USEAND CAREGUIDE
STOUT1LIGHTLANTERN-#93206
Questions,problems, missingparts?Beforereturningtothestore,
call Kenroy HomeCustomerService
8a.m.-6p.m., EST, Monday-Friday
904-642-4340
THANKYOU
Weappreciatethetrustand confidence you haveplacedinKenroyHomethrough thepurchaseofthislantern.
Westrivetocontinuallycreatequalityproductsdesignedto enhance yourhome.
Thank you forchoosing us!

TableofContents
SafetyInformation .......................................................................................................................................2
Warranty......................................................................................................................................................2
Pre-Installation............................................................................................................................................3
PlanningInstallation.............................................................................................................................3
PackageContents.................................................................................................................................. 4
Installation..................................................................................................................................................5,6
CareandCleaning........................................................................................................................................7
Troubleshooting ............................................................................................................................................7
SafetyInformation
Consultaqualifiedelectricianwithany
electrical questionsyoumayhave.
Warranty
1-YEAR LIMITEDWARRANTY
WHATIS COVERED
Themanufacturerwarrantsthislanterntobefreefrom defectsinthematerialsandworkmanshipforaperiod
ofone(1)yearfromdateofpurchase.Thiswarrantyapplies onlytotheoriginalconsumerpurchaserand
onlytoproductsusedinnormaluse.Ifthis productis foundtobedefective, themanufacturer'sonly
obligation,andyourexclusiveremedy, istherepairorreplacementoftheproductatthemanufacturer's
discretion, providedthattheproducthasnotbeendamagedthrough misuse,abuse,accident,modifications,
alterations,neglectormishandling.This warrantyshallnotapplytoanyproductthatis foundtohavebeen
improperlyinstalled, assembled,orusedinanywaynotinaccordance withtheinstructionssuppliedwiththe
product.Thiswarrantyshallnotapplytoafailureoftheproductasaresult ofanaccident,misuse,abuse,
negligence,alteration,faultyinstallation, oranyotherfailurenotrelatingtofaultymaterialor workmanship.
WHATIS NOTCOVERED
This warrantyshall notapplytothefinishonanyportionoftheproductduetoweathering, as this is
considerednormalwear.Themanufacturerdoesnotwarrantandspecificallydisclaimsanywarranty,whether
expressedor implied,otherthanthewarrantycontainedherein.Themanufacturerspecificallydisclaimsany
liabilityandshallnotbeliable forany consequentialor incidentalloss or damage,including butnotlimited
to,anylaboror expensecostsinvolvedinthereplacementor repairoftheproduct.
ContacttheCustomerServiceTeamat904-642-4340.
IMPORTANT:Inspectthewireinsulation for
anycuts,abrasions,or exposedcopperthatmay
haveoccurredduring shipping. Ifthereisa
defectinthewire,donotcontinuetheassembly
process. PleasecallourCustomerServiceTeam
at904-642-4340.
2

Pre-Installation
PLANNINGINSTALLATION
Readallinstructionsbeforeassembly.
Toavoiddamagingthisproduct,assembleitonasoft,non-abrasivesurfacesuchascarpet
or cardboard. Inspecteachpartfor defects thatmayhaveoccurredduring shipping.
Keepyourreceiptand theseinstructions forproofofpurchase.
NOTE:Thislanternrequirestheuseofone120V,60Hz,
60-Wattmax,medium-basetypeAbulb(not included).
Do notexceedtherecommendedwattage.
TOOLSREQUIRED
Wire
strippers Wirecutters
Flathead
screwdriver
Phillips
screwdriver
Ladder
Electrical
tape
HARDWAREINCLUDED
NOTE:Hardwarenotshowntoactualsize.
AA BB CC EE
DD
Part
AA
BB
CC
DD
EE
Description
Mounting plateassembly
Wirenut
Outlet boxscrew
Finial
Groundscrew
Quantity
3
1
2
1
2
3

Pre-Installation (continued)
PACKAGECONTENTS
Part
A
Description Quantity
1
Lanternbody
4
A
B
C
B1
Metal shade
C1
Socketring

1. Removingthemountingplate
Removethemountingplateassembly(BB)from
thelanternbody(A)byunscrewingthetwofinials
(DD).
Installationinstructions
5
BB
DD
DANGER:Ensurethepowerisoffatthemain
fusebox priortobeginning installation.
2. Installingthemountingplate
Turnofftheswitchat thewall.
Turnthepoweroffatthemainfusebox.
Attachthemountingplate assembly(BB)tothe
outletboxusingtheoutlet boxscrews (CC).
CC
BB
A
3. Connectingthewires
Install thefixturebarecopperground wire(1)
undertheground screw (EE) onthemounting
plate (BB).
Connectthefixturebarecopperground wire(1)
tothegreen(or bare, or green&yellow)supply
groundwire(2)intheoutletboxusing awire
nut(AA).
Connectthewhitefixturewire(3)tothewhite
(orribbed)supplywire(4)intheoutletbox
usingawirenut(AA).
Connecttheblackfixturewire(5)totheblack
(or red,orblue)supplywire(6)intheoutletbox
usingawirenut(AA).
Housewire
black
(orred, orblue)
(HOT)
Fixturewire
black
(HOT)
Housewire
white
(NEUTRAL)
Fixturewire
white
(NEUTRAL)
Housewire
green
(orbare wire,
orgreen&yellow)
(GROUND)
Fixturewire
bare wire
(GROUND)
2
EE
1615
3
AA
4

Installationinstructions(continued)
6
4. Installing thefixture
Raiselanternbody(A)tothewallandcarefully
tuckthewiresinsidetheoutlet box.Spreadthe
electrical splicessothat theblackwires areon
onesideoftheoutlet boxandthewhitewires
areontheotherside.lineupscrewswithholes
inbackplateandsecurewithtwofinials(DD).
Backplate
5. Sealingthemountingsurface
ApplysiliconorRTVcompoundbetweenthe
edgesofbackplate andwall.
6. Assemblingtheshade&
installingthebulb
Removethesocketring (C)fromsocketby
unscrewingthesocketring (C).
Place themetalshade(B)oversocketand secure
withthesocket ring (C).
Priortoinstallingthebulb,pleaseinspectsocket
forsilicapacket.ifpacketispresent,removeand
throwaway. do notexposetochildrenandpets.
Install one120V, 60Hz, 60-wattmax.
medium-basetypeAbulb(notincluded) intothe
socket onthelightfixture.
Backplate
Bulb
(not included)
DD
A
A
B
C

CareandCleaning
Cleanthelightfixturewith asoft,dry cloth. Donotuseany cleanerswith chemicals,solvents, orharsh abrasives.
Troubleshooting
PossibleCause
Thebulbisburnedout.
Thepowerisoff.
Thereisafaultywireconnection.
Thecircuitbreakerisoff.
Thereisanexposedwire.
Therearetoo manyitemson
onecircuit.
Discontinueuseofthelight
fixture.
Contact aqualifiedelectricianor
calltheCustomerServiceTeam at
904-642-4340.
Unplug otheritemson thecircuit.
Ensurethat thecircuitbreaker
issetintheonposition.
Checkthewiring.
Ensurethat thepowersupply
isturnedon.
Replacethelightbulb.
Solution
Thebulbwill notlight.
Thefuseblowsora
circuitbreakertripswhen
thelight isturnedon.
Problem
7
Installationinstructions(continued)
