VEHICLE SPECIFICATION 2010
www.kiamotors.ie

APPEARANCE AND AUDIO LX TX EX
16” alloy wheels - x x
16” steel wheels x - -
Michelin/ silica tyres x - x
Michelin V-let energy saver tyres - x -
Temporary spare wheel x x x
Tinted glass x x x
Body coloured door handles x x x
Body coloured bumpers x x x
Body coloured rear garnish x x x
Black bezel headlamps - x -
Chrome Grill x x x
Metallic centre fascia (silver) x x x
Front fog lamps x x x
In-dash single CD/MP3 RDS audio with USB & AUX input x x x
Rear roof-mounted aerial x x x
Four speakers x - x
Tweeter speakers x - x
6 speakers - x -
COMFORT AND CONVENIENCE LX TX EX
Keyless entry x x x
Power steering x x x
Lane change signal on indicator x x x
Steering wheel tilt/telescopic adjustment x x x
Leather covered steering wheel & gear lever - x x
Steering wheel audio remote x x x
Digital clock, calendar, outside temperature x x x
Trip computer inc: distance, fuel consumption, speed x x x
Sunvisors with covered vanity mirrors x x x
Sunvisor ticket holders x x x
Internal fuel flap release x x x
Central tail gate lock / unlock x - x
Door scuff guards x - x
Grab handles x 3 x x x
Rear coat hook x x x
Front cup holders x 2 x x x
Rear cup holders x 2 x x x
Centre console power outlet x x x
Front ashtray & cigar lighter x - x
Map lamp with sunglasses case x - x
Load area light x x x
Front door mounted courtesy reflector x x x
Driver and passenger seat lumbar support with lever x x x
Slide & reclining front passenger seat x x x
Drivers seat height adjustment x x x
Seatback pockets x x x
60:40 split folding rear seats x x x
Centre armrest with storage box x x x
Luggage net fixings x - x
Glove box with damper & illumination x - x
Glove box cooling x x x
Cloth upholstery x x -
Half leather upholstery - - x
Driver’s foot rest x x x
SAFETY & SECURITY LX TX EX
ABS with EBD x x x
Driver & passenger airbags x x x
Passenger air-bag cut-off switch x x x
Active headrests (front) x x x
Speed sensing auto door locking x x x
Impact sensing door unlocking x x x
Front power safety window (auto up/down with sensor) x x x
Rear power safety window (auto up/down with sensor) - - x
Side and curtain airbags x x x
Front seatbelt pre-tensioners with load limiters x x x
Rear seatbelt reminder warning x x x
3 x 3-point rear belts x x x
Front seat belt reminder x x x
ISOFIX rear anchor points x x x
Height adjustable front seatbelts x x x
Height adjustable front and rear head restraints x x x
Rear cargo area cover x - x
Engine immobiliser x x x
Deadlocks -x-
Child proof rear door locks x x x
Centre fascia door locking switch x x x
Visible Vin x x x
VENTILATION AND VISIBILITY LX TX EX
Air conditioning x x x
Cabin air filter x x x
Front electric windows x x x
Rear electric windows - - x
Body coloured electrically controlled heated with wide view
door mirrors
xxx
Variable intermittent front wipers x x x
Heated rear window x x x
Courtesy room light x x x
Rear wiper x x x
Multi speed heater system (Rotary type) x x x
MODEL FEATURES

MODEL FEATURES
1.4 1.6 Auto 1.6 CRDi 1.6 CRDi
Engine Type 1.4 DOHC CVVT 1.6 DOHC CVVT 1.6 CRDi VGT 1.6 CRDi VGT
Capacity (cc) 1,39 6 1,591 1,582 1,582
Max power (bhp/kw @ rpm) 109/80 @ 6,200 122/89.7 @ 6,200 115/84.6 @ 4,000 113/85 @ 4,000
Max Torque (Nm @ rpm) 137 @ 5,000 154 @ 4,200 255 @ 1,900 – 2,750 255 @ 1,900 – 2,750
Bore / stroke (mm) 77 / 74.99 77 / 85.44 77.2 / 84.5 77.2 / 84.5
Ignition system Distributorless ignition Distributorless ignition Compression ignition Compression ignition
Fuel injection system Multi point injection Multi point injection Common rail diesel injection Common rail diesel injection
Emission control Euro IV Euro IV Euro IV Euro IV
Transmission 5-speed manual 4-speed automatic 5-speed manual 6-speed manual
Emission system Catalytic convertor Catalytic convertor – –
DIMENSIONS 1,755
Overall length (mm) 4,235 4,235 4,235 4,235
Overall width (mm) 1,790 1,790 1,790 1,790
Overall height (mm) 1,4 80 1,480 1,480 1,4 8 0
Wheelbase (mm) 2,650 2,650 2,650 2,650
Wheel tread – front (mm), rear(mm) 1,546, 1,544 1,546, 1,544 1,546, 1,544 1,546, 1,544
Overhang – front (mm) 865 865 865 865
Overhang – rear (mm) 720 720 720 720
INTERIOR DIMENSIONS
Length (mm) 1,880 1, 880 1, 880 1, 880
Width (mm) 1,490 1,490 1,490 1,490
Height (mm) 1,235 1, 235 1, 235 1, 235
Max front headroom (mm) 1, 020 1,020 1,020 1,020
Max rear headroom (mm) 980 980 980 980
Max front legroom (mm) 1,105 1,105 1,105 1,105
Max rear legroom (mm) 900 900 900 900
Max front shoulder room (mm) 1,410 1,410 1,410 1,410
Max rear shoulder room (mm) 1,385 1,385 1,385 1,385
Cargo area (min) seats up (litres) 340 340 340 340
Cargo area (max) seat folding (litres) 1,30 0 1,300 1,30 0 1,300
SPECIFICATIONS
Max towing weights (kg) trailer without brakes 550 550 550 550
Maximum ball weight (kg) 55 75 75 75
Maximum roof load (kg) 80 80 80 80
Fuel tank capacity (litres) 53 53 53 53
SUSPENSION, STEERING & BRAKES
Front suspension McPherson strut with coil spring McPherson strut with coil spring McPherson strut with coil spring McPherson strut with coil spring
Rear suspension Multi Link Multi Link Multi Link Multi Link
Shock absorber Gas Gas Gas Gas
Steering system Motor driven power steering Motor driven power steering Motor driven power steering Motor driven power steering
Minimum turning (lock to lock) 2.69 turns 2.69 turns 2.69 turns 2.69 turns
Turning radius 5.17m 5 .17m 5.17m 5.17m
Anti-lock braking system ABS ABS ABS ABS
Front brakes Ventilated disc Ventilated disc Ventilated disc Ventilated disc
Rear brakes Solid disc Solid disc Solid disc Solid disc
Parking brake Drum in Hat Drum in Hat Drum in Hat Drum in Hat
Battery 45 AH 45 AH 68 AH 68 AH
PERFORMANCE
Maximum speed (kph) 187 187 188 188
Acceleration 0-100 kph (seconds) 11. 6 11.4 11. 5 11.1
FUEL CONSUMPTION (OFFICIAL GOVT. TEST FIGURES)
Urban (cold) l/100km 7.6 8.9 5.7 5.3
Extra urban mpg l/100km 5.2 5.8 4.2 4.0
Combined mpg l/100km 6.1 6.9 4.7 4.5
Emissions CO2g/km 145 165 125 118
Servicing 15,000 km or 1 year,
whichever is sooner
15,000 km or 1 year,
whichever is sooner
15,000 km or 1 year,
whichever is sooner
15,000 km or 1 year,
whichever is sooner
