KBR multicount 3D6-0-LCD-EP-US1 Operating instructions

3D6-0-LCD-EP-US1
3D6-1-LCD-ES-US1
multicount
Electronical
energy meter
Operating instructions
Technical Parameters
Your Partner for Network
Analyzing

KBR GmbH
Am Kiefernschlag 7
D-91226 Schwabach
T [phone]
F [phone]
E info@kbr,de
www.kbr.de

Page I of III
4709-1 GB
Preface
Dear Customer
We would like to thank you for choosing a KBR quality product.
In order to familiarize yourself with the operation and programming of the device and always be able to use
the whole functionality of this high-quality product, we recommend that you read this manual thoroughly.
The individual chapters serve to explain the technical details of the device and show how to avoid damage by
means of proper installation and commissioning.
The manual is included in the scope of delivery of the device and must be accessible for the user at all times
(e.g. in the switchgear cabinet). Even when the device is resold to third parties, the manual remains part of the
device.
Although we used the utmost care in assembling this manual, we would like to thank you in advance for notify-
ing us about any errors or ambiguous descriptions that might be in it. You will find a form for corrections in the
appendix.
Sincerely,
KBR GmbH Schwabach

Page II of III
4709-1 GB
Safety Precautions
General Safety Precautions
In order to prevent operating errors, handling of the device is kept as simple as possible. This way, you will be
able to use the device very soon.
In your own interest, however, you should read the following safety precautions carefully.
Disclaimer
The contents of this manual has been checked with the described hardware and software components.
Certain deviations, however, cannot be excluded, so the manufacturer is not liable for complete confor-
mity. The specifications made in this manual are checked on a regular basis, necessary corrections are
included in the next revision.
We appreciate your corrections and comments.
KBR GmbH 2002
Subject to change
aWarning During installation, the applicable DIN / VDE regulations must be observed.
Mains connection, setup and operation of the device must only be performed by
qualified personnel. Qualified personnel as understood in the safety precautions
of this manual are persons authorized to setup, ground and mark equipment, sys-
tems and wiring systems in accordance with applicable standards.
To avoid the hazard of fire and electrical shock, the device must not be subjected
to rain or other humidity!
Before the device is connected to the mains, you will have to check whether the
local mains conditions comply with the specifications on the manufacturer's label.
A wrong connection may destroy the device!
When connecting the device, the connection chart must be observed (see chap-
ter "Connection chart") and the connection lines must be powerless. Only use
proper line material and watch the correct polarity when wiring!
In order to ensure proper and safe operation of the product, it must be trans-
ported, stored, installed and mounted in accordance with the specifications and
operated and maintained carefully.
A device showing visible damage must by all means be considered as unfit for
operation and must be disconnected from the mains!
Error detection, repairs and maintenance work may only be carried out in our faci-
lities or after contacting our service team. Every warranty obligation of the manuf-
acturer expires if the device is opened without written consent from our service
team. Proper operation can no longer be guaranteed!
Opening the device may expose parts under voltage. Capacitors in the device
may still be loaded even if the device was disconnected from all voltage sources.
It is generally not allowed to operate the open device!
In facilities subject to hazard of lightning, lightning protection must be provided for
all input and output lines (recommendations see chapter "Protective measures")!

Seite III von III
4709-1 GB
Product Liability / Disposal
Product Liability
With these product, you have acquired a quality product.
In its manufacture, only components of the highest reliability and quality were used. Each device is subject to
long-term testing before it is delivered.
For information on product liability, please refer to our General Terms and Conditions for electronic devices.
The warranted properties of the device apply only if it is operated in accordance with its intended use!
Disposal
Please dispose of defective, outdated or no longer used devices properly.
At your request, we will be pleased to dispose of the devices for you

User Manual multicount
Version 2.00 Page 1 of 34
EDEBDA0145 / 4709-1 GB
Table of Contents
1 Device memory, battery-buffered ..........................................................3
2 Definition of Terms .................................................................................4
3 Field of application / Function range ....................................................5
4 Connecting the multicount 3D6-0-LCD-EP-.../3D6-1-LCD-ES-... .........6
4.1 Installation and Assembly ...................................................................................6
4.2 Connection diagram .............................................................................................8
4.3 Terminal assignment ............................................................................................8
5 Start-up ..................................................................................................10
5.1 Control and display panel ..................................................................................10
5.2 LEDs .....................................................................................................................10
6 Measuring values of the multicount 3D6-0-LCD-EP-.../
3D6-1-LCD-ES-... and their representation .........................................11
6.1 Display of active or reactive energy measurement .........................................11
6.2 Display of power measurement .........................................................................12
6.2.1 Display for energy consumption or recovery (multicount 3D6-1-LCD-ES-... only) 12
6.2.2 Display of the power factor .........................................................................................12
7 Programming ........................................................................................13
7.1 Working with the display menu .........................................................................13
7.2 Programming scheme ........................................................................................16
7.3 Working with the configuration menu ..............................................................16
7.4 Storage ................................................................................................................25
7.4.1 Device settings ............................................................................................................25
7.4.2 Devices - basic parameters ........................................................................................25
7.4.3 Long-term memory (multicount 3D6-1-LCD-ES-... only) .........................................25
7.4.3.1 Load profile memory ........................................................................................................... 25
7.4.3.2 Annual energy memory ....................................................................................................... 26
7.4.3.3 Pmax and Qmax annual memory ....................................................................................... 26
7.4.3.4 Event memory ...................................................................................................................... 26
7.4.4 Measuring period synchronization (multicount 3D6-1-LCD-ES-... only) ................27
7.4.4.1 Synchronization only by internal clock. ............................................................................ 27
7.4.4.2 Synchronization by the energy supplier’s synchronous pulse. ..................................... 27
7.4.4.3 Synchronization by KBR ENERGY BUS ............................................................................ 27
7.4.4.4 Synchronization when tariffs are changed ....................................................................... 27
8 Technical Data ......................................................................................28
8.1 Measuring and display values ...........................................................................28
8.2 Operating and display elements .......................................................................28
8.3 Measuring accuracy........................................................................................... 28
8.4 Measuring principle ............................................................................................29
8.5 Device memory ...................................................................................................29
8.6 Power supply ......................................................................................................29
8.7 Hardware inputs ..................................................................................................29
8.8 Electrical connection ..........................................................................................30

User Manual multicount
Page 2 of 34 Version 2.00
EDEBDA0145 / 4709-1 GB
8.9 Hardware outputs ...............................................................................................30
8.10 Mechanical Data ..................................................................................................30
8.11 Dimensioned drawing ........................................................................................31
8.12 Environmental conditions / Electrical safety ...................................................31
8.13 Default settings after reset ................................................................................31
8.14 Basic configuration when delivered .................................................................32
9 Serial interface ......................................................................................32
9.1 Operating modes and interface configuration .................................................32
9.1.1 RS 485 Bus operation ..................................................................................................32
9.1.2 Protective measures ....................................................................................................32
9.2 Overvoltage and lightning protection ...............................................................32
10 Error detection ......................................................................................33

User Manual multicount
Version 2.00 Page 3 of 34
EDEBDA0145 / 4709-1 GB
1 Device memory, battery-buffered
The device is equipped with an internal data memory, which is battery buffered to preserve long-term data. To
prevent it from being discharged, this backup battery (e.g. Varta CR 2032) is not built in when the device is
delivered, but included separately in the delivery.
Inserting or replacing backup battery:
1. Disconnect the device from the supply voltage.
2. Lift the upper casing cover with a suitable tool (e.g. a small screwdriver).
3. When replacing a battery, remove the empty battery from the clamp with the tool.
4. Push the new battery into the clamp and make sure that it is inserted correctly and has the right polarity.
5. Put the upper casing cover back on and click it into place by pushing.
6. Reconnect the device to the supply voltage.
aCaution
Before the initial commissioning of the device, please insert the backup battery
first (as described in the following), as otherwise all storage data would be lost in
case of a power failure.
aCaution
As, when the battery is empty or removed and there is no supply voltage, not only
the storage data are lost but the time is not correct anymore either, the time has to
be reset in Visual Energy with the corresponding command!

User Manual multicount
Page 4 of 34 Version 2.00
EDEBDA0145 / 4709-1 GB
2 Definition of Terms
Below you will find brief explanations of the terminology used in this manual.
Root-mean-square value: By definition the square of the mean value of a periodic or pulsating quantity
is referred to as the root-mean-square value. multicount 3D6-0-LCD-EP-.../
3D6-1-LCD-ES-... exclusively uses the effective values of pure periodic
quantities (RMS).
Instantaneous
root-mean-square value: Is the value determined by the multicount 3D6-0-LCD-EP-.../3D6-1-LCD- ES-... within its measuring interval.
Measuring interval: Within a measuring interval, the electrical quantity ”voltage” or ”current” of
one phase is scanned. The resulting scanning spots are available for further
calculations. This interval is mainly determined by the A/D conversion.
Measuring cycle: The measuring cycle is the time the device needs for measuring all possible
quantities for all three phases.
Firmware: Operating system software implemented in the multicount 3D6-0-LCD-EP-
.../3D6-1-LCD-ES-...'s microcontroller
Load profile memory: Saves the actual values of the measuring periods with timestamp.
Measuring period max: The measuring period containing the highest (maximum) value that
occurred.
Aktive- /
reaktive power periods
Actual active or reactive power within a measuring period.
Measuring period: The period of time used to determine the average power demand. Typical
intervals: e.g. 15, 30, 60 minutes.
DIN rail: Top hat rail / mounting rail acc. to DIN EN 50022

User Manual multicount
Version 2.00 Page 5 of 34
EDEBDA0145 / 4709-1 GB
3 Field of application / Function range
multicount 3D6-0-LCD-EP-.../3D6-1-LCD-ES-... is a compact, easy-to-use energy meter counting active as
well as reactive energy (for consumption and recovery).
This energy meter was designed in accordance with the standards DIN EN 61036 (IEC 1036),
DIN EN 61268 (IEC 1268) and the requirement specification 2.0 revision 12/97 by the German Electricity
Association (VDEW)
Dual-tariff meter function (HT/LT) (multicount 3D6-1-LCD-ES-... only)
Consumption during high tariff and low tariff times is saved separately. Switching from high to low tariff times
and vice versa is either carried out by means of a digital signal to be applied externally, e.g. from the energy
supplier, or via an internal clock. A display flashing on the front of the device indicates which tariff is active at
the moment. When operated with the KBR Energy Bus, switching over can also be carried out centrally via the
Multimaster or PC.
Convenient operation and display
The LCD serves to either display the measured values directly or enter the respective parameters and confi-
guration data. In addition, six LEDs serve to show the status and monitor the functions. Four buttons facilitate
clearly structured navigation through the menus.
For 100 to 500 V networks
The multicount 3D6-0-LCD-EP-.../3D6-1-LCD-ES-... can be applied in three-wire as well as four-wire
networks. The unit can be implemented in 100 V as well as in 500 V networks for direct measurement. Using
a transducer adaptor, up to 700 V can be connected to the meter. Higher voltages can only be connected via
external voltage transformers; primary and secondary voltage can be freely programmed. The measuring
voltage inputs of the device measure directly, i.e. they are not metallically separated by a voltage transformer!
For energy supply networks with outer conductor connected to the earth potential, suitable suitable control gear
with electrical isolation (e.g. voltage transformer) must be used.
x/5A or x/1A freely programmable
The measuring inputs for current must always be fed via current transformers, while the transformer ratio is
programmable. The primary current value as well as the secondary current value can be selected.
Programmable pulse output
Active energy or reactive energy proportional pulses can be output via a programmable output laid out as S0
interface. The pulse output type (in proportion to active or reactive energy for consumption or recovery) as well
as the pulse values (number of pulses per kWh or per kVArh) and the pulse length can be configured. These
pulses can be processed fo example by a master system for data acquisition or optimization, a maximum-
demand monitor or a central process control.
Each pulse is visualized by a flashing LED.
Serial port for connection to the KBR Energy Bus (multicount 3D6-1-LCD-ES-... only)
The multicount 3D6-0-LCD-EP-....has a serial port (RS485) is designed for conveniently configuring the
instrument via computer and optional software.
The interface offers the possibility to equip the multicount 3D6-0-LCD-EP-... with the funtionality of the
multicount 3D6-1-LCD-ES-... with an optionally available upgrade.
The multicount 3D6-1-LCD-ES-... has a serial port (RS485) for operation with the KBR Energy Bus.
A large amount of information that cannot be shown on the display can be read from the device via the Energy
Bus.
This allows both the online measured values for phase voltages, phase currents, individual power factors and
individual performance, as well as an entire series of data to be read out from the long-term memory.

User Manual multicount
Page 6 of 34 Version 2.00
EDEBDA0145 / 4709-1 GB
Extensive memory functions
In addition to its counter functions, the multicount 3D6-1-LCD-ES-... offers extensive storage functions.
-4-quadrant load profile memory to record the cumulated active and reactive power
- Memory to record the daily energy values for 365 days
- Memory for the measuring period maximum of the previous month
-Event memory (4096 entries), for logging actions of the meter such as mains failures,
tariff switching actions, delete functions, and many more.
These memory functions are exclusively available via the KBR Energy Bus..
Synchronization
For synchronization of the load profile memory, a digital input is integrated into the multicount 3D6-1-LCD-
ES-... to connect the the synchronization signal of the energy supplier, for example. Synchronization as well
as high / low tariff switching can be controlled centrally via the KBR Energy Bus as well as via the internal clock.
Software (optional)
A number of software products that can be run on most Microsoft® Windows® operating systems is available
for the convenient programming and storage of long-term data.
Separate power supply
The device requires a separate auxiliary voltage for operation (see nameplate).
For questions about this device or about our software products please don’t hesitate to contact us. We will be
glad to assist you.
Please see the cover of this manual for your contact.
4 Connecting the multicount 3D6-0-LCD-EP-.../3D6-1-LCD-ES-...
4.1 Installation and Assembly
The housing of the multicount 3D6-0-LCD-EP-.../3D6-1-LCD-ES-... has been designed for wall moun-
ting on 35 mm DIN rail. The module is snapped on the mounted DIN rail.
For the wiring of the pulse output, we recommend to use twisted pair and shielded material exclusively to avoid
disturbance (e.g. installation line I-Y(ST) Y 2x2x0.8mm, while the shielding may only be connected on one
side).
During installation, please also observe our notes on safety measures against overvoltage and lightning in
chapter “Protective Measures” of this manual.
aCaution
The control voltage as well as the applied measuring voltage of the device must
be protected by means of a back-up fuse.
When connecting the current transformers, the direction of the energy flow and
the correct assignment to the voltage paths must be observed!
,

User Manual multicount
Version 2.00 Page 7 of 34
EDEBDA0145 / 4709-1 GB
Rotary field:
As soon as the multicount 3D6-0-LCD-EP-.../3D6-1-LCD-ES-...cis connected to the mains, it will auto-
matically detect the rotary direction.
Current transformation connection:
Energy flow direction:
When mounting the transformers, observe the current flow or energy flow direction. If the current transformers
are inserted the wrong way, the current will have a negative sign for active power input. In this case,
interchange the pins of the terminals k and I of the affected transformers.
Assigning measuring voltage input / current transformer input:
The current transformer on terminal 20/21 (k1/l1) must be arranged in the phase where the measuring voltage
for the terminal 10 (L1) is measured. The same applies to the other transformer and measuring voltage con-
nections.
bNote
You should take the following points into consideration when connecting the
device to the three-phase network to be measured:
- Energy flow direction
Assigning measuring voltage input / current transformer input
aCaution
Before any interchanging the transformers must be shorted out!

User Manual multicount
Page 8 of 34 Version 2.00
EDEBDA0145 / 4709-1 GB
4.2 Connection diagram
4.3 Terminal assignment
Terminal 1 (L) / 2 (N) and PE: Connection power supply
A control voltage is required to supply the device with power. The device
can be operated with a voltage from 85V to 265V.
Terminal 20 (k1) and 21 (l1):
22 (k2) and 23 (l2)
24 (k3) and 25 (l3)
Measuring inputs for current
The measuring inputs for current must be connected via current
transformers x/1A AC or x/5A AC.
When connecting transformers, pay attention to the energy flow direction
and to the correct assignment of measuring voltage inputs to current
transformers.

User Manual multicount
Version 2.00 Page 9 of 34
EDEBDA0145 / 4709-1 GB
Terminal 10 (L1):
11 (L2)
12 (L3)
13 (N)
Measuring input for voltage
Three phase voltage measurement in 4-wire rotary current networks.
Direct measurement is possible in the following networks:
3 x 100V/57,7V AC;3 x 400V/230V AC;
For higher voltages, the unit needs to be connected via a voltage trans-
former.
Terminal 92 (B)
91 (A)
90 (Masse):
Bus connection
For communication at the Energy Bus
multicount 3D6-0-LCD-EP-...: to device parameters
multicount 3D6-1-LCD-ES-...: to connection for power bus
Terminal 34 (+) and 35 (-): Pulse output
Output of energy-proportional pulses via a digital contact (S0interface in
accordance with DIN 43864). Correct polarity is important for this output.
The output signals can be processed by a maximum demand monitor or
a master central process control, for example.
Terminal 36 (+) and 37 (-): Synchronization input (multicount 3D6-1-LCD-ES-... only)
A floating contact, e.g. from the energy supplier for synchronizing the
measuring period, can be connected to this input
Terminal 38 (+) and 39 (-): Tariff input (multicount 3D6-1-LCD-ES-... only)
A floating contact, e.g. from the energy supplier for switching from high to
low tariff, can be connected to this input.n.

User Manual multicount
Page 10 of 34 Version 2.00
EDEBDA0145 / 4709-1 GB
5Start-up
5.1 Control and display panel
The meter multicount 3D6-0-LCD-EP-.../3D6-1-LCD-ES-... features four key buttons, W, X, Vand
Qto reach the individual menus and submenus for programming the device. The 6-digit LCD serves to dis-
play the currently selected measuring values. Six green LEDs indicate the significance of the measured data
as well as different messages
5.2 LEDs
LED „K“
LED „M“
LED „G“
Whilethe LCDshowsthetype ofmeasurementandthemeasurednumericalvalue,
the three prefix LEDs “K”, M” and “G” show the significance of the unscaled unit. It
is decisive which LED is active:
-"K" means that the value is shown in "Kilo..." (e.g. [kW]),
-"M" stands for "Mega..." (e.g. [MVArh]) and
-"G" corresponds to "Giga..." (e.g. [GVA])
-Ifno LED is active, the value is represented as unscaled unit.
LED „Error“ This LED flashes if an error message is waiting or an error has occurred.
LED „ “ The LED lights up when the input external measuring period synchronization
is activated and a synchronous pulse is applied (e.g. from energy supplier).
LED „ “ This LED always flashes when the pulse output is active.

User Manual multicount
Version 2.00 Page 11 of 34
EDEBDA0145 / 4709-1 GB
6 Measuring values of the multicount 3D6-0-LCD-EP-.../3D6-1-
LCD-ES-... and their representation
The following section provides an overview of the measuring values of the multicount 3D6-0-LCD-EP-.../
3D6-1-LCD-ES-... and their representation on the device. The respective measuring range switches
automatically in the display.
6.1 Display of active or reactive energy measurement
It can be seen in the LC display through T1 or T2 whether the period is high or low tariff. The currently active
tariff is indicated by flashing of T1 or T2. (Two-tariff counter function only fori multicount 3D6-1-LCD-ES-
...)
The five digit places and the Prefix LEDs serve to show the instantaneous meter count.
As long as the meter count does not exceed 9999kWh, the entire meter count is displayed in one menu. From
10 MWh the display is divided into several menus so that more than five places can be read. These menus can
be called up using the A key. The overall value results from simply writing out the individual values one after
another.
Exampel:
Display:
Display of the Active energy W Act in kWh, MWh or GWh and the reactive energy WReact in kVArh, MVArh
or GVArh. The output measuring value must be multiplied with the respective significance ”Kilo”, ”Mega” or ”Gi-
ga”, depending on the active LED.
Display: High tariff HT Display: Active energy [Wh]
Display: Lowtariff NT Display: Reactive energy [Varh]
Display: Consumption or recovery 5 places for measured value display
000000
T1 Wh
T2 Varh
T1 Wh
T1 Wh
T1 Wh
12 G
M
k
X
345 G
M
k
X
g78.9 G
M
k
X

User Manual multicount
Page 12 of 34 Version 2.00
EDEBDA0145 / 4709-1 GB
6.2 Display of power measurement
The entire active power measurement is marked with a"p"in the first position, "s"tands for total apparent pow-
er measurement and "q"for total reactive power measurement.
Active power during energy consumption is displayed without polarity sign, during energy recovery
(multicount 3D6-1-LCD-ES-... only) with a negative polarity sign.
For inductive reactive power, the measured value is preceded by an "i" capacitive reactive power is iden-
tified by a "c".
For the display of the measured values themselves the same principles apply as for the display of active and
reactive energy. The output measuring value must be multiplied with the respective display significance ”Kilo”,
”Mega” or ”Giga”, depending on the active LED.
Display of active power in W, kW, MW, GW, the apparent power S in VA, kVA, MVA, GVA and the reactive
power Q in Var, kvar, Mvar, Gvar.
6.2.1 Display for energy consumption or recovery (multicount 3D6-1-LCD-ES-... only)
Whether energy is recovered can be determined by means of the polarity sign for the active power and the
continuous meter.
6.2.2 Display of the power factor
If the power factor λis measured, this is indicated by “PF” (power factor) in the first of the two places in the
display.
by definition the power factor is the relationship of the active power to apparent power
In contrast to the cos ϕ. for the power factor λthe proportion of distorted reactive power is included in the
calculation.
Display of the power factor λin the range 0.00 to 1.00.
λpPF P
S
------==
⎝
⎠
⎛
⎞

User Manual multicount
Version 2.00 Page 13 of 34
EDEBDA0145 / 4709-1 GB
7 Programming
Programming of the energy meter multicount 3D6-0-LCD-EP-.../3D6-1-LCD-ES-... is done using the 4
keys W,X, Vand Q.
7.1 Working with the display menu
Pressing the navigation key Wjumps to the respective following menu item. If the key Wis kept depressed,
the menus will be switched through with a new menu being activated every 0.5 seconds.
bNote The active tariff is displayed by permanent flashing of the
respective tariff display T1 or T2 in each display menu.
Active energy for
low tariff !2.35
Wh Display of the accumulated active energy
in low tariff
The tariff display T2 (low tariff) lights up
permanently
The tariff display T1 flashes, i.e. the
current counting tariff is T1 (high tariff).
§
Menu LC-Display Unscaled unit
Active energy WAct for high tariff !2345.g Wh kWh if the prefix LED "k" lights up. (if the
prefix LED "G" or "M" lights up, other
menus are available)
Continue in basic menu W
or XFor meter count detailed view
!2Wh Detailed view giga-watt hours
GWh if the prefix LED “G” is active
Continue with Xor Wto jump
back to basic menu
!45g Wh Detailed view mega-watt hours
MWh if the prefix LED “M” is activet
Continue with Xor Wto jump
back to basic menu
!789.5 Wh Detailed view kilo-watt hours
kWh if the prefix LED "K" lights up
Back to main menu
Xor W
Active energy WAct for Low tariff
(multicount 3D6-1-LCD-ES-...
only) 2345.g Wh kWh if the prefix LED "k" lights up. (if the
prefix LED "G" or "M" lights up, other me-
nus are available)
§

User Manual multicount
Page 14 of 34 Version 2.00
EDEBDA0145 / 4709-1 GB
Continue in basic menu W
or X
For meter count detailed view
2Wh Detailed view giga-watt hours
GWh if the prefix LED “G” is active
§
Continue with Xor Wto jump
back to basic menu
45g Wh Detailed view mega-watt hours
MWh if the prefix LED “M” is active.
§
Continue with Xor Wto jump
back to basic menu
789.5 Wh Detailed view kilo-watt hours
kWh if the prefix LED "K" lights up.
§
Continue with Xor Wto jump
back to basic menu
Reactive energy React for high
tariff
!2345.g kvarh if the prefix LED "k" lights up.
(if the prefix LED "G" or "M" lights up,
other menus are available)
Varh
Continue in basic menu W
or X
For meter count detailed view
!2Detailed view giga-var hours
Gvarh if the prefix LED “G” is active
Varh
Continue with Xor Wto jump
back to basic menu
!45g Detailed view mega-var hours
Mvarh if the prefix LED “M” is active
Varh
Continue with Xor Wto jump
back to basic menu
!789.5 Detailed view kilo-var hours
kvarh if the prefix LED "K" lights up.
Varh
Continue in basic menu W
or X
Reactive energy React for low
tariff
(multicount 3D6-1-LCD-ES-...only) 2345.g kvarh if the prefix LED "k" lights up. (if the
prefix LED "G" or "M" lights up, other me-
nus are available)
§Varh
Continue in basic menu W
or XFor meter count detailed view
