Kikusui PMC 18-1A User manual

Jun. 2009
Part No. Z1-004-632, IA004571
PMC 18-1A
PMC 18-2A
PMC 18-3A
PMC 35-0.5A
PMC 35-1A
PMC 35-2A
PMC 18-5A
PMC 35-3A
PMC 70-1A
PMC 110-0.6A
PMC 160-0.4A
PMC 250-0.25A
PMC 350-0.2A
PMC 500-0.1A
OPERATION MANUAL
REGULATED DC POWER SUPPLY
PMC-A SERIES
TYPE I
TYPE II

2PMC-A
Use of Operation Manual
Please read through and understand this Operation Manual before operating
the product. After reading, always keep the manual nearby so that you may
refer to it as needed.
If you find any misplaced or missing pages in this manual, they will be
replaced. If the manual gets lost or soiled, a new copy can be provided for a
fee. In either case, please contact Kikusui distributor/agent, and provide the
“Kikusui Part No.” given on the cover.
This manual has been prepared with the utmost care; however, if you have
any questions, or note any errors or omissions, please contact Kikusui dis-
tributor/agent.
Reproduction and reprinting of this operation manual, in whole or in part,
without written permission is prohibited.
Both unit specifications and manual contents are subject to change without
notice.
Copyright© 2009 Kikusui Electronics Corporation

PMC-A 3
Power Requirements of this Product
Power requirements of this product have been changed and relevant sections
of the Operation Manual should be revised accordingly. (Revision should be
applied to items indicated by a check mark .)
Input voltage
The input voltage of this product is Vac,
and the voltage range is to Vac. Use the product
within this range only.
Input fuse
The rating of this product’s input fuse is A, Va c ,
and .
•To avoid electrical shock, always disconnect the
power cord or turn off the switchboard before
attempting to check or replace the fuse.
•Use a fuse element having a shape, rating, and
characteristics suitable for this product. The use of a
fuse with a different rating or one that short circuits
the fuse holder may result in fire, electric shock, or
irreparable damage.
✓
WARNING

4PMC-A

PMC-A 5
Safety Symbols
For the safe use and safe maintenance of this product, the following
symbols are used throughout this manual and on the product. Note the
meaning of each of the symbols to ensure safe use of the product. (Not
all symbols may be used.)
or
Indicates that a high voltage (over 1000 V) is used here.
Touching the part causes a possibly fatal electric shock. If physi-
cal contact is required by your work, start work only after you
make sure that no voltage is output here.
DANGER Indicates an imminently hazardous situation which, if ignored,
will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if ignored,
could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if ignored, may
result in damage to the product and other property.
Shows that the act indicated is prohibited.
Indicates a general danger, warning, or caution.
When this symbol is marked on the product, see the relevant
sections in this manual.
Indicates a caution for hot surface of the product.
When this symbol is marked on the product, see the relevant
sections in this manual.
Protective conductor terminal.
Chassis (frame) terminal.
On (supply)
Off (supply)
In position of a bi-stable push control
Out position of a bi-stable push control
!

6PMC-A
Safety Precautions
The following safety precautions must be observed to avoid fire hazards,
electric shock, accidents, and other failures. Keep them in mind and make
sure to observe them.
Using the product in a manner that is not specified in this manual may
impair the protection functions provided by the product.
Users • This product must be used only by qualified personnel who
understand the contents of this operation manual.
•Ifunqualified personnel is to use the product, be sure the
product is handled under the supervision of qualified
personnel (those who have electrical knowledge). This is to
prevent the possibility of personal injury.
Purpose of use
•Never use the product for purposes other than the product's
intended use.
• This product is not designed or manufactured for general
home or consumer use.
Input power • Use the product within the rated input power voltage range.
• For applying power, use the power cord provided. For
details, see the respective page in the operation manual.
• This product is designed as an equipment of IEC
Overvoltage Category II (energy-consuming equipment
supplied from the fixed installation).
Fuse •Thefuse can be replaced with a new one. When replacing a
fuse, use the one which has appropriate shape, ratings, and
specifications. For details, refer to the specification section in
this manual.
Cover • Some parts inside the product may cause physical hazards.
Do not remove the external cover.
•When the product is under the operation, the surface of top
cover may get high temperature. It may cause burn on the
skin.
!
Operation
Manual
Line
Voltage

PMC-A 7
Grounding • This product is an IEC Safety Class I equipment (equipment
with a protective conductor terminal). To prevent the
possibility of electric shock, be sure to connect the protective
conductor terminal of the product to electrical ground (safety
ground).
Installation • This product is designed for safe indoor use. Be sure to use
it indoors.
•When installing this product, be sure to observe the
description in 2.2 Precautions Concerning Installation
Location in this manual.
Relocation •Turn off the POWER switch, and disconnect all cables
before relocating the product.
•When relocating the product, be sure to include the manual.
Operation •Ifamalfunction or abnormality is detected on the product,
stop using it immediately, and remove the power plug from
the outlet. Make sure the product is not used until it is
completely repaired.
• Use cables or wires with sufficiently large current capacity
for output wires and load cables.
• Do not disassemble or modify the product. If youneed to
modify the product, contact your Kikusui distributor/agent.
Maintenance
and
inspection
• To prevent the possibility of electric shock, make sure to
unplug the power plug before carrying out maintenance or
inspection. Do not remove the external cover during
maintenance or inspection.
• Check that the insulation coating of the power cord is not
broken and that the plug is not cracked or falling apart.
• If the panel needs cleaning, gently wipe using a soft cloth
with water-diluted neutral detergent.
• To maintain the performance and safe operation of the
product, it is recommended that periodic maintenance,
inspection, cleaning, and calibration be performed.
Service •Kikusui service engineers will perform internal service on the
product. If the product needs adjustment or repairs, contact
your Kikusui distributor/agent.
GNL
Check?

8PMC-A
How to Read This Manual
Preface
Thank youfor purchasing the PMC-A Series regulated DC
power supply.
This manual is intended for first-time users of the PMC-A
Series (hereafter abbreviated as: the PMC-A). It gives an
overview of the PMC-A and describes various settings,
operation, maintenance, safety precautions, etc.
Read this manual thoroughly to use the functions of the PMC-A
effectively. Youcan also review this manual; when youare
confused about an operation or when a problem occurs.
How to read this manual
This manual is designed to be read from beginning to end. We
recommend that youread the manual thoroughly from the
beginning before using the PMC-A for the first time.
Intended readers of this manual
This manual is intended for those using the PMC-A of
regulated DC power supply and teaching other users on how to
operate the PMC-A.
It assumes that the reader has knowledge of a regulated DC
power.

PMC-A 9
Notations used in this manual
The following marks are used with the corresponding
explanations in this manual.
Indicates an imminently hazardous situation which, if
ignored, could result in death or serious injury.
Indicates a potentially hazardous situation which, if
ignored, may result in damage to the product and other
property.
Indicates information that youshould know.
Explanation of terminology or operation principle.
Indicates reference to detailed information.
WARNING
CAUTION
DESCRIPTION
See

10 PMC-A
Contents
Safety Symbols - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5
Safety Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -6
How to Read This Manual - - - - - - - - - - - - - - - - - - - - - - - - - - - -8
Contents - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -10
Function index - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -13
Front panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -14
Rear Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -16
Chapter 1 General Description
1.1 About This Manual - - - - - - - - - - - - - - - - - - - - - - - - - - - -17
1.2 Product Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - -17
1.3 Features - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -18
1.4 Options - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -19
Chapter 2 Installation and Preparation
2.1 Checking the Package Contents - - - - - - - - - - - - - - - - - -23
2.2 Precautions Concerning Installation Location - - - - - - - - -24
2.3 Precautions to Be Taken When Moving the Product - - - -26
2.4 Rack-mount Adaptor Installation - - - - - - - - - - - - - - - - - -26
2.5 Connecting the Power Cord - - - - - - - - - - - - - - - - - - - - -27
2.6 Ground (Earth) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -28
2.7 Turning On the Power - - - - - - - - - - - - - - - - - - - - - - - - -29
Inrush Current - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -30
Reverse Polarity - - - - - - - - - - - - - - - - - - - - - - - - - - - -30
Chapter 3 Connecting the Load
3.1 Load Considerations - - - - - - - - - - - - - - - - - - - - - - - - - -31
3.1.1 When the Load Current Has Peaks or is Pulse-shaped
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -31
3.1.2 When the Load Generates a Reverse Current to the
Power Supply - - - - - - - - - - - - - - - - - - - - - - - - - - - -32
3.1.3 When the Load Has Accumulated Energy Such As
Batteries - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -32
3.2 Connecting the Load - - - - - - - - - - - - - - - - - - - - - - - - - -33
3.2.1 Load Cable - - - - - - - - - - - - - - - - - - - - - - - - - - - - -34
Current capacity of the load cable - - - - - - - - - - - - - - - -34
Contents

PMC-A 11
Contents
Dependence of allowable cable current on the maximum
allowable insulator temperature - - - - - - - - - - - - - - - - -34
Taking measures against noise - - - - - - - - - - - - - - - - - -35
Voltage rating of the load cable - - - - - - - - - - - - - - - - - -35
3.2.2 Connecting to the Output Terminal - - - - - - - - - - - - -35
Chapter 4 Basic Operation
4.1 Constant Voltage (CV) and Constant Current (CC) Power
Supplies - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 37
Crossover point - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 39
Example of CV/CC mode operation - - - - - - - - - - - - - - -39
4.2 Using the Power Supply as a Constant Voltage Power Supply
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -40
Output Setup Procedure - - - - - - - - - - - - - - - - - - - - - - -40
4.3 Using the Power Supply as a Constant Current Power Supply
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 40
Output Setup Procedure - - - - - - - - - - - - - - - - - - - - - - -40
4.4 Protection Function - - - - - - - - - - - - - - - - - - - - - - - - - - - 41
4.4.1 Overvoltage Protection (OVP) Function - - - - - - - - -41
Setup procedure of the OVP trip point - - - - - - - - - - - - -41
Clearing alarms - - - - - - - - - - - - - - - - - - - - - - - - - - - - -42
4.4.2 Overheat Protection (OHP) Function - - - - - - - - - - -42
4.4.3 Other Protection Functions - - - - - - - - - - - - - - - - - -42
4.5 Remote Sensing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 43
Handling of SENSING terminals - - - - - - - - - - - - - - - - -43
Connection and setup procedure - - - - - - - - - - - - - - - -44
4.6 Master-Slave Parallel Operation - - - - - - - - - - - - - - - - - - 45
Handling of J1 Terminal - - - - - - - - - - - - - - - - - - - - - - -45
4.6.1 Functions during Master-Slave Parallel Operation - -46
Connection and setup procedure - - - - - - - - - - - - - - - -47
Starting and ending parallel operation - - - - - - - - - - - - -48
4.7 Series Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 51
Maximum number of power supplies connected in series -
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -52
4.7.1 Functions during Series operation - - - - - - - - - - - - -52
Connection and setup procedure - - - - - - - - - - - - - - - -53
Starting and ending series operation - - - - - - - - - - - - - -53
Chapter 5 External Control
5.1 External Remote Control - - - - - - - - - - - - - - - - - - - - - - - 55

12 PMC-A
Contents
J2 connector - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -56
5.1.1 Remote Control Connection and Setup - - - - - - - - - -59
Controlling the output voltage using external voltage - - -60
Controlling the output voltage using external resistance -61
Controlling the output current using external voltage - - -61
Controlling the output current using external resistance -62
Output on/off control - - - - - - - - - - - - - - - - - - - - - - - - - -63
5.2 Remote Monitoring - - - - - - - - - - - - - - - - - - - - - - - - - - - -63
5.2.1 External Monitoring of the Output Voltage and Output
Current. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -63
5.2.2 External monitoring of the operating status - - - - - - -64
Chapter 6 Maintenance
6.1 Replacing the Fuse - - - - - - - - - - - - - - - - - - - - - - - - - - -66
6.2 Calibration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -67
Test equipment required for calibration - - - - - - - - - - - -67
Environment - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -67
Calibration Procedure - - - - - - - - - - - - - - - - - - - - - - - - -67
Voltage system calibration procedure - - - - - - - - - - - - -68
Current system calibration procedure - - - - - - - - - - - - - -71
Chapter 7 Specifications
7.1 Specifications (Type I) - - - - - - - - - - - - - - - - - - - - - - - - -75
7.2 Specifications (Type II) - - - - - - - - - - - - - - - - - - - - - - - - -80
7.3 Dimension Diagram - - - - - - - - - - - - - - - - - - - - - - - - - - -85

PMC-A 13
1
2
3
4
5
6
7
Function index
Preparation
Use
Usage scenarios Manual sections
page
Confirming accessories 2 Installation and
Preparation 23
Rated input values - quantities 2.5 Connecting the Power
Cord
7 Specifications
27
74
What may be used with power supply
connected to load
3.2 Connecting the Load 34
Precautions for connecting to remote sensing
lines
4.5 Remote Sensing 43
Necessary preparations for rack mounting 1.4 Options
2.4 Rack-mount Adaptor
Installation
7 Specifications
19
26
74
See
Usage scenarios Manual sections
page
Learning protection details 4.4 Protection Function 41
Learning available function 1.3 Features 18
Clearing alarm conditions immediately. 4.4 Protection Function 41
See

14 PMC-A
Front panel
1
11
2
3
4
5
67
8
9
10
12 13
14
15
16
17
18
19
㧖
275*275*
Press this indicated area
toQRGPVJGEQXGT
No. Name Description
page
1POWER switch Depressed position is ON29
2OUTPUT switch Depressed position is ON. When this switch
is turned OFF, the OUTPUT of the power
supply is at high impedance (several kΩ).
40
3OUTPUT LED Lights when the output is ON. (Green) −
4LIMIT switch The voltage and current settings are dis-
played while this switch is held down.
This switch only displays the current setting.
It is not a memory function.
40
5Voltmeter Displays the voltage. −
6Ammeter Displays the current. −
7C.V LED Lights when operating in constant voltage
(CV) mode. (Green) 40
See

PMC-A 15
1
2
3
4
5
6
7
*1 Not available on models with rated output of 70 V or higher.
8C.C LED Lights when operating in constant current
(CC) mode. (Red) 40
9VOLTAGE knob Sets the output voltage. (10 turns) −
10 CURRENT knob Sets the output current. (10 turns) −
11 OUTPUT terminal Red : + (positive) terminal
White : - (negative) terminal
Connect either output terminal to the GND
terminal using the short bar unless your
application requires the power supply output
to be floating.
Since Type II models use a relay switch
system, a relay switch noise may appear at
the rising edge of the output when the input
voltage is low or depending on the load
condition.
35
12 GND terminal Connected to the chassis of the power sup-
ply. −
13 SENSING terminal *1 Remote sensing terminal. 43
14 SENSING switch *1 Enables remote sensing. Turn off the switch
when youare not using remote sensing. 43
15 OVP variable resistor Sets the OVP (Overvoltage Protection) trip
point. 41
16 ALM LED Lights when the overvoltage or overheat
protection circuit strips entering an alarm
status. (Red)
41
17 S1 to S4 switches Used for analog remote control. 56
S5 switch Used for master-slave parallel control.
18 Variable resistor for cali-
bration
Used to calibrate the output voltage and the
meter. 67
19 Front sub-panel cover To open the cover, press the part indicated
as PUSH. Youcan remove the cover by pull-
ing the opened cover. Even if the claw (indi-
cated with ) breaks, the cover can be
attached without problem.
−
No. Name Description
page
See
㧖

16 PMC-A
Rear Panel
J1
J
2
KIKUSUI
ELECTRONICS
CORP.
WARNING
FOR CONTINUED
PROTECTION AGAINST
FIRE HAZARD,
REPLACE ONLY WITH
SAME TYPE AND
RATING FUSE.
CAUTION
TO AVOID ELECTRIC
SHOCK, THE AC POWER
CABLE PROTECTIVE
GROUNDING CONDUCTOR
MUST BE CONNECTED
TO GROUND. DO NOT
REMOVE COVERS,
REFER SERVICING TO
QUALIFIED PERSONNEL.
INPUT
AC100V 50 60Hz
MAX280VA
MADE IN CHINA
FUSE
AC250V
4A (S.B)
1
2
3
1
2
3
4
5
No. Name Description
page
1J1 connector Input/output terminals for master slave par-
allel operation.
43
45
2J2 connector Terminals for analog remote control and
monitoring function. 56
3Fuse holder Contains an AC input fuse (S.B type) 66
4INPUT connector Power cord connector for supplying power
to the power supply. 27
5Protective conductor terminal.
Always ground the power supply. 28
See

PMC-A 17
General Description
This chapter gives an overview and introduces the features of
the PMC-A Series.
1.1 About This Manual
The PMC-A series come in two types depending on the size of
case. This operation manual describes the following models.
■Type I
PMC18-1A, PMC18-2A, PMC18-3A, PMC35-0.5A,
PMC35-1A, PMC35-2A
■Type II
PMC18-5A, PMC35-3A, PMC70-1A, PMC110-0.6A,
PMC160-0.4A, PMC250-0.25A, PMC350-0.2A,
PMC500-0.1A
1.2 Product Overview
The PMC-A Series are compact, high-performance, constant
voltage, constant current Series regulated DC power supplies.
The adoption of Series regulated design realizes a highly stable
output with a low level of output noise. In addition, with an
optional power supply controller, it allows to operate via GPIB
systems which offers wide application in the field of R&D,
Manufacturing, Testing, etc.
1

18 PMC-A
1.3 Features
●Digital display on both voltage and current at the same
time.
The PMC-A series power supply has two bright LED meters
that display the output voltage, output current, and their set-
tings.
●High-resolution setting for output voltage and current.
The variable resistors for the output voltage and current set-
tings are 10-turn wire wound type, allowing high-resolution
settings.
●Output ON/OFF by external contact
The output ON/OFF switch is an electronic switch that emits
no chattering or noise. The switch can also be controlled
remotely.
●External Remote Control
The output voltage and current can be controlled remotely
using an external analog signal (voltage or resistance). By
connecting a power supply controller such as KIKUSUI's
PIA3200 or PIA4810 via the GPIB interface, the PMC-A
series power supply can be integrated into a system such as
an automated test system.
●External monitor function
The monitor output enables to monitor the status output, out-
put voltage, and output current from outside of the PMC-A.
●Remote sensing function
The remote sensing function stabilizes the output voltage
across the load. (equipped with 18 V, 35 V models)
●Equipped with overvoltage protection (OVP) function
as standard.
• To control the PMC-A series power supply using
KIKUSUI's PIA3200 (via the GPIB interface), the ROM
version of the PIA3200 must be 1.03 or later. If not, the

PMC-A 19
1
General Description
ROM needs to be upgraded. To have the ROM upgraded,
contact your Kikusui agent or distributor.
• On Type II models, the internal loss is decreased by
changing the input voltage of the series regulator. The
input voltage is changed by switching secondary taps of
the internal transformer using relays. The relay has three
switch points and changes depending on the input volt-
age. If the input voltage fluctuates when the output volt-
age of power supply is used near a relay switch point, you
may hear the sound of the relay switching. This is not a
malfunction. When the relay is switched, a spike volt-
age at the output voltage may be generated.
1.4 Options
The following options are available for the PMC-A series.
For details, contact your Kikusui agent or distributor.
■Guard cap (GP01-PMC)
Exchanged with the knob to prevent inadvertent
operation of voltage or current setting.
■Output terminal cover (OTC01-PMC)
Covers the output terminal to prevent unex-
pected accidents. Applies to models with a
rated output of 70 V or greater.
It is recommended that you use the output ter-
minal cover for your safety.

20 PMC-A
■Handle (CH01-PMC)
A convenient handle for carrying the
power supply.
Applies to all type II models.
■Rack mount options
The following options are available for rack mount system.
•The PMC-A power supply uses unforced air cooling.
In order to keep a space for cooling intake, at least
one layer of “blank panel” must be installed when
the PMC-A is rack mounted.
*JIS standard：50 mm、EIA standard：44.45 mm
For details, contact your Kikusui agent or distributor.
Name Model Note
Rack adapter KRA3 inch rack (EIA standard)
KRA150 Milli rack (JIS standard)
Blank panel
KBP3-2 (EIA, JIS common) - 1/2
width
KBP3-4 (EIA, JIS common) - 1/4
width
BP191(-M)*1
*1. the model added with “-M” is “mesh” type.
inch rack (EIA standard)
BP1H(-M)*1 Milli rack (JIS standard)
CAUTION
*
