Katana 220080 User manual

CORDLESS CIRCULAR SAW INSTRUCTION MANUAL
CORDLESS CIRCULAR SAW
INSTRUCTION MANUAL
220080
LITHIUM ION
18V
BLADES
165mm
WARRANTY*
5 YEAR

CORDLESS CIRCULAR SAW INSTRUCTION MANUAL
1
GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings and all
instructions.Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury. Save all warnings and instructions
for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such
as in the presence of flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators,ranges and refrigerators. There
is an increased risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
d) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric
shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired or under the influence of drugs,
alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source and/
or battery pack, picking up or carrying the tool. Carrying
power tools with your finger on the switch or energising power
tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating
part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding
of moving parts, breakage of parts and any other
condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
g) Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed. Use
of the power tool for operations different from those intended
could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with another
battery pack.
b) Use power tools only with specifically designated battery
packs. Use of any other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws
or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
6) Service
a) Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that
the safety of the power tool is maintained.
Additional Safety Instruction Circular Saw
a) Keep hands away from cutting area and the blade. Keep
your second hand on auxiliary handle, or motor housing.
If both hands are holding the saw, they cannot be cut by the
blade.
b) Do not reach underneath the workpiece. The guard cannot
protect you from the blade below the workpiece.
c) Adjust the cutting depth to the thickness of the workpiece.
Less than a full tooth of the blade teeth should be visible below
the workpiece.
d) Never hold piece being cut in your hands or across your
leg. Secure the workpiece to a stable platform. It is important
to support the work properly to minimize body exposure, blade
binding, or loss of control.
e) Hold power tool by insulated gripping surfaces when
performing an operation where the cutting tool may
contact hidden wiring. Contact with a “live” wire will also
make exposed metal parts of the power tool “live” and shock
the operator.
f) When ripping always use a rip fence or straight edge guide.
This improves the accuracy of cut and reduces the chance of
blade binding.
g) Always use blades with correct size and shape (diamond
versus round) of arbour holes. Blades that do not match the
mounting hardware of the saw will run eccentrically, causing
loss of control.
220080

CORDLESS CIRCULAR SAW INSTRUCTION MANUAL
2
The rating plate on your tool may show symbols. These represent important information about the product or
instructions on its use.
h) Never use damaged or incorrect blade washers or bolt. The
blade washers and bolt were specially designed for your saw,
for optimum performance and safety of operation.
Further safety instructions for all saws
Causes and operator prevention of kickback:
• Kickback is a sudden reaction to a pinched, bound or
misaligned saw blade, causing an uncontrolled saw to lift up
and out of the workpiece toward the operator;
• When the blade is pinched or bound tightly by the kerf closing
down, the blade stalls and the motor reaction drives the unit
rapidly back toward the operator;
• If the blade becomes twisted or misaligned in the cut, the teeth
at the back edge of the blade can dig into the top surface of the
wood causing the blade to climb out of the kerf and jump back
toward the operator.
• Kickback is the result of saw misuse and/or incorrect operating
procedures or conditions and can be avoided by taking proper
precautions as given below.
a) Maintain a rm grip with both hands on the saw and
position your arms to resist kickback forces. Position
your body to either side of the blade, but not in line with
the blade. Kickback could cause the saw to jump backwards,
but kickback forces can be controlled by the operator, if proper
precautions are taken.
b) When blade is binding, or when interrupting a cut for any
reason, release the trigger and hold the saw motionless
in the material until the blade comes to a complete stop.
Never attempt to remove the saw from the work or pull the saw
backward while the blade is in motion or kickback may occur.
Investigate and take corrective actions to eliminate the cause
of blade binding.
c) When restarting a saw in the workpiece, centre the saw
blade in the kerf and check that saw teeth are not engaged
into the material. If saw blade is binding, it may walk up or
kickback from the workpiece as the saw is restarted.
d) Support large panels to minimise the risk of blade
pinching and kickback. Large panels tend to sag under their
own weight. Supports must be placed under the panel on both
sides, near the line of cut and near the edge of the panel.
e) Do not use dull or damaged blades. Blunt or improperly set
blades produce narrow kerf causing excessive friction, blade
SYMBOLS
Direct current, DC Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check
with your Local Authority or retailer for
recycling advice.
Refer to instruction manual/booklet
Wear ear protection General warning
Wear eye protection Regulator compliance mark
Wear respiratory protection
220080
binding and kickback.
f) Blade depth and bevel adjusting locking levers must be
tight and secure before making cut. If blade adjustment
shifts while cutting, it may cause binding and kickback.
g) Use extra caution when making a “plunge cut” into
existing walls or other blind areas. The protruding blade
may cut objects that can cause kickback.
h) Check lower guard for proper closing before each use. Do
not operate the saw if lower guard does not move freely
and close instantly. Never clamp or tie the lower guard into
the open position. If saw is accidentally dropped, lower guard
may be bent. Raise the lower guard with the retracting handle
and make sure it moves freely and does not touch the blade or
any other part, in all angles and depths of cut.
i) Check the operation of the lower guard spring. If the guard
and the spring are not operating properly, they must be
serviced before use. The lower guard may become sluggish
due to, gummy deposits, or a build-up of debris.
j) Lower guard may be retracted manually only for special
cuts such as “plunge cuts” and “compound cuts.” Raise
lower guard by retracting handle and as soon as blade
enters the material, the lower guard must be released. For
all other sawing, the lower guard should operate automatically.
k) Always observe that the lower guard is covering the
blade before placing saw down on bench or oor. An
unprotected, coasting blade will cause the saw to walk
backwards, cutting whatever is in its path. Be aware of the
time it takes for the blade to stop after switch is released.
l) This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
m) Never hold piece being cut in your hands or across your
leg. Secure the workpiece to a stable platform. It is important
to support the work properly to minimize body exposure, blade
binding, or loss of control.
n) Do not use the tool with abrasive or masonry/wet diamond
wheels.
o) Only use blade diameter(s) in accordance with the
markings on
the tool.

CORDLESS CIRCULAR SAW INSTRUCTION MANUAL
LI-ION
Ah
18V CHARGE-ALL
18V CHARGE-ALL
18V CHARGE-ALL
LI-ION
Ah
18V CHARGE-ALL
18V CHARGE-ALL
18V CHARGE-ALL
3
Voltage 18V d.c.
Blade Size 165mm
Blade bore Size 16mm
Max. Cut at 90° 54mm
Max. Cut at 45° 40mm
No Load Speed 3800 rpm
SPECIFICATIONS
KNOW YOUR PRODUCT
11 - RIP FENCE KNOB
10 - RIP FENCE
12 - BEVEL
ADJUSTMENT
KNOB
13 - SPINDLE
LOCK
15 - FRONT HANDLE
14 - BASE
PLATE
1 - TRIGGER LOCK OFF 2 - TRIGGER 3 - REAR HANDLE
6 - SAFETY GUARD LEVER
4 - DEPTH ADJUSTMENT
LOCKING KNOB
8 - LOWER SAFETY GUARD
9 - BLADE DIRECTION INDICATION ARROW
7 - BLADE
(ANY 18V CHARGE-ALL BATTERY WILL FIT)
BATTERY
INSERTS HERE
5 - DUST EXTRACTION
PORT
HOW TO INSERT BATTERY ON TOOL
1. ALIGN BATTERY RIBS WITH TOOL 2. SLIDE INTO TOOL 3. STOP WHEN YOU HEAR IT CLICK IN PLACE
LI-ION
Ah
18V CHARGE-ALL
18V CHARGE-ALL
18V CHARGE-ALL
1 2 3
*CLICK*
220080

CORDLESS CIRCULAR SAW INSTRUCTION MANUAL
20
10
30
40
20
10
30
40
4
CIRCULAR SAW BASICS
20
10
30
40
HOW TO ATTACH THE RIP FENCE
HOW TO ADJUST BLADE DEPTH
HOW TO ADJUST SAW BEVEL
1. Loosen rip fence knob (11) 2. Slide the rip fence (10) through
the slots with the guide plate
facing down
3. When at the desired width,
tighten the rip fence knob
1
1
2
2
3
3
1 2
20
10
30
40
3
1. Loosen the bevel adjustment
knob (12)
1. Loosen the depth adjustment
locking knob (4)
2. Tilt the base plate (14) to the
desired bevel
2. Adjust the saw to the desired
depth
3. Once at the desired bevel,
tighten the bevel adjustment
knob
3. Once at the desired depth,
tighten the depth adjustment
knob
20
10
30
40
220080

CORDLESS CIRCULAR SAW INSTRUCTION MANUAL
5
HOW TO FIT/REPLACE BLADE
1. Press & hold spindle lock (13) 2. Remove spindle bolt with provided hex key (un-
der front handle in saw body). The thread is left
hand thread, turn the bolt clockwise to loosen.
3. Pull up the safety guard lever (6) to move the
lower safety guard (8) to allow space for the
blade to be removed.
5. Insert the new blade ensuring the direction
arrows on the blade match the blade direction
indication arrow (9).
4. Remove the old blade and while still holding the
safety guard lever.
6. To refit the spindle bolt and flange, hold the
spindle lock and tighten the bolt by turning it
anti-clockwise. Ensure it is fastened securely and
the blade is seated correctly.
1
3
5
2
4
6
220080
WARNING
• REMOVE BATTERY BEFORE REMOVING OR INSERTING BLADES
• THE MAX RATING OF THE SAW BLADE MUST BE HIGHER THAN 3800 RPM

CORDLESS CIRCULAR SAW INSTRUCTION MANUAL
6
HOW TO MAKE A CUT
2. MAKE SURE YOU HAVE THE RIGHT BLADE
4. ENSURE SAW IS SET UP CORRECTLY
6. CUT YOUR WORKPIECE
1
3
5
2
4
6
220080
1. ENSURE SAFETY
Always wear safety glasses when working with the
circular saw. Make sure to secure your hair and any
baggy clothes. In appropriate situations make sure
you wear ear muffs, a mask or a respiratory mask.
Ensure you have the correct rated blade for the
job. The blade supplied is for cutting wood. Check
blade instructions for the uses of different blades.
3. SECURE WORKPIECE
5. MEASURE TWICE, CUT ONCE
Make sure your workpiece is securely fastened. Ensure that the saw depth, bevel and rip fence
(if attached) are set up correctly and the safety
guards are in their correct position.
Have your job planned and marked out. Put the front of the saws baseplate on your workpiece
whilst ensuring the blade isn’t touching the material. Hold
the saw securely. Push the trigger lock off (1) and pull the
trigger (2), then slowly move the blade towards where
you are intending to cut. Guide the circular saw along the
marked line while letting the saw do the work.

MAINTENANCE
CORDLESS CIRCULAR SAW INSTRUCTION MANUAL
This power tool normally requires no maintenance; from time to time the ventilation slots on the motor
casing should be cleaned out. If the unit should become defective, repair should be performed by an
authorized service agent for electric tools.
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various
types of commercial solvents and may be damaged by their use. Use clean cloths to remove dirt, dust,
oil, grease, etc.
Warning!
Do not at any time let brake fluids, gasoline, petroleum based products, penetrating oils, etc., come in contact with
plastic parts. Chemicals can damage, weaken or destroy plastic which may result in serious personal injury.
Australia & Global
www.katanapowertools.com.au
[email protected]
[phone]
Made to Katana
specifications and
quality standards
in China.
NOT INTENDED
FOR TRADE USE
* Standard 3 year warranty with an additional 2 year warranty available subject to online
registration via katanapowertools.com.au. Warranty on this Katana product is given by Kincrome
Australia Pty Ltd of 3 Lakeview Drive, Caribbean Park, Scoresby, Victoria, Australia (Tel +61 3
9730 7100) If this product has materials or workmanship defects (other than defects caused by
abnormal or non warranted use) you can, at your cost, send the product to place of purchase,
an authorised Kincrome service agent or one of Kincromes addresses for repair or replacement.
Your rights under this warranty are in addition to any other rights you have under the Australian Consumer Law or other
applicable laws. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure. For further details please visit www.kincrome.com.au or call us. Due to
minor changes in design or manufacture, the product you purchase may sometimes differ from the one shown on the
packaging.
WARRANTY*
5 YEAR
220080
