KidKraft What's Cookin' Kitchen User manual

1
WARNING: CHOKING HAZARD
Unassembled parts may be a choking
hazard to children 3 years and younger.
CAUTION: Adult assembly required.
Hardware contains small screws with
sharp points. Keep unassembled parts
out of the reach of small children.
USE AND MAINTENANCE:
-Use on level surfaces only
-Please check assembly at regular intervals, and frequently
tighten hardware if necessary. If maintenance is not carried out,
the product could cease to function properly
What’s Cookin’ Kitchen
Assembly Instructions Item #53144
Please retain this information for future reference
Customer Service
1-800-933-0771
www.kidkraft.com

Customer Service
1-800-933-0771
www.kidkraft.com
2
What’s Cookin’ Kitchen
Assembly Instructions Item #53144
12
3
7
8
x 3
x 2
x 3
6
9
10 11
35
34
36
21
23
14 32
33
12
13
37
30
29
28
26
25
24
22
16
17
15
31
27
19
18
20
4
5

Customer Service
1-800-933-0771
www.kidkraft.com
3
What’s Cookin’ Kitchen
Assembly Instructions
Step 1
A
A
A
A
A
A
D
D
D
D
D
D
2
Item #53144
3
6
1
A. Red Cross Dowel Bolt
x 8 pcs
2 1/8 in, 53 mm
E. Red Screw x 6 pcs
1 in, 25 mm
J. Flat Screw x 16 pcs O. Large Washer x 1 pc
H. Small Washer x 2 pcs
Allen Wrench x 1 pc
Wrench x 2 pcs
The following tool is
required for assembly:
Phillips Screwdriver
R
5/8 in, 16 mm
K. Flat Screw x 2 pcs
L. Red Cap Nut x 8 pcs
M. White Cap Nut x 10 pcs
N. Nylon Lock Nut x 1 pc
1 in, 25 mm
F. White Screw x 21 pcs
1 in, 25 mm
G. Gray Screw x 4 pcs
1 in, 25 mm
I. Screw x 2 pcs
11/16 in, 18 mm
B. White Cross Dowel Bolt
x 10 pcs
2 1/8 in, 53 mm
C. Gold Cross Dowel
Bolt x 9 pcs
D. Cross Dowel Nut
x 27 pcs
2 1/8 in, 53 mm

Customer Service
1-800-933-0771
www.kidkraft.com
4
What’s Cookin’ Kitchen
Assembly Instructions Item #53144
Please retain this information for future reference
Step 2
Step 3
A
A
D
D
D
D
B
B
7
D
D
C
C
C
C
5
4

Customer Service
1-800-933-0771
www.kidkraft.com
5
What’s Cookin’ Kitchen
Assembly Instructions Item #53144
Please retain this information for future reference
Step 4
Step 5
8
8
8
H
H
N
C
CCCC
D
D
D
I
I
O

Customer Service
1-800-933-0771
www.kidkraft.com
6
What’s Cookin’ Kitchen
Assembly Instructions Item #53144
Please retain this information for future reference
Step 6
Step 7
F
F
F
E
E
F
E
E
9
9
E
F
10

Customer Service
1-800-933-0771
www.kidkraft.com
7
What’s Cookin’ Kitchen
Assembly Instructions Item #53144
Please retain this information for future reference
Step 8
Step 9
B
B
D
D
D
B
B
FFF
D12
17
F
F
F
F
19
21
22

Customer Service
1-800-933-0771
www.kidkraft.com
8
What’s Cookin’ Kitchen
Assembly Instructions Item #53144
Please retain this information for future reference
Step 10
Step 11
13
14
K
M
13
B
D
D
F
F
B
23
20

Customer Service
1-800-933-0771
www.kidkraft.com
9
What’s Cookin’ Kitchen
Assembly Instructions Item #53144
Please retain this information for future reference
Step 12 Step 13
Step 14
F
F
31
M
M
J
J
25
L
L
J
J
26
25
28 26
G
G

Customer Service
1-800-933-0771
www.kidkraft.com
10
What’s Cookin’ Kitchen
Assembly Instructions Item #53144
Please retain this information for future reference
Step 15
Step 16
24
30
27
24
27
29
F
F
G
G
L
L
J
J
M
J
J
M
