Kärcher K 2.55 User manual

English 2
Español 15
Français 28
9.760-071.0 07/05
K 2.55

2 English
Model Overview 3
Important Safety Instructions 4
Assembly Instructions 5
Operating Instructions 6
GFCI Instructions 7
Using the Accessories 7
Working with Detergents 8
Taking a Break ..five minutes or more9
Shutting Down & Clean-Up 9
Winterizing and Long-Term Storage10
Care and Maintenance Instructions 10
Cleaning Tips 11
Troubleshooting 13
DANGER
indicates “an imminently hazardous sit-
uation which, if not avoided, will result in
death or serious injury.’’
WARNING
indicates “a potentially hazardous situa-
tion which, if not avoided, could result in
death or injury.’’
CAUTION
indicates “a potentially hazardous situa-
tion which, if not avoided, may result in
minor or moderate injury’’ or in property
damage incidents.
Call: 1-800-537-4129 for help or visit
our website:
www.karcher-usa.com/home
Please take a moment to register your
presure washer online at
www.karcher-usa.com/warranty
Call: 1-800-465-4980 for help or visit
our website: www.karcher.ca
Call: 01-800-024-13-13 for help or visit
our website: www.karcher.com.mx
HIGH PRESSURE WASHER OPERATOR MANUAL
Safety Alert Symbols
Specifications
Operating pressure 1400 PSI
Water volume 1.3 GPM
Amp draw 13 AMPS
Voltage 120 V
Part No. 1.601-501.0
Serial no.
Kärcher Customer Support USA
Kärcher Customer Service CDN
Kärcher Customer Support Mexico

English 3
1 Power cord with Ground Fault Circuit
Interrupter (GFCI)
2 On/OFF switch
3 Trigger gun safety lock
4 High pressure hose
5 Trigger gun
6 Wash brush
7 Vario Power Spray wand
8 Water inlet with garden hose
connector
9 Detergent suction tube with filter
10 High pressure outlet
11 Connector for detergent suction tube
For household use only!
MODEL OVERVIEW

4 English
WARNING!
When using this product basic
precautions should always be
followed, including the following:
!Read all the instructions before us-
ing the product.
!To reduce the risk of injury, close su-
pervision is necessary when a prod-
uct is used near children.
!Know how to stop the product and
bleed pressures quickly. Be thor-
oughly familiar with the controls.
!Stay alert – watch what you are do-
ing.
!Do not operate the product when fa-
tigued or under the influence of alco-
hol or drugs.
!Keep operating area clear of all per-
sons.
!Do not overreach or stand on unsta-
ble support. Keep good footing and
balance at all times.
!Follow the maintenance instructions
specified in the manual.
!This Product Is Provided With A
Ground Fault Circuit Interrupter Built
Into The Power Cord Plug. If Re-
placement Of The Plug Or Cord Is
Needed, Use Only Identical Re-
placement Parts.
!Risk of Injection or Injury – Do Not
Direct Discharge Stream At Per-
sons.
!High pressure jets can be dangerous
if misused. The jet must not be di-
rected at persons, animals, electrical
devices, or the machine itself.
!Wear safety goggles.
!Do not use acids and solvents in this
product. These products can cause
physical injuries to the operator and
irreversible damage to the machine.
!To reduce the risk of electrocution,
keep all connections dry and off the
ground. Do not touch plug with wet
hands.
!The Trigger Gun Safety Lock PRE-
VENTS the trigger from accidentally
being engaged. This safety feature
DOES NOT lock trigger in the ON
position.
!Do not use extension cord with this
unit.
WARNING
To reduce the risk of electrocution, keep
all connections dry and off the ground.
Do not touch plug with wet hands.
In a double-insulated product, two sys-
tems of insulation are provided instead
of grounding. No grounding means is
provided on a double-insulated product,
nor should a means for grounding be
added to the product. Servicing a dou-
ble-insulated product requires extreme
care and knowledge of the system, and
should be done only by qualified service
personnel. Replacement parts for a
double-insulated product must be iden-
tical to the parts they replace. A double-
insulated product is marked with the
words “double-insulation” or “double-in-
sulated”. The symbol “!” may also be
marked on the product.
This product is supplied with a Ground
Fault Circuit Interrupter (GFCI) built into
the power cord plug. This device pro-
IMPORTANT SAFETY INSTRUCTIONS
SERVICING OF A DOUBLE-
INSULATED PRODUCT
GROUND FAULT CIRCUIT INTER-
RUPTER PROTECTION

English 5
vides additional protection from the risk
of electric shock. If power is interrupted
in the line, the GFCI will automatically
re-close the circuit to the load after pow-
er is restored. Depending on the GFCI
model, it may be necessary to manually
operate the reset button to restore pow-
er to the GFCI load circuit. If replace-
ment of the plug or cord is needed use
identical replacement parts.
CAUTION
When connecting the water inlet to the
water supply mains, local regulations of
your water company must be observed.
In some areas the unit must not be con-
nected directly to the public drinking wa-
ter supply. This is to ensure that there is
no feedback of chemicals into the water
supply. Direct connection via a receiver
tank or backflow preventer, for example,
is permitted.
Dirt in the feed water will damage the
unit. To avoid this risk, we recommend
fitting a water filter.
!Garden hose must be at least 5/8
inch in diameter.
!Flow rate of water supply must not
fall below 2 GPM (gallons per
minute).
!Flow rate can be determined by run-
ning the water for one minute into an
empty 5-gallon container.
!The water supply temperature must
not exceed 104°F/40°C.
!Never use the pressure washer to
draw in water contaminated with sol-
vents, e.g. paint thinners, gasoline,
oil, etc.
!Always prevent debris from being
drawn into the unit by using a clean
water source.
SAVE THESE INSTRUCTIONS!!
"STEP 1:
Connect the detergent suction tube
to the pressure washer.
WATER SUPPLY
(Cold Water Only)
ASSEMBLY INSTRUCTIONS

6 English
"STEP 1:
Connect the high pressure hose to
the unit’s high pressure outlet.
"STEP 2:
Insert the spray wand of your choice
into the trigger gun. Press in against
the spring tension and twist into
locked position.
"STEP 3:
Connect garden hose to unit’s water
inlet.
"STEP 4:
Connect garden hose to the cold wa-
ter source and turn water on com-
pletely. Plug the power cord into the
power outlet.
"STEP 5:
Unlock the Safety lock. Trigger the
gun to eliminate trapped air, wait for
a steady flow of water to emerge
from the spray nozzle.
"STEP 6:
Turn on the high pressure washer (I).
The motor starts only if the trigger
of the gun is pulled and shuts off
when the trigger is released.
OPERATING INSTRUCTIONS

English 7
"STEP 1: Plug the Ground Fault Cir-
cuit Interrupter (GFCI) into a working
outlet.
"STEP 2: Press ’’TEST’’, then press
’’RESET’’ to assure proper connec-
tion to power.
Note: The actual appearance of the
GFCI may be different from this illu-
stration.
WARNING
To avoid serious injury never point
spray nozzle at yourself, other per-
sons or animals.
!The Vario Power Spray Wand allows
you to adjust the cleaning pressure.
To clean at maximum pressure, the
wand must be positioned to the high
pressure setting (Max).
For lower pressure turn the wand
collar in the minus (Min) direction.
To apply detergent, the wand must
be positioned to the lower pressure
setting (Min).
This brush is ideal for removing stub-
born dirt and stains from finished sur-
faces. Use with detergents possible.
GFCI INSTRUCTIONS
12
USING THE ACCESSORIES
Vario Power Spray Wand
Wash Brush

8 English
Detergents can only be applied at
low pressure (Min.).
"STEP 1:
Install the Vario Power Spray Wand.
Set the spray wand to the low pres-
sure setting (Min.).
"STEP 2:
Fill a container with Kärcher deter-
gent. Place the filter end of detergent
suction tube into the container.
"STEP 3:
Turn on the pressure washer (I). Pull
trigger to operate unit: Liquid deter-
gent is drawn into the unit and mixed
with water. Apply detergent to work
area. Do not allow detergent to dry
on surface.
"STEP 4:
Always draw fresh water through
the detergent suction tube when
done, to rinse/flush any remaining
detergents from the injection sys-
tem.
For best results see Cleaning Tips
for specific information on how to
clean different surfaces.
CAUTION
This unit has been designed for use with
cleaning detergents recommended by
the manufacturer. The use of other
cleaning detergents may affect the op-
eration of the machine and void the war-
ranty.
Always Use Kärcher Detergent for Best
Results
Kärcher biodegradable detergents are
specially formulated to protect the envi-
ronment and your pressure washer. The
special formula won’t clog the suction
tube filter and will protect the internal
parts of the pressure washer for a long-
er life. For Kärcher Detergents, check
your retailer or visit our website:
www.karcher-usa.com/home
The following Kärcher detergents are
available:
One Gallon ready to use
!All Purpose & Vehicle Cleaner
!Deck & Patio Cleaner
!Heavy Duty Degreaser
!Exterior House Cleaner
CAUTION
Never use:
– Bleach, Chlorine products and other
corrosive chemicals
– Liquids containing solvents (i.e.,
paint thinners, gasoline, oils)
– Tri-sodium phosphate products
– Ammonia products
– Acid-based products
These chemicals will harm the unit and
will damage the surface being cleaned.
WORKING WITH DETERGENTS

English 9
"STEP 1:
Release trigger and engage gun
safety lock.
"STEP 2:
Turn pressure washer to OFF (O)
position.
"STEP 1:
Turn the switch to OFF (0) position
and unplug cord from outlet.
"STEP 2:
Turn off the water source.
"STEP 3:
Press trigger to release water pres-
sure.
"STEP 4:
Disconnect the garden hose from
the water inlet on the unit.
"STEP 5:
Disconnect the high pressure hose
from the high pressure outlet.
"STEP 6:
Release trigger and engage gun
safety lock.
TAKING A BREAK ..five minutes or more
SHUTTING DOWN & CLEAN-UP

10 English
"1: Disconnect all water connections.
"2: Turn on the machine for a few
seconds, until the water which had
remained in the pump exits, turn off
immediately.
"3: Do not allow high pressure hose
to become kinked.
"4: Store the machine and accesso-
ries in a room which does not reach
freezing temperatures. DO NOT
store near furnace or other sources
of heat as it may dry out the pump
seals.
CAUTION
Failure to follow the above directions
will result in damage to the pump as-
sembly and accessories.
Kärcher also recommends the regular
practice of using a pump protector like
“Kärcher Pump Guard’’ to help during
storage in the winter months.
Pull out the water inlet filter with flat-
nose pliers and rinse out in warm water.
Note: if you pull out the water inlet filter
the sealing gets out too. Take care to
mount it again after cleaning the filter.
The unit is maintenance-free.
WINTERIZING AND LONG-TERM STORAGE
CARE AND MAINTENANCE INSTRUCTIONS
Cleaning the water inlet filter Maintenance

English 11
(with or without detergent). Pre-rinse
deck and surrounding area with fresh
water. If using Kärcher Deck Wash, ap-
ply to surface at low pressure. For best
results, limit your work area to smaller
sections of approximately 25 square
feet. Allow Deck Wash to remain on sur-
face 1-3 minutes. Do not allow deter-
gent to dry on surface. Rinse at high
pressure in a long sweeping motion
keeping the spray nozzle approximately
3-6 inches from the cleaning surface.
Always clean from top to bottom and
from left to right. When moving on to a
new section of the cleaning surface, be
sure to overlap the previous section to
eliminate stop marks and ensure a more
even cleaning result.
(with or without detergent). Pre-rinse
cleaning surface with fresh water. If us-
ing Kärcher Pressure Wash, apply to
surface at low pressure (for best results,
limit your work area to sections of ap-
proximately 6 feet and always apply de-
tergent from bottom to top). Allow
Pressure Wash to remain on surface 1-
3 minutes. Do not allow detergent to dry
on surface, if surface appears to be dry-
ing, simply wet down surface with fresh
water. If needed, use special wash
brush attachment (not included) to re-
move stubborn dirt. Rinse at high pres-
sure from top to bottom in an even
sweeping motion keeping the spray
nozzle approximately 6 inches from the
cleaning surface.
(with or without detergent). Pre-rinse
cleaning surface with fresh water. If us-
ing Kärcher Pressure Wash or Degreas-
er, apply to surface at low pressure. For
best results, limit your work area to
smaller sections of approximately 25
square feet. Allow Pressure Wash or
Degreaser to remain on surface 1-3
minutes. Do not allow detergent to dry
on surface. Rinse at high pressure in a
sweeping motion keeping the spray
nozzle approximately 3-6 inches from
the cleaning surface. Always clean from
top to bottom and from left to right. For
removing extremely stubborn stains,
use the Dirtblaster Nozzle.
(with or without detergent). Pre-rinse
vehicle with fresh water. If using Kärch-
er Touchless Vehicle Wash, apply to
surface at low pressure. For best re-
sults, clean one side of vehicle at a time
and always apply detergent from bottom
to top, do not allow detergent to dry on
surface. If needed, use special wash
brush attachment (not included) to re-
move stubborn dirt. Rinse at high pres-
sure in a sweeping motion keeping the
spray nozzle approximately 6-8 inches
from the cleaning surface (distance
should increase when rinsing pin-strip-
ing or other sensitive surfaces). Always
clean from top to bottom and from left to
right. For best results, wipe surface dry
with a chamois or soft dry cloth.
CLEANING TIPS
Deck Cleaning
House Siding
Cement Patios, Brick and Stone
Cars, Boats & Motorcycles

12 English
(with or without detergent). Pre-rinse
cleaning surface with fresh water. If us-
ing Kärcher Pressure Wash or Degreas-
er, apply detergent at low pressure.
Allow Pressure Wash to remain on sur-
face 1-3 minutes.Do not allow detergent
to dry on surface. Rinse at high pres-
sure keeping the spray nozzle approxi-
mately 3-6 inches from the cleaning
surface. For removing extremely stub-
born dirt, it may be necessary to move
the spray nozzle even closer to the sur-
face for greater dirt cutting action.
(with or without detergent). Pre-rinse
furniture and surrounding area with
fresh water. If using Pressure Wash, ap-
ply to surface at low pressure. Allow
Pressure Wash to remain on surface 1-
3 minutes. Do not allow detergent to dry
on surface. If needed use special Wash
Brush Attachment (not included) to re-
move stubborn dirt. Rinse at high pres-
sure in a sweeping motion keeping the
spray nozzle approximately 3-6 inches
from the cleaning surface. For best re-
sults, clean from top to bottom and from
left to right.
!Before cleaning any surface an in-
conspicuous area should be cleaned
to test spray pattern and distance for
maximum cleaning results.
!If painted surfaces are peeling or
chipping, use extreme caution as
pressure washer may remove the
loose paint from the surface.
!When using on surfaces which might
come in contact with food, flush sur-
faces with plenty of drinking water.
!For additional cleaning tips, visit our
website at www.karcher-usa.com/
home
Barbecue Grills, Outdoor Power
Equipment & Gardening Tools
Patio & Lawn Furniture
Recommendations

English 13
CAUTION
Disconnect the machine from the power
source before making any repair.
Troubleshooting
Symptom Cause Solution
Motor will not start On/Off switch is in the “OFF”
(O) position.
Turn switch to the “ON” (I) po-
sition
Power cord is not plugged in. Plug in power cord.
Electrical outlet does not sup-
ply adequate power.
Try a different outlet.
Tripped circuit breaker. Switch off pressure washer.
GFCI will reset once the tem-
perature of the unit drops.
Unit does not reach
high pressure.
Diameter of garden hose is
too small.
Replace with a 5/8 inch or lar-
ger garden hose.
Water supply is restricted. Check garden hose for kinks,
leaks and blockage.
Not enough inlet water supp-
ly.
Open water source full force.
Water inlet filter is clogged. Remove filter and rinse out in
warm water.
Spray wand is on low pressu-
re position.
Turn spray wand to high pres-
sure position.
Output pressure va-
ries high and low.
Not enough inlet water supp-
ly.
Turn water on full force.
Check garden hose for kinks,
leaks or blockage.
Pump is sucking air. Check that hoses and fittings
are air tight. Turn off machine
and purge pump by squee-
zing trigger gun until a steady
flow of water emerges throu-
gh the nozzle.
Water inlet filter is clogged. Remove filter and rinse out in
warm water.
Discharge nozzle is obstruc-
ted.
Blow out or remove debris
with a fine needle.
Calcified gun, hose or spray
wand.
Run distilled vinegar through
detergent suction tube.

14 English
If you encounter any additional difficul-
ties not listed, please call
1-800-537-4129 for help or visit our
website: www.karcher-usa.com/home
Call: 1-800-465-4980 for help or visit
our website: www.karcher.ca
Call: 01-800-024-13-13 for help or visit
our website: www.karcher.com.mx
No detergent. Detergent suction tube not
properly connected to the ma-
chine.
Check connection.
Detergent is too thick. Dilute detergent, for best re-
sults use Kärcher detergent.
Filter on detergent suction
tube is clogged.
Run warm water through filter
to remove debris.
Damaged or clogged deter-
gent suction tube.
Remove obstruction or repla-
ce detergent suction tube.
Spray wand is in high pressu-
re position.
Turn spray wand tip to low
pressure position.
Discharge nozzle is obstruc-
ted.
Blow out or remove debris
with fine needle.
Garden hose con-
nection leaks.
Loose fittings. Tighten fittings.
Missing/worn rubber washer. Insert new washer.
Spray wand leaks. Spray wand not properly atta-
ched.
Insert the spray wand into the
trigger gun. Carefully press in
against the spring tension
and twist into the lokked posi-
tion.
Broken o-ring or plastic insert. Call Customer Support
Pump is noisy. Pump is sucking air. Check that hoses and fittings
are air tight. Turn off machine
and purge pump by squee-
zing trigger gun until a steady
flow of water emerges throu-
gh the nozzle.
Water leaks from
pump (up to 10 drops
per minute is permis-
sible).
Loose fittings. Check that all fittings are
tight.
Water seals are damaged or
worn.
Call Customer Support
Oil Drip. Oil seals are damaged or
worn.
Call Customer Support
Symptom Cause Solution
Kärcher Customer Support USA Kärcher Customer Service CDN
Kärcher Customer Support Mexico

Español 15
Vista General del Modelo 16
Instrucciones de Seguridad
Importantes 17
Instrucciones de Montaje 18
Instrucciones de Funcionamiento 19
Utilización de los Accesorios 20
Trabajar con Detergentes 21
Tomarse un Descanso de cinco
minutos o más 22
Apagado y Limpieza 22
Protección contra los Agentes
Invernales y Almacenamiento
Prolongado 23
Consejos de Limpieza 24
Localicación y reparación de averías26
PELIGRO
indica “una situación de peligro inmi-
nente que, si no se evita, puede causar
lesiones graves e incluso la muerte”.
ADVERTENCIA
indica “una situación de peligro poten-
cial que, si no se evita, puede causar le-
siones e incluso la muerte”.
ATENCIÓN
indica “una situación de peligro poten-
cial que, si no se evita, puede causar le-
siones de poca importancia o leves", o
daños materiales.
Llame al: 1-800-537-4129 si necesita
ayuda o visite nuestra página Web:
www.karcher-usa.com/home
Please take a moment to register your
presure washer online at www.kar-
cher-usa.com/warranty
Llame al: 1-800-465-4980 si necesita
ayuda o visite nuestra página Web:
www.karcher.ca
Llame al: 01-800-024-13-13 si necesita
ayuda o visite nuestra página Web:
www.karcher.com.mx
Manual de usario del Limpiador de Alta Presiòn
Símbolos de aviso de seguridad
Especificaciones
Presión de trabajo 1400 PSI
Volumen de agua 1.3 GPM
Amperaje 13 AMPS
Voltaje 120 V
Nº de pieza 1.601-501.0
Nº de serie
Soporte Kärcher EE.UU.
Soporte Kärcher CDN
Soporte Kärcher Mexico

16 Español
1 Cable de potencia con interruptor de
circuito de avería por puesta a tierra
2 Interruptor de encendido/apagado
3 Pestillo de seguridad de la pistola de
disparo
4 Manguera de alta presión
5 Pistola de disparo
6 Cepillo para lavar
7 Pulverizador telescópico variable
8 Toma de agua con conector para
manguera de jardín
9 Tubo de succión de detergente con
filtro
10 Salida de alta presión
11 Conexión de la manguera de aspira-
ción de detergente
Sólo para uso doméstico.
Vista General del Modelo

Español 17
ADVERTENCIA
Al utilizar este producto, tome
siempre las precauciones bá-
sicas, incluidas las siguientes:
!Lea todas las instrucciones antes de
utilizar el producto.
!Para reducir el riesgo de lesiones,
es necesario extremar las precau-
ciones cuando se utilice el aparato
cerca de niños.
!Tiene que saber cómo parar el apa-
rato y purgar la presión rápidamen-
te. Familiarícese con los controles.
! Esté alerta; mire lo que esté haciendo.
!No haga funcionar el producto si
está cansado o si está bajo los efec-
tos del alcohol o las drogas.
!Mantenga la zona en la que esté lim-
piando libre de personas.
!No se alargue demasiado sobre una
base ni se ponga sobre una base
inestable. Mantenga en todo mo-
mento una buena base de apoyo y
un buen equilibrio.
!Siga las instrucciones de manteni-
miento especificadas en el manual.
!Este producto se suministra con un
interruptor de circuito de avería por
puesta a tierra, que está montado
en el enchufe del cable de potencia.
Si es necesario reemplazar el en-
chufe o el cable, utilice sólo piezas
de repuesto idénticas.
!Riesgo de inyección o lesiones a
personas; no dé con el chorro direc-
tamente a personas.
!Los chorros de alta presión pueden
ser peligrosos si se utilizan mal. El
chorro no debe ser enfocado a per-
sonas, animales, aparatos eléctricos
ni al aparato mismo.
!Póngase gafas protectoras.
!No utilice ácidos ni disolventes con
este producto.. Estos productos
pueden causar lesiones físicas al
usuario y daños irreversibles al apa-
rato.
!Para reducir el riesgo de electrocu-
ción, mantenga todas las conexio-
nes secas y alejadas del suelo. No
toque el enchufe con las manos mo-
jadas.
!El pestillo de seguridad de la pistola
de disparo EVITA que la pistola se
dispare accidentalmente. Esta ca-
racterística de seguridad NO blo-
quea el disparo en la posición de
encendido.
!No se debe usar el cable de exten-
sión para esta máquina.
ADVERTENCIA
Para reducir el riesgo de electrocución,
mantenga todas las conexiones secas y
alejadas del suelo. No toque el enchufe
con las manos mojadas.
Los artefactos con doble aislamiento
tienen dos sistemas de aislamiento en
vez de conexión a tierra. Esto significa
que no trae medios de conexión a tierra
y que tampoco se le debe agregar uno.
El mantenimiento de estos artefactos
exige mucho cuidado y conocimiento
del sistema y sólo debe hacerlo perso-
nal calificado de servicio. Las piezas de
repuesto deben ser idénticas a las origi-
nales.Los artefactos con doble aisla-
miento están marcados "DOUBLE
INSULATION" o "DOUBLE INSULA-
TED". También podría tener el símbolo.
Instrucciones de Seguridad Importantes
MANTENIMIENTO A UN
ARTEFACTO QUE TIENE DOBLE
AISLAMIENTO

18 Español
Este producto se suministra con un inte-
rruptor de circuito de avería por puesta
a tierra montado en el enchufe del cable
de potencia. Este aparato proporciona
una protección adicional contra el ries-
go de electrochoque. Si la corriente se
interrumpe en la línea, el interruptor de
circuito de avería por puesta a tierra vol-
verá a cerrar, automáticamente, el cir-
cuito a la carga una vez restablecida la
corriente. En función del modelo de in-
terruptor, puede que sea necesario te-
ner que poner en funcionamiento el
aparato manualmente mediante el bo-
tón de reinicio para restaurar la corrien-
te del circuito de carga del interruptor de
circuito de avería por puesta a tierra. Si
es necesario reemplazar el enchufe o el
cable, utilice piezas idénticas.
ATENCIÓN
Al conectar la toma de agua a la red de
suministro del agua, es obligatorio res-
petar la normativa local establecida por
la compañía del agua. En algunas zo-
nas, está prohibido conectar la unidad
directamente a la red pública de sumi-
nistro de agua potable. Esto es así para
garantizar que no penetren sustancias
químicas en la red de suministro del
agua. Sí se permite efectuar la co-
nexión directamente por ejemplo a tra-
vés de un depósito receptor o un
dispositivo antirretorno.
Si el agua de alimentación está sucia, la
unidad sufrirá daños. Para evitar este
riesgo, le recomendamos que monte un
filtro de agua.
!La manguera de agua tiene que te-
ner al menos 5/8 pulgadas de diá-
metro.
!El caudal de agua no debe ser infe-
rior a 2 GPM (galones por minuto).
!El caudal de agua se puede determi-
nar llenando de agua un recipiente
vacío de 5 galones durante un minu-
to.
!La temperatura de la toma de agua
no de be sobrepasar los 104°F/
40°C.
!No utilice nunca el limpiador a pre-
sión para aspirar agua contaminada
con disolventes como, p. ej., dilu-
yentes de pintura, gasolina, aceite,
etc.
!Evite siempre que la unidad aspire
residuos utilizando una fuente de
abastecimiento cuya agua esté lim-
pia.
GUARDE ESTAS INSTRUCCIONES.
"PASO 1:
Conecte el tubo de succión de deter-
gente a la lavadora de presión.
Protección mediante interruptor de
circuito de avería por puesta a tierra
Suministro de agua
(sólo agua fría)
Instrucciones de Montaje

Español 19
"PASO 1:
Conecte la manguera de alta pre-
sión a la salida de alta presión de la
unidad.
"PASO 2:
Inserte el pulverizador telescópico
de su elección en la pistola de dispa-
ro. Empújelo en sentido contrario al
de la tensión que ejerce el muelle y
gírelo hasta que quede en la posi-
ción de bloqueo.
"PASO 3:
Conecte la manguera de jardín a la
toma de agua de la unidad.
"PASO 4:
Conecte la manguera de jardín a la
toma de agua fría y abra el agua del
todo. Enchufe el cable de potencia al
tomacorriente eléctrico.
"PASO 5:
Desbloquee el pestillo de seguridad.
Dispare la pistola para eliminar el
aire aprisionado y espere hasta que
salga un caudal de agua constante
de la boquilla pulverizadora.
"PASO 6:
Encienda el limpiador de alta pre-
sión (I).
El motor sólo arranca si se presio-
na el gatillo de la pistola, y se des-
conecta cuando se libera el
gatillo.
Instrucciones de Funcionamiento

20 Español
"PASO 1: Enchufe el interruptor de
circuito de avería por puesta a tierra
a un tomacorriente de servicio.
"PASO 2: Presione ’’TEST’’ (PRUE-
BA) y, después, presione ’’RESET"
(REINICIO) para asegurarse de que
la conexión a la toma de energía
eléctrica es correcta.
Nota: El aspecto actual del interrupt-
or de circuito de avería por puesta a
tierra puede ser distinto al de la il-
ustración.
ADVERTENCIA
Para evitar heridas graves, nunca di-
rija la boquilla pulverizadora hacia
usted mismo, hacia otras personas o
hacia animales.
Este cepillo es ideal para eliminar polvo
y manchas persistentes de las super-
ficies con acabado. Utilicelo con deter-
gentes.
!El pulverizador telescópico variable
accionado mecánicamente le permi-
te ajustar la presión de limpieza.
Para limpiar a la presión máxima, el
pulverizador se tiene que posicionar
en el ajuste de alta presión (máx.).
Para una presión menor, gire la ani-
lla del pulverizador en dirección al
mínimo (mín.).
Para poner detergente, el pulveriza-
dor se tiene que posicionar en el
ajuste de presión más baja (mín.).
Instrucciones del Interruptor de
Circuito de Avería por Puesta a Tierra
12
Utilización de los Accesorios
Cepillo de lavar
Pulverizador telescópico variable
accionado mecánicamente
