Kenwood CCL401WH User manual

TYPE CCL40
instructions
istruzioni
instrucciones
Bedienungsanleitungen
gebruiksaanwijzing
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Kenwood CCL401WH o
cerca il tuo prodotto tra le migliori offerte di Elettrodomestici da Cucina

English 2-24
Nederlands 25-49
Français 50-74
Deutsch 75-99
Italiano 100-125
Español 126-151
Português 152-176
Ekkgmij 177-199

(3
(2 -1
(1 ,:
(4
(5
(7
(6
(8





  
)1
(:
(9
(3
)5
)5
)4
)3
)3
)6
)6
)2
)7
):
)8
*1
)9 *7+8+7+6+4 +5+3 *9
*2 *3 *4 *5 *6 *8 *: +1 +2


6
DIRECT PREP
,5
,4
,3
,2
,1
,6
+9
+:
,8







,9
,7

temp
30-180˚C0-8hr 1-12
time speed
11
8
4
3b3a
5 6 7
109
1a 1b 2

2
contents
safety 3–6
key 7
language selection 7
using your cooking food processor 8-9
using your Direct Prep 9-10
display screen symbols explained 10
manual mode 11–12
using the pre-set programmes 13–19
Main Meal programme 14
Sauce programme 15
Steam programme 16-17
Soup programme 18
Stir Fry programme 18
Dessert programme 19
recommended usage chart 20
care and cleaning 21
service and customer care 22
troubleshooting guide 23–24
English

3
safety
ORead these instructions carefully and retain for future
reference.
ORemove all packaging and any labels.
OIf the cord is damaged it must, for safety reasons, be
replaced by KENWOOD or an authorised KENWOOD repairer.
OFor correct operation ensure that the bowl base is clean and
dry before fitting to the power unit.
OAlways switch off and unplug before:
{assembling or disassembling;
{when not in use;
{before cleaning.
OAlways remove the stir tool and whisk before pouring
content from the bowl to avoid burning from splashing hot
ingredients.
OThe knife blade has been designed to be retained on the
drive shaft and should only be removed once the content
has been removed from the bowl. The knife blade is sharp,
handle with care.
OKeep hands and utensils out of the bowl whilst connected to
the power supply.
OWhen leaving the appliance unattended in the cooking mode
pay close attention to the following:
{ensure the instructions are followed with regards to
temperatures and maximum quantities to process;
{make sure the unit and cord are positioned out of reach of
children and away from the edge of the work surface;
{check the progress on a regular basis to ensure enough
liquid is added and food is not overcooking.
OTake care when lifting this appliance as it is heavy. Ensure the
bowl is empty and outlet cover is secure before moving. Do
not lift by the bowl handles.
ODo not move the unit whilst in operation or still hot.
ONever use a damaged appliance or attachment. Get it
checked or repaired: see “service and customer care”.

4
ODo not exceed the maximum capacities stated.
ODo not exceed the 2.6 litres maximum fill level marked on the
inside of the bowl.
OThis appliance is not suitable for deep frying, when shallow
frying do not exceed the 0.5 litre max oil fill level marked on
the bowl. Remove any excess liquid/water before adding food
to the oil.
ONever let the power unit, cord or plug get wet.
OBe careful when handling or touching any part of the
appliance when being used in the cook mode or after
cooking. In particular the bowl, lid and tools as they will
remain HOT long after the appliance has been switched off.
OUse the handles to remove and carry the bowl. Use oven
gloves when handling the hot bowl and hot tools.
OThe underside of the bowl will remain hot long after the
heating has stopped. Use caution when handling and use a
work surface protection mat when placing the bowl on heat
sensitive surfaces.
OBe careful of steam escaping from the bowl particularly when
removing the lid or filler cap during the cooking mode or after
cooking.
ODo not remove the lid or filler cap whilst liquid is boiling.
OUse oven gloves to remove the lid or filler cap when the
appliance is being used in cooking mode or after cooking.
OAlways fit the filler cap when using the chopping function or
pureeing ingredients.
OAlways operate the appliance with the filler cap in place,
unless specified in the recipe.
OOnly use the bowl and tools supplied with this appliance.
ONever use the bowl with any other heat source.
ONever operate the appliance in the cooking mode with the
bowl empty.
ODo not use the lid to operate the appliance, always use the
Start/Stop or Cancel button.

5
OThis appliance will be damaged and may cause
injury if the interlock mechanism is subjected to
excessive force.
OWhen using this appliance ensure it is positioned on a
level surface away from the edge. Do not position below
overhanging cupboards.
OThis appliance is not intended to be operated by means of an
external timer or separate remote-control system.
OAlways ensure food is thoroughly cooked and is piping hot
before eating.
OFood should be eaten shortly after cooking or allowed to cool
quickly and then refrigerated as soon as possible.
OAlways ensure that the sealing ring is fitted correctly to
the drive coupling to prevent leakage and damage to your
cooking food processor.
OAlways use the bowl release buttons (5 before attempting to
remove the cooking bowl.
OMisuse of your appliance can result in injury.
OAppliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and if they
understand the hazards involved.
OChildren should be supervised to ensure that they do not play
with the appliance.
OThis appliance shall not be used by children. Keep the
appliance and its cord out of reach of children. Never let the
cord hang down where a child could grab it.
OOnly use the appliance for its intended domestic use.
Kenwood will not accept any liability if the appliance is subject
to improper use, or failure to comply with these instructions.

6
Direct Prep attachment
OThe discs are very sharp; handle with care when fitting,
removing and cleaning. Always hold by the finger grip
away from the cutting edge, both when handling
and cleaning.
ONever remove the lid until the cutting disc has
completely stopped.
ONever use your fingers to push food down the feed tube. Only
use the pusher supplied.
ODo not use excessive force to push food down the feed tube
– you could damage your attachment.
OAvoid contact with moving parts. Keep fingers out of the
discharge opening ,6.
OBefore removing the lid from the Direct Prep:
{switch off;
{wait until the disc has completely stopped.
Steamer attachment
OThis attachment produces steam which can burn you.
ODo not get burnt by steam coming out of your steamer,
especially when removing the lid.
OTake care when handling the parts; any liquid or condensation
will be very hot. Use oven gloves.
OCook meat, fish and seafood thoroughly. And never cook
them from frozen.
OIf you are using the steamer tray base and shelf, put meat,
poultry and fish in the bottom basket so that its raw juice
cannot drip onto food below.
ODo not reheat cooked rice in your steam tray attachment.
before plugging in
OMake sure your electricity supply is the same as the
one shown on the underside of the appliance.
OWARNING: THIS APPLIANCE MUST BE
EARTHED.
O This appliance conforms to EC Regulation
1935/2004 on materials and articles intended to
come into contact with food.
