Kenwood kMix KMX5 User manual

TYPE KMX5
KMX50 series, KMX60 series
KMX80 series, KMX90 series
instructions
istruzioni
instrucciones
Bedienungs nleitungen
gebruiks nwijzing

English 2 - 8
Nederlands 9 - 17
Français 18 - 26
Deutsch 27 - 35
Italiano 36 - 44
Português 45 - 53
Es añol 54 - 62
Dansk 63 - 70
Svenska 71 - 77
Norsk 78 - 84
Suomi 85 - 91
Türkçe 92 - 99
Ïesky 100 - 106
Magyar 107 - 115
Polski 116 - 123
Ekkgmij 124 - 132
Slovenčina 133 - 140
Українська 141 - 150
´¸∂w
151 - 751

safety
lRead these instructions carefully and
retain for future reference.
lRemove all packaging and any labels.
lSwitch off and unplug before fitting or
removing tools/attachments, after use
and before cleaning.
leep your fingers away from moving
parts and fitted attachments.
lNever leave the machine on unattended.
lNever use a damaged machine. Get it
checked or repaired: see ‘service and
customer care’.
lNever let the cord hang down where a
child could grab it.
lNever let the power unit, cord or plug get
wet.
lNever use an unauthorised attachment
or both outlets at the same time
lNever exceed the maximum capacities.
lWhen using an attachment, read the
safety instructions that come with it.
lTake care when lifting this appliance as it
is heavy. Ensure the head is locked and
that the bowl, tools, outlet cover and
cord are secure before lifting.
know your enwood kitchen machine
2

lThis appliance shall not be used by
children. eep the appliance and its cord
out of reach of children.
lChildren should be supervised to ensure
that they do not play with the appliance.
lMisuse of your appliance can result in
injury.
lAppliances can be used by persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use
of the appliance in a safe way and if they
understand the hazards involved.
lOnly use the appliance for its intended
domestic use. enwood will not accept
any liability if the appliance is subject to
improper use, or failure to comply with
these instructions.
3

before plugging in
lMake sure your electricity supply is the same as the one shown on
the underside of your machine.
lWA NING: THIS APPLIANCE MUST BE EA THED.
lThis appliance conforms to EC Regulation 1935/2004 on materials
and articles intended to come into contact with food.
know your Kenwood kitchen machine
mixer head
attachment outlet
outlet cover
bowl
tool socket
on/off and speed switch
mixer ready indicator light
mixer body
head release lever
-beater
whisk
dough hook
spatula
splashguard
spanner
4
know your enwood kitchen machine
















the mixing tools and some of their uses
beater lFor making cakes, biscuits, pastry, icing, fillings, éclairs and
mashed potato.
whisk lFor eggs, cream, batters, fatless sponges, meringues,
cheesecakes, mousses, soufflés. Don’t use the whisk for heavy
mixtures (eg creaming fat and sugar) – you could damage it.
dough hook lFor yeast mixtures.
to use your mixer
1 Lift the head release lever at the back of the appliance 
and at the same time lift the head until it locks in the raised
position .
to insert a tool 2 Push up until it stops then turn .
3 Fit the bowl onto the base. Place the handle directly over the
unlock symbol ,then gently turn the bowl clockwise until the
handle is directly above the lock symbol . DO NOT USE
excessive force and DO NOT overtighten .
4 Lift the head release lever at the back of the appliance and at the
same time lower the mixer head .
5 Plug into the power supply and the mixer ready indicator light
will glow.
6 Switch on by turning the speed switch to the desired setting.
to remove a tool 7 Turn and remove.
important
lIf the mixer head is raised during operation, the machine will stop
working straight away. To re-start the mixer, lower the mixer head,
turn the speed switch to the off position, wait a few seconds and
then re-select the speed. The mixer should resume operating
straight away.
lWhenever the mixer head is raised the mixer ready indicator light
will go out. When the head is lowered, the light will glow indicating
the mixer is ready to use.
hints lThe fold function can be used for folding light ingredients into
heavier mixtures for example meringues, mousses, fruit fools,
Genoese sponges and souffles, and to slowly incorporate flour and
fruit into cake mixtures. The mixer will operate at a constant slow
speed.
lEggs at room temperature are best for whisking.
lBefore whisking egg whites, make sure there’s no grease or egg
yolk on the whisk or bowl.
lUse cold ingredients for pastry unless your recipe states otherwise.
lWhen creaming fat and sugar for cake mixes, always use the
fat at room temperature or soften it first.
5
the mixer





lYour itchen Machine has been fitted with a ‘soft start’ feature to
minimise spillage. However if the machine is switched on with a
heavy mixture in the bowl such as bread dough, you may notice
that the mixer takes a few seconds to reach the selected speed.
points for bread making
important lNever exceed the maximum capacities below - you will overload
the machine.
lTo protect the life of the machine always allow a rest of 20 minutes
between loads.
lIf you hear the machine labouring, switch off, remove half the dough
and do each half separately.
lThe ingredients mix best if you put the liquid in first.
lAt intervals stop the machine and scrape the mixture off the dough
hook.
lDifferent batches of flour vary considerably in the quantities of liquid
required and the stickiness of the dough can have a marked effect
on the load imposed on the machine. You are advised to keep the
machine under observation whilst the dough is being mixed; the
operation should take no longer than 5 minutes.
speed switch
These are a guide only and will vary depending upon the quantity of
mix in the bowl and the ingredients being mixed.
beater lcreaming fat and sugar start on ‘min’, gradually increasing
to a higher speed.
lbeating eggs into creamed mixtures 4 - ‘max’.
lfolding in flour, fruit etc ‘min’ - 1 or fold .
lall in one cakes start on ‘min’, gradually increase to ‘max’.
lrubbing fat into flour ‘min’ - 2.
whisk lGradually increase to ‘max’.
dough hook lStart on ‘min’, gradually increasing to 1.
electronic speed sensor control
Your mixer is fitted with an electronic speed sensor control that is
designed to maintain the speed under different load conditions,
such as when kneading bread dough or when eggs are added to a
cake mix. You may therefore hear some variation in speed during
the operation as the mixer adjusts to the load and speed selected -
this is normal.
maximum capacities
shortcrust pastry 680g flour
fruit cake mix 2.72 g total mix
stiff bread dough 1.35 g flour
soft bread dough 1.3 g flour
egg whites 12
6
the mixer

1 Raise the mixer head until it locks.
2 Fit the bowl onto the base.
3 Push the splashguard onto the underside of the mixer head 
until fully located. The hinged section should be positioned as shown.
4 Insert required tool.
5 Lower the mixer head.
lDuring mixing, ingredients can be added directly to the bowl via
the hinged section of the splashguard .
lYou do not need to remove the splashguard to change tools.
6 Remove the splashguard by raising the mixer head and sliding it
down.
troubleshooting
problem
lThe whisk or beater knocks against the bottom of the bowl or
isn’t reaching the ingredients in the bottom of the bowl.
solution lAdjust the height using the spanner provided. Here’s how:
1 Unplug the appliance.
2 Raise the mixer head and insert the whisk or beater.
3 Lower the mixer head. If the clearance needs to be adjusted,
raise the mixer head and remove the tool. Ideally the whisk and
beater should be almost touching the bottom of the bowl .
4 Using the spanner provided loosen the nut sufficiently to allow
adjustment of the shaft . To lower the tool closer to the bottom
of the bowl, turn the shaft anti-clockwise. To raise the tool
away from the bottom of the bowl turn the shaft clockwise.
5 Re-tighten the nut.
6 Fit the tool to the mixer and lower the mixer head. (Check its
position see points above).
7 Repeat the above steps as necessary until the tool is set correctly.
Once this is acheived tighten the nut securely.
dough hook - this tool is set at the factory and should require
no adjustment.
problem
lThe mixer stops during operation.
solution lIf for any reason power to the mixer is interrrupted and the
machine stops working, turn the speed switch to the off position,
wait a few seconds and then re-select the speed. The mixer
should resume operating straight away.
to fit and use your splashguard


7



care and cleaning
lAlways switch off and unplug before cleaning.
mixer body, lWipe with a damp cloth, then dry.
outlet cover lNever use abrasives or immerse in water.
tools lWash by hand, then dry thoroughly. Do not wash in the dishwasher.
bowl, lWash by hand, then dry thoroughly or wash in the dishwasher.
splashguard lNever use a wire brush, steel wool or bleach to clean your
stainless steel bowl. Use vinegar to remove limescale.
leep away from heat (cooker tops, ovens, microwaves).
service and customer care
lIf the cord is damaged it must, for safety reasons, be replaced
by ENWOOD or an authorised ENWOOD repairer.
lIf you experience any problems with the operation of your appliance,
before requesting assistance visit www.kenwoodworld.com.
lPlease note that your product is covered by a warranty, which complies
with all legal provisions concerning any existing warranty and consumer
rights in the country where the product was purchased.
lIf your enwood product malfunctions or you find any defects, please
send it or bring it to an authorised ENWOOD Service Centre. To find up
to date details of your nearest authorised ENWOOD Service centre visit
www.kenwoodworld.com or the website specific to your Country.
lDesigned and engineered by enwood in the U .
lMade in China.
IMPO TANT INFO MATION FO CO ECT DISPOSAL OF THE
P ODUCT IN ACCO DANCE WITH THE EU OPEAN
DI ECTIVE ON WASTE ELECT ICAL AND ELECT ONIC
EQUIPMENT (WEEE)
At the end of its working life, the product must not be disposed of as urban
waste.
It must be taken to a special local authority differentiated waste collection
centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible negative
consequences for the environment and health deriving from inappropriate
disposal and enables the constituent materials to be recovered to obtain
significant savings in energy and resources. As a reminder of the need to
dispose of household appliances separately, the product is marked with a
crossed-out wheeled dustbin.
cleaning and service
8

veiligheid
lLees deze instructies zorgvuldig door en
bewaar ze voor toekomstig gebruik.
lVerwijder de verpakking en alle labels.
lSchakel het apparaat uit en haal de
stekker uit het stopcontact voordat u
instrumenten/hulpstukken aanbrengt of
verwijdert, na ieder gebruik en alvorens
het apparaat te reinigen.
lHoud uw vingers uit de buurt van
bewegende onderdelen en vaste
accessoires.
lLaat de machine nooit onbeheerd achter,
wanneer deze ingeschakeld is, en houd
hem buiten het bereik van kinderen.
lGebruik de machine niet als hij
beschadigd is. Laat hem nakijken of
repareren: zie paragraaf ‘onderhoud en
klantenservice’.
lLaat het snoer nooit naar beneden
hangen waar een kind erbij kan.
lDe motor, het snoer of de stekker nooit
nat laten worden.
lGebruik nooit een ongeautoriseerd
hulpstuk of meer dan één aansluitpunt
tegelijkertijd.
lOverschrijd nooit de maximumcapaciteit.
lLees eerst de veiligheidsvoorschriften bij
de accesoires, voordat u ze gebruikt.
9
de onderdelen van de enwood keukenmachine
NL
