Kikusui PWR-01 Series User manual

400W model
PWR401L PWR401MH
PWR401ML PWR401H
800W model
PWR801L PWR801MH
PWR801ML PWR801H
1200W model
PWR1201L PWR1201MH
PWR1201ML PWR1201H
Communication Interface Manual
Regurated DC Power Supply PWR-01 Series
PART NO. IB031623
Apr. 2018
Communication Interface Manual Regurated DC Power Supply PWR-01 Series
KIKUSUI ELECTRONICS CORP.
http://www.kikusui.co.jp/en
1-1-3 Higashiyamata, Tsuzuki-ku, Yokohama,
224-0023, Japan
Tel: [phone] Fax: [phone]
Website

Command List
KIKUSUI Electronics Corp. PWR-01 Interface Manual
*CLS
Clears all event registers including the status byte, event status, and error queue.
*ESE
Sets the event status enable register that is counted by the event summary bit (ESB) of the
status byte.
*ESR
Queries the event status register.
*IDN
Queries the model name, serial number, and rmware version of the PWR-01.
*LRN
Queries the command that can restore the current panel settings.
*OPC
Sets the OPC bit (bit 0) of the event status register when all the commands in standby have
been completed.
*OPT
Queries the option that are installed in the PWR-01.
*PSC
Sets whether to clear the event status enable register and the service request enable
register when the POWER switch is turned on (power-on status).
*RST
Resets the panel settings.
*SRE
Sets the service request enable register.
*STB
Queries the contents of the status byte register and the MSS (master summary status)
message.
*TRG
Trigger command.
Command List *TST
Executes a self-test.
*WAI
Prevents the PWR-01 from executing subsequent commands until all operations in standby
are complete.
ABOR
Aborts operations such as change and execute sequence in all sequence groups.
ABOR:PROG
Aborts the sequence trigger function.
ABOR:TRAN
Aborts the setting change trigger function.
DISP:BRIG
Adjusts the screen brightness.
GLOB:*RST
Resets the panel settings (see *RST) of all the channels in the same multichannel domain.
GLOB:*TRG
Trigger command for all the channels in the same multichannel domain.
GLOB:ABOR
Aborts modifications and sequence execution on all trigger subsystems (TRANsient/
PROGram) of all the channels in the same multichannel domain.
GLOB:CURR
Sets the current of all the channels in the same multichannel domain.
GLOB:INIT:PROG
Starts the sequence trigger function of all the channels in the same multichannel domain.
GLOB:INIT:TRAN
Starts the setting change (TRANsient) trigger function of all the channels in the same
multichannel domain.
GLOB:OUTP
Turns the output on and off of all the channels in the same multichannel domain.
GLOB:OUTP:PROT:CLE
Clears alarms of all the channels in the same multichannel domain.

Command List
KIKUSUI Electronics Corp. PWR-01 Interface Manual
GLOB:VOLT
Sets the voltagee of all the channels in the same multichannel domain.
INIT:PROG
Starts the sequence trigger function.
INIT:TRAN
Starts the setting change (TRANsient) trigger function.
INST
Species the channel to congure.
INST:CAT
Queries the list of channels that can be congured with the INST command.
INST:INFO
Queries the information of the channel currently being controlled.
FETC:ALL/ MEAS:ALL
Queries the current and voltage.
FETC:CURR/ MEAS:CURR
Queries the measured value of the current.
FETC:VOLT/ MEAS:VOLT
Queries the measured value of the voltage.
MEM:REC
Recalls the voltage, current, OVP, UVL, and OCP values saved in the preset memory.
MEM:REC:PREV
Queries the settings that are stored in the preset memory.
MEM:SAVE
Saves the present voltage, current, OVP, UVL, and OCP values in the preset memory.
OUTP
Turns the output on and off.
OUTP:DEL:ON
Sets the output-on delay.
OUTP:DEL:OFF
Sets the output-off delay.
OUTP:EXT
This is an old style command.
OUTP:EXT:ADV
Sets whether output will be turned on and off externally.
OUTP:EXT:LOG
Sets the logic used to control the turning of output on and off using an external contact.
OUTP:PON
Sets the output state at power-on.
OUTP:PROT:CLE
Clears alarms.
OUTP:PROT:WDOG
Sets the Communication monitor timer.
OUTP:TRIG:STAT
Sets whether to output a trigger signal when the output is turned on.
PROG:CRE
Deletes the existing program and creates a new program.
PROG:LOOP
Changes the number of times that the program will repeat.
PROG:REM:LOOP
Queries the number of repetitions remaining in the sequence that is running.
PROG:REM:TIME
Queries the time remaining in the sequence that is running.
PROG:STEPS
Queries the number of program steps.
PROG:STEPS:LOOP:ADD
Sets the starting step and ending step of an interval loop to execute in the program and the
number of interval loops.
PROG:STEPS:LOOP:LIST
Queries all interval loops set in the program.
PROG:STEP<n>:CURR/ PROG:STEP_T:CURR
Sets the current and transition to use in the step.

Command List
KIKUSUI Electronics Corp. PWR-01 Interface Manual
PROG:STEP<n>:DWEL/ PROG:STEP_T:DWEL
Sets the step execution time.
PROG:STEP<n>:TRIGIN/ PROG:STEP_T:TRIGIN
Sets the step’s trigger signal input.
PROG:STEP<n>:TRIGOUT/ PROG:STEP_T:TRIGOUT
Sets the step’s trigger signal output.
PROG:STEP<n>:VOLT/ PROG:STEP_T:VOLT
Sets the voltage and transition to use in the step.
PROG:UCOD
Sets the user code to identify sequences.
CURR
Sets the current.
CURR:EXT:RANG
Sets the CC and CV control range that is used during external control.
CURR:EXT:SOUR
Sets whether constant current will be controlled externally.
CURR:LIM:AUTO
Enables or disables the limit on the current setting.
CURR:PROT
Sets the overcurrent protection (OCP) value.
CURR:PROT:DEL
Sets the detection time of OCP activation.
CURR:SST:FALL
Sets the soft stop time when the output is turned off.
CURR:SST:RISE
Sets the soft start time when the output is turned on.
CURR:TRIG
Sets the current value that is applied when a trigger is sent.
RES
Sets the internal resistance.
VOLT
Sets the voltage.
VOLT:EXT:RANG
Sets the CC and CV control range that is used during external control.
VOLT:EXT:SOUR
Sets whether constant voltage will be controlled externally.
VOLT:LIM:AUTO
Set whether to limit the voltage setting so that it does not exceed the OVP setting or
become lower than the UVP setting.
VOLT:LIM:LOW
Sets the undervoltage limit (UVL) trip point.
VOLT:PROT
Sets the overvoltage protection (OVP).
VOLT:SST:FALL
Sets the soft stop time when the output is turned off.
VOLT:SST:RISE
Sets the soft start time when the output is turned on.
VOLT:TRIG
Sets the voltage that is applied when a trigger is sent.
STAT:OPER
Queries the event of the OPERation status register.
STAT:OPER:COND
Queries the condition of the OPERation status register.
STAT:OPER:ENAB
Sets the enable register of the OPERation status register.
STAT:OPER:NTR
Sets the negative transition of the OPERation status register.
STAT:OPER:PTR
Sets the positive transition of the OPERation status register.
STAT:OPER:INST
Queries the event of the OPERation:INSTrument subregister.

Command List
KIKUSUI Electronics Corp. PWR-01 Interface Manual
STAT:OPER:INST:COND
Queries the condition of the OPERation:INSTrument subregister.
STAT:OPER:INST:ENAB
Sets the enable register of the OPERation:INSTrument subregister.
STAT:OPER:INST:NTR
Sets the negative transition of the OPERation:INSTrument subregister.
STAT:OPER:INST:PTR
Sets the positive transition of the OPERation:INSTrument subregister.
STAT:OPER:INST:ISUM<n>
Queries the event of the OPERation:INSTrument:ISUMmary<n> subregister.
STAT:OPER:INST:ISUM<n>:COND
Queries the condition of the OPERation:INSTrument:ISUMmary<n> subregister.
STAT:OPER:INST:ISUM<n>:ENAB
Sets the enable register of the OPERation:INSTrument:ISUMmary<n> subregister.
STAT:OPER:INST:ISUM<n>:NTR
Sets the negative transition of the OPERation:INSTrument:ISUMmary<n> subregister.
STAT:OPER:INST:ISUM<n>:PTR
Sets the positive transition of the OPERation:INSTrument:ISUMmary<n> subregister.
STAT:QUES
Queries the event of the QUEStionable status register.
STAT:QUES:COND
Queries the condition of the QUEStionable status register.
STAT:QUES:ENAB
Sets the enable register of the QUEStionable status register.
STAT:QUES:NTR
Sets the negative transition of the QUEStionable status register.
STAT:QUES:PTR
Sets the positive transition of the QUEStionable status register.
STAT:QUES:INST
Queries the event of the QUEStionable:INSTrument subregister.
STAT:QUES:INST:COND
Queries the condition of the QUEStionable:INSTrument subregister.
STAT:QUES:INST:ENAB
Sets the enable register of the QUEStionable:INSTrument subregister.
STAT:QUES:INST:NTR
Sets the negative transition of the QUEStionable:INSTrument subregister.
STAT:QUES:INST:PTR
Sets the positive transition of the QUEStionable:INSTrument subregister.
STAT:QUES:INST:ISUM<n>
Queries the event of the QUEStionable:INSTrument:ISUMmary<n> subregister.
STAT:QUES:INST:ISUM<n>:COND
Queries the condition of the QUEStionable:INSTrument:ISUMmary<n> subregister.
STAT:QUES:INST:ISUM<n>:ENAB
Sets the enable register of the QUEStionable:INSTrument:ISUMmary<n> subregister.
STAT:QUES:INST:ISUM<n>:NTR
Sets the negative transition of the QUEStionable:INSTrument:ISUMmary<n> subregister.
STAT:QUES:INST:ISUM<n>:PTR
Sets the positive transition of the QUEStionable:INSTrument:ISUMmary<n> subregister.
STAT:PRES
Resets the ENABle, PTRansition, and NTRansition filter registers of all status registers
(including sub registers) to their default values. 32 bits registers are used by the
multichannel function.
SYST:BEEP:STAT
Turns the buzzer on and off.
SYST:COMM:RLST
Sets the operation of the PWR-01 to local or remote.
SYST:CONF:BLE
Sets the bleeder circuit operation.
SYST:CONF:MAST
Queries the number of units in master-slave parallel operation.
