USEANDCAREGUIDE
DALE 1LIGHTLANTERN-#93506,#93507
Questions,problems,missingparts?Beforereturningtothestore,
callKenroyHomeCustomerService
8a.m.-6p.m.,EST,Monday-Friday
904-642-4340
THANKYOU
Weappreciatethetrust and confidence you haveplacedinKenroyHome throughthepurchaseofthis lantern.
Westrivetocontinuallycreatequalityproductsdesignedtoenhanceyourhome.
Thankyouforchoosingus!

Table ofContents
Safety Information ....................................................................................................................................... 2
Warranty ......................................................................................................................................................2
Pre-Installation............................................................................................................................................ 3
PlanningInstallation.............................................................................................................................3
PackageContents.................................................................................................................................. 4
Installation................................................................................................................................................5,6
CareandCleaning........................................................................................................................................ 7
Troubleshooting............................................................................................................................................ 7
Safety Information
Consult aqualifiedelectricianwith any
electricalquestionsyou mayhave.
Warranty
1-YEARLIMITEDWARRANTY
WHAT ISCOVERED
Themanufacturerwarrantsthislanterntobefreefromdefects inthematerialsand workmanshipforaperiod
ofone(1)yearfromdateofpurchase.Thiswarranty appliesonly totheoriginalconsumerpurchaserand
only toproductsusedinnormaluse.Ifthisproductisfound tobedefective,themanufacturer's only
obligation,and yourexclusiveremedy, istherepairorreplacementoftheproductatthemanufacturer's
discretion,providedthattheproducthasnotbeendamagedthrough misuse,abuse,accident,modifications,
alterations,neglectormishandling. Thiswarranty shallnotapplytoany productthatisfound tohavebeen
improperlyinstalled,assembled,orusedinanywaynotinaccordance with theinstructionssuppliedwith the
product.Thiswarranty shall notapply toafailureoftheproductasaresultofanaccident,misuse, abuse,
negligence,alteration, faultyinstallation,oranyotherfailurenotrelatingtofaultymaterialorworkmanship.
WHAT ISNOT COVERED
This warrantyshall notapply tothefinishonanyportion oftheproductduetoweathering,asthisis
considerednormalwear. Themanufacturerdoes notwarrantand specificallydisclaimsany warranty,whether
expressedorimplied,otherthanthewarrantycontainedherein. Themanufacturerspecifically disclaimsany
liabilityand shall notbeliableforany consequentialorincidentalloss ordamage,includingbutnotlimited
to,any labororexpensecostsinvolvedinthereplacementorrepairoftheproduct.
ContacttheCustomerServiceTeamat904-642-4340.
IMPORTANT:Inspectthewireinsulation for
any cuts, abrasions, orexposedcopperthatmay
haveoccurredduring shipping.Ifthereisa
defectinthewire,do not continuetheassembly
process. PleasecallourCustomerService Team
at904-642-4340.
2

Pre-Installation
PLANNINGINSTALLATION
Readall instructions beforeassembly.
Toavoiddamaging this product, assembleit on asoft, non-abrasivesurface suchas carpet
orcardboard. Inspecteachpartfordefects thatmayhaveoccurredduring shipping.
Keepyourreceiptand theseinstructions forproofofpurchase.
NOTE:Thislanternrequirestheuseof one120V, 60Hz, 60-Wattmax,medium-base
typeA bulb (notincluded).Donotexceedtherecommendedwattage.
TOOLSREQUIRED
Safety
goggles
Wire
strippers Wirecutters
Flathead
screwdriver
Phillips
screwdriver
Ladder Electrical
tape
Pliers
HARDWAREINCLUDED
NOTE:Hardwarenotshowntoactualsize.
AA BB CC EE
DD FF GG
Part
AA
BB
CC
DD
EE
Description
Mounting plate
Wirenut
Outlet boxscrew
Mountingscrew
Groundscrew
Quantity
3
1
2
2
FF Small nut
GG Finial
1
2
2
3
NOTE: Thisitemisratedforwetlocation: IP03.

Pre-Installation (continued)
PACKAGE CONTENTS
Part
A
Description Quantity
1
Fixturebody
A
4

1. Removethemountingplate
Removethemountng plate(BB)frombackof
thebackplateby unscrewing twofinials (GG).
Installation instructions 3. Connectingthewires
Installthefixturebarecoppergroundwire(1)
underthegroundscrew(EE)on themounting
plate(BB).
Connectthefixturebarecoppergroundwire(1)
tothegreen(orbare, orgreen&yellow)supply
ground wire(2)intheoutletbox using awire
nut(AA).
Connectthewhitefixturewire(3)tothewhite
(orribbed)supplywire(4)intheoutletbox
using awirenut(AA).
Connecttheblackfixturewire(5)totheblack
(orred, orblue)supplywire(6)intheoutletbox
using awirenut(AA).
CAUTION:Ensurethepowerisoffat the main
fuseboxprior tobeginning installation.
BB GG
2. Installing themountingplate
Turnoff theswitchatthewall.
Turnthepoweroff atthemainfusebox.
Attachthemounting plate(BB)totheoutletbox
using theoutletboxscrews (CC).
CC
BB
5
6
4 3
1
2
AA
EE 1
Housewire
black
(orred,orblue)
(HOT)
Fixturewire
black
(HOT)
Housewire
white
(NEUTRAL)
Fixturewire
white
(NEUTRAL)
Housewire
green
(orbarewire,
orgreen&yellow)
(GROUND)
Fixturewire
barewire
(GROUND)
5
Backplate

Installation instructions (continued)
4. Installingthefixtureand bulb
Pushallexcess wires into theoutletbox.
Align theholes inbackplatewithtwo mounting screws (DD), and thensecurethefixtureto thewallwith
twofinials(GG).
Applysilicon orRTVcompound betweentheedges ofbackplateand wall.
Priortoinstalling thebulb,pleaseinspectsocketforsilica packet.ifpacketispresent,removeand throw
away. do not exposetochildrenand pets.
Install one120V, 60Hz,60-wattmax.medium-basetypeAbulb(notincluded)intothesocketin fixture
body (A).
GG
DD Backplate
Bulb
(notincluded)
A
6

Careand Cleaning
Clean the lightfixture witha soft, drycloth. Donotuse any cleaners withchemicals, solvents, orharshabrasives.
Troubleshooting
PossibleCause
Thebulbisburnedout.
Thepowerisoff.
Thereisafaultywireconnection.
Thecircuit breaker isoff.
Thereisanexposedwire.
Therearetoomanyitemson
onecircuit.
Discontinueuseofthelight
fixture.
Contact aqualifiedelectricianor
call theCustomerService Teamat
904-642-4340.
Unplug other itemson thecircuit.
Ensurethat thecircuit breaker
isset intheonposition.
Checkthewiring.
Ensurethat thepowersupply
isturnedon.
Replace thelightbulb.
Solution
Thebulbwill notlight.
Thefuseblowsora
circuitbreaker tripswhen
thelightisturnedon.
Problem
7
