KID Trax KT1309TR User manual

tWARNING
This manual contains important safety
and use informaon. Keep this manual for
future reference.
• An adult must read this enre manual
• Adult supervision is required at
all mes
12V LAND ROVER
DEFENDER
KT1309TR, KT1363TR
Age: 3 - 7 yrs
Weight: Maximum 130 lbs (59 kg)
Maximum Speed: 5 MPH
Baery: 12V12AH

2
-- WARNING
Safety
1
FAILURE TO FOLLOW THE SAFETY INSTRUCTIONS LISTED BELOW MAY RESULT IN SERIOUS INJURY OR DEATH. The owner’s manual
contains assembly, use and maintenance instrucons.
Child Safety Warnings
• Adults supervising children must read and understand this enre
manual before allowing any child to use this product.
• Adults must evaluate their own children as to maturity, strength,
judgment and ability to follow safety rules. Published age
guidelines are not a substute for careful evaluaon of your own
child.
• Adults must teach children about thinking ahead while riding as
this may be the rst me a child has ever controlled a motorized
ride-on toy. While you supervise, see through the child’s eyes,
and verbally teach them about steering and avoiding obstacles in
the approved riding area.
• Riding a motorized ride-on toy can be a dangerous acvity,
even under the best of circumstances. Good choices regarding
where and when to ride, constant adult supervision of riding,
and pracce and careful riding by the child can all help to
minimize risk. However this ride-on toy is intended to move and
therefore it is possible to lose control, fall o and/or get into
dangerous situaons that no amount of care, instrucon or
experse can eliminate.
• If this inherent risk is not acceptable, adults should not allow
children to ride this ride-on toy.

3
--
Safe Riding Warnings
Before using the ride-on toy the child should understand the
controls and safety issues. They must also demonstrate the
capability to handle the ride-on toy and operate its controls. It is
the responsibility of the adult to educate the child and supervise
the use. Explain the following safety warnings to any child using
the ride-on toy before riding
• Adults must teach their children not to allow other children to
use this ride-on toy. Adults must communicate this message to
the adult supervisors of friends and neighbors who have
children that play with your children.
• Never leave child unaended. Connuous adult supervision
required.
• Body parts such as hands, legs, hair and clothing can get caught
in moving parts. Never place a body part near a moving part or
wear loose clothing while using the ride-on toy.
• Always wear shoes when using the ride-on toy.
• Not to be used by children under 3 years of age or over 7 years
of age.
• Do not exceed the maximum weight capacity of 130 lbs (59 kg).
• Children must not have access to the charging equipment or
touch any part of the ride-on toy while it is charging.
• Always use common sense and safe pracces when using the
ride-on toy.
• Never use the ride-on toy in an unsafe manner. Examples include
but are not limited to:
ͳPulling the ride-on toy with another ride-on or similar
moving product
ͳAllowing more than two rider
ͳPushing the user from the back
ͳTraveling at an unsafe speed
ͳAny kind of stunt riding or other more risky use
ͳGoing over jumps or other type of ramps
ͳ Not riding in a seated posion
ͳ Not riding with the baery or other covers fully closed
• ADULTS MUST SET UP PHYSICAL BARRIERS, SUCH AS GATES OR
FENCES, TO KEEP CHILDREN AWAY FROM HAZARDOUS AREAS.
• Always use the ride-on toy in a safe, secure environment with
connuous adult supervision.
• This ride-on toy does not have brakes or any braking capability.
Do not leave a child unaended while using this ride-on toy or
allow use of this ride-on toy in any locaon that requires braking
capability, as this could result in a roll away or loss of control,
which may cause serious injury or death.
WARNING

4
----
Baery and Charging Warnings
The following safety hazards may result in serious injury or
death to the user of the ride-on:
Corrosive Material Warnings
• Baery posts, terminals and related accessories contain lead
and lead compounds (acids) chemicals and are toxic and
corrosive. Never open the baery.
• Contact or exposure to baery leakage (lead acid) may cause
serious injury. If contact or exposure occurs with the skin or in
the eyes, or if the chemical is swallowed, immediately call 911.
Safe Riding Warnings (connued)
• Do not ride in wet condions such as rain and snow. Doing so
may result in unexpected acon such as p over and skidding,
as well as damage to the electrical system and baery.
• Do not ride near swimming pools or other bodies of water.
• Do not ride on roads, streets, near other ride-on toys or where
other types of moving objects are present.
• Do not ride at night or in condions of low visibility.
• Do not ride near drop-os such as steps, sloped surfaces
or hills.
• Do not ride into loose dirt, mud, sand, ne gravel, loose gravel
and rough surfaces.
• For best performance, ride-on at, hard surfaces.
• Never hitch (aach) on to another ride-on or pull anyone
or anything.
WARNING WARNING

5
--
Electric Shock / Fire Warnings
• Liquids on the baery may cause re or electric shock.
Always keep all liquids away from the baery and keep the
baery dry.
• Tampering or modifying the electric circuit system may cause a
shock, re or explosion and permanently damage the system.
Exposed wiring, circuitry in the charger may cause electric
shock. Always keep the charger housing closed.
• Regularly check charger, supply cord and connector for wear
and damage. Look for frayed or kinked wires, any exposed inner
wires, any missing insulaon. If any damage is observed do not
plug in the charger and do not charge
the baery.
WARNING
Flammable and Explosive Materials Warnings
• Use of a baery or charger other than the supplied 12V
rechargeable baery and charger may cause a re or explosion.
Only use the supplied 12V rechargeable baery and charger with
the ride-on toy.
• Do not charge the baery near heat or ammable materials.
• Using the 12V recharbeable baery and charger for any other
product many result in overheang, re or explosion. Never use
the 12V rechargeable baery and charger with another product.
• Contact between the posive and negave terminals may result
in re or explosion. Avoid direct contact between the terminals.
Liing the baery by the wires or charger can cause damage to
the baery and may result in a re. Always li the baery by its
case or handles.
• Plug wall charger directly into a wall outlet. Do not use an
extension cord when charging as the use of an extension cord
can cause a re.
Baery and Charging Warnings (connued)

6
-- CAUTION
WARNING
If you are unsure of any informaon in this manual or have a queson regarding assembly or use please call customer service. Always
keep this manual for reference and include it with resale of the ride-on toy.
Re-Charge Interval and Time
Important!
• Damage to the baery may occur if it is allowed to drain
completely. Do not allow the baery to drain completely.
• Check the baery and charger (supply cord, connector) for
wear and damage before charging. Do not charge the baery if
damage has occurred. Do not use an extension cord when
charging the ride-on toy.
• On average you will need to charge the baery for 12 hours
and no more than 24 hours. Failure to charge the baery as
directed could cause permanent damage to the baery and
void the warranty.
• Only an adult who has read and understands the safety
warnings should handle, charge and recharge the baery.
Product Warning
• This product can expose you to chemicals including lead, which
is known to the State of California to cause cancer and birth
defects or other reproducve harm. For more informaon go
to www.P65Warnings.ca.gov.
Assembly Warnings
• The ride-on toy must be assembled by an adult who has read
and understands the instrucons in this manual.
• Choking hazard to children under the age of 3 years.
This ride-on toy contains small parts that are for adult
assembly only. Keep small children away when assembling.
• Remove and dispose of all protecve materials, plasc bags
and packaging before assembly.

7
PRE-RIDE SAFETY CHECKLIST
(To be performed by a supervising adult)
Before every ride, it is important to carry out the following
safety checks. Do not ride a baery powered ride-on toy that is
not in proper working condion! Replace any worn or broken parts
as needed.
Steering and Control
The steering wheel or handlebars are ghtened and secured in
the mount or dashboard.
The steering wheel or handlebars are posioned so that the
rider can easily operate and steer the ride-on. There must be
no diculty for the rider in turning and/or operang the
powered foot pedal or hand operated push buon.
The steering wheel or handlebars are aligned so that the
steering column and front wheels are oriented in the
same direcon.
Wheels
The wheels are securely aached to the baery powered
ride-on and the are in good condion. It is acceptable to have
slight lateral movement in each wheel.
The wheels have no holes or are worn down in any one area
and that the tracon strips are intact and secured to the
wheels.
The drive wheel is securely fastened to the gear box, which
houses the motor.
Ride-on
For all electrical components, make sure:
ͳ The baery is fully charged
ͳ The charging cord is NOT aached to the ride-on in
any way
ͳAll connectors are securely snapped in place and will not
come detached while riding
ͳNo wiring is exposed, worn, or detached in any way; the
motor is not hot to touch
ͳ All electrical buons, including the power buon,
accelerator foot pedal or hand operated buon, and any
buons for lights and sounds, work properly
ͳIf the ride-on’s electrical components show any sign of
damage or missing parts DO NOT RIDE unl the condion
is corrected
Make sure the ride-on is:
ͳ Clean, dry, and in good condion
ͳ All plasc pieces, including fenders, seat, footrests,
steering wheel or handlebars, wheels, bumpers, and/or
hub caps are securely aached
ͳThere are no cracks or structural problems on the
ride-on toy
ͳIf the ride-on toy shows any sign of damage or missing
parts DO NOT RIDE IT unl the condion is corrected
Make sure all safety labels are in place and readable, and
understood by the rider.

8
Parts
2
19 20
1
6
7
54
3
2
8
910
1112
13
14 15
1617
18

9
Before beginning assembly, check to ensure that the parts listed are
present. Some hardware is aached to the sub assembly.
Hardware
Tools Required
x1 x1
Parts List
#Part name Quanty
1Front Bumper 1
2Front Wheel Well 2
3Mirror Assembly 2
4Mirror 2
5Snorkel 1
6Rear Wheel Well 2
7Seat 2
8Steering Wheel 1
9Roll Bar Assembly 1 2
10 Roll Bar Assembly 2 1
11 Rear Bumper 1
12 Rear Bumper Brace 2
13 Rear Axle 1
14 Gearbox 2
15 Rear Wheel 2
16 Wheel Hubcap 4
17 Front Wheel 2
18 Steering Column 1
19 Wrench 2
20 Charger 1
x4 x6
(included)
(x13 Seat) (x2 Seat) (x6 Seat)

10
Rear Bumper Assembly
It is best to do these steps with
the Land Rover pped over. Use
a blanket or other so surface
to avoid scratches
TIP!
Front Bumper Assembly
Assembly
3
4 x 14 4 pcs
❶ ❶

11
First slide the rear bumper into place and then gently pull the rear
bumper rim over the rear support braces for an easier t.
TIP!
4 x 14 2 pcs
4 x 14 2 pcs 4 x 14 2 pcs
❷
❸
❹ ❹
❺ ❺
❸

12
Route the Baery Wire
❶
❷

13
3 x 10 6 pcs

14
The gear boxes are marked Driver Side and Passenger Side to assist in assembly
TIP!
Rear Wheel Assembly
❶ ❶ ❸ ❸ ❹ ❹
❺ ❺ ❷ ❷

15
Front Wheel Assembly
❹ ❸ ❹ ❶ ❶
❷ ❷ ❺ ❺
❸

16
Steering Wheel Assembly
It can be dicult to align and install the steering wheel. To simplify
assembly use your hand or have a helper push up on the wheel
axle so that you can align the bolt with the drill hole in the
steering column.
TIP!
❶
❷
❶

17
Rear Bumper Assembly (connued)
❹ ❸
4 x 14 3 pcs

18
Roll Bar Assembly
❶
❶
❸
❷
❷
4 x 14 2 pcs

19
Mirror Assembly Snorkel Assembly

20
Connect the wires labeled Drivers Side coming from the body of
the car to the motor wire labeled Drivers Side. Then connect the
wires labeled Passenger Side coming form the body of the car to
the motor wire labeled Passenger Side
Note
Connecng the Baery and Motors to the Vehicle
❷
❶
❸
❹
