Ketra N3 Satellite User manual

N3
Satellite
INSTALLATION GUIDE
Model: Ketra N3 Satellite, Revision 3, Firmware version 1.2

PAGE 2 770-000014-01 r02 N3 INSTALL ATION GUIDE
! !
WARNING
Shock Hazard. May result in serious injury or death.
Turn power OFF at circuit breaker or remove fuse. Damage to this
product caused by wiring with power on voids the warranty.
Due to risk of electric shock, a licensed electrician should install this
luminaire in strict compliance with the National Electrical Code and any
state or local code which may apply.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.

PAGE 3 770-000014-01 r02 N3 INSTALLATION GUIDE
CONTENTS
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Components/ Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Pre-Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Pre-Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Before Physical Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Physical Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Overview of Third Party Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Warranty/ Tech Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

PAGE 4 770-000014-01 r02 N3 INSTALL ATION GUIDE
Ketra’s N3 satellite provides several vital system functions: control of luminaires,
integration of third party control and lighting products, and on-board memory and
astronomical time clock functionality. The N3’s wireless connectivity enables its
installation in multiple, convenient locations. To simplify the integration of third
party control systems, it includes multiple inputs and outputs.
PRODUCT OVERVIEW
AC Power/Signal Out
Connect to Ketra
Luminaires
0-10V In/Out
Contact Closure In/Out
0-24V Input
Multifunction I/O
Status Indicators
Architectural Lighting Controls
DMX In & Out/Thru
USB
Firmware Updates
DMX Termination Switch
AC Power In

2.76”
70mm
9.97”, 253.3mm
0.2”
5mm
11.05”, 280.7mm
1.1 "
4
4"
2.4" 60mm
.1"
2mm
PAGE 5 770-000014-01 r02 N3 INSTALL ATION GUIDE
COMPONENTS/ SPECIFICATIONS
ENVIRONMENTAL
Operating Temperature -20 to 50˚C
Storage Temperature -20 - 80°C
Humidity 0 - 95%, Non-condensing
Certification UL, cUL, FCC Class A, RoHS
Location UL Damp Location, IP20
MECHANICAL
Weight 2.93 lbs, 1.33 kg
Housing Material Formed Steel, Polymer
POWER
Load Ratings Per Unit: 4Amps @ 220 VAC, 50 Hz
Power Requirements
Unit consumes 5W electrical power
Current: .023 Amps @ 220VAC
To compute total load, add 5W to sum of all connected luminaire
power ratings.
Voltage 100-277V 60Hz
ENCLOSURE/ CONNECTIONS
Connections (Class 2)
AC Power In (3 Conductor
120-277VAC 60Hz)
10-16AWG (Line Neutral,
Ground)
AC Power Out (4 Line ) Standard Ketra Leader Cable
or 10-16 AWG
Connections (Class 2)
Multifunction I/O (4 channels) 16-24 AWG
Max Voltage per channel: 30 Volts DC
0-10V Input/Output
0-10V Sinking
Max Current Per Channel:
Max Current Per Channel:
100 mA
200 mA
0-10V Current Sourcing
Max Current Per Channel: less than 5 uA
Contact Closure Mode
0-24V Input
Voltage Range 0 to 24 volts
DMX Input and Thru/ Full Universe of DMX Out
KetraNet MeshTM Wireless
USB Port 1 - Micro-B USB console port,
for firmware updates
SPECIFICATIONS
N3 SATELLITE UNIT

PAGE 6 770-000014-01 r02 N3 INSTALLATION GUIDE
Warning: Turn OFF electrical power to all circuit breakers feeding into the panel before installing or
servicing this product.
Warning: Improper use or installation can cause SERIOUS INJURY, DEATH, OR LOSS/DAMAGE OF
PROPERTY.
This device should be protected by a 20amp circuit breaker.
This device includes a two-way radio. For optimal performance and signal integrity:
• Do not install in third-party metal enclosures
• Use non-metal enclosures (e.g. plastic, fiberglass or PVC)
Product is plenum-rated for non-air-handling spaces.
Product is direct-insulation contact rated.
If placed in enclosure alongside other electrical components, take necessary precautions regarding
operating temperatures.
Product is UL surface mount listed. Does not require dedicated enclosure.
This product contains both class one and class two electrical connections. The sections are physically
separated by a barrier. MAINTAIN PHYSICAL SEPARATION BOTH INSIDE AND OUTSIDE OF DEVICE IN
ACCORDANCE WITH ELECTRICAL CODES.
This device must be installed by a licensed electrician in accordance with all national and local codes.
PREINSTALLATION
PREINSTALLATION

PAGE 7 770-000014-01 r02 N3 INSTALLATION GUIDE
PREINSTALLATION
PREINSTALLATION INSTRUCTIONS
This product has numerous capabilities and functions. Not all uses will apply to each specific application.
Wireless Network
Product needs to be within range of Ketra’s wireless network, KetraNet MeshTM.
KetraNet MeshTM is a wireless mesh network system in which each wireless device both sends and receives
data commands. Devices should be configured within 50 ft (15.24m) of another KetraNet MeshTM connected
device.
Depending upon topology and materials within the space, range may be limited.
• Avoid metal obstructions.
• Walls may impact communication depending upon construction method and materials.
• For complete design specification details, please refer to the Ketra System Specification Guide.
G2 Port Specifications
The G2 product has a 50 ft (15.24m) leader cable. Product should be within that range for functional control.
Control Connections
Distance limitations for each control topology should be taken into consideration.
• DMX – 1,800 ft (548m) maximum.
• 0-10 – 50 ft (15.24m) maximum total, depending on wire gauge.
• Contact Closure – 50 ft (15.24m) maximum total, depending on wire gauge.
• 24 Volt – 50 ft (15.24m) maximum total, depending on wire gauge.

AC Mains INTRIAC Control
LN LN
Power & Signal OUT
SNL
Activity
Status Monitor
B A DMX DALI TRIAC Power
AB
DC Out DALIDMX Out DMX In
Analog I/O
+ – +4
3
2
1
+ + + COM COM COM
COM D+
– +
D+ D– GND
GND D–
SN: KD00000016
DC: K3914
OC: N3INDREC1BK
Fig. 1
Fig. 2
AC Mains INTRIAC Control
LN L
N
Power & Signal OUT
SNL
Activity
Status Monitor
B A DMX DALIT RIAC Power
AB
DC Out DALIDMX OutD MX In
Analog I/O
+ – +4
3
2
1
+ + + COM COM COM COM
D+
– + D+ D–
GND
GND D–
15.24cm/6”
20.32cm/8”
6.34mm
1/4 inch
PAGE 8 770-000014-01 r02 N3 INSTALL ATION GUIDE
BEFORE PHYSICAL MOUNTING
Note the serial number and product location; this information will be useful later in the
installation. (The serial number can be found on the top of the control board cover - see fig. 1.)
INSTALL ATION
INSTALLATION
Product is UL damp location listed (can be used in outdoor locations provided it is protected from
direct water exposure).
Choose a suitable mounting surface and four fasteners that will fit the 0.2 inch/5mm mounting holes
(e.g. #8 countersunk head, #9 countersunk head).
This product has a suggested clearance to ensure access to all connections and all analog user
interface switches. (see fig. 2)
Serial Number

Fig. 3
Fig. 4
Fig. 5
Main Cover Conduit Plugs
Screws
Mounting Holes
4.76mm (3/16”) hole
PAGE 9 770-000014-01 r02 N3 INSTALLATION GUIDE
INSTALLATION
PHYSICAL MOUNTING
1. Remove the lid. (Note that screws are captive and need not be fully removed from lid -
see fig. 3.)
2. Remove plastic plugs from knock-outs as required. (see fig. 4)
3. Mount box to surface with appropriate fasteners. (Note: inner diameter of hole is 4.76mm
(3/16) - see fig. 5.)

PAGE 11N3 INSTALLATION INSTRUCTIONS 770-000014-01-01-r3
INSTALLATION
7
6
!
WARNING: DO NOT CONNECT AC SUPPLY
TO TERMINALS MARKED “TRIAC CONTROL.”
PAGE 11N3 INSTALLATION INSTRUCTIONS 770-000014-01-01-r3
INSTALLATION
7
6
!
WARNING: DO NOT CONNECT AC SUPPLY
TO TERMINALS MARKED “TRIAC CONTROL.”
Fig. 6 Fig. 7
PAGE 10 770-000014-01 r02 N3 INSTALL ATION GUIDE
INSTALLATION INSTALLATION
INSTALLATION
WARNING: DO NOT CONNECT AC SUPPLY TO TERMINALS MARKED “TRIAC CONTROL.”
Triac Control feature is not supported.
STEP 1
Connect AC supply.
Use conduit or NM type cable as appropriate.
Note: Acceptable wire is both solid core and stranded. Gauge range is 2.59 Ø[mm]/5.26 Ø[mm2] - 1.29
Ø[mm]/1.31 Ø[mm2].)
1. Open appropriate terminals by flipping orange levers into UP position. (see fig. 6) Make
connections to the “AC Mains In” section connecting to appropriate line, neutral and ground
terminals.
Note: wire strip length is 12mm/.47 inches.
2. Insert appropriate conductors from Mains Power. (see fig. 7)
Black conductor goes to “L” terminal.
White conductor goes to “N” terminal.
Green conductor goes to “ ” terminal.
Note: Conductor colors are not always as listed. These colors vary depending on your wiring
setup. To ensure the correct wiring, consult a professional electrician.

PAGE 13N3 INSTALLATION INSTRUCTIONS 770-000014-01-01-r3
INSTALLATION
6
7
PAGE 13N3 INSTALLATION INSTRUCTIONS 770-000014-01-01-r3
INSTALLATION
6
7
Fig. 8 Fig. 9
PAGE 11 770-000014-01 r02 N3 INSTALL ATION GUIDE
INSTALLATION
STEP 1
Connect power and signal output to G2 Linear luminaires.
Note: Details on G2 linear connections available in G2 Installation Guide.
1. Open appropriate terminals by flipping orange levers into UP position. (see fig. 8)
2. Make connections to the “Power and Signal OUT” section connecting to appropriate line, neutral
and ground terminals.
Note: wire strip length is 12mm/.47 inches.
3. Insert appropriate conductors from G2 leader cable. (see fig. 9)
Black conductor goes to “L” terminal.
White conductor goes to “N” terminal.
Green conductor goes to “ ” terminal.
Red conductor goes to the “S” terminal.

PAGE 12 770-000014-01 r02 N3 INSTALL ATION GUIDE
INSTALLATION INSTALLATION
OVERVIEW OF THIRD PARTY CONTROLS
The class 2 control input/output compartment enables interface with numerous devices. Choose
appropriate terminals based upon your application.
Sections include:
Analog I/O
This section contains four ports. Each port can be configured independently to be any of the
following control types. Refer to applicable protocol wiring diagrams.
• Contact closure input
• Contact closure output
• 0-10V input
• 0-10V output
• 0-24V input
DMX
This section contains two ports – “DMX In” and “DMX Out/Through.”
“DMX Out/Through” can be configured to either pass through “DMX In” signal or operate as a
stand-alone DMX universe of control. Refer to applicable protocol wiring diagrams.
Connect Third Party Controls
1. Use conduit or NM type cable as appropriate.
Note: acceptable wire is both solid core and stranded. Gauge range is 1.29 Ø[mm]/1.31 Ø[mm2]
- 0.511 Ø[mm]/0.205 Ø[mm2]).
2. Open appropriate terminals by depressing appropriate terminal buttons.
3. Make connections to the appropriate ports.
Note: wire strip length is 9-10mm/.35-.39 inches.
Refer to applicable protocol wiring diagrams.

PAGE 13 770-000014-01 r02 N3 INSTALLATION GUIDE
INSTALLATION
Verify Successful Installation
1. Apply power to circuit.
2. Green “Power” LED will illuminate indicating successful installation and product functionality.
3. Optional If data is present at any control port, appropriate LED will indicate status.
4. Disconnect power and install cover.
5. Restore power and configure device using Ketra Design Studio Software.
6. For software download and updates, visit ketra.com.

PAGE 14 770-000014-01 r02 N3 INSTALLATION GUIDE
WARRANTY/ TECH SUPPORT
Limited warranty terms can be found at:
www.ketra.com/warranty
For questions and technical support please contact:
[phone]
[e-mail]

PAGE 15 770-000014-01 r02 N3 INSTALL ATION GUIDE

3815 S. Capital of Texas Highway
Suite 100
Austin, TX 78704
ketra.com
[phone]
