Karlik MCUSBBO-7 User manual

USER MANUAL - MCUSBBO-7
DOUBLE USB CHARGER
Specification of MCUSBBO-7 double USB charger
The MCUSBBO-7 charger is intended to charge devices like smartphones, tablets and other electronic
equipment. Before connecting the device, check compliance of the charger with charging
parameters of the given device.
1 I 3
Specification
Number of USB ports (type C)
2
Nominal input voltage
100-240 V~ 50/60Hz
Nominal output current
ź5V/3A, 9V/2.22A, 12V/1.67A (when device is
connected to only one USB output)
ź5V/3.1A (in the case of connecting devices to
two outputs, the output current is divided
equally between each USB socket)
Maximum output power
20 W
Maximum power consumption in idle mode
0.1 W
Operating temperature and humidity
-10 ÷ +40 C; 20~90% RH
0
Storage temperature and humidity
-20 ÷ +85 C; 10~95% RH
0
Ingress protection degree
IP 20
54,00
54,00
45,50

2 I 3
Detection function of available charger protocols:
- when using only one USB-C output
APPLE
5V 2.4A
BC 1.2
DCP 5V 1.5A
SAMSUNG AFC
9V
HUAWEI FCP
5V, 9V, 12V
SCP
-
QC 2.0
5V, 9V, 12V
QC 3.0
11.70V max
- when using both 2 x USB-C outputs
APPLE
-
BC 1.2
DCP 5V 1.5A
SAMSUNG AFC
9V
HUAWEI FCP
-
SCP
-
QC 2.0
5V, 9V, 12V
QC 3.0
-
Warranty conditions
Warranty is granted for a period of 12 months of the date of purchase. The defective MCUSBBO-7
charger along with the proof of purchase should be sent to the manufacturer or to the seller. Warranty
does not include mechanical damages, defects resulting from unauthorised repairs and improper use
of the product.
Warranty period will be extended for the duration of the repair.

ASSEMBLY INSTRUCTIONS
3 I 3
NOTE!
The connection to the installation should be done as shown in Figure 2. With improper connection, the
charger may be damaged or may work incorrectly.
The installation must be done by a person with sufficient qualifications, with power supply
disconnected, and must comply with national safety standards.
2. Unscrew the screw (3) and pull out the adapter (4) together with the USB charger module (5). If
necessary, you can detach the USB charger module from the adapter by pressing the movable catch
on the module.
3. Disassemble the intermediate frame (6) from the mounting block (8). To disassemble, bend the cube
latches or pull the intermediate frame harder.
1. Remove the adapter (2) of the charger by levering it with a knife or a flat screwdriver in the place of
the recess (1) on the adapter.
4. Install the mounting block (8) in the box (9) using claws or screws at the box (10).
5. Attach the intermediate frame (6) to the outer frame (7) and snap the whole thing onto the latches
(8) protruding from the cube.
6. Connect the power cable to the terminal strip of the USB charger module (see Figure 2) respectively,
the phase wire under the "L" terminal, the neutral wire under "N".
7. Insert the adapter (4) with the USB charger module (5) into the intermediate frame (6) and screw it to
the mounting block (8) using the screw (3).
8. Insert the adapter (2).
Fig. 2
8
Fig. 1
1
2
3
4
5
6
910
7
