INSTRUCTION MANUAL
RAX
KEPCO
KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11352 U.S.A. " TEL [phone] " FAX [phone]
http://www.kepcopower.com " email: [e-mail]
An ISO 9001 Company.
175 WATT SINGLE OUTPUT
SWITCHING POWER SUPPLIES
I — INTRODUCTION
SCOPE OF MANUAL. This instruction manual covers the installation and operation of the Kepco RAX 175W Series of Switch-
ing Power Supplies. For service information, please refer to the Service Manual for the RAX 175W Series, which can be pur-
chased either from your Kepco Representative, or by writing directly to: Kepco Inc. 131-38 Sanford Avenue, Flushing, New York
11352, U.S.A. When ordering a Service Manual, please state Model Designation and Serial Number of your RAX power
supply. This information can be found on the nameplate of the unit.
DESCRIPTION. The Kepco RAX 175W Series consists of seven models of switching power supplies, with a single output as
shown in Table 1. Units may be operated with either 115V a-c or 230V a-c 47-440Hz input. They will also operate on 240V to
370V d-c input. The RAX 175W Series employs a light weight ferrite core with 140 KHz switching frequency. Regulation is pro-
vided by pulse width modulation. A FET power stage, operating in the forward conversion mode provided a smooth isolated d-c
output. A triac “soft-start” circuit prevents excessive turn-on current surge. Overvoltage protection and optically isolated remote
TTL on-off control is provided. Current limiting with automatic recovery from short circuit is featured. Units are enclosed in a
wrap-around aluminum case with an LED “output present” light visible on the terminal side of the case.
Table 1 contains specifications and operating limits of individual RAX 175W Series models. Section II (following) contains spec-
ifications and operating limits common to all RAX 175W Series Models.
II — SPECIFICATIONS
The following specifications are at nominal input voltages at 25°C unless otherwise specified.
INPUT VOLTAGE: (Jumper selectable, see Section III, FIG. 3):
120V a-c nominal, range: 85 -132V a-c
220-240V a-c nominal, range: 170 -264V a-c
320V d-c nominal, range: 240 -370V d-c
For d-c input the jumper is placed in the 230V position.
INPUT SOURCE FREQUENCY:
Nominal 50/60 Hz; Range 47-440 Hz. (At 440 Hz the leakage current exceeds the VDE safety specification limit.)
TABLE 1. OUTPUT RATINGS AND SPECIFICATIONS, RAX 175W SERIES
MODEL RAX 3.3-35K RAX 5-35K RAX 12-14K RAX 15-11K RAX 24-7.2K RAX28-6.2K RAX 48-3.6K
OUTPUT VOLTS, d-c 3.3V 5V 12V 15V 24V 28V 48V
ADJUSTMENT RANGE 1.8 - 3.6V 4.0 - 5.5V 8.4 - 13.2V 12.0 - 16.5V 16.8 - 26.4V 19.6 -30.8V 32.6 - 52.8V
MAXIMUM
OUTPUT
RATINGS
(AMPS,
WATTS)
50° C amb. 35.0A/115.5W 35.0A/175W 14.0A/168W 11.0A/165W 7.2A/172.8W 6.2A/173.6W 3.6A/172.8W
60° C amb. 24.5A/80.9W 24.5A/122.5W 9.8A/117.6W 7.7A/115.5W 5.0A/120.96W 4.34A/121.5W 2.5A/120.96W
71° C amb. 14.0A/46.2W 14.0A/70W 5.6A/67.2W 4.4A/66W 2.88A/69.12W 2.48A/69.4W 1.44A/69.12W
CURRENT LIMIT (AMPS)(1) 36.8 - 38.5 36.8 - 38.5 14.7 - 15.4 11.8 - 12.1 8.0 - 8.3 7.0 - 7.3 4.3 - 4.5
OVP RANGE (VOLTS) 3.9 - 4.8 6.0 - 6.9 13.7 - 15.7 17.0 - 19.5 27.0 - 30.5 32.0 - 35.0 55.0 - 63.0
RIPPLE
AND
NOISE(2)
(mV p-p)
source (typ) 5 5 15 15 25 30 35
source (max) 10 10 30 30 40 60 90
switching (typ) 25 25 25 25 25 25 25
switching (max) 40 40 50 50 60 60 60
spike noise
(max)(3) 100 100 170 200 290 330 530
(1) Change of current setting with the specified variations for operating temperatures and source input voltage is within ±10% of the rated values.
(2) Source component 2x source frequency, and switching component approximately 150KHz.
(3) Measured with a 50 MHz bandwidth.
CAUTION: UNIT IS SET
TO 115V AC OPERATION

2228-1227 REV 2 022101
KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11352 U.S.A. " TEL [phone] " FAX [phone]
http://www.kepcopower.com " email: [e-mail]
BROWNOUT VOLTAGE:
115V a-c input selection, 80V a-c min. (85V a-c min. for model RAX 28-6.2K)
230V a-c input selection, 160V a-c min. (170V a-c min. for model RAX 28-6.2K)
320V d-c input selection, 220V d-c min. (Jumper in 230V a-c position)
INPUT CURRENT: (maximum load at 50°C with nominal output voltage):
INPUT PROTECTION AND SOFT START: A triac soft start circuit reduces start-up surge. Units are protected against
shorts by an input fuse. Fuse value 6.3A.
INPUT SURGE: At 25°C from cold start:
NOTE: There are two input surges at turn-on:
EFFICIENCY: 75% typical (79% typical for model RAX 3.3-35K)
STABILIZATION:
TRANSIENT RECOVERY: A step load change from 50% to 100% of rated load current in 50 microseconds or more, pro-
duces no more than 4% output voltage excursion. Recovery to 1% of the original voltage is less than 1 millisecond.
OUTPUT HOLDING TIME: Output is maintained for 20 milliseconds minimum upon input interruption (30 milliseconds typi-
cal) with nominal input voltage and output load at 50°C current rating.
OVERVOLTAGE PROTECTION: Fixed, factory set. See Table 1. The overvoltage circuit is reset by interrupting input for
approximately 15 seconds.
OPERATING TEMPERATURE: 0 -71°C. See the derating graph, Figure 1.
STORAGE TEMPERATURE: -20°C to + 75°C.
HUMIDITY: 20% to 95% relative humidity, noncondensing
ISOLATION: (at 25°C ambient, 65% relative humidity):
Between input and output terminals, 3.75 KV a-c for 1 minute (with Y-capacitors removed).
Between input and output or chassis, 2000V a-c for 1 minute.
Between output terminals and chassis, 500V a-c for 1 minute.
INSULATION RESISTANCE: Between output and chassis, 100 megohms minimum (500V d-c)
LEAKAGE CURRENT:
0.5mA max at 120V a-c (U.L. Method)
0.75mA max at 240V d-c (U.L./VDE Method)
VIBRATION: Three Axes:
5-10 Hz., 10 mm amplitude
10-55 Hz., 2g
SHOCK: Three axes, 20g, 11 ms ±5msec pulse duration
INPUT SOURCE NOMINAL INPUT VOLTAGE MINIMUM INPUT VOLTAGE
120 V a-c input selection 3.4A typ. - 4.2A max. 3.8A typ. - 4.4A max.
220-240V a-c input selec-
tion 1.7A typ. - 2.2A max. 2.1A typ. - 2.3A max.
d-c input selection 1.2A max. (320V input) 1.5A max. (220V input)
INPUT SOURCE FIRST SURGE (5ms max.) SECOND SURGE (3ms max.)
120 V a-c input selection 17A max. 20A typ.
220-240V a-c input selec-
tion 34A max. 15A typ.
320V d-c input selection 34A max. 34A typ.
CHARACTERISTIC TYPICAL MAXIMUM
Source Effect (min - max) 0.8% 1.5%
Load Effect, measured at sensing terminals (10% - 100% load change) 0.8% 1.5%
Temperature effect (0 to 71°C) 1.0% 2.0%
Combined effect (envelope) 2.0% 4.0%
Drift (8 hr. at 25°C) 0.1% 0.5%

KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11352 U.S.A. " TEL [phone] " FAX [phone]
http://www.kepcopower.com " email: [e-mail]
022101 228-1227 REV 2 3
EMI CONDUCTED: FCC Class A
SAFETY: All units designed to meet UL 1950D3, UL 478, CSA Electrical Bulletin 1402C, VDE 0806, TÜV Rheinland
EN60950 and IEC 950 Safety Standards. RAX are CE marked per the Low Voltage Directive (LVD), EN60950. [The stan-
dards do not apply with DC input operation].
REMOTE ERROR SENSING: RAX 3.3-35K and 5-35K models, up to 0.25V per load wire. All other models, up to 0.4V per
load wire. The power supply is factory set with links in place.
REMOTE CONTROL ON/OFF:
“High,” 2.4V-24V (or open), unit ON
“Low,” 0.0V-0.4V (or closed), unit OFF
When Remote Control (RC) is at “Low” level, the output voltage remains Vo <0.5V.
Vo <5% of nominal voltage for 12, 15, 24, 28, and 48 volt models.
III — OPERATION UNIT WILL NOT WORK WITH SENSE LEADS DISCONNECTED (SEE FIG. 2).
INSTALLING THE POWER SUPPLY: Refer to Figure 4. The unit may be mounted on one of the three mounting surfaces.
Mounting holes are provided for each mounting style. The air surrounding the power supply must not exceed the ambient val-
ues given in the graph in Figure 1.
CONNECTING AND SWITCHING THE LOAD: The load is connected as shown in Figure 2. Error sensing may be done at
the load terminals to compensate for voltage loss in the connecting wires. The jumper links must therefore be removed from
the sense terminals.
SELECTING INPUT VOLTAGE: Input voltage is selected with a jumper. Refer to Figure 3. The power supply is delivered
for 120V a-c operation. Change the jumper to the position marked “230V” to operate the unit from a nominal 220-240V a-
c or 320V d-c source.
VOLTAGE ADJUSTMENT: The unit is provided with a voltage adjustment control. To adjust voltage, first place the unit under
an operating load, then monitor the + and - sense terminals with a precision voltmeter and turn the voltage control to the
desired operating value. Refer to Table 1 for Adjustment Range.
CHANGING FUSE: Remove the cover to replace a fuse. (Refer to Figure 3.) The fuse holder will accept two sizes, either:
KEPCO P/N: 541-0084 or Manufacturer SOC P/N ST4-6.3A-N1 (1/4” x 1-1/4”)
KEPCO P/N: 541-0099 or Manufacturer Littelfuse P/N Type F (5mm x 20mm)
REMOTE TURN-ON TURN-OFF When power is on at the source the unit may be turned on or off with the remote control fea-
ture. The output of the remote turn-on/off RC (remote control) terminals operates at TTL logic levels (2.4V-24V “high” and 0.0
to 0.4V “low”). The unit is turned off by bringing the RC terminals to “low” logic level with a switch or solid state device. If the
remote on/off feature is not desired, the terminals should be left open.
FIGURE 1. TEMPERATURE DERATING FIGURE 2. CONNECTING THE LOAD WITH ERROR SENSING
LINKS
(SEE NOTE)
NOTE:
THE SENSE LEADS MUST NEVER BE DISCONNECTED FROM THE OUTPUT. IF THE
SENSE LEADS ARE ALLOWED TO FLOAT FREE OF THE OUTPUT, THE OUTPUT VOLT-
AGE WILL RISE TO THE OVERVOLTAGE POINT AND THE UNIT WILL SHUT DOWN.
•FOR REMOTE SENSING CONNECT THE SENSE TERMINALS TO THE LOAD AS
SHOWN, AND REMOVE THE TWO SENSING LINKS.
•FOR LOCAL SENSING LEAVE THE SENSING LINKS IN PLACE AND CONNECT
THE LOAD DIRECTLY TO THE BUS BAR.
3041270

4228-1227 REV 2 022101
KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11352 U.S.A. " TEL [phone] " FAX [phone]
http://www.kepcopower.com " email: [e-mail]
NOTES: 1. Dimensions in parentheses are in millimeters, others are in inches.
2. TOLERANCES: ; ±0.04” (±1.0 mm) unless specified. 3. MOUNTING SCREW PENETRATION: 0.028” (7 mm) maximum. 4. TERMINAL BLOCK: 9 Terminals. KEPCO P/N/ 567-0017. Terminal screws: M4x6 with
captive flat and lock washer, KEPCO P/N 501-0058.
5. MATERIAL AND FINISH: A) Case is aluminum, phosphate coated; B) Terminal Block is
Polybutylene Terephthalate (black).
6. WEIGHT: 3.97 lbs (1.8Kg.) max., 3.31lbs. (1.5 Kg) typ.
FIGURE 3. SIMPLIFIED VIEW, COVER REMOVED FIGURE 4. OUTLINE DRAWING, RAX 175W SERIES
