Kidde i9040EU User manual

Manual P/N 21008004 Rev. A 0940-7204-01
ATTENTION: Please take a few minutes to thoroughly read this
user’s guide which should be saved for future reference and
passed on to any subsequent owner.
Smoke Alarm
User’s Guide
i9040EU
• 9 Volt Battery Operated
Model: i9040EU, i9060EU and i9080EU
i9060EU i9080EU
EN14604: 2005
LPCB Ref No. 904a/06
LPCB Ref No. 904a/07
LPCB Ref No. 904a/08
0832-CPD-1427
0832-CPD-1428
0832-CPD-1429
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

Smoke Alarm Procedure
NEVER IGNORE THE SOUND OF THE ALARM!
Smoke alarms are designed to minimize false alarms. Cigarette
smoke will not normally set off the alarm, unless the smoke is
blown directly into the alarm. Combustion particles from cook-
ing may set off the alarm if it is located too close to the cook-
ing area. Large quantities of combustion particles are generat-
ed from spills or when broiling. Using the fan on a range hood
which vents to the outside (non-recirculating type) will also
help remove these combustion particles from the kitchen.
If the alarm sounds, check for fires first. If a fire is discovered,
follow these steps. Become thoroughly familiar with these
steps and review with all family members:
• Alert small children in the home.
• Leave immediately by your escape plan. Every second
counts, so don’t waste time getting dressed or picking up
valuables.
• In leaving, don’t open any inside door without first feeling its
surface. If hot, or if you see smoke seeping through cracks,
don’t open that door! Instead, use your alternate exit. If the
inside of the door is cool, place your shoulder against it,
open it slightly and be ready to slam it shut if heat and
smoke rush in.
• If the air is smoky, stay close to the floor. Breathe shallowly
through a cloth, wet if possible.
• Once outside, go to your selected meeting place and make
sure everyone is there.
• Call the fire department from your neighbour’s home - not
from yours!
• Don’t return to your home until the fire officials say that it is
all right to do so.
What to do When the Alarm Sounds!
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

Welcome
i9040EU and i9060EU - 9 Volt Battery Operated Smoke Alarm with
“HUSH” Control to temporarily silence nuisance alarms.
i9080EU - 9 Volt Battery Operated Smoke Alarm with “HUSH”
Control to temporarily silence nuisance alarms and with Battery
Powered Safety Light.
Thank you for purchasing this smoke alarm. It is an important part
of your family’s home safety plan. You can trust this product to pro-
vide the highest quality safety protection. We know you expect
nothing less when the lives of your family are at stake.
Important Warning Statements
IMPORTANT! READ ALL INSTRUCTIONS BEFORE INSTALLATION
AND KEEP THIS MANUAL NEAR THE ALARM FOR FUTURE REFER-
ENCE.
WARNING: BATTERY DOOR WILL NOT CLOSE AND/OR ALARM
WILL NOT ATTACH TO MOUNTING BRACKET UNLESS BATTERY IS
INSTALLED CORRECTLY.
REMOVAL OF BATTERY WILL RENDER THE SMOKE ALARM INOPER-
ATIVE.
WARNING: TEST YOUR SMOKE ALARM OPERATION AFTER RV OR
MOBILE HOME VEHICLE HAS BEEN IN STORAGE, BEFORE EACH
TRIP AND AT LEAST ONCE A WEEK DURING USE.
CAUTION: DUE TO THE LOUDNESS OF THE ALARM (85 DECIBELS),
ALWAYS STAND AN ARMS-LENGTH AWAY FROM THE UNIT WHEN
TESTING.
CAUTION: BEFORE USING THE ALARM HUSH FEATURE, IDENTIFY
THE SOURCE OF THE SMOKE AND BE CERTAIN A SAFE CONDITION
EXISTS. NOTE: DENSE SMOKE WILL OVERRIDE THE HUSH
CONTROL FEATURE AND SOUND A CONTINUOUS ALARM.
SMOKE ALARMS ARE DEVICES THAT CAN PROVIDE EARLY WARN-
ING OF POSSIBLE FIRES AT A REASONABLE COST; HOWEVER,
ALARMS HAVE SENSING LIMITATIONS. IONISATION SENSING
ALARMS MAY DETECT INVISIBLE FIRE PARTICLES (ASSOCIATED
WITH FAST FLAMING FIRES) SOONER THAN PHOTOELECTRIC
ALARMS. PHOTOELECTRIC SENSING ALARMS MAY DETECT VISIBLE
FIRE PARTICLES (ASSOCIATED WITH SLOW SMOLDERING FIRES)
SOONER THAN IONISATION ALARMS. HOME FIRES DEVELOP IN
DIFFERENT WAYS AND ARE OFTEN UNPREDICTABLE. FOR MAXI-
MUM PROTECTION, KIDDE RECOMMENDS THAT BOTH
IONISATION AND PHOTOELECTRIC ALARMS BE INSTALLED.
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

Contents of This User’s Guide
1. Recommended Locations for Smoke Alarms
2. Locations to avoid
3. Installation Instructions
4. Operation and testing
5. Nuisance Alarms
6. Maintenance
7. Limitations of Smoke Alarms
8. Good Safety Habits
9. Ionisation Information
10. Additional Information
11. Service and Warranty
This alarm detects products of combustion using the ionisation tech-
nique. It contains 0.9 microcurie of Americium 241, a radioactive materi-
al (see section 9). Do not try to repair the smoke alarm yourself. Refer
to the instructions in section 11 for service.
LOSS OF POWER TO THE ALARM WILL RENDER THIS ALARM
INOPERATIVE.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed
of with household waste.
Please recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice.
Product Specifications
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

• Locate the first alarm in the immediate
area of the sleeping rooms. Try to monitor
the exit path as the sleeping rooms are
usually farthest from the exit. If more than
one sleeping area exists, locate additional
alarms in each sleeping area (See figure 3).
• Locate additional alarms to monitor any
stairway as stairways act like chimneys for
smoke and heat.
• Locate at least one alarm on every floor
level.
• Locate an alarm in every sleeping room.
• Locate an alarm in every room where elec-
trical appliances are operated (i.e. portable
heaters or humidifiers).
• Locate an alarm in every room where
someone sleeps with the door closed. The
closed door may prevent an alarm not
located in that room from waking the
sleeper.
• Smoke, heat, and combustion products
rise to the ceiling and spread horizontally.
Mounting the smoke alarm on the ceiling
in the centre of the room places it closest
to all points in the room. Ceiling mount-
ing is preferred in ordinary residential con-
struction.
• For mobile home installation, select loca-
tions carefully to avoid thermal barriers
that may form at the ceiling. For more
details, see MOBILE HOME INSTALLATION
below.
• When mounting an alarm on the ceiling,
locate it at a minimum of 10 cm from the
side wall (see figure 1).
• When mounting the alarm on the wall,
use an inside wall with the top edge of
the alarm at a minimum of 10 cm and a
maximum of 30.5 cm below the ceiling
(see figure 1).
1. Recommended Locations for Smoke Alarms
FIGURE 1
ANYWHERE ALONG
10 cm
10 cm
FIGURE 3
FIGURE 2
ANYWHERE ALONG
THIS BOLD SURFACE
30.5 cm
FIGURE 4
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

1. Recommended Locations for Smoke Alarms
• Put smoke alarms at both ends of a hallway or large room if the hall-
way or room is more than 9.1 m long. For large rooms, one smoke
alarm is recommended for every 47 square meters of floor space.
• In homes that are not well insulated, extreme heat or cold can be
transferred from the outside to the inside through poorly insulated
walls and roof. This may create a thermal barrier which can prevent
the smoke from reaching an alarm mounted on the ceiling. If you are
not sure about the insulation in your home, or if you notice that the
outer walls and ceiling are either hot or cold, install the alarm on an
inside wall. In such homes, install the smoke alarm with the top edge
of the alarm at a minimum 10 cm and a maximum of 30.5 cm below
the ceiling (see figure 1).
• Install Smoke Alarms on sloped, peaked or cathedral ceilings at or
within 0.9m of the highest point (measured horizontally). Smoke
alarms in rooms with ceiling slopes greater than 0.3m in 2.4 m
horizontally shall be located on the high side of the room. A row of
detectors shall be spaced and located within 0.9m of the peak of the
ceiling measured horizontally (see figure 2).
• Install Smoke Alarms on tray-shaped ceilings (coffered ceilings) on the
highest portion of the ceiling or on the sloped portion of the ceiling
within 30.5cm) vertically down from the highest point (see figure 4).
Mobile Home Installation
Modern mobile homes have been designed and built to be energy effi-
cient. Install smoke alarms as recommended above (refer to RECOM-
MENDED LOCATIONS and Figures 1 and 2). In older mobile homes that
are not well insulated compared to present standards, extreme heat or
cold can be transferred from the outside to the inside through poorly
insulated walls and roof. This may create a thermal barrier which can
prevent the smoke from reaching an alarm mounted on the ceiling. In
such units, install the smoke alarm on an inside wall with the top edge
of the alarm at a minimum of 10cm and a maximum of 30.5cm below
the ceiling (see figure 1).
If you are not sure about the insulation in your mobile home, or if you
notice that the outer walls and ceiling are either hot or cold, install the
alarm on an inside wall. For minimum protection, install at least one
alarm close to the sleeping rooms. For additional protection, see SINGLE
FLOOR PLAN in figure 2.
WARNING: TEST YOUR SMOKE ALARM OPERATION AFTER RV
OR MOBILE HOME VEHICLE HAS BEEN IN STORAGE, BEFORE
EACH TRIP AND AT LEAST ONCE A WEEK DURING USE.
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

• In the garage. Products of combustion are present when you start
your automobile.
• Less than 10cm from the peak of an “A” frame type ceiling.
• In an area where the temperature may fall below 0ºC or rise above
40ºC, such as garages and unfinished attics; this should also include
electrical boxes exposed to these environments.
• In dusty areas. Dust particles may cause nuisance alarm or failure to
alarm.
• In very humid areas. Moisture or steam can cause nuisance alarms.
• In insect-infested areas.
• In areas where the Relative Humidity (RH) is above 93%.
• Smoke alarms should not be installed within .9m of the following: the
door to a kitchen, the door to a bathroom containing a tub or shower,
forced air supply ducts used for heating or cooling, ceiling or whole
house ventilating fans, or other high air flow areas.
• Kitchens. Normal cooking may cause nuisance alarms. If a kitchen
alarm is desired, it should have an alarm silence feature or be a photo-
electric type.
• Near fluorescent lights. Electronic “noise” may cause nuisance alarms.
• Smoke alarms are not to be used with detector guards unless the
combination (alarm and guard) has been evaluated and found suitable
for that purpose.
• In front of forced air supply ducts used for heating and air condition-
ing, near ceiling fans,or other high air flow areas.
2. Locations To Avoid
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

3. Installation Instructions
FIGURE 5
AA
FIGURE 6
FIGURE 7 FIGURE 7A
FIGURE 8 FIGURE 9
mounting
bracket
The “A” line should be
horizontal and the “UP FOR
WALL MOUNTING” arrow
must be pointing up.
Alignment marks
Install Remove
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

3. Installation Instructions
MOUNTING INSTRUCTIONS
CAUTION: This unit is sealed. The cover is not removable!
1. Remove the mounting plate from the back of the alarm by holding the
mounting plate and twisting the alarm in the direction indicated by the
“OFF” arrow on the alarm cover.
2. To insure aesthetic alignment of the alarm with the hallway or wall, the
“A” line on the mounting plate should be parallel with the hallway when
ceiling mounting or horizontal when wall mounting.
3. After selecting the proper smoke alarm location as described in section 1,
attach the mounting plate to the ceiling as shown in figure 5. For wall
mounting see figure 6. Place mounting plate on the wall as described in
the mounting illustrations. Use the screws and anchors provided to
secure the mounting plate (use 3/16” drill bit for anchor holes).
4. Battery installation instructions are provided on the inside of the battery
door. To ensure proper installation of the smoke alarm battery, follow
the instructions.
5. When installing the battery, press the battery reminder finger down into
the battery compartment and install the battery (see figure 7 and figure
7A for the i9080EU alarm).
CAUTION! IF THE BATTERY REMINDER FINGER IS NOT HELD DOWN IN
THE BATTERY COMPARTMENT BY THE BATTERY, THE BATTERY DOOR
WILL NOT CLOSE AND THE UNIT WILL NOT ATTACH TO THE MOUNT-
ING BRACKET. NOTE: THE I9040EU DOES NOT HAVE A BATTERY
DOOR.
6. Alignment marks are provided on the edge of the trim plate and the
alarm. After installing the mounting plate, place the alarm on the
mounting plate with the alignment marks lined up. Twist the alarm in the
direction indicated by the “ON” arrow on the alarm cover (see figure 8)
until it locks in place.
7. USING TAMPER RESIST LOCKING PIN (all models except i9040EU): To
make your smoke alarm tamper resistant, a locking pin has been provid-
ed in the bag with the screws and anchors. Using this pin will help deter
children and others from removing the alarm from the mounting plate.
To use the pin, insert it into the hole in the side of the alarm after the
alarm has been installed on the mounting plate (see figure 9).
NOTE: THE TAMPER RESIST PIN WILL HAVE TO BE REMOVED IN
ORDER TO CHANGE THE BATTERIES. USE LONG NOSE PLIERS TO PULL
THE PIN OUT OF THE HOLE. IT IS NOW POSSIBLE TO REMOVE THE
ALARM FROM THE MOUNTING PLATE.
8. After installation, test your alarm by depressing and holding down the
test button for at least 5 seconds. This should sound the alarm.
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

4. Operation and Testing
OPERATION: The smoke alarm is operating once a fresh battery is
installed and testing is complete. When products of combustion are
sensed, the unit sounds a loud 85db pulsating alarm until the air is
cleared.
HUSH CONTROL: The “HUSH” feature has the capability of temporarily
desensitizing the alarm circuit for approximately 8 minutes. This feature
is to be used only when a known alarm condition, such as smoke from
cooking, activates the alarm. If the smoke is not too dense, the alarm
will silence immediately and the Red LED will flash once every 10 sec-
onds for approximately 8 minutes. This indicates that the alarm is in a
temporarily desensitized condition. The smoke alarm will automatically
reset after approximately 8 minutes and sound the alarm if particles of
combustion are still present. The “HUSH” feature can be used repeated-
ly until the air has been cleared of the condition causing the alarm.
NOTE: DENSE SMOKE WILL OVERRIDE THE HUSH CONTROL FEA-
TURE AND SOUND A CONTINUOUS ALARM.
CAUTION: BEFORE USING THE ALARM HUSH FEATURE, IDENTIFY
THE SOURCE OF THE SMOKE AND BE CERTAIN A SAFE CONDITION
EXISTS.
FLASHING LED LIGHT: This smoke alarm is equipped with a flashing
red indicator light. The light is located under the test button and will
flash every 40 seconds to indicate that the smoke alarm is receiving
power.
TESTING: Test by pushing the test button on the cover and holding it
down for a minimum of 5 seconds. This will sound the alarm if the elec-
tronic circuitry, horn, and battery are working. If no alarm sounds, the
unit has defective batteries or other failure. DO NOT use an open flame
to test your alarm, you could damage the alarm or ignite combustible
materials and start a structure fire.
TEST THE ALARM WEEKLY TO ENSURE PROPER OPERATION.
Erratic or low sound coming from your alarm may indicate a defective
alarm, and it should be returned for service (see section 11).
NOTE: WEEKLY TESTING IS REQUIRED.
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

Smoke alarms are designed to minimize nuisance alarms. Cigarette
smoke will not normally set off the alarm, unless the smoke is blown
directly into the alarm. Combustion particles from cooking may set off
the alarm if the alarm is located close to the cooking area. Large quanti-
ties of combustible particles are generated from spills or when broiling.
Using the fan on a range hood which vents to the outside (non-recircu-
lating type) will also help remove these combustible products from the
kitchen. If the alarm does sound, check for fires first. If a fire is discov-
ered, get out and call the fire department. If no fire is present, check to
see if one of the reasons listed in section 2 may have caused the alarm.
5. Nuisance Alarms
6. Maintenance
BATTERY REPLACEMENT
Note: Replacement batteries are available where you purchased your
alarm.
If tamper resist pin has been used, refer to TAMPER RESIST LOCKING
PIN in section 3 for removal instructions. To replace the battery, remove
the alarm from the mounting plate by rotating the alarm in the direction
of the “OFF” arrow on the cover (see figure 8).
These Smoke Alarms are powered by a 9V battery. A fresh battery
should last for one year under normal operating conditions. This
alarm has a low battery monitor circuit which will cause the alarm
to “chirp” Approximately every 30 - 40 seconds for a minimum of
seven (7) days when the battery gets low. Replace the battery when
this condition occurs.
NOTE: ANY STATEMENTS REFERRING TO A BATTERY, APPLIES
TO BOTH BATTERIES USED WITH THE i9080EU
USE ONLY THE FOLLOWING 9 VOLT BATTERIES FOR SMOKE ALARM
BATTERY REPLACEMENT.
Alkaline type: ENERGIZER 522; DURACELL MN1604, MX1604;
GOLD PEAK 1604A.
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

NOTE: WEEKLY TESTING IS REQUIRED.
WARNING! USE ONLY THE BATTERIES SPECIFIED. USE OF DIFFER-
ENT BATTERIES MAY HAVE A DETRIMENTAL EFFECT ON THE
SMOKE ALARM.
CLEANING YOUR ALARM
YOUR ALARM SHOULD BE CLEANED AT LEAST ONCE A YEAR
To clean your alarm, remove it from the mounting bracket as outlined in
the beginning of this section. You can clean the interior of your alarm
(sensing chamber) by using compressed air or a vacuum cleaner hose
and blowing or vacuuming through the openings around the perimeter
of the alarm. The outside of the alarm can be wiped with a damp cloth.
After cleaning, reinstall your alarm and test your alarm by using the test
button. If cleaning does not restore the alarm to normal operation the
alarm should be replaced.
SAFETY LIGHT
MODEL i9080EU
NOTE: If the safety light appears dim during regular testing, replace
both batteries immediately. Use only the following 9 volt alkaline
batteries for powering the safety light:
Alkaline Type Energizer 522
Duracell MN1604 or MX1604
Gold Peak 1604A
The safety light has a 6.3 V 250mA fuse lamp with an average life of 50
hours. If the safety light fails to operate with a fresh alkaline battery,
then replace the lamp. To replace the lamp, remove the alarm from the
mounting bracket by rotating the alarm in the direction of the “OFF”
arrow on the cover (See Figure 7, and Alarm Tamper Resist Feature sec-
tion if this feature has been activated).
Open the battery door and remove both batteries from the unit. Grip
the lamp holder handle with your thumb and finger and pull out the
lamp holder assembly. Slide the old lamp out of the lamp holder and
replace it with a new lamp. Contact Kidde for a replacement lamp.
6. Maintenance
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

7. Limitations of Smoke Alarms
WARNING: PLEASE READ CAREFULLY AND THOROUGHLY
• Fire-warning equipment for residential occupancies are capable of
protecting about half of the occupants in potentially fatal fires. Victims
are often intimate with the fire, too old or too young, or physically or
mentally impaired such that they cannot escape even when warned
early enough that escape should be possible. For these people, other
strategies such as protection-in-place or assisted escape or rescue
would be necessary.
• Smoke alarms are devices that can provide early warning of possible
fires at a reasonable cost; however, alarms have sensing limitations.
Ionisation sensing alarms may detect invisible fire particles (associated
with fast flaming fires) sooner than photoelectric alarms. Photoelectric
sensing alarms may detect visible fire particles (associated with slow
smoldering fires) sooner than ionisation alarms. Home fires develop in
different ways and are often unpredictable. For maximum protection,
Kidde recommends that both Ionisation and Photoelectric alarms be
installed.
• A battery powered alarm must have a battery of the specified type, in
good condition and installed properly.
• AC powered alarms (without battery backup) will not operate if the
AC power has been cut off, such as by an electrical fire or an open
fuse.
• Smoke alarms must be tested regularly to make sure the batteries and
the alarm circuits are in good operating condition.
• Smoke alarms cannot provide an alarm if smoke does not reach the
alarm. Therefore, smoke alarms may not sense fires starting in chim-
neys, walls, on roofs, on the other side of a closed door or on a differ-
ent floor.
Reinstall the lamp holder. It will snap easily into the base. Put working
batteries back in the alarm and remount the alarm on its mounting
bracket.
CAUTION: Use only the lamp specified. Use of a different lamp
may have a detrimental effect on the smoke alarm or the safety
light operation.
NOTE: The safety light is not intended to satisfy the requirements
for approved illumination under various local codes. Very thick
and/or dense smoke may obscure the light.
6. Maintenance
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

7. Limitations of Smoke Alarms
• If the alarm is located outside the sleeping room or on a different
floor, it may not wake up a sound sleeper.
• The use of alcohol or drugs may also impair one’s ability to hear the
smoke alarm. For maximum protection, a smoke alarm should be
installed in each sleeping area on every level of a home.
• Although smoke alarms can help save lives by providing an early
warning of a fire, they are not a substitute for an insurance policy.
Home owners and renters should have adequate insurance to protect
their lives and property.
8. Good Safety Habits
DEVELOP AND PRACTICE A PLAN OF ESCAPE
• Make a floor plan indicating all doors and windows and at least two
(2) escape routes from each room. Second story windows may need a
rope or chain ladder.
• Have a family meeting and discuss your escape plan, showing every-
one what to do in case of fire.
• Determine a place outside your home where you all can meet if a fire
occurs.
• Familiarize everyone with the sound of the smoke alarm and train
them to leave your home when they hear it
• Practice a fire drill at least every six months, including fire drills at
night. Ensure that small children hear the alarm and wake when it
sounds. They must wake up in order to execute the escape plan.
Practice allows all occupants to test your plan before an emergency.
You may not be able to reach your children. It is important they know
what to do.
• Install and maintain fire extinguishers on every level of the home and
in the kitchen, basement and garage. Know how to use a fire extin-
guisher prior to an emergency.
• Current studies have shown smoke alarms may not awaken all sleep-
ing individuals, and that it is the responsibility of individuals in the
household that are capable of assisting others to provide assistance to
those who may not be awakened by the alarm sound, or to those
who may be incapable of safely evacuating the area unassisted.
• There are situations where a smoke alarm may not be effective to pro-
tect against fire as noted by the NFPA and UL. For instance:
- Smoking in bed.
- Leaving children unsupervised.
- Cleaning with flammable liquids, such as gasoline.
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

Ionisation type smoke alarms use a very small amount of a radioactive ele-
ment in the sensing chamber to enable detection of visible and invisible
combustion products. The radioactive element is safely contained in the
chamber and requires no adjustments or maintenance. This smoke alarm
meets or exceeds all government standards. It is manufactured and distrib-
uted under license from the U.S. Nuclear Regulatory Commission.
9. Ionisation Information
10. Additional Information
Smoke Detection - Where required by applicable laws, codes, or standards
for a specific type of occupancy, approved single- and multiple-station
smoke alarms shall be installed as follows:
(1) In all sleeping rooms and guest rooms
(2) Outside of each separate dwelling unit sleeping area, within 6.4 m (21 ft)
of any door to a sleeping room, the distance measured along a path of travel
(3) On every level of a dwelling unit, including basements
(4) On every level of a residential board and care occupancy (small facility),
including basements and excluding crawl spaces and unfinished attics
(5) In the living area(s) of a guest suite
(6) In the living area(s) of a residential board and care occupancy (small facility)
Are More Smoke Alarms Desirable? The required number of smoke alarms
might not provide reliable early warning protection for those areas separated
by a door from the areas protected by the required smoke alarms. For this
reason, the use of additional smoke alarms for those areas for increased pro-
tection is recommended. The additional areas include the basement, bed-
rooms, dining room, furnace room, utility room, and hallways not protected
by the required smoke alarms. The installation of smoke alarms in kitchens,
attics (finished or unfinished), or garages is not normally recommended,
because these locations occasionally experience conditions that can result in
improper operation.
- Fires where the victim is intimate with a flaming initiated fire; for
example, when a person's clothes catch fire while cooking.
- Fires where the smoke is prevented from reaching the detector due
to a closed door or other obstruction.
- Incendiary fires where the fire grows so rapidly that an occupant's
egress is blocked even with properly located detectors
8. Good Safety Habits
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

11. Service and Warranty
LIMITED WARRANTY
KIDDE SAFETY EUROPE LTD warrants to the original purchaser that the
enclosed smoke alarm (but not the battery) will be free from defects in
material and workmanship or design under normal use and service for a
period of three years (model i9040EU alarm) or five years (i9060EU or
i9080EU alarm) from the date of purchase. The obligation of KIDDESAFE-
TY EUROPE LTD under this warranty is limited to repairing or replacing the
smoke alarm or any part which we find to be defective in material, work-
manship or design, free of charge to the customer, upon sending the
smoke alarm with proof of date of purchase, postage and return postage
prepaid, to Warranty Service Department, KIDDE SAFETY EUROPE LTD.,
Mathisen Way, Colnbrook SL3 OHB
This warranty shall not apply to the smoke alarm if it has been dam-
aged,modified, abused or altered after the date of purchase or if it fails to
operate due to improper maintenance or inadequate A.C. or D.C. electri-
cal power.
THE LIABILITY OF KIDDE SAFETY EUROPE LTD OR ANY OF ITS PARENT OR
SUBSIDIARY CORPORATIONS ARISING FROM THE SALE OF THIS SMOKE
ALARM OR UNDER THE TERMS OF THIS LIMITED WARRANTY SHALL NOT
IN ANY CASE EXCEED THE COST OF REPLACEMENT OF SMOKE ALARM
AND, IN NO CASE, SHALL KIDDE SAFETY EUROPE LTD OR ANY OF ITS PAR-
ENT OR SUBSIDIARY CORPORATIONS BE LIABLE FOR CONSEQUENTIAL
LOSS OR DAMAGES RESULTING FROM THE FAILURE OF THE SMOKE
ALARM OR FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS
OR IMPLIED, EVEN IF THE LOSS ORDAMAGE IS CAUSED BY THE COMPA-
NY’S NEGLIGENCE OR FAULT.
This warranty does not affect your statutory rights.
If after reviewing this manual you feel that your smoke alarm is defective
in any way, do not tamper with the unit.
Return for servicing to: Kidde Safety Europe LTD., Mathisen Way,
Colnbrook SL3 0HB 0800-917-0722 (See Warranty for in-warranty
returns)
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM

QUESTIONS OR FOR MORE INFORMATION
Call our Consumer Hotline at 0800 917 0722 or contact
us at our website at www.kiddesafetyeurope.co.uk
Kidde Safety Europe Ltd.
Mathisen Way, Poyle Road, Colinbrook, Berkshire SL3 0HB
0940-7204-01(21008004A)_V1_EU.qxd:_ 2010.11.16 5:29 PM
