Keiser M SERIES Use and care manual

CALIBRATING YOUR KEISER M SERIES EQUIPMENT
Procedure for software vers on U406 and above
STEP 1
STEP 2
STEP 3
555512_D
1 ROTATION ONLY
Turns on Computer
Be sure to read all steps very closely before beg nn ng. You have 25 seconds to go from
ST P 2 to ST P 9. After 25 seconds the computer will exit calibration mode and you must
allow it to shutdown before attempting to calibrate again. All work is done from the left
side of the machine, except on the M5, the work is done from the right and the plastic
cover must be removed.
Move the red shifter handle all the
way down.
Note: If you are unsure of your software
version, check the version by removing the
batteries for at least 20 seconds. Reinstall
the batteries and watch the display during
start-up for “U###”. Allow the computer to
go to sleep before continuing to step 2.
Slowly rotate the pedal until the
computer turns on. Once it comes
on, continue turning for one-half
revolution then stop the crank
arm. Zeroes will appear on the
time slot on the display as shown
to the right.
Slide your red calibration tool onto
the flywheel as shown.

CALIBRATING YOUR KEISER M SERIES EQUIPMENT
Procedure for software vers on U406 and above
STEP 4
STEP 5
STEP 6
555512_D
The magnets must align with the
tool as shown in the detail view
Pull the calibration tool
upward to the magnet
housing.
Turn the magnet housing
counter/anti-clockwise and
allow the magnets to rotate
into your calibration tool.
Release the magnet housing.
It will automatically make a
slight clockwise turn back
into its resting position.

CALIBRATING YOUR KEISER M SERIES EQUIPMENT
Procedure for software vers on U406 and above
STEP 7
STEP 8
STEP 9
555512_D
6X
1 ROTATION ONLY
Until the computer shows 0:01 in the time row
Slide the calibration tool
from the magnet housing.
Remove the calibration
tool from the flywheel.
Rotate the pedal, no more
than one turn, until the
computer shows 0:01 in the
time row, continue turning
for one-half revolution
then stop the crank arm.
Once you see 0:01 appear
on the display, twist and
release the magnet housing
6 times. The magnet
housing must rotate from
stop to stop.

CALIBRATING YOUR KEISER M SERIES EQUIPMENT
Procedure for software vers on U406 and above
555512_D
Succesful Cal brat on
When CAL'b appears on
your display, your
Keiser M series machine
has been successfully
calibrated. Allow the
computer to go to
sleep before normal
usage.
Note: If you receive an error symbol “ rr#” on the display please allow the computer to go to
sleep then begin the calibration process again from Step 1. If the problem continues, note the
error number that appeared on your display and contact Keiser service at 1-800-888-7009 or
via email at [e-mail].
For a v deo demonstrat on on cal brat on, browse the nternet to: http://www.ke ser.com.
