VEHICLE FEATURE TIPS

OWNER’S MANUAL, FEATURES AND FUNCTIONS GUIDE

Many of the Tips presented below are covered in greater detail

in the Owner’s Manual, Multimedia System Manuals, Features

and Functions Guide and Quick-Start Guide hangtag supplied

with your new vehicle.

VOICE RECOGNITION1AND BLUETOOTH®2

Using Voice Recognition

Improve Bluetooth®2 Voice Recognition (VR)

performance by making a few simple changes to your

phone contacts:

• Use full names (first and last names) vs. short

or single syllable names (“John Smith” vs. “Dad,”

“Smith Residence” vs. “Home”).

• Avoid using special characters, emojis, and

hyphenated names (@, &, #, /, -, *, +, etc.).

• Avoid using acronyms (“Emergency” vs. “ICE”

or “In Case of Emergency”) or words with all

capital letters.

• Spell words completely; system will not recognize

abbreviations (“Doctor Smith” vs. “Dr. Smith”).

• Always wait for the beep before speaking

any commands.

• When using VR to place a call, speak in a natural,

moderate tone, with clear pronunciation. The

system may have trouble recognizing commands if

you speak too soft or too loud.

• Open windows, sunroof, weather (wind/rain), or an

A/C fan operating at higher speeds can interfere

with VR accuracy.

• Your VR system may have difficulty understanding

some accents or uncommon names.

• Press the talk button and say “Help” to get a list of

available commands.

Pairing or Connecting Your Phone with Bluetooth®2

• Press the Phone hard key (if equipped) or “Call”

button on the steering wheel to begin the pairing

process if no phone has previously been paired.

• To pair a second phone or subsequent phones,

reference the manuals and guides supplied with your

Stinger as steps vary by radio.

• During the pairing process, please make sure you

accept all requests for phonebook download and

future auto-connection on your phone.

• If you experience any issues with auto-connection,

try the following:

• Reboot your phone (turn the phone off and then on).

• Update the phone operating system to the most

recently released version.

• Delete the phone from the UVO display and the

UVO display from the phone, and re-pair.

• Ensure the phone has the Bluetooth®2

feature activated.

• If some contacts are not downloading to the UVO

display, check to confirm that the contact has been

entered correctly and that it has been stored under the

categories (HOME, MOBILE, WORK, iPhone®3) that are

supported by the UVO display. Some contact categories

(MAIN, PAGER, OTHER) may not be supported. If the

number of contacts exceeds the maximum number

allowed on the UVO display, contacts will be partially

downloaded. Ensure that only the “phone contact list” is

selected for contact download on your phone (not social

media or email contact lists as these contacts may not

download to the UVO display).

• Phone operating systems change frequently and some

phones may have varying compatibility levels with the

Bluetooth®2 system. For any questions regarding the

features of your vehicle, please contact your preferred

Kia dealer or contact Kia Consumer Assistance at

1-800-333-4542.

Other Bluetooth®2 Tips

• Bluetooth®2 reception is affected by carrier coverage

and is dependent on the phone.

• If streaming audio through Bluetooth®2 from a device,

ensure the listening volume on the device is turned up.

SATELLITE RADIO RECEPTION

Satellite radio reception requires direct line of sight with the satellite transmitting

the radio signal. Tunnels, bridges, covered parking, mountainous terrain, tall buildings,

heavy foliage, and other obstacles may momentarily interrupt the signal. This is

normal operation, and reception will be restored within a few seconds in an open,

unobstructed area.

The signal can become weak in some areas that are not covered by the satellite

repeater network.

SMARTPHONE CONNECTIVITY1

Apple CarPlayTM3

Your vehicle offers you effortless command of your compatible iPhone®when you connect

through Apple CarPlayTM on your UVO display. This will enable you to make calls, send hands-free

texts, access your favorite music and apps, and get navigation help with Siri®voice control.

To connect Apple CarPlay, visit https://youtu.be/N1FQ1VqDt4A.

Android AutoTM3

Your vehicle allows you to connect to your compatible AndroidTM phone via Android Auto on your

UVO display. Through this feature, you can access music, your phone’s dialer, navigation help and

more with an intuitive interface and voice commands. You can even access your phone through

your steering wheel controls.

To connect Android Auto, visit https://youtu.be/QPV7y06-RJ4.

USB PORTS AND USE OF CABLES

Vehicle may contain USB port(s) for playing music from a compatible media device as well as USB port(s) for charging.

Note: Devices will only be recharged when the vehicle is in ACC/ON/Start position. If you encounter difficulty plugging in a

USB device, change the orientation of the device (may be upside down). Always use the USB charging cable that has been

certified by the phone manufacturer. Use of aftermarket cables is NOT recommended as they may affect functionality.

QR CODE

To view a video on your mobile device, snap this QR Code

or visit the listed website.

https://www.youtube.com/KiaFeatureVideos

AUTO HOLD*

OFF

(Button located below

Gear Shift)

Auto Hold temporarily maintains the vehicle at a standstill even if the brake pedal is

released. Auto Hold can be turned ON/OFF using the AUTO HOLD switch Alocated below

the Gear Shift. Before Auto Hold will operate, the driver’s door, engine hood and trunk

must be closed, and the driver’s seat belt must be fastened.

The Auto Hold indicator has four states:

White: Standby - With vehicle at a standstill, and AUTO HOLD switch Aturned ON, the

indicator will illuminate white. While driving the vehicle (vehicle is not at a standstill), the

Auto Hold indicator will remain white.

Green: Engaged - When coming to a complete stop by depressing the brake pedal, the

Auto Hold indicator changes from white to green.

OFF (not illuminated) - The indicator will turn OFF when the AUTO HOLD switch Ais

manually turned OFF or when the EPB is manually turned ON.

Yellow: Malfunction - When the indicator is illuminated yellow, there may be a system

malfunction. Take your vehicle to a local Kia dealer.

FRONT SEAT HEADREST ADJUSTMENT

To raise headrest: Pull headrest up.

To lower headrest: Press lock A, then press the headrest down.

REMINDER: Do not adjust the headrest while driving as this may cause you to lose

control of the vehicle.

SMART POWER LIFTGATE OPERATION*

To open the Smart Power Liftgate,* press and hold the Smart Key Liftgate button until

the Liftgate begins opening. To close, push the power liftgate close button located inside

the liftgate lid, press and hold the Smart Key Liftgate button again, or push the button on

the dash panel to the left of the steering wheel.

When the Smart Key fob is on your person and you are near the back of the vehicle,

within close proximity, the hazard lights will blink and a chime will sound for about

3 seconds as an alert that the Smart Power Liftgate* is about to open.

Then the alert system will blink and chime two additional times before opening the

Smart Power Liftgate.*

The Smart Power Liftgate* feature is OFF by default. To enable the Smart Power

Liftgate,* go to User Settings in the LCD Instrument Cluster modes.

WIRELESS SMARTPHONE CHARGING SYSTEM*

12V

180W

AUX USB

1. Slide open tray cover A.

2. Place compatible smartphone on the center of the charging pad B.

3. Indicator light Cwill change to amber once the wireless charging begins.

4. Once charging is complete, the amber light Cwill change to green.

LANE KEEPING ASSIST (LKA) / LANE DEPARTURE WARNING (LDW)*5

(Button panel located left

of Steering Wheel)

If an unintentional lane departure is detected, LDWS*5may issue a warning on the LCD screen.

With the Engine Start/Stop button in the ON position, press the LDWS5button Ato turn

the system ON. The LDWS5icon in the instrument cluster will illuminate green. To cancel,

press the button again.

When the vehicle exceeds approximately 37 mph and the LDWS5system recognizes

the lane the vehicle is traveling in, the lane indicators will both be illuminated. If the

vehicle begins to drift, the lane indicator will blink either on the left or right lane in the

instrument cluster with an audible alert.

CHECK ENGINE LIGHT FROM FUEL CAP

Tighten the cap until it clicks one time, otherwise the Check Engine

Light may illuminate.

The Fuel Filler Door Release button is located on the driver’s side

lower dash next to the trunk release.

DRIVE MODE INTEGRATED CONTROL SYSTEM

(Button located below Gear Shift)

VIEW

The Drive Mode Integrated Control System includes 4 drive modes: SMART, COMFORT,

SPORT/CUSTOM and ECO. The system drive mode will default to COMFORT at each key

cycle except when ECO is the selected mode prior to the key “off.” If it is in ECO mode,

ECO mode will be set when the engine is restarted. To change the drive mode, rotate the

DRIVE MODE knob. When SMART mode is activated, the system automatically selects the

drive mode best suited to the current driving style.

HEAD-UP DISPLAY (HUD)*

The Head-Up Display (HUD) is a transparent display that projects a snippet of information from the instrument cluster

and navigation system onto the windshield glass. Drivers can turn the HUD display on or off in User Settings.

The HUD displays:

• Turn By Turn (TBT) navigation information4

• Road signs

• Speedometer

• Cruise setting speed

• Smart Cruise Control (SCC) with Stop &

Go information*

• Blind Spot Collision Warning (BCW) information*

• Warning lights (low fuel, BCW)

• AV Mode information

Head-Up Display (HUD) Display Settings

Drivers can adjust the HUD settings from the LCD

Instrument Cluster modes in User Settings. HUD

settings include:

• Display Height: Adjust the height of the HUD

image on the windshield glass

• Rotation: Adjust the degree of HUD rotation

• Brightness: Adjust the intensity of the

HUD brightness

• Contents Select: Activate or deactivate HUD

content (TBT,4SCC, LDW, BCW)

• Speedometer Size: Choose the size of the HUD

speedometer (Small, Medium, Large)

• Speedometer Color: Choose the color of the HUD

speedometer (White, Amber, Green)

Warning: Failure to pay attention to travel conditions and vehicle operation could result in loss of vehicle control.

Always drive safely and use caution.

FORWARD COLLISION-AVOIDANCE ASSIST-PEDESTRIAN (FCA-Ped) /

FORWARD COLLISION WARNING (FCW)*5

Collision Warning

Emergency Braking

The FCA-Ped5is designed to help alert the driver, and under certain conditions if necessary,

apply emergency braking, when rapidly approaching a vehicle that is slowing down, braking

or stopped. Initially, the FCA-Ped5provides FCW5when it detects a potential collision with

a vehicle in front by emitting an audible warning and visual alert on the instrument cluster.

Adjust the alert settings (Early, Normal, Late) in the User Settings. To turn the FCA-Ped/

FCW5off, go to User Settings again and turn off.

If the system detects possible imminent collision, under certain conditions, the FCA-Ped5

automatically applies the brakes to reduce your speed, helping minimize the effects of a

possible collision. FCA-Ped4can be turned ON in the User Settings menu on the Instrument

Cluster display.

The FCA-Ped/FCW5will become active when the:

• Engine Start/Stop button is ON

• Vehicle is traveling more than 5 mph

• Electronic Stability Control (ESC) is ON

WINDSHIELD DEFOGGING

AUTO

SYNC

OFF

CLIMATE

A/C

REARFRONT

AB Windshield fogging is caused by moisture in the air condensing on the cold glass. The

following practices can help reduce window fogging:

• Keeping the inside of the glass as clean as possible.

• Utilizing the Defrost Mode A, which activates the A/C and opens Fresh Air Vent.

• Adjusting the Temperature Control Bto the desired temperature.

PARKING ASSIST SYSTEM5

The Parking Assist System5is a supplemental system that assists the driver by

chiming if an object is detected within the sensing areas in the front and rear of

the vehicle when parking or backing up.

When the Engine Start/Stop button is ON and the shift lever is in R (Reverse),

the system is activated and the Parking Assist button indicator is illuminated.

When the ignition is ON, the system is activated. If the vehicle is moving at speeds

over 6 mph, the system may not activate correctly.

When more than two objects are sensed at the same time, the closest one will be

recognized first.

Parking Assist System is not a substitute for safe driving, and may not detect

every object behind or in front of the vehicle. Always drive safely and use caution.

(Rear sensors shown)

WINDSHIELD WIPER SERVICING POSITION

To inspect or replace the windshield wiper blades without damaging the hood, move the

blades to the service position A

. After turning the ignition OFF, within 20 seconds, move

the wiper switch to the MIST position and hold the switch for more than two seconds until

the wiper blade is in the fully up position.

SEAT WARMERS6/ VENTILATED SEATS*

(Buttons located below Gear Shift)

AUTO

HOLD

DRIVEMODE

OFF

• Seat Warmers6– Press button Aup once for high setting (3 LEDs lit). Press button

twice for medium setting (2 LEDs lit). Press a third time for low setting (1 LED lit) and

again to turn OFF.

• Ventilated Seats – Press button Bdown once for high setting (3 LEDs lit). Press twice

for medium setting (2 LEDs lit). Press a third time for low setting (1 LED lit) and again to

turn OFF.

DRIVER POSITION MEMORY SYSTEM*7

(Buttons located on Driver’s Door Panel)

To store a seating position into memory, first place the shifter into P (Park) while the

ignition switch is ON. Then:

1. Adjust the driver’s seat, outside rearview mirrors, leg extension,* and steering

wheel positions.

2. Press the Memory button Aon the control panel. The system will beep once.

3. Press one of the memory buttons (“1” or “2”) Bwithin 4 seconds. The system will beep

twice when memory has been stored.

4. “Driver (1 or 2) set is memorized” will appear on the instrument cluster LCD display.

BLIND-SPOT COLLISION WARNING (BCW) SYSTEM*5

The BCW system*5uses radar sensors in the rear bumper to monitor and warn the driver

of an approaching vehicle detected in the driver’s blind spot area.

When the BCW5button is pressed ON, the BCW5indicator on the button will illuminate.

The outside rearview mirror warning lights will also illuminate for 3 seconds.

The system will become active when the vehicle is traveling more than 20 mph and will

alert the driver if another vehicle is detected by the radar sensor.

SURROUND VIEW MONITORING (SVM) SYSTEM*5

The SVM system5is a parking assistance system that shows the areas around the

front, rear, left and right sides of the vehicle via four cameras displayed onto the

navigation screen.

Press Ato turn the SVM system5ON/OFF.

• When OFF: The camera view will automatically display on the navigation screen when

the vehicle is shifted into Reverse. The camera view will turn off when the vehicle is

shifted out of Reverse.

• When ON: The camera view will display on the navigation screen in both Drive and

Reverse. In Drive, the camera view will continue to display until the vehicle is traveling

at speeds above approximately 13 mph. If you keep the SVM system5on, the camera

view will reappear on the navigation screen whenever the vehicle speed drops below

approximately 13 mph.

Images or graphics for illustration only. *If equipped. (1) The driver’s primary responsibility is in the safe and legal operation of a vehicle, and use of any handheld

devices, other equipment or vehicle systems which take the driver’s focus away from the safe operation of a vehicle or that are not permissible by law should

never be used during operation of the vehicle. (2) The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such

marks by Kia is under license. A Bluetooth®enabled cell phone is required to use Bluetooth®Wireless Technology. (3) Apple CarPlay, iPhone and Siri are registered

trademarks of Apple Inc. Android and Android Auto are trademarks of Google LLC. (4) If Turn By Turn (TBT) navigation information is selected as HUD content,

TBT information will not be displayed on the LCD. (5) Driver-assist technologies are not substitutes for safe driving, and may not detect all objects surrounding

vehicle. Always drive safely and use caution. (6) Use extreme caution when using the seat warmers to avoid burns. Refer to the Owner’s Manual for more safety
