OPERATION MANUAL
AC Electronic Load
Part No. Z1-004-002, IB013706
Jul 2018
PCZ1000A
General
Description
Unpacking
and Installation
Operation
Remote Control
Maintenance
and Calibration
Specifications
Appendix
1
2
3
4
5
6

Use of Operation Manual
Please read through and understand this Operation Manual before operating the product. After reading,
always keep the manual nearby so that you may refer to it as needed. When moving the product to another
location, be sure to bring the manual as well.
If you find any incorrectly arranged or missing pages in this manual, they will be replaced. If the manual
gets lost or soiled, a new copy can be provided for a fee. In either case, please contact Kikusui distributor/
agent, and provide the “Kikusui Part No.” given on the cover page.
This manual has been prepared with the utmost care; however, if you have any questions, or note any
errors or omissions, please contact Kikusui distributor/agent.
Differences in Operation
The following operations differ between the previous PCZ1000A, which is equipped with a JOG/SHUT-
TLE dial, and this PCZ1000A, which is equipped with a rotary knob.
Parallel Operation and Tracking Operation
If the firmware version of the PCZ1000A with a JOG/SHUTTLE dial is 1.40 or later, parallel operation
and tracking operation are possible with the PCZ1000A with a rotary knob.
Reproduction and reprinting of this operation manual, whole or partially, without our permission is prohib-
ited.
Both unit specifications and manual contents are subject to change without notice.
© 2018 Kikusui Electronics Corporation
Panel operation
Fine adjustment of setting
values Turn the JOG dial. Turn the rotary knob slowly.
Coarse adjustment of set-
ting values Turn the SHUTTLE dial. Turn the rotary knob quickly.
Configuration settings Turn the JOG dial. Turn the rotary knob slowly.
19
JOG dialSHUTTLE dial
Rotary knob

PCZ1000A i
Power Requirements of this Product
Power requirements of this product have been changed and the relevant
sections of the Operation Manual should be revised accordingly.
(Revision should be applied to items indicated by a check mark .)
Input voltage
The input voltage of this product is VAC,
and the voltage range is to VAC. Use the product within
this range only.
Input fuse
The rating of this product's input fuse is A, VAC, and .
• To avoid electrical shock, always disconnect the power cord or turn
off the switch on the switchboard before attempting to check or
replace the fuse.
• Use a fuse element having a shape, rating, and characteristics
suitable for this product. The use of a fuse with a different rating or
one that short circuits the fuse holder may result in fire, electric
shock, or irreparable damage.
✓
WARNING

ii PCZ1000A
This page is intentionally blank.

PCZ1000A iii
Safety Symbols
For the safe use and maintenance of this product, the following symbols are used
throughout this manual and on the product itself. Note the meaning of each of the
symbols to ensure safe use of the product. (Not all symbols may be used.)
or
Indicates that a high voltage (over 1 000 V) is used here.
Touching the part will result in a possibly fatal electric shock. If physical
contact is required by your work, start work only after you make sure
that no voltage is output here.
DANGER Indicates an imminently hazardous situation which, if ignored, will result
in death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if ignored, could result
in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if ignored, may result
in damage to the product and other property.
Shows that the act indicated is prohibited.
Indicates a general danger, warning, or caution.
When this symbol is marked on the product, see the relevant sections in
this manual.
Protective conductor terminal.
Chassis (frame) terminal.
On (supply)
Off (supply)
In position of a bi-stable push control
Out position of a bi-stable push control
!

iv PCZ1000A
Safety Precautions
The following safety precautions must be observed to avoid fire hazards, electric
shock, accidents, and other failures. Please keep these in mind and follow the
instructions carefully.
Using the product in a manner that is not specified in this manual may impair the
protection functions provided by the product.
Users • This product must be used only by qualified personnel who
understand the contents of this operation manual.
• If an unqualified person is to use the product, be sure the product is
handled under the supervision of qualified personnel (those who have
electrical knowledge). This is to prevent the possibility of personal
injury.
Purpose of
use
• Never use the product for purposes other than the product's intended
use.
• This product is not designed or manufactured for general home or
consumer use.
Input power • Use the product within the rated input power voltage range.
• Use the power cord provided. For details, see the relevant page in the
operation manual.
• This product is a IEC Overvoltage Category II device (energy-
consuming equipment supplied from the fixed installation).
Fuse • The fuse can be replaced on this product. When replacing the fuse,
use a fuse with the correct shape, rating, and characteristics for the
product. For details, see the relevant page in the operation manual.
Cover • Some parts inside the product may cause physical hazards. Do not
remove the external cover.
!
Operation
Manual
Line
Voltage

PCZ1000A v
Grounding • This product is an IEC Safety Class I device (device with protected
conductor terminals). To prevent electric shock, be sure to connect the
protective conductor terminal of the product to electrical ground
(safety ground).
Installation • This product is designed for safe indoor use. Only use the product
indoors.
• Please read the section 2.2, “Precautions for Installation” section of
this manual before installing the product and comply with the
instructions.
Relocation • Turn off the POWER switch, and disconnect the cables before
relocating the product.
• The product weighs over 20 kg. When moving the product, have more
than one person carry it. The weight of the product is indicated on the
rear panel of the product and in the specification table in this manual.
• When relocating the product, remember to also relocate the manual.
Operation • Before using the product, be sure to check the input power voltage and
that there is no abnormality in the appearance of the AC power cord.
Be sure to remove the power cord plug from the outlet before checking.
• If a malfunction or abnormality is detected on the product, stop using it
immediately, and remove the power cord plug from the outlet. Make
sure the product is not used until it is completely repaired.
• Use cables or wires with sufficiently large current capacity for output
wires and load cables.
• Do not disassemble or modify the product. If you need to modify the
product, contact your Kikusui distributor or agent.
Maintenance
and inspection
• To prevent electric shock, be sure to turn off the switchboard breaker
before carrying out maintenance or inspection.
• Do not remove the external cover during maintenance or inspection.
• To maintain the performance and safe operation of the product, it is
recommended that periodic maintenance, inspection, cleaning, and
calibration be performed.
Service • Kikusui service engineers will perform internal service on the product.
If the product needs adjustment or repairs, contact your Kikusui
distributor or agent.
GNL
Check?

vi PCZ1000A
How to Read This Manual
Introduction
Thank you for purchasing the PCZ1000A AC electronic load.
This manual is intended for first-time users of the PCZ1000A. It gives an overview
of the PCZ1000A and describes various settings, program messages, maintenance,
and precautions, etc.
Read this manual thoroughly to use the functions of the PCZ1000A effectively. You
can also review this manual when you are confused about an operation or when a
problem occurs.
How to read this manual
This manual is designed to be read from beginning to end. We recommend that you
read this manual thoroughly from the beginning before using the PCZ1000A for the
first time.
Intended readers of this manual
This manual is intended for users of the PCZ1000A or persons teaching other users
on how to operate the PCZ1000A.
The manual assumes that the reader has knowledge about electronic load equipments.
Information on the remote control commands are provided with the premise that the
reader has sufficient knowledge about controlling measuring instruments using a
personal computer.

PCZ1000A vii
1
2
3
4
5
6
Appx.
Structure of this manual
This operation manual consists of the following chapters. The following outlines
each chapter.
Chapter 1 General Description
This chapter gives an overview and describes the features of the PCZ1000A.
Chapter 2 Unpacking and Installation
This chapter describes the necessary procedures from unpacking the product to
preparation before use.
Chapter 3 Operation
This chapter describes each mode and function of the operation.
Chapter 4 Remote Control
This chapter describes how to program the remote control features of the
PCZ1000A using an external device such as a personal computer. The explanation
covers the command syntax, details of each command, and the registers.
Chapter 5 Maintenance and Calibration
This chapter describes the maintenance procedures including cleaning, inspection,
and calibration.
Chapter 6 Specifications
This chapter gives the specifications and dimensions of the PCZ1000A.
Appendix
The appendix contains the basic operating modes, operating range, and
troubleshooting.
Notation used in this manual
• The PCZ1000A AC electronic load is simply referred to as the PCZ1000A in this
manual.
• The term "computer" is used to refer to a personal computer, workstation, or
similar.
• The following markings are used in this manual.
Indicates a potentially hazardous situation which, if ignored,
could result in death or serious injury.
Indicates a potentially hazardous situation which, if ignored,
may result in damage to the product and other property.
Indicates information that you should know.
Explanation of terminology or operation principle.
Indicates a reference to detailed information.
SHIFT+key name (marked in blue)
Indicates an operation involving pressing the named key
(printed in blue) when the LED above the SHIFT key
illuminates after the SHIFT key is held down.
WARNING
CAUTION
See

viii PCZ1000A
Contents
Power Requirements of this Product - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - i
Safety Symbols - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - iii
Safety Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - iv
How to Read This Manual - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - vi
Contents - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - viii
Function Index - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - xi
Front panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - xii
Rear panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - xiv
Chapter 1 General Description
1.1 About This Manual - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
1.2 Product Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
1.3 Features - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
1.4 Options - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-3
Chapter 2 Unpacking and Installation
2.1 Unpacking Checks - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-2
2.2 Precautions for Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-2
2.3 Precautions for Moving - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-4
2.4 Attaching to the Rack Mount Frame - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-5
2.5 Checking the Input Power and Fuse- - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-6
2.6 Connecting the AC Power Cord - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-8
Procedure for Connecting the Power Cord - - - - - - - - - - - - - - - - - - - - - 2-8
2.7 Load Wiring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-9
2.7.1 Precautions Concerning Wiring- - - - - - - - - - - - - - - - - - - - - - - - - - - 2-9
Overvoltage - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-10
Other Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-10
Input Voltage Waveforms - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-11
2.7.2 Connection to the Load Input Terminals - - - - - - - - - - - - - - - - - - - 2-13
Chapter 3 Operation
3.1 Basic Panel Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-2
Function Keys - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-2
Preset Memory Key - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-3
Other Keys - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-4
3.2 Turning On the Power- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-5
3.3 Load-On/Load-Off - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-6
3.4 Protection Functions and Alarms - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-7
Alarm Occurrence and Release - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-7
Protection Functions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-7
3.5 Operation Modes - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-10
Operation Mode Display - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-10

PCZ1000A ix
1
2
3
4
5
6
Appx.
3.5.1 CC Mode Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-11
3.5.2 Constant Resistance (CR) Mode - - - - - - - - - - - - - - - - - - - - - - - - 3-12
3.5.3 Constant Power (CP) Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-15
3.5.4 Crest Factor Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-16
3.6 Saving and Recalling Preset Memory - - - - - - - - - - - - - - - - - - - - - - - - - - 3-17
Saving Preset Memory - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-18
Changing Preset Memory - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-19
Recalling Preset Memory - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-20
3.7 Parallel Operation and Tracking Operation- - - - - - - - - - - - - - - - - - - - - - - 3-21
3.7.1 Configuration (CONFIG) Settings - - - - - - - - - - - - - - - - - - - - - - - - 3-21
How to Display and Set Configuration Settings - - - - - - - - - - - - - - - - - 3-22
3.7.2 Parallel Operation- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-23
Procedure for Connecting Units in Parallel- - - - - - - - - - - - - - - - - - - - - 3-24
Procedure for Setting Master and Slave Units - - - - - - - - - - - - - - - - - - 3-25
3.7.3 Tracking Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-27
Connecting Units for Tracking Operation - - - - - - - - - - - - - - - - - - - - - - 3-28
Procedure for Setting Master and Slave Units - - - - - - - - - - - - - - - - - - 3-28
3.7.4 Calibration of the Ammeter on the Master Unit During Parallel Operation
3-30
Preparation for Calibration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-30
Calibration Procedure - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-31
3.7.5 Alarms During Parallel and Tracking Operation - - - - - - - - - - - - - - 3-33
3.7.6 Returning to Standalone Operation - - - - - - - - - - - - - - - - - - - - - - 3-33
3.8 Factory Default Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-34
Chapter 4 Remote Control
4.1 Overview of Remote Control - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-2
4.1.1 RS232C Interface - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-2
4.2 Programming Format - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-4
4.2.1 Program Messages- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-4
4.3 Device Messages - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-5
4.3.1 Program Header and Program (Response) Data - - - - - - - - - - - - - - 4-5
4.3.2 Configuration of Device Messages - - - - - - - - - - - - - - - - - - - - - - - - 4-6
Basic Messages - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-6
System Messages- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-8
Communication Settings and Control Codes - - - - - - - - - - - - - - - - - - - - 4-8
4.4 Assignment of Register Bits - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-9
Fault Register - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-9
Fault Register 2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-9
Error Register - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-10
Communication Command Errors - - - - - - - - - - - - - - - - - - - - - - - - - - 4-10
Chapter 5 Maintenance and Calibration
5.1 Cleaning and Inspection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-2
Inspecting the Power Cord - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-2
Cleaning the Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-2

xPCZ1000A
Replacing the Backup Battery - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-2
Cleaning the Dust Filter - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-2
5.2 Calibration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-3
Chapter 6 Specifications
6.1 Specifications- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-2
6.2 Dimensions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-5
Appendix
A.1 Explanation of Operating Functions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-2
A.1.1 Operating Functions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-2
Operating Range - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-2
Differences Between DC and AC Loads - - - - - - - - - - - - - - - - - - - - - - - A-2
A.1.2 Explanation of Operating Mode- - - - - - - - - - - - - - - - - - - - - - - - - - - A-4
Constant-Current (CC) Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-4
Constant-Resistance (CR) Mode- - - - - - - - - - - - - - - - - - - - - - - - - - - - A-5
Constant-Power (CP) Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-6
A.2 Troubleshooting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-7
Index

PCZ1000A xi
1
2
3
4
5
6
Appx.
Function Index
Preparation
Operation
Others
Topic Section in the Manual
Page
How do I check that all accessories are included. Unpacking Checks 2-2
What precautions should I observe when installing? Precautions for Installation 2-2
What precautions should I observe regarding grounding? Connecting the AC Power Cord 2-8
What precautions should I observe regarding the load
unit?
Load Wiring 2-9
How do I connect the power cord? Connecting the AC Power Cord 2-8
How do I connect the load? Connection to the Load Input
Terminals 2-13
Where do I find detailed explanation of initial settings? Turning On the Power 3-5
How do the protection functions work? Protection Functions and Alarms 3-7
What settings are available? Basic Panel Operation 3-2
What are the connector requirements and what is the
procedure for connecting PCZ1000A units to operate in
parallel?
Procedure for Connecting Units in
Parallel 3-24
Topic Section in the Manual
Page
How do I turn the power on and off? Turning On the Power 3-5
How do I set the protection functions? Protection Functions and Alarms 3-7
How do I use the PCZ1000A in constant-current mode? CC Mode Operation 3-11
How do I use the PCZ1000A in constant-resistance
mode?
Constant Resistance (CR) Mode 3-12
How do I use the PCZ1000A in constant-power mode? Constant Power (CP) Mode 3-15
How do I use the Crest Factor function? Crest Factor Function 3-16
How do I set the configuration (CONFIG)? Configuration (CONFIG) Settings 3-21
Topic Section in the Manual
Page
How can I check whether the PCZ1000A is faulty? Troubleshooting A-7
How do I perform troubleshooting?
Where do I find detailed command reference? Programming Format 4-4
What do the remote control error messages mean? Assignment of Register Bits 4-9
How do I perform maintenance? Cleaning and Inspection 5-2
What is the procedure for calibration? Calibration of the Ammeter on the
Master Unit During Parallel
Operation
3-30
How do I reset the PCZ1000A to the factory default
settings?
Factory Default Settings 3-34
See
See
See

xii PCZ1000A
Front panel
18
17
Control panel
Control panel
1
Display
Display
2
3
4
567
8910
11
1213
14

PCZ1000A xiii
1
2
3
4
5
6
Appx.
No.
Name
Explanation
Page+SHIFT
1POWER Power on/off switch
The power is ON when the switch is in position ( ) and OFF when the
switch is out position ( ).
3-5
2C.F ON/OFF Turns CF mode on or off. 3-3
C.F LED Illuminates to indicate when CF mode is on. 3-10
3SHIFT Enables keys indicated in blue.
-
SHIFT LED Illuminates to indicate when the SHIFT key is active.
4LOAD ON/OFF Turns the load on or off. 3-2
LOAD LED Illuminates to indicate when the load is on. -
5I SET Sets CC mode and to set the current limit using the rotary knob. 3-2
CONFIG Specifies various settings that control the operation. 3-21
6C.C LED Illuminates to indicate when CC or CP mode is on. 3-10
C.R LED Illuminates to indicate when CR or CP mode is on. 3-10
7R SET Sets CR mode and to set the resistance limit using the rotary knob.
3-3
RANGE Range selection key
8P SET Sets CP mode and to set the power limit using the rotary knob. 3-3
9ARecalls the preset memory A value; pressing the MEM key and A saves
the value to preset memory A.
3-3
BRecalls the preset memory B value; pressing the MEM key and B saves
the value to preset memory B.
CRecalls the preset memory C value; pressing the MEM key and C saves
the value to preset memory C.
10 MEM Saves preset memory values.
3-3
D MEM Modifies preset memory values.
11 Rotary knob Fine and coarse adjustment of setting values 3-2
12 ENTER Enter key for preset memory
3-4
LOCAL Local operation selection key
13 ESC Cancels the selected function.
3-4
ALM CLR Clears an alarm.
14 Ventilation louvers Provides ventilation for the unit. Fitted with an internal dust filter. 5-2
See

xiv PCZ1000A
Rear panel
No. Name Explanation
Page
1Power supply voltage range
selection switch
Switch for selecting the power supply voltage to be used 2-6
2PARALLEL OUT Connector for parallel operation (output). Incorporates a
protective socket.
3-23
3PARALLEL IN Connector for parallel operation (input). Incorporates a protective
socket.
4Ventilation outlets Cooling ventilation outlets 2-3
5LOAD INPUT Load input terminals 2-9
6Serial number The serial number of the instrument -
7RS232C RS232C connector used by the remote control function 4-2
8AC INPUT AC power supply inlet 2-8
9FUSE Power supply fuse holder, includes a spare fuse (1) 2-2,
2-7
1
8
23 45
6
7
9
See

General Description
This chapter gives an overview and describes the features of
the PCZ1000A.

1-2 PCZ1000A
1.1 About This Manual
This operation manual describes the PCZ1000A AC electronic load.
Applicable firmware versions
page 3-5 This manual applies to PCZ1000A with firmware version 1.4x.
When making an inquiry about the product, please provide us with the following
information:
•Model Name (PCZ1000A)
•Firmware version
•Serial number (indicated at the lower section on the rear panel)
1.2 Product Overview
The PCZ1000A is an AC electronic load featuring high reliability and safety. In
addition to the resistive loads generally used in tests, it is capable of simulating
capacitive-input rectifier loads.
1.3 Features
●Crest-factor function
In addition to the constant-current*, constant-resistance*, and constant-power*
modes, the PCZ1000A also features a crest-factor function which is useful for
load testing of peak or harmonic currents. This helps reduce design and labor
time and cost as well as improve the quality of the equipment under test.
* The instrument always allows a current waveform close to a sine waveform to
flow unaffected by the voltage waveform.
●Simple operation
The key features can be operated quickly on a one-key-to-one-feature basis. Fine
adjustment is possible with the rotary knob.
●Easy-to-see LCD with backlight
The instrument features an LCD with LED backlight, enabling a variety of
operations to be performed. Test results are displayed clearly and are unaffected
by ambient light.
●Parallel operation
Up to five units can be used in parallel under the control of a single master unit. A
PCZ1000A can be set as a master and up to four slave PCZ1000As connected in
parallel (max. 5 kW, 50 Arms). The total power is displayed on the front panel of
the master unit.
See

PCZ1000A 1-3
1
General Description
●Tracking operation
Up to five units can be tracked
Setup values specified on the master unit are also applied to the slave units and
any changes to the master unit settings are also applied immediately to the
slaves. Useful for testing single-phase/three-wire or three-phase/three-wire AC
power supply loads.
1.4 Options
The following options are available for the PCZ1000A.
For details on the options, contact your Kikusui agent or distributor.
■Rack mounting option
Part Name Model No. Remarks
Rack mounting
bracket
KRB3 For EIA standard inch units racks
KRB150 For JIS standard metric units racks
KRB3
KRB150
Unit: mm
57
463
482
132.5
37.75
5024.5
149
460
480

1-4 PCZ1000A
■Signal cable for parallel operation
Cable used for parallel operation
Part name Model No. Remarks
Signal cable for
parallel operation
PC01-PCZ1000A 300 mm, 10-pin
