Kasco CertiSafe User manual

CertiSafe™Suspended Mount
Assembly & Installation Manual
800 Deere Rd. Prescott, WI 54021 • 715-262-4488 • [email protected] • www.kascomarine.com
Document number 852112

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
2
Contents
Safety First .......................................................................................................3
Product and Installation Overview....................................................................4
Suggested Tools and Supplies .........................................................................4
Parts Included...................................................................................................5
Tank Penetration for Cable Support and Cord Grip..........................................7
Stretcher Assembly...........................................................................................9
Suspension Chains and Power Cable............................................................10
Cable Support................................................................................................. 11
CertiSafe™ Tank Mixer Maintenance Recommendations..............................12
CertiSafe™ Tank Mixer Warranty ...................................................................13
Non-Warranty Repairs....................................................................................14
Repair Contact Form ......................................................................................15
Phone: [phone]
Fax: [phone]
www.kascomarine.com
[email protected]
Questions?

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
3
IMPORTANT: PLEASE READ THIS MANUAL AND SAVE FOR FUTURE REFERENCE
SAFETY FIRST
• Under NO circumstances should anyone enter the water with the mixer connected or in operation.
• Running the unit out of water will create a dangerous situation and damage the seals.
• NEVER lift the unit by the power cord. If you need to remove the mixer, use the installation or mount apparatus.
• The unit must be connected to a GFCI-protected circuit.
• Comply with local and national wiring standards during any electrical service disconnect.
• Consult a qualied professional for electrical installation.
• Use all Personal Protective Equipment necessary for safe ingress, installation, and egress from the work site.
• Refer to applicable national and local laws and standards to facilitate the safe installation of a CertiSafe Tank Mixer. These may
include but are not limited to OSHA, CCOHS, and other regulations related to:
• Working over or near water
• Fall protection systems
• Falling object protection systems
• Electrical standards
• Illumination
• Ventilation
• Installation of CertiSafe™ Tank Mixers requires entry into environments that pose potential hazards, such as those described in
section 1910.146 of OSHA’s Occupational Safety and Health Standards for Permit-required conned spaces. As such:
• Observe any applicable pre-entry measures required by the entry supervisor.
• Only those authorized via the permit system in place at the installation site should participate in installation.
• Any authorized entrant should be accompanied by at least one authorized attendant to monitor conditions inside and outside
the permit spaces during installation.
• Prior to installation, be aware of all potential fall, trip, and atmospheric hazards in the permit space, both before and after an
entrance cover is removed.
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
4
PRODUCT AND INSTALLATION OVERVIEW
Featuring durable stainless steel, Kasco’s SM-100 Suspended Mount positions CertiSafe™ Tank Mixers securely within the tank for
effective water movement. This manual will provide instructions for mounting a CertiSafe™ unit using the SM-100 and installing the
entire assembly within the tank.
• Read these instructions thoroughly prior to installation.
• Contact your CertiSafe™ representative for specic recommendations as necessary.
• The cord grip and cable support equipment described here are supplied with the mixer unit.
• To prevent galling, we recommend a moisture-cured, polyurethane compound sealant suitable for contact with potable water and
certied to meet the shrinkage for interior and exterior use. Refer to NSF/ANSI Standard 61 for indirect additives.
• Be aware of clearance between the mixer assembly and any xed objects within the tank, including ladders, ensuring that there is
enough room for the CertiSafe™ unit to function correctly and avoid damage to any protective coatings.
• Please consult your CertiSafe™ sales representative for mixer mount placement, retrieval, and inspection requirements.
Note: some parts will arrive pre-assembled from Kasco; however, all assembly steps are listed for reference.
SUGGESTED TOOLS AND SUPPLIES
Pan to catch shavings
Adjustable pliers
Electric or cordless drill
Half-round metal le
3/8” drill bit 7/8” hole saw
or 1-7/64” (for 10 AWG cord)
hole saw
Side cutter
10mm wrench
7/16” wrench
1/2” wrench
1/2” socket wrench
1/8” Allen wrench
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
5
PARTS INCLUDED
Assembly Item Description Quantity Part number
Mount AStretcher bar - 60 in. 1 997310
BJaw slide 4 997206
C1/4”-20 x 1/2” shoulder screw 4 451112
D1/4”-20 x 3/4” shoulder screw 2 451110
E1/4”-20 nylon locknut 6 566212
F1/4” at washer 4566208
GLong chain - 50 ft. 2 636382
HShort chain 2 636383
IZip ties 12 415038
Tank Penetration J5/16” eye bolt 2 566226
K5/16” nylon locknut 2 566202
L5/16” at washer 4 566204
M5/16” sealing washer 2 566229
NConnecting link 2 636342
for use with Cord AWG
Ships with
CertiSafe™ mixer
OCord grip
14-16 AWG
1
997210
12 AWG 997211
10 AWG* 997212
PCord grip nut 12-16 AWG 1997215
10 AWG 997216
QCable support 10 AWG 1997220
12-16 AWG 997221
*Requires larger hole in tank roof (Ø 1-7/64”)
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
6
Stretcher bar - 60 in. (A)
Jaw slide (B)
Long chain - 50 ft. (G)
Short chain (H)
Zip ties (I)
5/16” eye bolt (J)
5/16” nylon locknut (K)
5/16” sealing washer (M)
Connecting link (N)
Cord grip (O)
Cord grip nut (P)
Cable support (Q)
1/4”-20 x 1/2” shoulder screw (C)
1/4”-20 nylon locknut (E)
CertiSafe™ jaw slide (B)
Steel tank roof
5/16” at washer (L)
5/16” at washer (L)
Fig. 1
1/4”-20 x 1/2” shoulder screw (C)
1/4”-20 x 3/4” shoulder screw (D)
1/4” at washers (F)
1/4”-20 nylon locknuts (E)
Steel tank roof
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
7
TANK PENETRATION FOR CABLE SUPPORT AND CORD GRIP
Note:
• The maximum tank roof thickness accommodated by the tank penetration parts included is 1/8”.
• Suggested measurements are based on a 24” square access hatch.
1. Drill two 3/8” clearance holes through the tank, 58” apart, each 29” from the tank hatch center point. These are for the eye bolts (J).
2. Deburr both sides of each hole.
3. Drill a 7/8” clearance hole approximately 4” from one of the holes drilled in step 1. This is for the cord grip (O).
4. Deburr both sides of the third hole.
5. From the tank exterior, pass the O-ringed side of the cord grip
(O) through the 7/8” hole, with the O-ring outside the tank roof.
6. From the tank interior, t the cord grip nut (P) on the threads
protruding into the tank.
7. Tighten the nut until snug, being careful not to over-tighten.
Steel tank roof
Steel tank roof
O
P
Fig. 3
Fig. 4
Ø 7/8”
Ø 3/8”
4”
29”29”
Ø 3/8”
Tank hatch center point
Fig. 2
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
8
8. Fit a at washer (L) and then the sealing washer (M) onto
the eye bolt (J).
9. From the tank interior, insert the eye bolt (J) with washers
(L, M) through the 3/8” hole.
10. From the tank exterior, t a second at washer (L) onto the eye
bolt.
11. Fasten the 5/16” nylon locknut (K) to the eye bolt.
12. Tighten the locknut until snug, being careful not to damage the
sealing washer.
13. Attach the top connecting link (N) to the eye bolt.
L
M
L
K
N
Steel tank roof
Steel tank roof
J
L, M
Fig. 5
Fig. 6
Fig. 7
Repeat steps 8 through
13 for the second eye bolt
pass-through.
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
9
STRETCHER ASSEMBLY
1. Insert the end link of a short chain (H) between the mixer cage loops on one side of the cage.
2. Secure the chain (H) with a 1/4”-20 x 3/4” shoulder screw (D), two 1/4” washers (F), and 1/4”-20 locknut (E).
3. Repeat steps 1 and 2 for the other cage loop and short chain (H).
4. Tighten all locknuts until snug, without over-tightening.
5. Insert one short chain loop (H) into an inner jaw slide (B) afxed to the
stretcher bar (A).
6. Secure with 1/4”-20 x 1/2” shoulder screw (C) and locknut (E).
7. Repeat steps 5 and 6 for the second inner jaw slide (B),
fastening the chain (H) with another shoulder screw (C)
and locknut (E).
8. Tighten all locknuts until snug, without over-tightening.
H
D
F
F
E
H
B
A
B
H
C
E
C
E
Fig. 8
Fig. 9
Fig. 10
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
10
SUSPENSION CHAINS AND POWER CABLE
1. Insert one end link of a long chain (G) into an outer jaw slide (B)
placed at the end of the stretcher bar.
2. Secure with a 1/4”-20 X 1/2” shoulder screw (C) and 1/4”-20
locknut (E).
3. Repeat steps 1 and 2 to secure the remaining long chain (G) at
the opposite end of the stretcher bar (A).
4. Tighten stretcher bar fasteners, taking care not to over-tighten.
5. Use zip ties (I) to secure the power cord to the stretcher bar (A) in two places and to guide the cord around the corner where the
bar meets the long chain, making sure not to put tension on the power cable.
6. Continue to apply the zip ties (I) every 4 feet along the long chain (G) and power cable length.
7. Attach the long chain (G) with the power cord to the connecting link (N) closest to the cord grip (O).
8. Attach the long chain (G) without the cord to the connecting link (N) farthest from cord grip (O).
9. Coil any excess chain and tie with wire.
G
C
E
B
Fig. 11
IA
G
Fig. 12
O
Fig. 14
N
G
Steel tank roof
G
N
Fig. 15
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
11
CABLE SUPPORT
1. Attach the cable support (Q) to the connecting link (N).
2. Close and tighten the connecting link.
3. Feed power cable through the cable support (Q).
Fig. 17
4. Continue to feed power cable through the cord grip (O) and out of the tank
until all excess cord length has been taken up, leaving only enough so that
there is no strain on the cable.
5. Tighten the top nut on the cord grip (O) to seal the power cable penetration.
6. Terminate the power cable into an exterior junction box (not supplied by
Kasco).
Fig. 16
Q
N
Fig. 18
O
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
12
CERTISAFE™ TANK MIXER MAINTENANCE RECOMMENDATIONSCERTISAFE™ TANK MIXER MAINTENANCE RECOMMENDATIONS
Electrical Troubleshooting
• If a unit fails to operate, you can use a series of simple checks to determine the general cause.
• Once you’ve located the fault, please contact your distributor for information on how to proceed with repair.
Is the GFCI Tripped?
1. If yes, reset the GFCI and check operation.
2. If the GFCI continues to trip, disconnect the unit in the panel and reset the GFCI.
• If the GFCI doesn’t trip, the fault lies in the unit or its cord.
• If the GFCI continues to trip, the fault lies in the control panel power source.
Is the cord damaged?
1. With the power off, perform a visual inspection of the power cord.
• If there is visible damage, contact your distributor for repair options.
What happens with an alternate
power source?
1. If the power cord and unit appear to be in good condition, safely plug it into an
alternate GFCI-protected power source.
• If the unit starts and continues to run, fault lies in the control panel or power
source.
• If the alternate GFCI continues to trip, fault lies in the unit or cord.
GFCI
• GFCI (Ground Fault Circuit Interrupter) is a safety feature
that can alert you to problems with the mixer. It is important
to test the GFCI upon installation, after each re-installation,
and regularly thereafter to ensure consistent operation. If
you experience repeat interruptions, disconnect and remove
the equipment. Inspect the power cord and unit (mixer) for
damage. If no damage is apparent, please contact your
Kasco distributor or representative for further instruction.
Observation
• Monitor the operating mixer for any reduction or variation in
performance.
• Inspect the mixer annually and clean as needed to allow for
heat dissipation and to verify that the propeller is clean and
free of nicks.
• Inspect the power cable annually for damage or abrasion
and replace as necessary.
• Regularly clean all external rotating parts and examine them
for wear.
• If you note a deciency in performance, remove the equip-
ment from service and inspect for any damage or failure. If
you observe any canister leakage during annual inspection,
send the mixer to Kasco’s factory for service and repair.
Cleaning
• The stainless-steel motor housing needs to be kept clean in
order to allow heat to effectively dissipate.
Seal and Oil Replacement
• Replacing the seal and changing the oil every 3-5 years will
add reliability and longevity to the mixer.
• Seal replacement and all other repair services should be
performed by Kasco Marine.
IMPORTANT: Disconnect electrical power prior to any maintenance or servicing!
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
13
CERTISAFE™ TANK MIXER WARRANTY
Kasco offers a standard 3-year warranty with the following
models:
• 2400C61
• 3400C61 / 3400HC61
• 4400C61 / 4400HC61
• 8400C61
At the time of purchase, a 5-year warranty is available for pack-
ages including Advanced model control panels.
Warranty must be purchased at the same time as the mixer
package. (Mixer package consists of the mixer, mount, and
control panel.)
Control panel MUST have GFCI protection.
Kasco® Marine, Inc. warrants this CertiSafe™ mixing system to
be free from defects in material or workmanship under appro-
priate use and service. The Kasco Marine, Inc. obligation under
this warranty is limited to replacing or repairing, without charge,
proven defective part while within the warranty period. Customer
shall pay shipping charges for returning the unit to Kasco.
Note: Kasco only accepts complete assemblies for warranty repair. We must receive the power cord and all other components
with the motor as originally assembled. Kasco will bill the customer to replace any missing parts necessary for repair. It is not
necessary to return the control panel, mount, or other parts with the motor assembly, unless specically requested by a Kasco
representative.
Please attach a repair form with the shipment. The repair form must include a name, physical address (for return delivery of the
repaired unit), daytime phone number, and an e-mail address for correspondence regarding the warranty claim.
Any expedited shipping method for the return of the unit is at the customer’s expense. Kasco Marine will return units repaired
under warranty at our expense via ground freight within the continental United States.
Shipping Address:
Kasco Marine, Inc.
800 Deere Rd.
Prescott, WI 54021
Attn: Repairs
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES,
EXPRESSED OR IMPLIED. IN NO EVENT WILL KASCO
MARINE, INC. BE LIABLE FOR ANY CONSEQUENTIAL
DAMAGES.
Warranty is void if:
• The mixer is not maintained according to the recommenda-
tions supplied in this manual.
• The mixer is returned for repair without the power cord.
• The unit, control box, or power cord are altered in any way
from original shipment.
• The power cord is nicked or cut.
• The mixer is damaged by unauthorized service.
Warranty Claim Procedure
Warranty period is established by the original receipt. For efcient service, please register the unit online at:
www.kascomarine.com/warranty-registration.
Once warranty coverage has been established, you may send the unit to Kasco for evaluation and repair.
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
14
NON-WARRANTY REPAIRS
You can often repair failed equipment at a lower cost than re-
placement. Kasco Marine estimates repairs at the request of the
customer. This request should include a daytime phone number
and e-mail address.
Estimate options are as follows:
• Kasco contacts the customer with a repair total after we
evaluate the unit, but before we perform the work quoted.
• Customer pre-approves repair of the unit if costs are below
a stated dollar amount. Example: “Please repair if total is
under $150.00 before shipping charges.”
Kasco will recycle any unit we receive for estimate but which
the customer declines to repair, unless the customer species
otherwise. If the customer would like the product returned, Kasco
will return the unit to the condition in which we received it, and
we will ship it at the customer’s expense.
Billing
Contact Kasco to arrange payment for any non-warranty repairs.
We will request payment information upon customer approval of
the estimate.
Kasco Marine
800 Deere Road
Prescott, WI 54021
Contact Us
Phone: [phone]
Fax: [phone]
www.kascomarine.com
[email protected]
Back to Contents

SM-100 CERTISAFE™ SUSPENDED MOUNT MANUAL
852112 / 2021.1.1
15
REPAIR CONTACT FORM
• Kasco requires that all equipment sent for repair MUST be accompanied by this form and marked to Repairs attention.
• Kasco is NOT responsible for shipping damage accrued in return shipment.
• It is the responsibility of the customer to ship and pay freight to Kasco.
• Do not ship the mount or control panel with unit, unless otherwise instructed.
• A fee of $60 per hour will be assessed for cleaning excessively dirty units.
• Refer to the CertiSafe™ Tank Mixer Operation & Maintenance Manual for easy-to-follow troubleshooting tips to rule out site issues.
Note: Contact Information should be that of the person or company to contact for repair information.
Company name
Contact name
First name Last name
Address
Street
City
State
ZIP code
Phone number
Primary Alternate
Email address
Preferred method of contact
(circle) Phone Email
Purchase order number
Additional notes
for repair technician:
Kasco Marine
800 Deere Road
Prescott, WI 54021
Back to Contents
