Add SSD Accessories
1CC145A and 1CC150A
Keysight UXG X-Series
Agile Signal Generators
Installation Note

Notices
© Copyright 2019 Keysight Technologies, Inc.
The information contained in this document is subject to change without notice.
Keysight Technologies makes no warranty of any kind with regard to this material, including but
not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Keysight Technologies shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of this material.
Manual Part Number
N5191-90025
Edition
Edition 1, May 2019
Supersedes: None
Printed in USA/Malaysia
Published by:
Keysight Technologies, Inc.
1400 Fountaingrove Parkway
Santa Rosa, CA 95403

Installation Note N5191-90025 3
Add SSD Accessories 1CC145A and 1CC150A
Add SSD Accessories 1CC145A and 1CC150A
1CC145 - Empty Drive Tray accessory
1CC150A - Additional Solid-State Drive
Introduction
These accessory kits add an empty drive tray or an additional solid-state drive to the UXG X-Series
Agile Signal Generators.
Installation includes the following major steps:
1CC145A - Empty Drive Tray accessory - Page 6
1. Check signal generator functionality.
2. If you are installing the empty drive:
—Remove the current SSD
—Install the empty drive tray from kit N5191-60215
3. If you are installing your own SSD:
—Remove the current SSD
—Remove the plate from the empty drive tray
—Secure SSD onto the drive tray
—Install the SSD tray
1CC150A - Additional Solid-State Drive - Page 9
1. Check signal generator functionality.
2. Remove the current SSD
3. Install the Keysight SSD
Product Affected: . . . . . . . . . . . . . . . . . . . . . . . . . N5191A, N5192A, N5193A, and N5194A
Serial Numbers: . . . . . . . . . . . . . . . . . . . . . . . . . . All
Options: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To Be Performed By: . . . . . . . . . . . . . . . . . . . . . . (X) Keysight Technologies Service Center
(X) Personnel Qualified by Keysight Technologies
(X) Customer
Estimated Installation Time: . . . . . . . . . . . . . . . 0.5 hours
Estimated Verification Time: . . . . . . . . . . . . . . . 0.5 hours

4Installation Note N5191-90025
Add SSD Accessories 1CC145A and 1CC150A
Installation Kit Parts List
1CC145A - Kit part number N5191-60215
1CC150A - Kit part number N5191-60217
Tools Required
— TORX T-10 driver
— TORX T-15 driver
Safety Considerations
Contacting Keysight
For assistance, get in touch with your nearest Keysight Technologies Sales and Service Office. To
find your local Keysight office access the following URL, or if in the United States, call the following
telephone number:
http://www.keysight.com/find/assist
1-800-829-4444 (8am-8pm EST Monday -Friday)
Quantity Description Part Number
1 Tray assembly w/o SSD drive N5191-60216
1 Installation note N5191-90025
1 Corrugated carton 9211-6181
Quantity Description Part Number
1 Tray assembly with SSD drive N5191-60129
1 Installation note N5191-90025
1 Corrugated carton 9211-6181
Before you disassemble the instrument, turn the power switch off and unplug the signal
generator. Failure to unplug the signal generator can result in personal injury.
Electrostatic discharge (ESD) can damage or destroy electronic components. All work on
electronic assemblies should be performed at a static-safe workstation.

Installation Note N5191-90025 5
Check Signal Generator Functionality
Check Signal Generator Functionality
Use the following procedure to confirm that the signal generator powers up and the internal check
identifies no errors. The internal check evaluates the operation of the signal generator and returns
an error message if it detects a problem.
1. Turn on the signal generator and let it warm up for at least five minutes.
2. Run the signal generator self-test by pressing System > Instrument Info/Help Mode > Self
Test > Run Complete Self Test. Upon completion, a summary of the self-test will be
displayed. Use the N5191A/N5193A Service Guide to troubleshoot any failures detected by
the test.
3. Check to see if the ERR annunciator is on.
—If the ERR annunciator is on, review the error messages in the error queue by pressing
System > Error Info. The first page of error messages in the error queue appears in the
display text area. (Refer to the signal generator error messages document for information
about each error message.)
After resolving all problems causing errors, press Clear Error Queue(s).
—If the ERR annunciator is off, the signal generator functionality check has passed.
When the signal generator is first connected to ac line power, Reference Oven Cold
occurs which causes the OVEN COLD annunciator to turn on.
After approximately five minutes, the OVEN COLD annunciator automatically clears.
Some circuits may require up to 50 minutes to warm up before passing the
self-test. If self-tests continue to fail after 50 minutes of warm up, troubleshoot
the instrument.

6Installation Note N5191-90025
1CC145A - Empty Drive Tray Accessory Installation
1CC145A - Empty Drive Tray Accessory Installation
The empty drive tray can be used in two ways:
— If no SSD is desired in the instrument.For security reasons, some lab areas do not permit
removable mass storage devices in instruments.
— For a customer purchased SSD installation.
1. Disconnect the power cord.
2. Refer to Figure 1. Remove the Solid State Drive (1) by using the T-15 driver to loosen the
thumb screws where indicated and pulling out of the rear panel.
Figure 1 SSD Removal
This drive tray is designed to carry a 2.5-inch solid state drive (SSD). If you are installing an SSD
from a third-party manufacturer, the SSD must have a SATA III 6Gb/s interface and an operating
temperature range equal to or greater than the operating temperature range of the instrument.
Only drives purchased from Keysight Technologies are covered under warranty. Keysight does not
warrant third party supplied hardware or software including third party SSDs.

Installation Note N5191-90025 7
1CC145A - Empty Drive Tray Accessory Installation
If no SSD is desired in the instrument:
3. Install the empty drive tray by sliding the tray into the rear panel opening. Secure by
tightening the thumb screw. Torque to 9 in-lbs.
For a customer purchased SSD installation:
4. Refer to Figure 2. Remove the SSD plate (2) by using the T-10 driver to remove the 4 screws
(1).
Figure 2 Plate Removal

8Installation Note N5191-90025
1CC145A - Empty Drive Tray Accessory Installation
5. Refer to Figure 3. Install the SSD onto the tray using the same screws. Torque to 4 in-lbs.
Figure 3 SSD Installation
6. Install the drive tray by sliding the tray into the rear panel opening. Press to mate with the
connectors. Secure by tightening the thumb screw. Torque to 9 in-lbs.
7. Connect the power cord and turn the instrument on. There should be no errors.

Installation Note N5191-90025 9
1CC150A - Additional SSD Drive Installation
1CC150A - Additional SSD Drive Installation
1. Disconnect the power cord.
2. Refer to Figure 4. Remove the Solid State Drive (1) by using the T-15 driver to loosen the
thumb screws where indicated and pulling out of the rear panel.
Figure 4 SSD Removal
3. Install the new SSD tray by sliding the tray into the rear panel opening. Press to mate with the
connectors. Secure by tightening the thumb screw. Torque to 9 in-lbs.
4. Connect the power cord and turn the instrument on. There should be no errors.
