KaVo MASTERmatic LUX M07 L User manual

Instructions for use
MASTERmatic LUX M07 L - 1.009.3610
MASTERmatic LUX M20 L - 1.009.3620
MASTERmatic LUX M29 L - 1.009.3580

Distributed by:
KaVo Dental GmbH
Bismarckring 39
D-88400 Biberach
Phone [phone]
Fax [phone]
Manufacturer:
KaVo Dental GmbH
Bismarckring 39
D-88400 Biberach
www.kavo.com

Table of contents
1User instructions............................................................................................................................................... 5
2Safety............................................................................................................................................................... 6
2.1 Description of safety instructions.............................................................................................................. 6
2.2 Safety instructions.................................................................................................................................... 6
3Product description........................................................................................................................................... 8
3.1 Purpose – Intended use............................................................................................................................ 8
3.2 Technical Specifications M07 L................................................................................................................ 9
3.3 Technical Specifications M20 L.............................................................................................................. 10
3.4 Technical Specifications M29 L.............................................................................................................. 10
3.5 Transportation and storage conditions................................................................................................... 10
4Start up and shut down................................................................................................................................... 11
4.1 Check the amount of water..................................................................................................................... 11
5Operation........................................................................................................................................................ 12
5.1 Attach the medical device....................................................................................................................... 12
5.2 Remove the medical device.................................................................................................................... 12
5.3 Insert the INTRA LUX ............................................................................................................................ 12
5.4 Remove the INTRA LUX ........................................................................................................................ 12
6Troubleshooting.............................................................................................................................................. 13
6.1 Check for malfunctions........................................................................................................................... 13
6.2 Troubleshooting...................................................................................................................................... 13
6.2.1 Replacing the O-rings................................................................................................................ 13
6.2.2 Cleaning the spray nozzle......................................................................................................... 13
6.2.3 Changing the water filter............................................................................................................ 14
7Reprocessing steps in accordance with ISO 17664....................................................................................... 15
7.1 Preparations at the site of use................................................................................................................ 15
7.2 Cleaning.................................................................................................................................................. 15
7.2.1 Manual cleaning - external........................................................................................................ 15
7.2.2 Automated external cleaning..................................................................................................... 15
7.2.3 Manual cleaning - internal......................................................................................................... 15
7.2.4 Automated internal cleaning...................................................................................................... 16
7.3 Disinfection............................................................................................................................................. 16
7.3.1 Manual disinfection - external.................................................................................................... 17
7.3.2 Manual disinfection - internal..................................................................................................... 17
7.3.3 Machine disinfection - external and internal.............................................................................. 17
7.4 Drying..................................................................................................................................................... 17
7.5 Care products and systems - Servicing.................................................................................................. 18
7.5.1 Care with KaVo Spray............................................................................................................... 18
7.5.2 Care with the KaVo SPRAYrotor............................................................................................... 18
7.5.3 Servicing with KaVo QUATTROcare 2104 / 2104A.................................................................. 18
7.5.4 Servicing with KaVo QUATTROcare PLUS 2124 A.................................................................. 19
7.5.5 Servicing with KaVo QUATTROcare 2140 A............................................................................. 19
7.6 Packaging............................................................................................................................................... 20
7.7 Sterilisation............................................................................................................................................. 20
7.8 Storage................................................................................................................................................... 20
Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
Table of contents
3 / 24

8Tools and consumables.................................................................................................................................. 21
9Warranty terms and conditions....................................................................................................................... 22
Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
Table of contents
4 / 24

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
1 User instructions |
1 User instructions
Dear User
Congratulations on purchasing this KaVo quality product. By following the instructions
below you will be able to work smoothly, economically and safely.
© Copyright by KaVo Dental GmbH
Symbols
Refer to the chapter on Safety/Warning symbol
Important information for users and service technicians
Can be steam-sterilised at 134 oC -1 oC / +4 oC (273 oF -1.6 oF / +7.4 oF)
Thermodisinfectable
CE-Zeichen (Communauté Européenne). Ein Produkt mit diesem Zeichen
entspricht den Anforderungen der anwendbaren EG-Richtlinie.
Action request
Target group
This document is intended for dentists and their assistants. The section on starting up
is also intended for service technicians.
5 / 24

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
2 Safety | 2.1 Description of safety instructions
6 / 24
2 Safety
2.1 Description of safety instructions
Warning symbol
Structure
DANGER
The introduction describes the type and source of the hazard.
This section describes potential consequences of non-compliance.
▶ The optional step includes necessary measures for hazard prevention.
Description of hazard levels
The safety instructions listed here, together with the three levels of danger will help
avert property damage and injury.
CAUTION
CAUTION
indicates a hazardous situation that can cause damage to property or mild to moder‐
ate injuries.
WARNING
WARNING
indicates a hazardous situation that can lead to serious or fatal injury.
DANGER
DANGER
indicates a maximal hazard due to a situation that can directly cause death or fatal
injury.
2.2 Safety instructions
WARNING
Hazard from incorrectly reconditioned products.
An infection hazard exists from contaminated products.
▶ Take suitable personal protective measures.
WARNING
Hazards for the care provider and the patient.
In the case of damage, irregular running noise, excessive vibration, un-typical warm‐
ing or when the cutter or grinder cannot be held.
▶ Do not use further and notify Service.

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
2 Safety | 2.2 Safety instructions
CAUTION
Hazard from use as a light probe.
Do not use the device as a light probe since the rotating cutters or grinders can cause
injury.
▶ Use an appropriate light probe for additional illumination of the oral cavity or site
of preparation.
CAUTION
Premature wear and malfunctioning from improper storage during long periods of
nonuse.
Reduced product life.
▶ The medical device should be cleaned, serviced and stored in a dry location, ac‐
cording to instructions, before long periods of nonuse.
The following individuals are authorized to repair and service KaVo products:
▪ Technicians at KaVo branches throughout the world
▪ Technicians specially trained by KaVo
To ensure proper function, the medical device must be set up according to the reproc‐
essing methods described in the KaVo Instructions for Use, and the care products and
care systems described therein must be used. KaVo recommends specifying a service
interval at the dental office for a licensed shop to clean, service and check the func‐
tioning of the medical device. This service interval depends on the frequency of use
and should be adjusted accordingly.
Service may only be carried out by KaVo-trained repair shops using original KaVo re‐
placement parts.
7 / 24

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
3 Product description | 3.1 Purpose – Intended use
8 / 24
3 Product description
MASTERmatic LUX M07 L (Mat. no. 1.009.3610)
MASTERmatic LUX M20 L (Mat. no. 1.009.3620)
MASTERmatic LUX M29 L (Mat. no. 1.009.3580)
3.1 Purpose – Intended use
Indications for use:
This medical device is

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
3 Product description | 3.2 Technical Specifications M07 L
▪ intended for dental treatment only. All other types of use or modifications of the
product are not permitted and can be hazardous. The medical device, used in
combination with the respective handpiece heads, is intended for the following ap‐
plications: Removal of carious material, cavity and crown preparations, removal of
fillings, processing of tooth and restoration surfaces.
▪ A medical device according to relevant national statutory regulations.
Proper use:
According to these regulations, this medical device may only be used for the descri‐
bed application by a knowledgeable user. You need to comply with the following:
▪ the applicable health and safety regulations
▪ the applicable accident prevention regulations
▪ these Instructions for use
According to these regulations, the user is required to:
▪ only use equipment that is operating correctly,
▪ adhere to the specified intended use
▪ protect him or herself, the patient and third parties from danger, and
▪ avoid contamination from the product.
3.2 Technical Specifications M07 L
Drive speed max. 40,000 rpm
Step-down ratio 2.7 : 1
Maximum speed: max. 15,000 rpm
identification 1 green ring
Spray water pressure 0.8 to 2.0 bar (12 to 29 psi)
Spray air pressure 1.0 to 2.0 bar (15 to 29 psi)
Spray air quantity min. 1.5 Nl/min (at 2 bar)
Cooling air flow 5.5 to 9.5 Nl/min
All INTRA heads and INTRA LUX heads can be used.
The shank can be mounted on all INTRAmatic motors and motors fitted with a connec‐
tion in accordance with ISO 3964 / DIN 13940.
9 / 24

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
3 Product description | 3.3 Technical Specifications M20 L
10 / 24
3.3 Technical Specifications M20 L
Drive speed max. 40,000 rpm
Step-down ratio 1 : 1
Maximum speed: max. 40,000 rpm
Identification 1 blue ring
Spray water pressure 0.8 to 2.0 bar (12 to 29 psi)
Spray air pressure 1.0 to 2.0 bar (15 to 29 psi)
Spray air quantity min. 1.5 Nl/min (at 2 bar)
Cooling air flow 5.5 to 9.5 Nl/min
All INTRA heads and INTRA LUX heads can be used.
The shank can be mounted on all INTRAmatic motors and motors fitted with a connec‐
tion in accordance with ISO 3964 / DIN 13940.
3.4 Technical Specifications M29 L
Drive speed max. 40,000 rpm
Step-down ratio 7.4 : 1
Maximum speed: max. 5,000 min-1
identification 2 green rings
Spray water pressure 0.8 to 2.0 bar (12 to 29 psi)
Spray air pressure 1.0 to 2.0 bar (15 to 29 psi)
Spray air quantity min. 1.5 Nl/min (at 2 bar)
Cooling air flow 5.5 to 9.5 Nl/min
All INTRA heads and INTRA LUX heads can be used.
The shank can be mounted on all INTRAmatic motors and motors fitted with a connec‐
tion in accordance with ISO 3964 / DIN 13940.
3.5 Transportation and storage conditions
CAUTION
It is hazardous to start up the medical device after it has been stored strongly refriger‐
ated.
This can cause the medical device to malfunction.
▶ Prior to start-up, very cold products must be heated to a temperature of 20oC to
25oC (68oF to 77oF).
Temperature: -20°C to +70°C (-4°F to +158°F)
Relative humidity: 5% RH to 95% RH absence of condensation
Air pressure: 700 hPa to 1060 hPa (10 psi to 15 psi)
Protect from moisture

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
4 Start up and shut down | 4.1 Check the amount of water
4 Start up and shut down
WARNING
Hazard from non-sterile products.
Infection hazard for care provider and patient.
▶ Before first use and after each use, prepare and sterilise the medical device and
accessories accordingly.
WARNING
Disposal of the product in the appropriate manner.
Prior to disposal, the product and accessories must be appropriately prepared or
sterilised if this is necessary.
4.1 Check the amount of water
CAUTION
Overheating of the tooth due to insufficient amount of cooling water.
Thermal damage to the dental pulp.
▶ Adjust the water amount for the spray cooling to a minimum of 50 ml/min!
CAUTION
Hazard from insufficient spray water.
Insufficient spray water can cause the medical device to overheat and damage the
tooth.
▶ Check the spray water channels and clean the spray nozzles with the nozzle nee‐
dle Mat. no. 0.410.0921 if necessary.
11 / 24

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
5 Operation | 5.1 Attach the medical device
12 / 24
5 Operation
5.1 Attach the medical device
WARNING
Release of the medical device during treatment.
A medical device that is not properly locked in place can release from the motor cou‐
pling and fall off.
▶ Carefully pull on it before each treatment to ensure that the medical device is se‐
curely locked on the motor coupling.
CAUTION
Removing and attaching the handpiece while the drive motor is rotating.
Damage to the catch.
▶ Never attach or remove the reducing shank while the device is rotating!
▶ Attach medical device to the (LUX) motor coupling and turn it until the latch audi‐
bly snaps into place.
▶ Pull on the medical device to make sure that it is securely affixed to the coupling.
5.2 Remove the medical device
▶ Unlock the medical device from the motor coupling and then pull it off along its
axis.
5.3 Insert the INTRA LUX
CAUTION
Loosening of the medical device during treatment.
If the head is not properly locked in place, it can fall out during treatment.
▶ Do not mount or remove the head while rotating. Before each treatment, check
that the head is firmly seated and that the clamping ring is tight.
▶ Rotate the clamping ring in the direction of the arrow to the stop.
▶ Insert the head to the stop. Make sure that the catches are properly seated.
▶ Rotate the clamping ring in the opposite direction (-> close) and tighten it.
5.4 Remove the INTRA LUX
▶ Rotate the clamping ring in the direction of the arrow to the stop.

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
6 Troubleshooting | 6.1 Check for malfunctions
6 Troubleshooting
6.1 Check for malfunctions
CAUTION
Missing or damaged O-rings.
Malfunctions and premature failure.
▶ Make sure that all O-rings are on the coupling and undamaged.
CAUTION
Heating of the product.
Burns or product damage from overheating.
▶ Do not use the product if it is irregularly heated.
▶ The medical device is too hot while idling:
Check the amount of cooling air.
▶ The medical device is too hot while working:
Caring for the medical device.
▶ When the speed drops or is uneven:
Caring for the medical device.
▶ An O-ring is missing on the motor coupling:
Replace O-ring.
6.2 Troubleshooting
6.2.1 Replacing the O-rings
CAUTION
Hazard from improper care of the O-rings.
Malfunctions or complete failure of the medical device.
▶ Do not use Vaseline or other grease or oil.
Note
The O-ring on the coupling may only be lubricated with a cotton ball wet with KAVO
spray.
▶ Press the O-ring between your fingers to form a loop.
▶ Shove the O-ring to the front, and remove it.
▶ Insert new O-rings into the grooves.
6.2.2 Cleaning the spray nozzle
CAUTION
Hazard from insufficient spray water.
Overheating of the medical device and damage to the tooth.
▶ Check the spray water channels and clean the spray nozzles with the nozzle nee‐
dle Mat. no. 0.410.0921 if necessary.
▶ Check the water filter and exchange if necessary.
13 / 24

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
6 Troubleshooting | 6.2 Troubleshooting
14 / 24
▶ Use the nozzle needle (Mat. no. 0.410.0921) to free the water passage in the
spray nozzles.
6.2.3 Changing the water filter
CAUTION
Hazard from insufficient spray water.
Insufficient spray water can cause the medical device to overheat and damage the
tooth.
▶ Check the filter and exchange if necessary.
▶ Check the spray water channels and clean the spray nozzles with the nozzle nee‐
dle Mat. no. 0.410.0921 if necessary.
▶ Screw out and remove the filter with the wrench (Mat. no. 1.002.0321).
▶ Insert the new filter (Mat. no. 1.002.0271) and screw it in with the wrench.

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
7 Reprocessing steps in accordance with ISO 17664 | 7.1 Preparations at the site of use
7 Reprocessing steps in accordance with ISO 17664
7.1 Preparations at the site of use
WARNING
Hazard from nonsterile products.
There is a risk of infection from contaminated medical devices.
▶ Take suitable personal protective measures.
Note
For preparation, remove the head from the shank.
▶ Remove all residual cement, composite or blood without delay.
▶ Reprocess the medical device as soon as possible after treatment.
▶ The medical device must be dry when transported for reconditioning.
▶ Do not place it in a solution or similar.
7.2 Cleaning
CAUTION
Malfunctions from cleaning in the ultrasonic unit.
Defects in the product.
▶ Only clean manually or in a thermodisinfector.
7.2.1 Manual cleaning - external
Accessories required:
▪ Tap water 30 oC ± 5 oC (86 oF ± 10 oF)
▪ Brush, e.g. medium-hard toothbrush
▶ Brush off under flowing tap water.
7.2.2 Automated external cleaning
KaVo recommends washer disinfectors in compliance with EN ISO 15883-1, which
are operated using alkaline cleaning agents.
▶ For program settings as well as cleansers and disinfectants to be used, please re‐
fer to the Instructions for Use of the thermodisinfector.
▶ In order to prevent negative effects on the medical device, make sure that the in‐
terior and the exterior of the medical device are dry after completion of the cycle,
and then grease it immediately with servicing agents from the KaVo care system.
7.2.3 Manual cleaning - internal
Validated interior cleaning (residual protein removal) can only be accomplished with
KaVo CLEANspray and KaVo DRYspray.
15 / 24

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
7 Reprocessing steps in accordance with ISO 17664 | 7.3 Disinfection
16 / 24
▶ Cover the medical device with the KaVo CLEANpac bag, and place it on the cor‐
responding care adapter. Press the spray button three times for 2 seconds each
time. Remove the medical device from the spray attachment and let the cleaner
work for one minute.
▶ Afterwards, rinse for 3-5 seconds with KaVo DRYspray.
See also:
2KaVo CLEANspray / KaVo DRYspray Instructions for Use
Note
KaVo CLEANspray and KaVo DRYspray for manual interior cleaning are only avail‐
able in the following countries:
Germany, Austria, Switzerland, Italy, Spain, Portugal, France, Luxembourg, Bel‐
gium, Netherlands, United Kingdom, Denmark, Sweden, Finland and Norway.
In other countries interior cleaning can only be carried out with thermodisinfectors in
accordance with EN ISO 15883-1.
7.2.4 Automated internal cleaning
KaVo recommends washer disinfectors in compliance with EN ISO 15883-1, which
are operated using alkaline cleaning agents.
▶ For programme settings as well as cleansers and disinfectants to be used, please
refer to the Instructions for Use of the washer disinfector.
▶ In order to prevent negative effects on the medical device, make sure that the in‐
terior and the exterior of the medical device are dry after completion of the cycle,
and then grease it immediately with servicing agents from the KaVo care system.
7.3 Disinfection
WARNING
Hazard due to incomplete disinfection.
Principally, KaVo recommends carrying out an final disinfection of the unpackaged
item if complete disinfection cannot be guaranteed without this measure.
CAUTION
Malfunctioning from using a disinfectant bath or disinfectant containing chlorine.
Defects in the product.
▶ Only disinfect in a thermodisinfector or manually.
CAUTION
Malfunctioning from using the disinfectant bath or chlorine-containing disinfectants.
Defects in the device.
▶ Do not use an ultrasonic bath.
CAUTION
Never use alkaline or chlorine-containing disinfectants.
The saline solution corrodes the metal parts.
▶ Immediately remove all residue.

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
7 Reprocessing steps in accordance with ISO 17664 | 7.4 Drying
7.3.1 Manual disinfection - external
KaVo recommends the following products based on material compatibility. The micro‐
biological efficacy must be ensured by the disinfectant manufacturer.
▪ Mikrozid AF made by Schülke & Mayr (liquid or cloths)
▪ FD 322 made by Dürr
▪ CaviCide made by Metrex
Consumables required:
▪ Cloths for wiping off the medical device.
▶ Spray the disinfectant on a cloth, then wipe down the medical device and allow
the disinfectant to act according to the instructions of the disinfectant manufactur‐
er.
▶ Follow the instructions for use of the disinfectant.
7.3.2 Manual disinfection - internal
The efficacy of manual internal disinfection must be demonstrated by the manufactur‐
er of the disinfection agent. With KaVo products, use only disinfection agents that
have been released by KaVo with respect to the compatibility of materials (e.g. WL-
cid / made by ALPRO).
▶ Blow off with compressed air until no water drops are visible.
▶ Immediately after internal disinfection, lubricate the KaVo medical device immedi‐
ately with care agents from the KaVo care system.
7.3.3 Machine disinfection - external and internal
KaVo recommends washer disinfectors in compliance with EN ISO 15883-1, which
are operated using alkaline cleaning agents.
▶ For programme settings as well as cleansers and disinfectants to be used, please
refer to the Instructions for Use of the washer disinfector.
▶ In order to prevent negative effects on the medical device, make sure that the in‐
terior and the exterior of the medical device are dry after completion of the cycle,
and then grease it immediately with servicing agents from the KaVo care system.
7.4 Drying
Manual Drying
▶ Blow off the outside and inside with compressed air until water drops are no lon‐
ger visible.
Automatic Drying
The drying procedure is usually a part of the cleaning program of the thermodisinfec‐
tor.
▶ Follow the instructions for use of the thermodisinfector.
17 / 24

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
7 Reprocessing steps in accordance with ISO 17664 | 7.5 Care products and systems - Servicing
18 / 24
7.5 Care products and systems - Servicing
CAUTION
Premature wear and malfunctions from improper servicing and care.
Reduced product life.
▶ Perform proper care regularly!
Note
KaVo only guarantees that its products will function properly when the care prod‐
ucts are used that are listed as accessories since they were tested for proper use
on our products.
7.5.1 Care with KaVo Spray
Note
The shank can be serviced either alone or with a head attached to it.
KaVo recommends servicing the product as part of the reprocessing after each use,
i.e. after each cleaning, disinfection, and before each sterilisation.
▶ Cover the product with the Cleanpac bag.
▶ Plug the product onto the cannula, and press the spray button for one second.
7.5.2 Care with the KaVo SPRAYrotor
Note
The shank can be serviced either alone or with a head attached to it.
▶ Place the product on the appropriate coupling of the KaVo SPRAYrotor and cover
it with a Cleanpac bag.
▶ Servicing the product.
See also:
2Instructions for use KaVo SPRAYrotor
7.5.3 Servicing with KaVo QUATTROcare 2104 / 2104A
Note
The shank can be serviced either alone or with a head attached to it.
Cleaning and servicing unit with expansion pressure for effective cleaning and care.
Note
QUATTROcare 2104 / 2104 A is no longer included in the current delivery pro‐
gramme.
Follow-up products:
▶ QUATTROcare PLUS 2124 A
▶ QUATTROcare CLEAN 2140 A

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
7 Reprocessing steps in accordance with ISO 17664 | 7.5 Care products and systems - Servicing
Servicing and cleaning device with expansion pressure for the interior cleaning of inor‐
ganic residues and optimum care.
(no validated cleaning of the interior in accordance with German RKI requirements)
KaVo recommends servicing the product as part of the reprocessing after each use,
i.e. after each cleaning, disinfection, and before each sterilisation.
▶ Remove the cutter or grinder.
▶ Servicing the product.
See also:
2Instructions for use KaVo QUATTROcare 2104 / 2104A
7.5.4 Servicing with KaVo QUATTROcare PLUS 2124 A
Note
The shank can be serviced either alone or with a head attached to it.
Servicing and cleaning device with expansion pressure for the interior cleaning of inor‐
ganic residues and optimum care.
(no validated cleaning of the interior in accordance with German RKI requirements)
▶ Remove the cutter or grinder.
▶ Servicing the product in the QUATTROcare PLUS.
See also:
2Instructions for Use KaVo QUATTROcare PLUS 2124 A
7.5.5 Servicing with KaVo QUATTROcare 2140 A
Programme-controlled cleaning and servicing device for perfect servicing of handpie‐
ces and turbines.
▶ Remove the cutter or grinder.
▶ Servicing the product in QUATTROcare CLEAN.
See also:
2Instructions for use KaVo QUATTROcare CLEAN 2140 A
19 / 24

Instructions for use MASTERmatic LUX M07 L - 1.009.3610 MASTERmatic LUX M20 L - 1.009.3620 MASTERmatic LUX
M29 L - 1.009.3580
7 Reprocessing steps in accordance with ISO 17664 | 7.6 Packaging
20 / 24
7.6 Packaging
Note
The sterilisation bag must be large enough for the handpiece so that the bag is not
stretched.
The quality and use of the sterilisation packaging must satisfy applicable standards
and be suitable for the sterilisation procedure!
▶ Weld each medical device individually in a sterilised item package!
7.7 Sterilisation
Sterilisation in a steam steriliser (autoclave) in accordance with EN
13060 / ISO 17665-1
CAUTION
Premature wear and malfunctions from improper servicing and care.
Reduced product life.
▶ Before each sterilisation cycle, service the medical device with KaVo care prod‐
ucts.
CAUTION
Contact corrosion due to moisture.
Damage to product.
▶ Immediately remove the product from the steam steriliser after the sterilisation cy‐
cle!
The KaVo medical device has a maximum temperature resistance of up to 138 ℃
(280.4 °F).
Select a suitable procedure (depending on the available autoclave) from the following
sterilisation processes:
▪ Autoclave with three times pre-vacuum:
- at least 3 minutes at 134 °C -1 °C / +4 °C (273 °F -1.6 °F / +7.4 °F)
▪ Autoclave using the gravity method:
- at least 10 minutes at 134 °C -1 °C / +4 °C (273 °F -1.6 °F / +7.4 °F)
▶ Use according to the manufacturer's Instructions for Use.
7.8 Storage
▶ Reprocessed products should be stored protected from dust with minimum expo‐
sure to germs in a dry, dark and cool space.
Note
Comply with the expiry date of the sterilised items.
