KENT Elite Plus-New User manual

Instruction Handbook
for Installation, Operation
and Maintenance.
Removes Dissolved Impurities
Retains Essential Minerals
Multiple Purification
RO + UV + UF + TDS Control
Marketed by:
KENT RO SYSTEMS LTD.
E-6, 7 & 8, Sector-59, Noida, U.P.-201 309, India.
E-mail: [e-mail] | Website: www.kent.co.in
Manufactured by:
KENT RO SYSTEMS LTD.
1) Khasra No. 93, Village-Bantakhedi, Tehsil-Roorkee,
District-Haridwar, Uttarakhand-247 668, India.
2) A-6, Sector-87, Noida-201 305, U.P., India.
For customer complaints, contact our customer care officer at:
E-6, 7 & 8, Sector-59, Noida, UP-201 309, India. Call: 92-789-12345
E-mail: [e-mail] or visit us at www.kent.co.in
Reverse Osmosis Water Purifier with
Ultra Filtration /Ultra Violet Process & TDS Controller
TM
Mineral RO © 2005 - 2019 KENT RO SYSTEMS LTD, the process & purifier is patented vide patent no. 199716.
Reverse Osmosis Water Purifier + Ultra Violet + Ultra Filtration Purification + TDS Controller
NEW
Reverse Osmosis Water Purifier with
Ultra Filtration / Ultra Violet Process & TDS Controller
online
purification
online
purification

Dear Customer
Welcome to the world of KENT, leader of water purification industry in India. With
a KENT product you, have all the reasons to smile, since at KENT we take pride
in the quality and laboratory-tested performance of our products.
We are confident that your decision to own KENT Elite Plus-New Water Purifier
will go a long way in serving you with pure and mineral enriched drinking water,
thus keeping you and your family in good health. We assure you, that you will be
satisfied with its trouble-free performance and quality, which comes without any
compromise.
This manual is an effort towards familiarising you with the operation and
maintenance of KENT Elite Plus-New. Before operating the unit, please read it
thoroughly and retain it for future reference.
Best Wishes,
KENT RO SYSTEMS LTD.
to KENT
Table of Contents
1. KENT TECHNOLOGY - A Breakthrough in Water Purification 1
2. Salient Features 1
3. Items in the Box 1
4. Important Instructions 2
5. Reverse Osmosis Process 3
6. UV Process 3
7. Auto-flushing System 3
8. Water Flow Diagram 4
9. Electrical Circuit Diagram 4
10. UV Fail Alarm 5
11. Filter Change Alarm 5
12. Automatic Operation 5
13. Installation Instructions 5
14. TDS Adjustment 7
15. Starting-up the Purifier 7
16. Recommended Usage of Rejected Water 7
17. Maintenance 7
18. Important Safety Instructions 7
19. Warning 7
20. Recommended Frequency for Filters/Membrane Change 8
21. Technical Specifications 8
22. Testing Information 8

1
Important Instructions
2
KENT proudly presents KENT Elite Plus-New - a technologically advanced commercial water
purifier based on the patented KENT Technology. The ground-breaking KENT Technology,
developed at KENT laboratory, broadly comprises of state-of-the-art RO+UV+UF+TDS Control
System. While the initial purification by RO membrane having porosity as fine as 0.0001
microns effectively removes even dissolved impurities (hard salts, heavy metals, etc.), the
double purification by UF process ensures protection against bacteria and viruses. Moreover,
the patented TDS Control System intelligently retains essential natural minerals in purified
water, thus taking total care of your health and well-being.
KENT TECHNOLOGY - A Breakthrough
in Water Purification
Salient Features of KENT Elite Plus-New Water Purifier
nHigh Purification Capacity of 50 L/hr.*
nSuitable for attachment to water coolers
n + Double Purification by RO UV + UF
effectively filter out bacteria, viruses and cysts
nAdjustable TDS Control System facilitates TDS
adjustment in purified water
nFully automatic operation with auto-on and
auto-off function
nFTamper-proof RO/U Membranes fused
inside membrane housing
nPush-fit components for leak-proof &
maintenance-free performance
n Horizontally mounted SMPS for protection
against high voltage
n ABS construction for corrosion-free life span
n Suitable for Purification of Brackish/ Tap
Water/Municipal Corporation Water
n Filter change alarm to indicate filter
replacement time
n Inbuilt auto-flushing system
n High flow membrane
1. KENT Elite Plus-New Water Purifier : 1 N
2. 3-Way Connector : 1 N
3. S.S. Ball Valve : 1 N
4. Food Grade Pipe (Blue) ¼ inch : 2.5 M
3
5. Food Grade Pipe (White) / inch : 2.5 M
8
6. Food Grade Pipe (White) ¼ inch : 2.5 M
7. Screws & Plastic Inserts : 2 N
8. Warranty Card : 1 N
Items in the Box
Avoid exposure to direct sunlight
and installation in damp areas.
Make sure that the purifier is
connected to normal temperature
water supply only.
10 M
Water Source
Water in
Do not place the reject water pipe at a
level higher than the purifier, else
reject water may flow backwards into
the purifier.
Reject Water
Drain
Maximum distance between the
purifier and water source should not
be more than 3 meters.
Do not confine the
purifier in a cabinet.
Avoid sharp bends in pipe.
Do not block the reject water pipe.
Do not try to service the purifier on your own.
Instead, call the service technician for help.
Use Genuine KENT Spare Parts for optimum performance.
*Treatment capacity tested for tap water having TDS level of 750 ppm at room temperature

3
Reverse Osmosis also known as Hyper Filtration,
is the finest filtration process known till date. The
process ensures removal of particles as small as
ions from a solution. Reverse Osmosis process
uses a semi-permeable membrane to reduce the
dissolved salts from potable / brackish water. In
Reverse Osmosis, water pressure is applied on the
inlet impure water resulting into the squeezing of
purer wa ter from the concentrated end of
membrane towards the diluted end. Dissolved
salts present in water as charged ions get repelled
by the RO membrane and are not allowed to pass
through. Similarly, bacteria and germs are also
blocked by the ultra-fine pores of RO membrane. These rejected impurities suspended on the
concentrated end of the membrane are washed away in a stream of waste water preventing the
membrane from clogging.
Reverse Osmosis Process
Waste Stream
to Drain
Auto-flushing System
The purpose of the Auto-flushing System is to help prevent scaling or fouling of the RO
membrane by providing a rapid rinse which washes away impurities from the membrane's
surface and keeps the membrane clean. It offers following benefits:
n Lowers outflow of rejected water.
n Improves TDS rejection rate i.e increases RO membranes efficiency.
n Extends life of RO membrane.
UV Process
The ultra-violet (UV) light has shorter wavelength (higher energy) than visible light. It is called ultra-
violet because it is just beyond violet light in the light spectrum. Technically, ultra-violet light is
defined to be any wavelength of light, which is shorter than 400 nanometer.
UV rays, which penetrate into micro-organisms, are absorbed by the DNA of pathogen, in the water.
The DNA is altered in such a way that the pathogen cannot reproduce itself. Thus, it is essentially
killed and cannot cause infection. This process of DNA modification is called inactivation.
700400
Wavelength(nm)
UVB
280-315 UVA
315-400
UVC
200-280
X-Rays Ultraviolet Visible Infrared Microwaves Radio
4
Water Flow Diagram
The above specifications are subject to modification for improvement without notice
Electrical Circuit Diagram

56
Use white pipe for raw water supply.
When the water cooler’s storage tank gets filled up completely the
float in the cooler will cut off the RO purified water supply from
KENT Elite Plus -New. This will further create a water pressure. In
turn the high pressure sensor installed in the machine will cut off
the electric supply to the machine. The purification of KENT Elite
Plus-New will automatically start again as soon as the water level
drops.
ELECTRICITY
WATER
SUPPLY REJECT WATER
RO WATER
WATER COOLER
TO FLOAT
Use blue pipe for reject water.
KENT Elite Plus-New is designed to facilitate wall mounting as well as counter-top purification.
It is easy and convenient to install.
Recommended Site Preparations:
n Single phase 100-250 V AC, 50-60 Hz. supply not more than 3m away from the point of
installation
n Raw water supply with ½ inch nipple not more than 3m away
n Drain for reject water not more than 3m away
n Installation space as per the dimensions of the purifier
n For proper installation, make sure that the purifier is mounted on a wall surface. Avoid
installation on wooden and metallic stands
n For optimum inlet pressure, source water tank should be at least 10 ft. above the purifier
installed
Installation Instructions
Automatic Operation
nThe purifier automatically shuts off when the tank is full.
2
nThe purifier does not start when inlet water supply pressure fall below 0.3kg/cm
nThe purifier automatically restarts when the water level drops below the maximum level
nThe purifier does not allow any water rejection in absence of electricity/when tank is full
nThe purifier automatically flushes & cleans the RO membrane on periodic intervals
234mm
* Tested & Certified by TUV-SUD South Asia (P) Ltd.
Installation Procedure:
1. Screw in two 10x50 self taping screws, 234 mm apart
horizontally.
2. Wall-mount the purifier with the help of slot holes given on back
side.
3. Fasten the SS ball valve to ¼ inch port of 3-way connector.
4. Attach the threaded end of 3-way connector to raw water
supply and plug off the other end or connect to a tap.
5. Now connect one end of white pipe to SS ball valve and
the other end to lower elbow fitting connector labeled as
WATER IN, on the bottom of purifier.
6. Connect one end of blue pipe to upper elbow fitting connector labeled as REJECT
WATER and lead the other end to drain.
.
7. Connect the purified water pipe to the water cooler.
8. Turn on the lever given on SS ball valve to initiate the water flow to purifier.
9. Allow the filters to pre-soak in the water for 2-3 minutes.
10. Connect the power supply.
11. Installation is complete.
UV Fail Alarm*
KENT Elite Plus-New Water Purifier has an in-built feature that sounds an audible alarm if the UV lamp malfunctions.
This feature is provided to ensure purity. This UV Fail Alarm will sound as follows:
Single short beeps after every two seconds.
In case such an alarm is audible, kindly switch off the purifier and call the service technician for help.
The purifier will stop its purification process in such a circumstance.
2 Se c. 2 Se c. 2 Se c.2 Se c.
Filter Change Alarm
KENT Elite Plus-New Water Purifier has an in-built feature that sounds an audible alarm to indicate
replacement time for filters. This alarm will be audible after 700 hrs of use since the last filter change (or since
the time of installation). The Filter Change Alarm will sound as follows:
4 short beeps after every two seconds; for 30 seconds. The alarm will repeat after every 2 hours of use.
In case such an alarm is audible, please call the service technician and request him to change the filters of the
purifier. However, if the filters are not changed within the next 60 hours of operation, the purifier will stop
functioning to ensure purity and hygiene. The following alarm will be audible after 60 Hrs. A continuous beep
for an infinite time.
In case, such an alarm is audible, kindly switch off the purifier and call the service technician to replace
the filters. In such a circumstance, the purifier will not function unless the filters are changed.
2 Ho urs
30 S ec. 30 S e c.

7
8
Recommended Usage of Rejected Water
Although the rejected water has high
concentration of salts, it is absolutely clean
and free from impurities like chlorine, dirt,
sand, etc. This rejected water usually goes
down the drain but can be used for gardening
purpose. The high concentration of salts and
minerals accelerate the plant growth.
Rejected water can also be used for cleaning
utensils, mopping etc.
Maintenance
To ensure that the purifier operates at its BEST, a routine maintenance must be performed. The
frequency of the maintenance will greatly depend upon the raw water quality and consumption
of purified water.
n Tank must be drained and cleaned once in
every 15 days
n Replace RO membranes once in a year
n Replace UF membrane once in a year
n Replace sediment filter, activated carbon
filter once in a year or earlier if they
get clogged. It is recommended to
change FRT alongwith the filters
n Replace UV Lamp once in a year
Technical Specifications
*Purification capacity tested on raw water with TDS level of 750 ppm at room temperature
For optimum performance we recommend the following frequency for replacement of
cartridges:
Sediment /Activated Carbon à Once in a year or earlier if they get clogged
RO/UF Membranes à Once in a year or earlier if they get clogged
UV Lamp à Once in a year
Recommended Frequency for Filters/Membrane Change
Important Safety Instructions
Please note that the replacement time of consumables such as filters and membranes is
dependent on the quality of raw water and the quantity of water consumed.
Product KENT Elite Plus-New
Product Code 11148
Product Generic Name Water Purifier
Product Colour White
Application Suitable for Purification of Brackish/Tap Water
Municipal Corporation Water
Installation Suitable as attachment to water coolers
Body Material ABS Food Grade Plastic
Mounting Wall-mounted
Purification Production Rate 50 L/hr.* (Under standard testing conditions)
Max. Duty Cycle 250 L/Day
Filter Cartridge Sediment, Activated Carbon, UF, Post Carbon
UV Lamp Wattage 11 W
Life of UV Lamp 5000 hrs. of operation
Membrane Type Thin Film Composite RO (2)
Auto Flushing System Yes
2
Inlet Water Pressure/Temp (Min.) 0.3 kg/cm /10ºC
2
Inlet Water Pressure/Temp (Max.) 4 kg/cm /40ºC
Min./Max. Operating pH 6.5-8.0
Booster Pump Voltage 24 V DC
Total Power Consumption 120 W
Product Dimensions (mm) 410 (L) x 240 (W) x 480 (H)
Net Weight 13.47 Kg
Input Power Supply Single Phase 100–250 V AC, 50-60 Hz.
IP Rating IPX1
The System has been tested according to IS 10500:2012 (Standards for drinking water as per Bureau of Indian
Standards) for reduction of the hazardous substances as listed below.
Testing Information
Starting-up the Purifier
nSwitch on the power supply
nAllow water to fill to the maximum level
nSwitch off the power supply
nOpen the faucet and drain water to
remove residual dust particles present in
the pipes and tank
nClose the faucet and switch on the
power supply
nPurifier is ready to use
The unique TDS Controller enables customers to retain the contents of natural minerals in
purified water, as per their requirement:
• Tur ning the screw of the valve
anti-clockwise, results in an increased
mineral content
• Turning the screw of the valve
clockwise, results in a decreased
mineral content
TDS Adjustment
We recommend keeping the TDS at lowest possible level but not below 50mg/l.
n If the supply cord is damaged, it must be replaced by the original part in order to avoid hazard
n Children should be supervised to ensure that they do not play with the appliance
n This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety
Warning
n Do not operate the UV-C emitter when it is removed from the appliance enclosure
n Read the maintenance instructions before opening the appliance
n The appliance must be disconnected from the supply before replacing the UV-C emitter
