Keysight ixia UHD100T32 User manual

UHD100T32
Release 1.1
Getting Started Guide
913-2626-01
Document version: 202010142139+05:30

Notices
Copyright Notice
© Keysight Technologies 2018–2020
No part of this document may be
reproduced in any form or by any means
(including electronic storage and retrieval
or translation into a foreign language)
without prior agreement and written
consent from Keysight Technologies, Inc.
as governed by United States and
international copyright laws.
Warranty
The material contained in this document
is provided “as is,” and is subject to being
changed, without notice, in future
editions. Further, to the maximum extent
permitted by applicable law, Keysight
disclaims all warranties, either express or
implied, with regard to this manual and
any information contained herein,
including but not limited to the implied
warranties of merchantability and fitness
for a particular purpose. Keysight shall not
be liable for errors or for incidental or
consequential damages in connection
with the furnishing, use, or performance
of this document or of any information
contained herein. Should Keysight and the
user have a separate written agreement
with warranty terms covering the
material in this document that conflict
with these terms, the warranty terms in
the separate agreement shall control.
Technology Licenses
The hardware and/or software described
in this document are furnished under a
license and may be used or copied only in
accordance with the terms of such
license.
U.S. Government Rights
The Software is "commercial computer
software," as defined by Federal
Acquisition Regulation ("FAR") 2.101.
Pursuant to FAR 12.212 and 27.405-3 and
Department of Defense FAR Supplement
("DFARS") 227.7202, the U.S. government
acquires commercial computer software
under the same terms by which the
software is customarily provided to the
public. Accordingly, Keysight provides the
Software to U.S. government customers
under its standard commercial license,
which is embodied in its End User License
Agreement (EULA), a copy of which can
be found at
http://www.keysight.com/find/sweula.
The license set forth in the EULA
represents the exclusive authority by
which the U.S. government may use,
modify, distribute, or disclose the
Software. The EULA and the license set
forth therein, does not require or permit,
among other things, that Keysight: (1)
Furnish technical information related to
commercial computer software or
commercial computer software
documentation that is not customarily
provided to the public; or (2) Relinquish
to, or otherwise provide, the government
rights in excess of these rights
customarily provided to the public to use,
modify, reproduce, release, perform,
display, or disclose commercial computer
software or commercial computer
software documentation. No additional
government requirements beyond those
set forth in the EULA shall apply, except to
the extent that those terms, rights, or
licenses are explicitly required from all
providers of commercial computer
software pursuant to the FAR and the
DFARS and are set forth specifically in
writing elsewhere in the EULA. Keysight
shall be under no obligation to update,
revise or otherwise modify the Software.
With respect to any technical data as
defined by FAR 2.101, pursuant to FAR
12.211 and 27.404.2 and DFARS 227.7102,
the U.S. government acquires no greater
than Limited Rights as defined in FAR
27.401 or DFAR 227.7103-5 (c), as
applicable in any technical data. 52.227-
14 (June 1987) or DFAR 252.227-7015 (b)
(2) (November 1995), as applicable in any
technical data.
– ii – 913-2626-01

This page intentionally left blank.
913-2626-01 – iii –

Contacting Us
Keysight headquarters
1400 Fountaingrove Parkway
Santa Rosa, CA 95403-1738
www.ixiacom.com/contact/info
Support
Global Support [phone] [e-mail]
Regional and local support contacts:
APAC Support [phone] [e-mail]
Australia [phone] [e-mail]
EMEA Support [phone] [e-mail]
Greater ChinaRegion [phone] [e-mail]
Hong Kong [phone] [e-mail]
India Office [phone] [e-mail]
Japan Head Office [phone] [e-mail]
Korea Office [phone] [e-mail]
Singapore Office [phone] [e-mail]
Taiwan (local toll-free number) 00801856991 [e-mail]
– iv – 913-2626-01

Documentation conventions
The following documentation conventions are used in this guide:
Describing interactions with the UI
You can interact with products by using different input methods: keyboard, mouse, touch, and more.
So in most parts of the user documentation, generic verbs have been used that work with any input
method. In cases where input-neutral verbs do not work, mouse-specific verbs are used as the first
choice, followed by touch-specific verbs as the second choice.
See the following table for examples on how you can interpret the different input methods.
Input-neutral Mouse Touch
Select Modify. Click Modify.Tap Modify.
Select Accounts >Other
accounts >Add an account.
Click Accounts >Other
accounts >Add an account.
Tap Accounts >Other
accounts >Add an account.
To open the document in Outline
view, select View >Outline.
To open the document in
Outline view, click View >
Outline.
To open the document in
Outline view, tap View >
Outline.
Select Protocols. Click the Protocols tab. Tap Protocols.
-NA- Double-click the Client wizard. Double-tap the Client wizard.
Open the Packages context
menu.
Right-click Packages to open
the shortcut menu.
Long tap Packages to open
the shortcut menu.
Deprecated words
The following words have been replaced with new words, considering the audience profile, our modern
approach to voice and style, and our emphasis to use input-neutral terms that support all input
methods.
Old usage... New usage...
shortcut menu, right-click menu context menu
click, right-click select
drag and drop drag
Documentation conventions
913-2626-01 – v –

CONTENTS
Contacting Us iv
Documentation conventions v
Symbols and their meanings x
Product Safety Information xii
Informations sur la sécurité du produit xiii
About This Guide xiv
Record product information xv
Chapter 1 About UHD100T32 1
Overview 1
Specifications 1
Chapter 2 Prerequisites 11
Hardware requirements 11
Software requirements 11
Chapter 3 Getting started workflow 13
Chapter 4 How do I... 15
Unpack UHD100T32 15
Rack mount UHD100T32 16
Connect UHD100T32 20
– vi – 913-2626-01

Sign in to UHD100T32 21
Configure UHD100T32 25
Connect to UHD100T32 30
Restart UHD100T32 31
Shut down UHD100T32 31
Chapter 5 FAQs 33
Appendix A KCOS CLI command reference 37
kcos date-time date set 39
kcos date-time date show 40
kcos date-time ntp-servers delete 41
kcos date-time ntp-servers set 42
kcos date-time ntp-servers show 43
kcos date-time ntp disable 44
kcos date-time ntp enable 45
kcos date-time time-zone set 46
kcos date-time time-zone show 47
kcos date-time time set 48
kcos deployment offline-install 49
kcos deployment packages show 50
kcos exit 51
kcos networking dns-servers add 52
kcos networking dns-servers delete 53
kcos networking dns-servers show 54
kcos networking hostname set 55
kcos networking hostname show 56
kcos networking ip set 57
kcos networking ip show 58
913-2626-01 – vii –

kcos shell 59
kcos snapshot create 60
kcos snapshot delete 61
kcos snapshot restore 62
kcos snapshot show 63
kcos system poweroff 64
kcos system reboot 65
kcos system welcome-screen show 66
INDEX 67
– viii – 913-2626-01

This page intentionally left blank.
913-2626-01 – ix –

Symbols and their meanings
The following notational conventions are used in this guide.
Text is bolded to highlight important information.
The caution symbol denotes information that is of critical importance to the operation of
UHD100T32.
The electrical hazard symbol indicates that the power supplies in your system may produce high
voltages and energy hazards, which can cause bodily harm.
The hot surface symbol indicates that a surface or component is hot.
The electrostatic discharge (ESD) symbol indicates proper antistatic precautions should be
taken to avoid damaging electronic equipment including printed circuit boards and components that
are sensitive to static electricity.
The pointer symbol indicates that the information that follows provides helpful tips on how to
use and configure UHD100T32.
Note: Notes are written like this.
– x – 913-2626-01

This page intentionally left blank.
913-2626-01 – xi –

Product Safety Information
Before installing the unit, read all product safety instructions contained in this document.
These instructions contain specific safety messages that will alert you to any hazards
associated with the installation and proper operations of the equipment. Failure to follow
those instructions can result in serious injury or death.
The unit is a 100GE Test System for enhancing network reliability and powered by 2
redundant, load-sharing hot-swappable power supplies, rated 100-240VAC, 50-60Hz, 12-5A
per PS.
Disconnect both power supply cords before servicing.
CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used
Batteries According to the Instructions.
Rack Mount Instructions
1. Elevated Operating Ambient Temperature: If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may be greater
than room ambient temperature. Therefore, consider installing the equipment in an
environment that is compatible with the maximum allowable ambient temperature
specified for the equipment (35° C).
2. Reduced Air Flow: Installation of the equipment in a rack should be such that the
amount of air flow required for safe operation of the equipment is not compromised.
3. Mechanical Loading: Mount the equipment so that it is level in the rack and that a
hazardous condition is not caused.
4. Circuit Overloading: Consideration should be given to the connection of the equipment
to the supply circuit and the effect that overloading of the circuits might have on
overcurrent protection and supply wiring. Appropriate consideration of equipment
nameplate ratings should be used when addressing this concern.
5. Reliable Earthing: Maintain reliable earthing (grounding) of rack-mounted equipment.
Equipment frame should be screwed down to racks to ensure proper grounding path. In
addition, pay special attention to supply connections other than direct connections to
the branch circuit (such as use of power strips).
– xii – 913-2626-01

Informations sur la sécurité du produit
Avant d'installer l'unité, lisez toutes les instructions de sécurité du produit contenues dans
ce document. Ces instructions contiennent des messages de sécurité spécifiques qui vous
alerteront de tout risque associé à l'installation et au bon fonctionnement de l'équipement.
Si ces instructions ne sont pas respectées, cela peut entraîner des blessures graves, voire
mortelles.
L’unité est un système de test 100GE destiné à améliorer la fiabilité du réseau et est
alimentée par 3 blocs alimentations, 100-240 VCA, 50-60 Hz, 12-5 A par PS.
Débranchez les deux cordons d'alimentation avant l'entretien.
CAUTION: Risque d'explosion si la batterie est remplacée par un type incorrect. Jetez les
piles usagées conformément aux instructions.
Instructions de montage en rack
1. Température ambiante de fonctionnement élevée: si installé dans un ensemble en rack
fermé ou multi-unités, la température ambiante de fonctionnement de l'environnement
du rack peut être supérieure à la température ambiante de la pièce. Par conséquent,
envisagez d'installer l'équipement dans un environnement compatible avec la
température ambiante maximale autorisée spécifiée pour l'appareil (35 ° C).
2. Débit d'air réduit: L'installation de l'équipement dans un rack doit être telle que la
quantité d'air requise pour un fonctionnement en toute sécurité de l'équipement ne soit
pas compromise.
3. Chargement mécanique: montez l'appareil de manière à ce qu'il soit de niveau dans le
rack et qu'aucune condition dangereuse ne soit provoquée.
4. Surcharge du circuit: Il convient de prendre en compte le raccordement de
l'équipement au circuit d'alimentation et les effets qu'une surcharge des circuits peut
avoir sur la protection contre les surintensités et le câblage d'alimentation. Lors de la
résolution de ce problème, il convient de prendre en compte les caractéristiques de la
plaque signalétique de l'équipement.
5. Mise à la terre fiable: Maintenez une mise à la terre fiable des équipements montés en
armoire. Le cadre de l'appareil doit être vissé sur les racks pour assurer un bon chemin
de mise à la terre. De plus, faites particulièrement attention aux connexions
d’alimentation autres que les connexions directes au circuit de dérivation (telles que
l’utilisation de barrettes d’alimentation).
Informations sur la sécurité du produit
913-2626-01 – xiii –

About This Guide
The Getting Started Guide provides instructions for the basic set up and configuration of the
UHD100T32 fixed chassis.
Notes, Cautions, Warnings
Icons are used throughout the documentation to draw attention to caution and warning statement, and
to highlight information that can help you make more effective use of your system.
Note: Provides information that needs special attention within text.
Provides information that is needed to avoid potential harm to equipment or the environment.
Provides information needed to prevent certain harm to a person, piece of equipment, or the
environment.
UHD100T32 on ixiacom.com
The Ixia UHD100T32 Solution Brief, plus related information, is available from the Ixia website:
https://www.ixiacom.com/products/uhd100t32
Additional information
See the following document for additional information about the UHD100T32 fixed chassis:
lUHD100T32 User Guide
– xiv – 913-2626-01

Record product information
You need to record the product information required during initial system configuration (and for future
reference).
lThe Host Name is the Serial Number, located on a label on the bottom of the unit, and also on the
green pull tab on the right side of the faceplate.
lThe Part Number and Product Key are printed on the label on the back of the unit.
lThe IP address is either assigned by the network's DHCP server or statically assigned by a
system administrator.
Host Name:
Part Number:
IP address:
Record product information
913-2626-01 – xv –

CHAPTER 1About UHD100T32
This section contains an overview of the UHD100T32 fixed chassis and its specifications.
Section contents:
Overview 1
Specifications 1
Overview
UHD100T32 is the industry’s highest density 100GE test solution that addresses the density challenges
of validating 100GE devices and networks in a cost-effective way. In just a 1U form-factor, the fixed
chassis provides 32 QSFP28 100GE ports, ready for use cases ranging from white box production-line
testing to data center pre-deployment and post-deployment testing.
This fixed chassis supports 100GE, 50GE, 40GE, 25GE, and 10GE fan-out speed test capabilities. It
also includes Keysight’s proven technology for layer 2 to 3 traffic generation and analysis. Optional
routing protocols are available that include OSPF, BGP, and ISIS and RFC 2544 benchmark test
capabilities.
Specifications
This section describes the specifications, switch, power, and LED controls of the UHD100T32 fixed
chassis.
Hardware specifications
The hardware specifications are listed in the following table.
The current datasheet containing detailed specifications is available on the website:
https://www.ixiacom.com/products/uhd100t32-32-port-100ge-test-system
Specifications
UHD100T32
Perpetual
Part number: 944-
1180
UHD100T32
Base Subscription
Part number:
U100-BASE
UHD100T32
Standard
Subscription
Part number: U100-
STANDARD
Hardware Fixed Chassis System Specifications
– 1 – 913-2626-01

Specifications
UHD100T32
Perpetual
Part number: 944-
1180
UHD100T32
Base Subscription
Part number:
U100-BASE
UHD100T32
Standard
Subscription
Part number: U100-
STANDARD
RU/Number of Ports 1 RU 32-port fixed chassis system
Physical Interfaces Native QSFP28 physical port
Supported Port
Speeds
l100GE/port: 100GE-capable fiber and passive copper cable media
l2×50GE/port: 50GE-capable passive copper (DAC) for point-point and
fan-out cables, and multimode fiber point-to-point AOC media
l40GE/port: 40GE-capable passive copper (DAC) for point-point and
fan-out cables, and multimode fiber point-to-point AOC media
l4×25GE/port: 25GE-capable fiber and passive copper point-point and
fan-out cable media
l4×10GE/port: 10GE-capable fiber and passive copper point-point and
fan-out cable media
Multicore processor Multicore processor with 4GB of CPU memory per resource group
IEEE Interface
Protocols for 100GE
lIEEE 802.3 100GBASE-R LAN
lIEEE P802.3bj
lIEEE P802.3bm
lIEEE P802.3by
lIEEE 802.3ba
lIEEE 802.3ae
Layer 1 support 100GE:
lAuto-negotiation (AN), Clause 73 for passive copper DAC
lLink training for 100GE copper cable media, Clause 73
lEthernet Forward Error Correction RS-FEC, Clause 91
oFEC statistics: FEC Corrected and Uncorrected Codeword Counts
lAbility to independently turn ON or OFF AN with Link training, or FEC,
or to allow IEEE defaults to automatically manage the interoperability
or FEC, or to allow IEEE defaults to automatically manage the
interoperability
50GE:
lEthernet Forward Error Correction:
oFC-FEC, Clause 74 for BASE-R PHYs
oRS-FEC, Clause 91 for 50GBASE-R PHYs
Chapter 1 About UHD100T32
913-2626-01 – 2 –

Specifications
UHD100T32
Perpetual
Part number: 944-
1180
UHD100T32
Base Subscription
Part number:
U100-BASE
UHD100T32
Standard
Subscription
Part number: U100-
STANDARD
lFEC statistics:
oFEC Corrected and Uncorrected Codeword Counts
lIndependent fan-out ports with physical fan-out media for up to
2×50GE per QSFP28 port
40GE:
lAuto-negotiation (AN), Clause 73 for passive copper DAC
lLink training for copper cable media, Clause 73
25GE:
lAuto-negotiation (AN), Clause 73 for passive copper DAC.
lLink Training (LT) for 25GE copper DAC media (Clause 93, 110)
Note: Clause 72 link training patterns are not supported
lEthernet Forward Error Correction:
oFC-FEC, Clause 74 for BASE-R PHYs
oRS-FEC, Clause 108 for 25GBASE-R PHYs
lFEC statistics:
oFEC Corrected and Uncorrected Codeword Counts
lAbility to independently turn ON or OFF AN with Link training, or FEC,
or to allow IEEE defaults to automatically manage the interoperability
lIndependent fan-out ports with physical fan-out media for up to
4×25GE per QSFP28 port
10GE:
lIndependent fan-out ports with physical fan-out media for up to
4×10GE per port
Transceiver
Support
l100GBASE-SR4 and 4×25GBASE-SR QSFP28 for multimode fiber
oPluggable transceiver
o100GE speed support requires a point-to-point cable
o40GE speed support requires a point-to-point
o25GE speed support requires a point-to-point cable or a fan-out
cable
o10GE speed support requires a point-to-point cable or a fan-out
cable
l100GBASE-LR4 QSFP28 for single-mode fiber
Chapter 1 About UHD100T32
– 3 – 913-2626-01

Specifications
UHD100T32
Perpetual
Part number: 944-
1180
UHD100T32
Base Subscription
Part number:
U100-BASE
UHD100T32
Standard
Subscription
Part number: U100-
STANDARD
oPluggable transceiver
o40GE speed not compatible with 100GBASE-LR4 QSFP28. Must
use 40GBASE-LR4 QSFP transceiver for 40GE speed
l100G PSM4 QSFP28 for single mode fiber
oPluggable transceiver
o100GE support requires a point-to-point cable
o25GE support requires a point-to-point or a fan-out cable
Cable Media l100GBASE-SR4 multimode fiber Active Optical Cable (AOC) and MT-
MT 12-fiber point-to-point cables for QSFP28
l100GBASE-CR4, passive, copper Direct Attached Cable (DAC) up to
five meters in length
Note: Requires RS-FEC to be enabled
l50GBASE-CR2 passive, copper Direct Attached Cable (DAC) QSFP28-
to-2×QSFP28 fan-out media, up to 3 meters in length
Note: Requires BASE-R FEC Clause 74 or RS-FEC Clause 91 to
be enabled
l50GBASE-SR2 multimode fiber Active Optical Cable (AOC) media, 850
nm, three meter length
l25GBASE-SR multimode fiber Optical Cable (AOC) and MT-MT 12-fiber
point-to-point cable for QSFP28, three meter length is available
l25GBASE-SR multimode fiber MT-to-4×LC fan-out cable for QSFP28,
three meter and five meter lengths are available
l25GBASE-LR single mode fiber MT-to-4×LC fan-out cable for QSFP28,
three meter length is available
l25GBASE-CR passive, copper Direct Attached Cable (DAC) point-
point, up to five meters in length
Note: Requires BASE-R FEC Clause 74 or RS-FEC Clause 91 to
be enabled
l25GBASE-CR passive, copper Direct Attached Cable (DAC) QSFP28-
to-4×SFP28 fan-out media, up to five meters in length
Note: Requires BASE-R FEC Clause 74 or RS-FEC Clause 91 to
be enabled
Chapter 1 About UHD100T32
913-2626-01 – 4 –

Specifications
UHD100T32
Perpetual
Part number: 944-
1180
UHD100T32
Base Subscription
Part number:
U100-BASE
UHD100T32
Standard
Subscription
Part number: U100-
STANDARD
Fixed Chassis System
Dimensions (W × D ×
H)
440 × 509 × 44 mm (17.32 × 20.03 × 1.73 inches)
Fixed Chassis System
Weights
lHardware only: 20.05 lbs. (10.00 kg)
lShipping: 25 lbs. (11.33 kg)—Approximate (includes rackmount
slides, power cords, sync cables, and packaging)
Fixed Chassis System
Electrical Power
Two redundant, load-sharing hot-swappable AC, 1000 W
100 to 240 VAC at 50–60 Hz
Fan Hot-swappable fans with N+1 redundancy
Temperature Operating: 0 °C to 40 °C (32 °F to 104 °F)
Storage: -40 °C to 70 °C (-40 °F to 158 °F)
Humidity 0 % to 95 %, non-condensing
Regulatory
Compliance
Specifications
IEC/EN/UL/CSA 60950-1, IEC/EN/UL/CSA 62368-1, CE (LVD, EMC, RoHS),
EN/IEC 55032, EN/IEC 55024, CFR 47, FCC Part 15B, ICES-003, AS/NZ
CISPR 32/24, KN32/35, Korea (KCC), Customs Union (EAC)
Transmit Feature Specifications
Transmit Engine Wire-speed packet generation with timestamps, sequence numbers and
packet group signatures
Max. Streams per Port
and Speed
l100GE: 16 streams
l50GE: 8 streams
l40GE: 16 Streams
l25GE: 4 streams
l10GE: 4 streams
l100GE: 1 stream
l50GE: 1 stream
l40GE: 1 stream
l25GE: 1 stream
l10GE: 1 stream
l100GE: 16 streams
l50GE: 8 streams
l40GE: 16 Streams
l25GE: 4 streams
l10GE: 4 streams
Stream Controls lRate and frame size change on the fly
lAdvanced stream scheduler support
Minimum Frame Size l200 bytes at full
line rate
l64 bytes at full line
rate on a subset of
200 bytes at full line
rate
l200 bytes at full
line rate
l64 bytes at full line
rate on a subset of
Chapter 1 About UHD100T32
– 5 – 913-2626-01
