Keysight N5221AU-626 Installation and operation manual

Keysight Extended Frequency
Range Upgrade Kit

Installation Note
To Upgrade PNA N5221A to N5222A
Upgrade Kit Order Numbers: N5221AU-626
Keysight Kit Number: N5222-60109

2 Installation Note N5222-90109
WARRANTY STATEMENT
THE MATERIAL CONTAINED IN THIS DOCUMENT IS PROVIDED “AS IS,” AND IS SUBJECT TO BEING
CHANGED, WITHOUT NOTICE, IN FUTURE EDITIONS. FURTHER, TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, KEYSIGHT DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED WITH REGARD
TO THIS MANUAL AND ANY INFORMATION CONTAINED HEREIN, INCLUDING BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. KEYSIGHT
SHALL NOT BE LIABLE FOR ERRORS OR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES IN CONNECTION
WITH THE FURNISHING, USE, OR PERFORMANCE OF THIS DOCUMENT OR ANY INFORMATION CONTAINED
HEREIN. SHOULD KEYSIGHT AND THE USER HAVE A SEPARATE WRITTEN AGREEMENT WITH WARRANTY
TERMS COVERING THE MATERIAL IN THIS DOCUMENT THAT CONFLICT WITH THESE TERMS, THE
WARRANTY TERMS IN THE SEPARATE AGREEMENT WILL CONTROL.
DFARS/Restricted Rights Notice
If software is for use in the performance of a U.S. Government prime contract or subcontract, Software is
delivered and licensed as “Commercial computer software” as defined in DFAR 252.227-7014 (June 1995), or
as a “commercial item” as defined in FAR 2.101(a) or as “Restricted computer software” as defined in FAR
52.227-19 (June 1987) or any equivalent agency regulation or contract clause. Use, duplication or disclosure of
Software is subject to Keysight Technologies’ standard commercial license terms, and non-DOD Departments
and Agencies of the U.S. Government will receive no greater than Restricted Rights as defined in FAR 52.227-
19(c)(1-2) (June 1987). U.S. Government users will receive no greater than Limited Rights as defined in FAR
52.227-14 (June 1987) or DFAR 252.227-7015 (b)(2) (November 1995), as applicable in any technical data.

Installation Note N5222-90109 3
Description of the Upgrade
This upgrade extends the frequency range of the PNA model N5221A from 13.5 GHz up to 26.5 GHz. After
installation of this upgrade, the PNA will be an N5222A.
Getting Assistance from Keysight
By internet, phone, or fax, get assistance with all your test and measurement needs.
Contacting Keysight
Assistance with test and measurements needs and information on finding a local Keysight office are available
on the Web at:
http://www.keysight.com/find/assist
If you do not have access to the Internet, please contact your Keysight field engineer.
NOTE In any correspondence or telephone conversation, refer to the Keysight product by its model
number and full serial number. With this information, the Keysight representative can
determine whether your product is still within its warranty period.

4 Installation Note N5222-90109
Getting Prepared
CAUTION The PNA contains extremely sensitive components that can be ruined if mishandled. Follow
instructions carefully when making cable connections, especially wire harness connections.
The person performing the work accepts responsibility for the full cost of the repair or
replacement of damaged components.
To successfully install this upgrade kit, you will need the following:
• A license key - refer to “License Key Redemption” below.
• A PDF copy or a paper copy of the PNA Service Guide - refer to “Downloading the Online PNA Service
Guide” below.
• An ESD-safe work area - refer to “Protecting Your Workspace from Electrostatic Discharge” below.
• Enough time - refer to “About Installing the Upgrade” on page 5.
• Test equipment for the post-upgrade adjustments and full instrument calibration. To view the equipment
list, click the Chapter 3 bookmark “Tests and Adjustments” in the PDF Service Guide1.
License Key Redemption
NOTE The enclosed Option Entitlement Certificate is a receipt, verifying that you have purchased a
licensed option for the PNA of your choice. You must now use a Keysight Web page to request
a license key for the instrument that will receive the option.
To enable the option product, you must request a license key from: http://www.keysight.com/find/
softwarelicense. To complete the request, you will need to gather the following information:
• From the certificate
❏Order number
❏Certificate number
• From your instrument
❏Model number
❏Serial number
❏Host ID
The instrument information is available on the network analyzer – on the analyzer’s Help menu, click About
Network Analyzer.
If you provide an email address, Keysight will promptly email your license key. Otherwise, you will your receive
your license key via postal mail.
1. See “Downloading the Online PNA Service Guide” on page 5.

Installation Note N5222-90109 5
Downloading the Online PNA Service Guide
To view the online Service Guide for your PNA model number, use the following steps:
1. Go to www.keysight.com.
2. In the Search box, enter the model number of the analyzer (Ex: N5222A) and click Search.
3. Click Technical Support > Manuals.
4. Click Service Manual.
5. Click the service guide title to download the PDF file.
6. When the PDF of the Service Guide is displayed, scroll through the Contents section bookmarks to locate
the information needed.
Protecting Your Workspace from Electrostatic Discharge
• For information, click on the Chapter 1 bookmark, “Electrostatic Discharge Protection” in the PDF Service
Guide1.
ESD Equipment Required for the Installation
About Installing the Upgrade
1. See “Downloading the Online PNA Service Guide” on page 5.
Description Keysight Part Number
ESD grounding wrist strap 9300-1367
5-ft grounding cord for wrist strap 9300-0980
2 x 4 ft conductive table mat and 15-ft grounding wire 9300-0797
ESD heel strap (for use with conductive floors) 9300-1308
Products affected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . All N5221A microwave network analyzers
Installation to be performed by . . . . . . . . . . . . . . . . . . . . . . Keysight service center, personnel qualified by
Keysight, or customer
Estimated installation time . . . . . . . . . . . . . . . . . . . . . . . . . 5 minutes
Estimated verification time . . . . . . . . . . . . . . . . . . . . . . . . . 5 minutes
Estimated adjustment time . . . . . . . . . . . . . . . . . . . . . . . . . 2 hours
Estimated full instrument calibration time . . . . . . . . . . . . . 4.5 hours

6 Installation Note N5222-90109
Items Included in the Upgrade Kit
Check the contents of your kit against the following list. If any of these items is missing, contact Keysight
Technologies. Refer to “Getting Assistance from Keysight” on page 3.
Installation Procedure for the Upgrade
Installation Requirements
• The network analyzer must be in proper working condition prior to installing this option. Any necessary
repairs must be made before proceeding with this installation.
• This installation does not require removal of the analyzer’s protective outer covers.
• The analyzer must be powered up and operating to perform this installation. The network analyzer program
must be running.
• This installation requires that a keyboard and a mouse be connected to the network analyzer.
Table 1 Contents of Upgrade Kit
Quantity Description Part Number
1Installation Note (this document) N5222-90109
1Option Entitlement Certificate 5964-5145
1Nameplate, N5222A (26.5 GHz) N5222-80001

Installation Note N5222-90109 7
Step 1. Verify the Option, Serial, and New Model Numbers
If you haven’t done so already, follow the instructions in “License Key Redemption” on page 4. As stated, you
must use the online Keysight HostID utility to get a new Host ID.
Refer to the license message you received from Keysight:
• Verify that the analyzer’s option number (626), serial number, and upgraded model number (N5222A) match
those on the license message you received from Keysight.
• Note the 12-digit license key for later use.
If the model number, serial number, or option number do not match those on the license message you received
from Keysight, you will not be able to install the option. If this is the case, contact Keysight for assistance.
Refer to “Getting Assistance from Keysight” on page 3.
Step 2. Enter the New Model Number
1. Click System > Service > Option Enable.
2. Click Repair.
3. Click the Check if model shown is incorrect check box.
4. Click Begin Repair.
5. In the drop down list that appears, select your new, upgraded PNA model number–N5222A.
6. Using the keyboard, enter the 12-digit license key in the box provided. The license key is printed on the
license message you received from Keysight. Enter this key exactly as it is printed on the message.
7. Click Change Model.
8. Click Yes in answer to the displayed question in the Restart Analyzer? box.
9. When the installation is complete, click Exit.
NOTE The PNA contains adjustment data for the original frequency range only. Performance above
this range is not calibrated and may cause errors to be displayed. This will be corrected when
the source and receiver adjustments are performed.
NOTE Previously installed software options require new license keys. Contact Keysight to receive
these keys.

8 Installation Note N5222-90109
Step 3. Verify that the New Model Number Is Enabled
Once the analyzer has restarted and the network analyzer program is again running:
1. On the toolbar, click Help, then click About Network Analyzer.
2. Verify that the new model number you enabled is shown in the display. Click OK.
NOTE If the new model number has not been enabled, perform the ”Step 2. Enter the New Model
Number” procedure again. If the option is still not enabled, contact Keysight Technologies.
Refer to “Getting Assistance from Keysight” on page 3.
Step 4. Replace the Nameplate
Remove the Old Nameplate
1. Using a sharp object such as a knife blade, lift one end of the old nameplate. Be careful not to scratch the
front-panel painted surface.
2. Using your fingers, pull the nameplate completely off of the front panel and discard it.
3. If any adhesive remains on the front panel surface, it can be removed by rubbing it with your finger. Do not
use a sharp object to remove this adhesive. If necessary, the surface can be cleaned with isopropyl alcohol.
Install the New Nameplate
1. Remove the protective backing from the new nameplate to expose the adhesive. Avoid touching the
adhesive with your fingers as this may affect its ability to adhere to the front panel surface.
2. Loosely align the new nameplate over the recess in the front panel and apply lightly.
3. Once the nameplate is properly aligned, press it firmly onto the surface to secure it.

Installation Note N5222-90109 9
Step 5. Perform Post-Upgrade Adjustments and Calibration
Adjustments
The following post-upgrade adjustments must be made.
•sourceadjustment
• receiver adjustment
• receiver characterization
These adjustments are described in the PNA Service Guide and in the PNA on-line HELP. A list of equipment
required to perform these adjustments is also found in the service guide.
To view this service guide information, click the Chapter 3 bookmark “Tests and Adjustments” in the PDF
Service Guide1.
After the specified adjustments have been performed, the analyzer should operate and phase lock over its
entire frequency range.
Operator’s Check
Perform the Operator’s Check to check the basic functionality of the analyzer. For instructions, click the
Chapter 3 bookmark “Tests and Adjustments” in the PDF Service Guide1.
If you experience difficulty with the basic functioning of the analyzer, contact Keysight. Refer to “Contacting
Keysight” on page 3.
Calibration
Although the analyzer functions, its performance relative to its specifications has not been verified. It is
recommended that a full instrument calibration be performed using the analyzer’s internal performance test
software. To view information on the performance test software, click the Chapter 3 bookmark “Tests and
Adjustments” in the PDF Service Guide1.
1. See “Downloading the Online PNA Service Guide” on page 5.
