Kenmore 580.72187300 Manual

REPAIR
PARTS
LIST
Model No.
580.72187300
◆Product Type ◆Part Number
◆Model Number ◆Part Description
Sears, Reobuck and Co., Hoffman Estates, IL 60179 U.S.A.
To Call
Toll Free
For Parts:
1-800-366-PART
(1-800-366-7278)
1-800-4-MY-HOME
(1-800-469-4663)
For Service:
The model number of your Air Conditioner can be found
on the right side of the cabinet.
All repair parts listed are available for immediate
purchase or special order when you visit your nearest
Sears Service Center, or the Service Department at most
Sears stores. To order parts by phone, call the toll free
parts number listed to the left.
When requesting service or ordering parts, always
provide the following information:
®
ROOM AIR CONDITIONER
OFFON
Auto Swing
TurnoffAutoSwing
WhenOperationSwitchisoff

04/03 - 2 -
4-A
2-A
5-A
6-A
1-A
7-A
3-A
REPAIR PARTS
Room Air Conditioner To order Parts call Toll Free
Model No. 580.72187300 1-800-4-MY-HOME®(1-800-469-4663)
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
CABINET & FRONT GRILLE ASSEMBLY

- 3 - 04/03
580.72187300
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
CABINET & FRONT GRILLE ASSEMBLY
# = Functional Parts
* = Non-illustrated Parts
ILLUSTRATION NUMBER
1 - A
2 - A
3 - A
4 - A
5 - A
6 - A
7 - A
*
*
PART NUMBER
3530AR1182A
3530AR1531A
5230AR1327A
5990AR2972C
3091AR6057C
2H00858E
3850A20423G
3828A20292K
3828A30032T
DESCRIPTION
FRONT GRILLE
INLET GRILLE
AIR FILTER ASSEMBLY
VANE
CABINET ASSEMBLY
UPPER GUIDE
LABEL, ENERGY
MANUAL OWNER'S
MANUAL SERVICE

04/03 - 4 -
580.72187300
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
CONTROL BOX ASSEMBLY
2-B14-B10-B 1-B 4-B16-B12-B
3-B
15-B
9-B
17-B
6-B
7-B
8-B
13-B
11-B
5-B

- 5 - 04/03
580.72187300
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
CONTROL BOX ASSEMBLY
# = Functional Parts
* = Non-illustrated Parts
ILLUSTRATION NUMBER
1 - B #
2 - B
3 - B
4 - B
5 - B #
6 - B
7 - B
8 - B
9 - B
10 - B
11 - B
12 - B
13 - B
14 - B
15 - B
16 - B
17 - B
PART NUMBER
4994AR1587A
2H01127B
2H00598F
6120AR2359E
2H00677U
4941AR7134C
2H01316C
3721A20058K
4004AR4357A
6631AR2687P
2H01102A
4520AR4386A
4520AR4339A
6877A20002A
3551A30015A
4H00442F
3661AR6149C
DESCRIPTION
CONTROL BOX
THERMOSTAT
ROTARY SWITCH
SH CAPACITOR
POWER CORD ASSEMBLY
KNOB ASS’Y
ROCKER SWITCH
PANEL, CONTROL
CLIP CORD
CONNECTOR ASSEMBLY
SYNCHRONOUS MOTOR
LINK
CAM
CONNECTOR ASSEMBLY
COVER, CONTROL BOX
CLAMP, CAPACITOR
HOUSING ASSEMBLY(MECH)

04/03 - 6 -
580.72187300
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
AIR HANDLING & CYCLE PARTS
5-C
6-C
9-C
7-C
8-C
12-C
10-C
11-C
2-C
22-C
1-C
4-C
15-C
16-C
21-C
13-C
3-C
14-C
11-C
20-C
19-C
17-C
18-C
23-C
24-C

- 7 - 04/03
580.72187300
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
AIR HANDLING & CYCLE PARTS
# = Functional Parts
* = Non-illustrated Parts
ILLUSTRATION NUMBER
1 - C
2 - C
3 - C
4 - C
5 - C
6 - C
7 - C #
8 - C
9 - C #
10 - C #
11 - C
12 - C
13 - C
14 - C #
15 - C #
16 - C
17 - C
18 - C
19 - C
20 - C
21 - C
22 - C
23 - C
24 - C
PART NUMBER
3041A30002Y
5238AR1584B
3072AR1583A
4790AR1558A
4900AR7265A
4960AR1596A
4681AR6033K
3040AR6160A
5834AR1599B
5900AR1508A
3H02932C
4998AR1597A
4800AR7272A
5421A20059F
5403A20004F
3550AR6173A
4H01029F
3H02773A
4H00261A
4H02023A
3530A20042D
5301A30001B
5220A30006A
3661A20014B
DESCRIPTION
BASE PAN WELD ASSEMBLY
AIR GUIDE
SCROLL
BARRIER
DAMPER
MOTOR MOUNT
MOTOR ASSEMBLY
INSULATION, EPS
BLOWER
FAN
CLAMP SPRING
SHROUD
BRACE
EVAPORATOR ASSEMBLY
CONDENSER ASSEMBLY
COVER, SHROUD
WASHER RUBBER
DRAIN PIPE
PIPE ELBOW
HOLE RUBBER
GRILLE, REAR
ELECTRIC HEATER ASSEMBLY
DRAIN VALVE
HOUSING ASSEMBLY(MECH)

04/03 - 8 -
580.72187300
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
COMPRESSOR PARTS
1-D
3-D
4-D
2-D
5-D
6-D
7-D
9-D
8-D
10-D 11-D
12-D
13-D
14-D
16-D
15-D

- 9 - 04/03
580.72187300
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
COMPRESSOR PARTS
# = Functional Parts
* = Non-illustrated Parts
ILLUSTRATION NUMBER
1 - D
2 - D #
3 - D
4 - D
5 - D
6 - D
7 - D
8 - D
9 - D
10 - D
11 - D
12 - D
13 - D
14 - D
15 - D
16 - D
PART NUMBER
4H00982C
5416A20003J
4H01811C
1NHA0801206
6877A20002B
4986U-L001D
3550U-L002C
4H01058A
4H00947A
5211A30066K
5211A20204C
5211A20433B
5211A20434B
5211AR7059W
5211A20020P
5851A30001F
DESCRIPTION
ANTI-VIBRATION BUSHING
COMPRESSOR ASSEMBLY
BRACKET, WASHER
HEXAGON NUTS
CONNECTOR ASSEMBLY
GASKET
TERMINAL COVER
GASKET NUT
TERMINAL COVER NUT
TUBE ASSEMBLY, DISCHARGE
TUBE ASSEMBLY SUCTION
TUBE ASSEMBLY, EVA IN
TUBE ASSEMBLY, EVA IN
TUBE CONNECTION, COND. OUT
TUBE, CAPILLARY
DRIER, ASSEMBLY

04/03 - 10 -
580.72187300
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
INSTALLATION KIT ASSEMBLY
1-E
4-E
6-E
2-E
7-E 5-E
3-E
8-E

- 11 - 04/03
580.72187300
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
INSTALLATION KIT ASSEMBLY
# = Functional Parts
* = Non-illustrated Parts
ILLUSTRATION NUMBER
1 - E
2 - E
3 - E
4 - E
5 - E
6 - E
7 - E
8 - E
PART NUMBER
4H01785B
4959AR3402E
4959AR3402F
3H01479D
3H01395C
4H01516A
4H01483A
4H01482A
DESCRIPTION
LBRACKET
CURTAIN ASSEMBLY
CURTAIN ASSEMBLY
SUPPORT BRACKET
SILL BRACKET
LOCK NUT
CARRIAGE BOLT
M-SCREW
