Kieback&Peter FSM21 Operating and installation instructions

Technical Data Sheet 2.50-35.021-01-en Rev
FSM21 Front Switch Module
For connection to the FBM38 fieldbus module.
Device Description
Kieback&Peter GmbH & Co KG
Tempelhofer Weg 50 · 12347 Berlin, Germany
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
www.kieback-peter.de
A
Subject to change
Issue date October 10, 2005 Rev DIN EN 61439-1, 2012-06
FSM21 Front Switch Module
For connection to the FBM38 fieldbus module.
The FSM21 front switch module is used for the direct operation of
1 or 2-stage unit or device switches.
The module functions through macro assignments on the FBM38
fieldbus module. A load/rolling switch with different switching delays can be
set in the macro function.
The FSM21 and FBM38 modules form a single operating unit.
Contents
FSM21 Front Switch Module.............................................................................................................................................................1
Information About the Device Description.........................................................................................................................................2
Safety Instructions ............................................................................................................................................................................2
Qualified Technicians........................................................................................................................................................................2
Application ........................................................................................................................................................................................3
Type..................................................................................................................................................................................................3
Technical Data..................................................................................................................................................................................3
Mounting...........................................................................................................................................................................................4
Installation.........................................................................................................................................................................................5
Macro Function.................................................................................................................................................................................6
Function/Operation............................................................................................................................................................................6
Switch stop........................................................................................................................................................................................7
Setting the switch stop......................................................................................................................................................................7
LED Settings.....................................................................................................................................................................................9
Commissioning .................................................................................................................................................................................9
Setting Notes ..................................................................................................................................................................................10

Technical Data Sheet 2.50-35.021-01-en Rev
Device Description
FSM21 Front Switch Module
For connection to the FBM38 fieldbus module.
A
I
nformation About the Device Description
The description contains information for using and installing the FSM21 front switch module.
If you have any questions that are not covered by the device description, contact the supplier or manufacturer for
further information.
The specified regulations/guidelines for installation and mounting are applicable for the Federal Republic of
Germany.
If the device is used in other countries, it is the responsibility of the system installer or operator to comply with local
regulations.
Operating personnel are to be instructed according to the description of the technical data sheet.
S
afety Instructions
Adhere to applicable regulations regarding occupational safety and accident prevention as well as those from the
VDE (Association for Electrical, Electronic & Information Technologies) when mounting and using the devices.
Mounting, installation and commissioning work on the devices may only be carried out by qualified technicians. See
the “Qualified Technicians” section.
Each person who uses the devices must have read and understood the descriptions on the technical data sheet.
If the device is not used according to the device description, the protection provided could be impaired.
Meanings of symbols on the technical data sheet:
Note
Caution
Danger
Warning of dangerous electric voltage
General warning; information in note must be observed
Additional note to be observed
Danger Means that non-observance could lead to mortal danger, serious bodily injury or major
material damage.
Caution Means that non-observance could risk injury or material damage.
Note Means that the information requires special attention.
Q
ualified Technicians
Qualified technicians in the context of the technical data sheet are persons who are familiar with the described
evices and have the necessary qualifications for their job.d
This includes, for example:
Authorization to connect the devices in accordance with VDE regulations and the local power company’s
regulations, as well as authorization to switch on, off and enable devices according to in-house regulations.
Knowledge of accident prevention regulations.
Knowledge of the use of devices within the system.
etc.
Page 2 / 12

Technical Data Sheet 2.50-35.021-01-en Rev
FSM21 Front Switch Module
For connection to the FBM38 fieldbus module.
Device Description
A
Application
The FSM21 front switch module is operated with the FBM38 fieldbus module, and is
used for manual operation of two 1 or 2-stage units, each with two
operating and malfunction message displays per control channel.
A load/rolling switch with switching delays can be set on the FBM38 fieldbus module.
The FSM21 and FBM38 modules form a single operating unit.
Type
FSM21 Front switch module for the FBM38 fieldbus module, used for
manual/automatic control of two 1 or 2-stage units.
Switch-on load/rolling switch with settable switching delays.
Technical Data
Operation Only in connection with the FBM38 fieldbus module
Operating voltage DC 12 V ±20%, 67 mA, 0.8 VA at nominal voltage
Power is supplied over the QB interface
Connection Terminal connection to QB interface, 4-wire,
maximum cable length 200 m
Controls Two manual/automatic switches for the
Automatic/Off/Position1/Position2 positions with mechanically
adjustable switch stop for limitation of the switching positions
Switch 1 switches the FBM relay outputs K1 and K2
Switch 2 switches the FBM relay outputs K3 and K4
Displays Four green signal LEDs For displaying operating messages on the binary FBM inputs
(can be switched off) 51/IN–54/IN (“Remote” operating mode);
For status displays of the FBM relay outputs (“Local” operating mode)
Four red signal LEDs For displaying malfunction messages on the binary FBM inputs 55/IN–
58/IN
Overvoltage category III
Rated impulse voltage 800 V
Level of contamination 2
Automatic action Type 1
Degree of protection IP20
Ambient temperature 0–45 °C
conditions Humidity 20–80% r.h., non-condensing
Weight 80 g
A
ccessories WAS01 Set for wall mounting
Dimensions
23
45,6
8
132,5
110
25,4
50
122,5
FSM21
Page 3 / 12

Technical Data Sheet 2.50-35.021-01-en Rev
Device Description
FSM21 Front Switch Module
For connection to the FBM38 fieldbus module.
A
Mounting
The FSM21 front switch module can be inserted in the switchboard door or a 19" KA rack.
Two screws are included for mounting the module in a 19" KA rack.
The WAS01 set is available as an accessory for wall mounting.
Mounting on a switchboard or in a 19" KA rack may only be carried out by qualified
technicians. The power must be disconnected from the switchboard.
Switchboard excerpt for
mounting in the switchboard door
3 für Zylinder-
Blechschraube
B 3,5 x 13
11,3 62,1
+0,5 48+0,5 98,8+0,5
FSM.. FSM..
36,7+0,5 87,5
+0,5
122,5+0,5
50,8
112
+0,5
+0,5
Danger
The switchboard excerpt for the 19" KA rack is shown in the device description of the 19" rack (Technical Data Sheet
2.85-90.100-01).
Page 4 / 12

Technical Data Sheet 2.50-35.021-01-en Rev
FSM21 Front Switch Module
For connection to the FBM38 fieldbus module.
Device Description
A
In
.stallation
Electrical installation and device connection in the switchboard may only be carried out
by qualified technicians. The power must be disconnected from the switchboard.
1
Ausgangskontakte K1..K4: max. 230 V AC/24 V DC, 6 (3) A
17 18 19 20 45678910
17 18 19 20
Zentrale
DDC3000-System FSM21
3456
Feldbus + Feldbus - + 12 V DC 0 V DC
Netz-
gerät
12 V DC +
-
+ 12 V DC 0 V DC Data Clk
+12 V DC
0 V DC
FBM38
QBSchnittstelle
Betriebs-
spannung
QBSchnittstelle
Feldbus (CAN)
Feldbus (CAN)
Backbone
2
3
21
22 24
K2
31
32 34
K3
2
1
Vordere
Hintere
Anschluss-
klemmen
Hintere
Anschluss-
klemmen
Vordere
Anschluss-
klemmen 0V 51
IN 52 IN 53 IN 54 IN 55 IN 56 IN 57 IN 58 IN 59 IN 60 IN 0V
paarig
verdrillt paarig verdrillt
11
12 14
K1
7
8
9
10
FBM38 SBM21/41
0 V DC L-Test SSM SSM-Q
78910
Anschluss alternativ
1) 2)
meldung
(nicht DDC3010/3035/3100)
Relais K1
(Stufe 1.1)
1) Taster: LED-Test
2) Taster: Quittierung
der Sammelstör-
(Adressein-
stellung >16)
Backbone-Anschluss
an max. 63 FBM38
und max. 16 SBM21/41
37/37
33/32
34/33
35/34
L
N
Gerät/Aggregat 1
41
42 44
K4
Die binären Eingänge
55/IN..58/IN können
als Schließer oder
Öffner angeschlossen
werden.
Umschaltung am
FBM38.
Relais K2
(Stufe 1.2) Relais K3 (Stufe 2.1) Relais K4 (Stufe 2.2)
Gerät/Aggregat 2
-
51/IN..54/IN zusätzliche
Betriebsmeldungen
nur bei Betriebsart Fern
Störmeldungen 1..4
1234
Ensure that this process complies with VDE guidelines and local wiring regulations.
Danger The FSM21 front switch module is connected to the QB interface of the FBM38 fieldbus module.
The 4-wire QBS connection line can have a maximum length of 200 m.
Wiring diagram
Displayed in
wiring diagram:
Switch levels with reciprocal
hardware locking (e.g. for
fan control (OR function)).
When the switch levels are
switched together, then the
K2 and K4 inputs must be
connected directly to “L”
(e.g. for electric air heaters
(AND function)).
Bridges K1-K2 and K3-K4
are omitted.
The software setting of the
A
ND/OR function is made
on the FBM38.
Connection of the DC 12 V operating voltage is only made on connection terminals 1 and 2 of the
FBM38.
Note Continue to observe the connection instructions in the device description of the FBM38 fieldbus module
(Technical Data Sheet 2.50-30.038-01-en).
Page 5 / 12

Technical Data Sheet 2.50-35.021-01-en Rev
Device Description
FSM21 Front Switch Module
For connection to the FBM38 fieldbus module.
A
M
acro Function
The functions of the two 2 or 1-stage device controls are made by assigning macro 21 on the FBM38 fieldbus
odule.m
Using the macro function, relay outputs K1/K2 and K3/K4 are each controlled on the FBM38 with 2-stage control.
Depending on the switch setting, the relays lock against each other or switch together. A mechanical limitation of the
switch positions can be made by attaching switch stop rings (see the “Switch stop” section).
A
load/rolling switch with different switching delays can be set in macro 21.
Binary inputs 55/IN–58/IN on the FBM38 are defined as malfunction messages by the macro function, and are
hown on the signal LEDs (1.3/1.4, 2.3/2.4) on the FSM21.s
Depending on the operating mode set on the FBM38 ( / ), the following is signaled by the signal LEDs (1.1/1.2,
.1/2.2):
2
Binary inputs 51/IN–54/IN as operating messages (“Remote” operating mode )
The status of relay outputs K1–K4 on the FBM38 (“Local” operating mode )
A
ll macro settings are made on the FBM38 fieldbus module.
The FBM settings and a detailed macro description are found in technical data sheets 2.50-30.038-01-en and
2.50-30.038-02-en. Both of these are included with the FBM38
fieldbus module.
Function/Operation
Manual/automatic switch 1
Switch positions:
– Automatic operation, relay K1 and K2
– Off, relay K1 and K2
– On, level 1.1 (FBM38 relay output K1)
– On, level 1.2 (FBM38 relay output K2)
Signal LED 1.3: Malfunction
message
(FBM38 input 55/IN)
Signal LED 1.4: Malfunction
message
(FBM38 input 56/IN)
Signal LED 2.3: Malfunction
message
(FBM38 input 57/IN)
Signal LED 2.4: Malfunction
message
(FBM38 input 58/IN)
Manual/automatic switch 2
Switch positions:
– Automatic operation, relay K3 and K4
– Off, relay K3 and K4
– On, level 2.1 (FBM38 relay output K3)
– On, level 2.2 (FBM38 relay output K4)
Signal LED 1.1:
Operational feedback, level 1.1, on/off
(FBM38 input 51/IN;
Relay output K1 on/off)
Signal LED 1.2:
Operational feedback, level 1.2, on/off
(FBM38 input 52/IN;
Relay output K2 on/off)
Signal LED 2.1:
Operational feedback, level 2.1, on/off
(FBM38 input 53/IN;
Relay output K3 on/off)
Signal LED 2.2:
Operational feedback, level 2.2, on/off
(FBM38 input 54/IN;
Relay output K4 on/off)
Note
Only the green LEDs (1.1, 1.2, 2.1 and 2.2) can be switched off. The red LEDs (1.3, 1.4, 2.3 and 2.4)
cannot be configured.
Page 6 / 12

Technical Data Sheet 2.50-35.021-01-en Rev
FSM21 Front Switch Module
For connection to the FBM38 fieldbus module.
Device Description
A
Manual/automatic switch 1 and 2
The relay outputs K1/K2 on the FBM38 are controlled as 2 or 1-stage
using the manual/automatic switch 1 (unit 1, levels 1.1 and 1.2).
The relay outputs K3/K4 on the FBM38 are controlled as 2 or 1-stage
using the manual/automatic switch 2 (unit 2, levels 2.1 and 2.2).
Depending on the FBM setting, the 2-stage relay outputs K1/K2 and K3/K4 in automatic and manual mode each
lock against each other or switch together.
The switching delays apply in the same way when the load/rolling switch is switched on in automatic and manual
operation.
The possible switching positions can be limited by setting the inserted switch stops under the front panel
accordingly (e.g. to 1-stage control of a unit).
Switch stop
A mechanical switch stop is inserted behind the front panel of each automatic/manual switch. This allows the
limitation of switching positions on any switch position.
Switch stop
Switch positions
AUTO / OFF / POSITION 1 / POSITION 2
Switch positions with stop limitation
AUTO
AUTO / OFF
AUTO / OFF / POSITION 1
Setting the switch stop
Page 7 / 12

Technical Data Sheet 2.50-35.021-01-en Rev
Device Description
FSM21 Front Switch Module
For connection to the FBM38 fieldbus module.
A
Green signal LED (1.1/1.2, 2.1/2.2) with “Remote” operating mode activated
Two signal LEDs are found to the right of each manual/automatic switch. They are used to display operating
messages on binary inputs 51/IN–54/IN of the FBM38 (e.g. display of feedback from the connected
devices/units).
The green signal LEDs on the control channels can be switched off as required (see the “LED Settings” section).
S
ignal LED 1.1: On when binary input 51/IN of the FBM38 switches
S
ignal LED 1.2: On when binary input 52/IN of the FBM38 switches
S
ignal LED 2.1: On when binary input 53/IN of the FBM38 switches
Signal LED 2.2: On when binary input 54/IN of the FBM38 switches
Upcoming operating messages are signaled by a constantly lit LED.
If an operating message input does not match the corresponding control signal after 3 seconds have elapsed,
then the signal LEDs begin to flash. The active operating message is signaled by a constantly lit LED when the
operating message input and control signal match.
Green signal LED (1.1/1.2, 2.1/2.2) with “Local” operating mode activated
Two signal LEDs are found to the right of each manual/automatic switch. They are used to display the switching
states of the assigned output relay on the FBM38.
Switched levels lead to a constantly lit green LED.
Delayed switches within the load/rolling switch are signaled by a flashing LED.
The green signal LEDs on the control channels can be switched off as required (see the “LED Settings” section).
Red malfunction message LED (1.3/1.4, 2.3/2.4)
Two red malfunction message LEDs are found to the right underneath each manual/automatic switch. They are
used to display malfunction messages on binary inputs 55/IN–58/IN of the FBM38.
S
ignal LED 1.3: On when binary input 55/IN of the FBM38 switches
S
ignal LED 1.4: On when binary input 56/IN of the FBM38 switches
S
ignal LED 2.3: On when binary input 57/IN of the FBM38 switches
Signal LED 2.4: On when binary input 58/IN of the FBM38 switches
The malfunction messages are acknowledged on the backbone connection SSM-Q of the FBM38.
The signaling of malfunction messages is described in detail in the macro description of the FBM38 fieldbus
module (see Technical Data Sheet 2.50-30.038-02-en).
Page 8 / 12

Technical Data Sheet 2.50-35.021-01-en Rev
FSM21 Front Switch Module
For connection to the FBM38 fieldbus module.
Device Description
A
LED Settings
The green signal LEDs can be switched off individually (optional).
The setting is made using a DIP switch behind the front panel of the FSM21. The corresponding DIP switches are
arranged next to the LEDs.
ON
12
Ein Aus
LEDs can be
switched
Commissioning
Commissioning may only be carried out by qualified personnel, e.g. a commissioning
technician. The power must be disconnected from the switchboard.
Danger
Check the mounting, installation and device connections with the power disconnected from the FBM38 fieldbus
module and FSM21 front switch module.
Settings on the FBM38 fieldbus module
The device description of the FBM38 fieldbus module must be observed here (Technical Data Sheet 2.50-30.038-
01-en).
– Assign macro 21 using the FSM selector switch .2..
- Adjust the macro functions using DIP switches .3., .4. and .6..
Switch on the power supply and check the switching functions with the messaging and acknowledgement
functions of the FSM21 and FBM38 operating unit.
Page 9 / 12

Technical Data Sheet 2.50-35.021-01-en Rev
Device Description
FSM21 Front Switch Module
For connection to the FBM38 fieldbus module.
A
Setting Notes
Project: _________________________________________________________
Plant: _________________________________________________________
Plant position: _________________________________________________________
Commissioning: ____________________________ _____________________
Commissioning technician Date
C
onnected fieldbus module FBM38 ( ) Macro 21 ( )
Switching function: OR ( ), AND ( )
Load/rolling switch: On ( ), Off ( )
Switching delay: On = 12 s/Off = 10 s ( )
or On = 6 s/Off = 3 s ( )
Malfunction message inversion: Yes ( ), No ( )
Operating mode: Remote ( ), Local ( )
Control of unit 1:
Control of unit 2:
_
____________________________
_
____________________________
Mechanical limitation
of switching positions: No ( )
AUTO ( )
AUTO / OFF ( )
AUTO / OFF / POSITION 1 ( )
_
____________________________
_
____________________________
Mechanical limitation
of switching positions: No ( )
AUTO ( )
AUTO / OFF ( )
AUTO / OFF / POSITION 1 ( )
Signal LED 1.1: _____________________
On ( ), Off ( )
Signal LED 1.2: _____________________
Signal LED 2.1: _____________________
On ( ), Off ( )
Signal LED 2.2: _____________________
On ( ), Off ( )
Signal LED 1.3: _____________________
Signal LED 1.4: _____________________
On ( ), Off ( )
Signal LED 2.3: _____________________
Signal LED 2.4: _____________________
Other notes on the following pages ( )
Page 10 / 12
