Keysight DSO1000B Series Technical manual

Keysight DSO1000B Series
Oscilloscopes
This manual provides the documentation
for the following instruments:
DSO1052B
DSO1072B
DSO1012B
DSO1152B
Declassification
and Security

2
Notices
© Keysight Technologies, Inc.
2012
No part of this manual may be
reproduced in any form or by any
means (including electronic
storage and retrieval or translation
into a foreign language) without
prior agreement and written
consent from Keysight
Technologies, Inc. as governed by
United States and international
copyright laws.
Manual Part Number
54139-92001
Print Date
May 2012
Published in USA
Keysight Technologies Inc.
1900 Garden of the Gods Rd
Colorado Springs, CO 80907
Warranty
THE MATERIAL CONTAINED IN
THIS DOCUMENT IS PROVIDED
“AS IS,” AND IS SUBJECT TO
BEING CHANGED, WITHOUT
NOTICE, IN FUTURE EDITIONS.
FURTHER, TO THE MAXIMUM
EXTENT PERMITTED BY
APPLICABLE LAW, KEYSIGHT
DISCLAIMS ALL WARRANTIES,
EITHER EXPRESS OR IMPLIED
WITH REGARD TO THIS MANUAL
AND ANY INFORMATION
CONTAINED HEREIN, INCLUDING
BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE.
KEYSIGHT SHALL NOT BE LIABLE
FOR ERRORS OR FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH THE
FURNISHING, USE, OR
PERFORMANCE OF THIS
DOCUMENT OR ANY
INFORMATION CONTAINED
HEREIN. SHOULD KEYSIGHT AND
THE USER HAVE A SEPARATE
WRITTEN AGREEMENT WITH
WARRANTY TERMS COVERING
THE MATERIAL IN THIS
DOCUMENT THAT CONFLICT WITH
THESE TERMS, THE WARRANTY
TERMS IN THE SEPARATE
AGREEMENT WILL CONTROL.
Technology Licenses
The hardware and/or software
described in this document are
furnished under a license and may
be used or copied only in
accordance with the terms of such
license.
Restricted Rights Legend
If software is for use in the
performance of a U.S. Government
prime contract or subcontract,
Software is delivered and licensed
as “Commercial computer
software” as defined in DFAR
252.227-7014 (June 1995), or as
a “commercial item” as defined in
FAR 2.101(a) or as “Restricted
computer software” as defined in
FAR 52.227-19 (June 1987) or any
equivalent agency regulation or
contract clause. Use, duplication
or disclosure of Software is
subject to Keysight Technologies’
standard commercial license
terms, and non-DOD Departments
and Agencies of the U.S.
Government will receive no
greater than Restricted Rights as
defined in FAR 52.227-19(c)(1-2)
(June 1987). U.S. Government
users will receive no greater than
Limited Rights as defined in FAR
52.227-14 (June 1987) or DFAR
252.227-7015 (b)(2) (November
1995), as applicable in any
technical data.
Safety Notices
A CAUTION notice denotes a hazard.
It calls attention to an operating
procedure, practice, or the like that,
if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or the
like that, if not correctly performed
or adhered to, could result in
personal injury or death. Do not
proceed beyond a WARNING notice
until the indicated conditions are
fully understood and met.

3
Where to Find the Latest Information
Documentation is updated periodically. For the latest information about these products, including
instrument software upgrades, application information, and product information, see the following
URLs:
http://www.keysight.com/find/1000B-Series-manual
To receive the latest updates by email, subscribe to Keysight Email Updates:
http://www.keysight.com/find/MyKeysight
Information on preventing instrument damage can be found at:
Is your product software up-to-date?
Periodically, Keysight releases software updates to fix known defects and incorporate product
enhancements. To search for software updates for your product, go to the Keysight Technical
Support website at:
http://www.keysight.com/find/techsupport

4
Table of Contents
Contacting Keysight Sales and Service Offices ................................................................................................. 5
Products Covered by this Document.................................................................................................................. 6
Security Terms and Definitions........................................................................................................................... 7
Instrument Memory ............................................................................................................................................. 8
Summary of Memory Declassification Procedures ............................................................................................ 9
User and Remote Interface Security Measures................................................................................................ 12
Screen and Annotation Blanking.................................................................................................... 12
USB Mass Storage Device Security................................................................................................ 12
Remote Access Interfaces .............................................................................................................. 12
Procedure for Declassifying a Faulty Instrument............................................................................................. 13
References ......................................................................................................................................................... 14

5
Contacting Keysight Sales and Service Offices
Assistance with test and measurement needs, and information on finding a local Keysight office, is
available on the Internet at:
http://www.keysight.com/find/assist
If you do not have access to the Internet, please contact your field engineer.
In any correspondence or telephone conversation, refer to the instrument by its model number
and full serial number. With this information, the Keysight representative can determine whether
your unit is still within its warranty period.

6
Products Covered by this Document
Product Family Name Product Names Model Numbers
DSO1000B family of Digital
Storage Oscilloscopes
DSO1000B Series Oscilloscopes DSO1052B, DSO1072B, DSO1012B,
DSO1152B
This document describes instrument security features and the steps to declassify an instrument through
memory clearing, sanitization or removal.
For additional information, go to:
http://www.keysight.com/find/security
Be sure that all information stored by the user in the instrument that needs to be saved is
properly backed up before attempting to clear any of the instrument memory. Keysight
Technologies cannot be held responsible for any lost files or data resulting from the clearing of
memory. Be sure to read this document entirely before proceeding with any file deletion or
memory clearing.

7
Security Terms and Definitions
Term Definition
Clearing As defined in Section 8-301a of DoD 5220.22-M, clearing is the process of eradicating the data on
media before reusing the media so that the data can no longer be retrieved using the standard
interfaces on the instrument. Clearing is typically used when the instrument is to remain in an
environment with an acceptable level of protection.
Instrument
Declassification
A term that refers to procedures that must be undertaken before an instrument can be removed from
a secure environment, such as is the case when the instrument is returned for calibration.
Declassification procedures include memory sanitization or memory removal, or both. Keysight
declassification procedures are designed to meet the requirements specified in DoD 5220.22-M,
Chapter 8.
Sanitization As defined in Section 8-301b of DoD 5220.22-M, sanitization is the process of removing or
eradicating stored data so that the data cannot be recovered using any known technology.
Instrument sanitization is typically required when an instrument is moved from a secure to a non-
secure environment, such as when it is returned to the factory for calibration.
Keysight memory sanitization procedures are designed for customers who need to meet the
requirements specified by the US Defense Security Service (DSS). These requirements are specified
in the “Clearing and Sanitization Matrix” in Section 5.2.5.5.5 of the ISFO Process Manual.
Secure Erase Secure Erase is a term that is used to refer to either the clearing or sanitization features of Keysight
instruments.

8
Instrument Memory
This section contains information on the types of memory available in your instrument. It explains
the size of memory, how it is used, its location, volatility, and the sanitization procedure.
Table 1: Summary of instrument memory
Memory Type
and Size
Writable During Normal Operation? Data Retained When Powered Off?
Purpose/ Contents Data Input
Method
Location in
Instrument and
Remarks
Sanitization
Procedure
Main Memory
(SDRAM)
8 MB
Yes No Program Operating System Main system
board in CPU
area.
Cycle power
Display Memory
(SDRAM)
8 MB
Yes No Display/screen Memory Display controller Main system
board in CPU
area.
Cycle power
Acquisition
Memory
(SDRAM)
4 MB
Yes No Channel Data Acquisition
Channels
Main system
board in CPU
area.
Cycle power
Main Memory
(Flash)
8 MB
Yes Yes System firmware &
Storage
User Data
Storage/
Firmware
Upgrades/
Calibration
Main system
board in CPU
area.
Clear User
Data
NVRAM
512 KB
Yes Yes System Settings Operating System Main system
board in CPU
area.
Press
[Default
Setup] front
panel key

Summary of Memory Declassification Procedures
This section explains how to clear, sanitize, and remove memory from you instrument for all
memory that can be written to during normal operation and for which the clearing and sanitization
procedure is more than trivial such as rebooting your instrument.
Table 2: Main Flash
Description and
purpose
Main memory flash used to store factory calibration and user configuration data, as well as
instrument program code.
Size 8 MB.
Memory clearing Same procedure as sanitization.
Memory sanitization User-data – Save-Recall @ 10 Setup Registers:
1. Press the [Default Setup] button on front panel.
2. Press the [Save/Recall] button on the front panel.
3. Press the Storage softkey until Setups is selected.
4. Press the Internal softkey.
5. Adjust Location softkey setting until it is at Int_00.
6. Press the Delete File softkey.
7. Repeat steps 5 & 6 for all Location selections (Int_01 through Int_09).
8. Adjust Location softkey setting until it is at Int_00.
9. Press the Save softkey.
10. Repeat steps 5 & 6 for all Location selections (Int_01 through Int_09).
11. The original setting have both been cleared and overwritten.
12. Done.
User-data – Saved Waveforms @ 10 Waveform files:
1. Disconnect all channel inputs.
2. Press the [Default Setup] button on front panel.
3. Press the [Save/Recall] button on the front panel.
4. Press the Storage softkey until Waveform is selected.
5. Press the Internal softkey.
6. Adjust Location softkey setting until it is at Int_00.
7. Press the Delete File softkey.

10
8. Repeat steps 5 & 6 for all Location selections (Int_01 through Int_09).
9. Adjust Location softkey setting until it is at Int_00.
10. Press the Save softkey.
11. Repeat steps 5 & 6 for all Location selections (Int_01 through Int_09).
12. The original saved waveform locations have both been cleared and overwritten
trivial data.
13. Done.
User-data – Reference Waveform:
1. Cycle Power.
2. Disconnect all channel inputs.
3. Remove any thumb drives from USB host connector on front of instrument.
4. Press the [Default Setup] button on front panel.
5. Press the [Ref] button on the front panel.
6. Press the Save softkey.
7. The original reference waveform data has been overwritten trivial data.
8. Done.
User-data – Sequence Waveform record:
1. Cycle Power.
2. Disconnect all channel inputs.
3. Remove any thumb drives from USB host connector on front of instrument.
4. Press the [Default Setup] button on front panel.
5. Press the [Acquire] button on the front panel.
6. Press the Sequence softkey.
7. Press the Mode softkey until Record is selected.
8. Adjust End Frame softkey unit the maximum setting (1000).
9. Press the Operate softkey, wait until all frames are recorded. (There should be a
red progress readout in the upper left corner of graticule.)
10. Press the Mode softkey until Storage is selected.
11. Adjust Location softkey setting until it is at Internal.
12. Press the 1-2 down arrow (bottom) softkey.
13. Press the Save softkey.
14. The original set of sequence waveform locations have been overwritten trivial
data.
