CORDLESS 1/2” DRIVE IMPACT WRENCH INSTRUCTION MANUAL
CORDLESS 1/2” Drive IMPACT
WRENCH INSTRUCTION MANUAL
220020
LITHIUM ION
18V
WARRANTY*
5 YEAR
MAX TORQUE
400Nm

CORDLESS 1/2” DRIVE IMPACT WRENCH INSTRUCTION MANUAL
1
GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings and all
instructions.Failure to follow the warnings and
instructions may result in electric shock, fire
and/or serious injury. Save all warnings and
instructions for future reference. The term “power tool” in
the warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators,ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
220020

CORDLESS 1/2” DRIVE IMPACT WRENCH INSTRUCTION MANUAL
2
TOOL ASSEMBLY
INSTALLING THE BELT CLIP
Place provided belt clip (4) in the desired position
on the base of the impact wrench. Using a Phillips
head #2 screwdriver, place screw through clip into
screw hole & hand tighten until you feel resistance
& clip is adequately tight.
The rating plate on your tool may show symbols. These represent important information about the product or
instructions on its use.
c) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
6) Service
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is main-
tained.
Additional Safety Instructions impact wrench
1) Wear ear protectors when impact drilling. Exposure
to noise can cause hearing loss.
2) Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury
3) Hold power tool by insulated griping surfaces, when
performing an operation the cutting accessory
may contact hidden wiring or its own cord. Cutting
accessory contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
SYMBOLS
Direct current, DC Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check
with your Local Authority or retailer for
recycling advice.
Refer to instruction manual/booklet
Wear ear protection General warning
Wear eye protection
220020

CORDLESS 1/2” DRIVE IMPACT WRENCH INSTRUCTION MANUAL
CHARGE-ALL
18V
3
Voltage 18V d.c.
Drive size 1/2” Square
Impact rate 0-2700 ipm
Nut-busting torque 300 ft-lb/400Nm
Tightening torque 260 ft-lb/350Nm
No load speed 0-2200 rpm
SPECIFICATIONS
KNOW YOUR PRODUCT
1 - 1/2” SQUARE
DRIVE
5 - TRIGGER
2 - RUBBER NOSE CONE
3 - FORWARD/REVERSE BUTTON
4 - BELT CLIP
(ANY 18V CHARGE-ALL BATTERY WILL FIT)
BATTERY
INSERTS HERE
HOW TO INSERT BATTERY ON TOOL
1. ALIGN BATTERY RIBS WITH TOOL 2. SLIDE INTO TOOL 3. STOP WHEN YOU HEAR IT CLICK IN PLACE
CHARGE-ALL
4 • 6 • 8 • 10 • 12 • 14
18V
18V CHARGE-ALL
18V CHARGE-ALL
LI-ION
Ah
18V CHARGE-ALL
18V CHARGE-ALL
LI-ION
Ah
CHARGE-ALL
4 • 6 • 8 • 10 • 12 • 14
18V
18V CHARGE-ALL
18V CHARGE-ALL
LI-ION
Ah
CHARGE-ALL
4 • 6 • 8 • 10 • 12 • 14
18V
1 2 3
*CLICK*
Minimum recommended 4Ah battery
220020

CORDLESS 1/2” DRIVE IMPACT WRENCH INSTRUCTION MANUAL
CHARGE-ALL
18V
4
HOW TO INSERT AN ACCESSORY
HOW TO REMOVE AN ACCESSORY
CHARGE-ALL
18V
1
1
TO INSERT AN ACCESSORY
TO REMOVE AN ACCESSORY
Firmly push any 1/2” drive impact rated socket or accessory onto the 1/2” square drive (1), ensuring it is
seated correctly.
To remove a socket or accessory, pull it directly away from the impact wrench off the 1/2” square drive.
220020

CORDLESS 1/2” DRIVE IMPACT WRENCH INSTRUCTION MANUAL
CHARGE-ALL
18V
5
HOW TO USE THE IMPACT WRENCH
CHARGE-ALL
18V
1. ENSURE SAFETY 2. MAKE SURE YOU HAVE THE RIGHT
SOCKET/ACCESSORY
Always wear safety glasses when working with the
impact wrench. Make sure to secure your hair and
any baggy clothes. In appropriate situations make
sure you wear ear muffs, a mask or a respiratory
mask.
Ensure you have the correct size socket or
accessory for the job and that it is impact rated.
3. SECURE WORKPIECE
Ensure the forward/reverse button (3) is in the
correct position and the socket or accessory has
been attached securely to the drive anvil.
Hold the impact wrench securely against the bolt or fastener and
slowly begin to press the trigger (5) whilst applying firm pressure
directly down on the impact wrench to stop the bolt or fastener
from slipping. Slowly increase pressure on the trigger until the
screw or bolt is tightened to desired torque.
Make sure your workpiece is securely fastened.
4. ENSURE WRENCH IS SET UP CORRECTLY
5. USING THE IMPACT WRENCH
CHARGE-ALL
18V
1
3
2
4
5
220020

CORDLESS 1/2” DRIVE IMPACT WRENCH INSTRUCTION MANUAL
6
MAINTENANCE
This power tool normally requires no maintenance; from time to time the ventilation slots on the motor
casing should be cleaned out. If the unit should become defective, repair should be performed by an
authorized service agent for electric tools.
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various
types of commercial solvents and may be damaged by their use. Use clean cloths to remove dirt, dust,
oil, grease, etc.
Warning!
Do not at any time let brake fluids, gasoline, petroleum based products, penetrating oils, etc., come in contact with
plastic parts. Chemicals can damage, weaken or destroy plastic which may result in serious personal injury.
220020

Australia & Global
www.katanapowertools.com.au
[email protected]
[phone]
Made to Katana
specifications and
quality standards
in China.
NOT INTENDED
FOR TRADE USE
* Standard 3 year warranty with an additional 2 year warranty available subject to online
registration via katanapowertools.com.au. Warranty on this Katana product is given by Kincrome
Australia Pty Ltd of 3 Lakeview Drive, Caribbean Park, Scoresby, Victoria, Australia (Tel +61 3
9730 7100) If this product has materials or workmanship defects (other than defects caused by
abnormal or non warranted use) you can, at your cost, send the product to place of purchase,
an authorised Kincrome service agent or one of Kincromes addresses for repair or replacement.
Your rights under this warranty are in addition to any other rights you have under the Australian Consumer Law or other
applicable laws. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure. For further details please visit www.kincrome.com.au or call us. Due to
minor changes in design or manufacture, the product you purchase may sometimes differ from the one shown on the
packaging.
WARRANTY*
5 YEAR
