Kärcher product that are not manufactured by Kärcher, including, but not limited to gasoline
engines, pumps, etc.
3. Defects caused by improper or negligent operation or installation, accident, abuse, misuse, neglect, unauthorized modifications, repair or maintenance
of the product by persons other than authorized representatives of Kärcher, including, but not limited to, the failure of the Customer to comply with
recommended product maintenance schedules.
4. Kärcher products that have been returned by the original Customer and are ultimately re-sold by an Authorized Servicing Dealer or other sales or
service outlet to another purchaser.
5. Kärcher products that are sold by any distributor or retailer that is not an official authorized dealer or retailer of Kärcher products.
6. Defects caused by acts of nature and disaster including, but not limited to, floods, fires, wind, freezing, earthquakes, tornadoes, hurricanes and
lightning strikes.
7. Defects caused by water sediments, rust corrosion, thermal expansion, scale deposits or a contaminated water supply (such as water in the unit with
chloride content higher than that of 80 mg/liter or use of chemicals not approved or recommended by Kärcher).
8. Defects caused by improper voltage, voltage spikes or power transients in the electrical supply.
9. Devices or accessories not distributed or approved by Kärcher.
10. Any cost of labor arising from the removal and reinstallation of the alleged defective part by Customer.
11. Transportation of the product to an Authorized Servicing Dealer, field labor, replacement rental and any freight charges.
Any components, accessories or other devices provided with the product but not manufactured by Kärcher (such as engines, pumps, etc.) are subject to war-
ranties and service through their respective manufacturers authorized service centers and according to the applicable terms and conditions of such manufac-
turers warranties. Such components or other devices not manufactured by Kärcher should be referred by the Customer to an authorized service center or their
respective manufacturers for repair or replacement.
THE FOREGOING WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF ANY KIND, WHETHER ARISING BY LAW, CUSTOM OR CONDUCT.
KÄRCHER MAKES NO ADDITIONAL WARRANTIES, EITHER EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY EXPRESSED
OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS OF EQUIPMENT FOR A PARTICULAR PURPOSE AND ANY SUCH WARRAN-
TIES ARE EXPRESSLY DISCLAIMED. KÄRCHER FURTHER DISCLAIMS ANY WARRANTY THAT THE PRODUCT PURCHASED BY CUSTOMER
WILL MEET ANY PARTICULAR REQUIREMENT OF CUSTOMER EVEN IF KÄRCHER HAS BEEN ADVISED OF SUCH REQUIREMENT.
THE RIGHTS AND REMEDIES PROVIDED UNDER THIS WARRANTY ARE EXCLUSIVE AND IN LIEU OF ANY OTHER RIGHTS OR REMEDIES OF
CUSTOMER. KÄRCHER SHALL NOT UNDER ANY CIRCUMSTANCES BE LIABLE TO ANY PERSON OR ENTITY INCLUDING, BUT NOT LIMITED
TO, THE CUSTOMER OR ANY END USER OF THE PRODUCT FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES
OR ECONOMIC LOSS, LOSS OF PROFITS OR LOSS OF USE OF THE PRODUCT, ARISING IN CONNECTION WITH THE SALE, DELIVERY,
INSTALLATION, TRAINING OR USE OF PRODUCT.
KÄRCHER’S LIABILITY, WHETHER IN CONTRACT OR IN TORT, ARISING OUT OF ANY WARRANTIES OR REPRESENTATIONS,
INSTRUCTIONS OR DEFECTS FROM ANY CAUSE, SHALL BE LIMITED EXCLUSIVELY TO THE COST OF REPAIR OR REPLACEMENT PARTS
UNDER AFORESAID CONDITIONS.
The purpose of the foregoing limitations on liability and Customer remedies is to protect Kärcher from unknown or undeterminable risks. Some states do
not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to the Customer.
Kärcher sales and service representatives are not authorized to waive or alter the terms of this warranty, or to increase the obligations of Kärcher
under the warranty.
Kärcher reserves the right to make design changes in any of its products without prior notification to the Customer
.
26

R
www.karchercommercial.com
Form # 9.800-083.0 • Revised 01/13 • Printed in U.S.A. or Mexico
