Kilowatt Labs SIRIUS 500-12-B-1C SL Series User manual

SIRIUS CAPACITOR MODULE
User Manual
Model number: 500-12-B-1C-X-X-X-X-X-SL
Version 1.1; Release Date: January 2021
Author:
Mamoona Khalid

Introduction
The Sirius Capacitor Module (“Sirius”) is supercapacitor-based storage that uses supercapacitors as
storage cells instead of chemical cells. Kilowatt Labs’ proprietary balancing, control and charge
retention algorithms control the operation of the supercapacitor-based modules, making Sirius a safe,
efficient and effective alternative to chemical batteries wherever chemical batteries are deployed.
Legal Provisions
No part of this User Manual (“Manual”) may be reproduced, or transmitted, in any form or by any
means, without the prior written permission of Kilowatt Labs, Inc. (“Kilowatt” or the “Company”).
Specifications in this Manual are subject to change without notice. While every attempt has been
made to make the Manual accurate and up-to-date, users are cautioned that product improvements
may cause the Company to make changes to specifications without advance notice. Users are
encouraged to consult the Company or its Resellers before using the Manual. Neither the Company
nor its Resellers shall be liable for any indirect, incidental, or consequential damages under any
circumstances caused by reliance on the material presented, including, but not limited to, omissions,
typographical errors, arithmetical errors or listing errors in the content material. The content of this
manual shall not be modified without the written authorization of the Company.
Trademarks
All trademarks are recognized, even if not explicitly identified as such. Kilowatt Labs® is a registered
trademark of the Company.

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
3
Table of Contents:
1. Safety Instructions:...................................................................................................................5
1.1 Symbols Convention: ........................................................................................................5
1.2 Safety Precautions: ...........................................................................................................5
1.3 Modules Connection Safety Precautions:.........................................................................7
1.4 Shipping: ...........................................................................................................................7
1.5 Qualified Installer:.............................................................................................................7
2. Product Introduction: ...............................................................................................................8
2.1 Product Part Number:.......................................................................................................8
1) Capacity of Module in Wh ................................................................................................8
2.2 Product Overview: ..................................................................................................................8
2.2.1 Appearance:.......................................................................................................................8
2.2.2 Mechanical Drawings:........................................................................................................9
2.2.3 Dimensions and Weight:..................................................................................................10
2.3 Product Description:.............................................................................................................11
1. Power Switch: .................................................................................................................11
2. Fault Reset Button: .........................................................................................................11
3. Terminals: .......................................................................................................................11
3. Module Installation:................................................................................................................12
3.1 Inspection: ............................................................................................................................12
3.2 Safety Gear: ..........................................................................................................................12
3.3 Unpacking and Contents Check:...........................................................................................12
4. Electrical Installation:..............................................................................................................13
4.1 Cable Size:.............................................................................................................................13
4.2 Connecting Cable Lugs, Washers and Bolts to Module Terminals: ......................................13
4.3 Connecting Module to Power Supply:......................................................................................14
4.4 Connecting Module to Load: ....................................................................................................15
4.5 Connecting Modules in Parallel:...............................................................................................16
4.6 Connecting Modules in Series: .................................................................................................17
5. Operation Procedures:............................................................................................................18
5.1 Module Configuration:..........................................................................................................18

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
4
6. Recovery Procedure:...............................................................................................................19
7. Trouble Shooting: ...................................................................................................................20
8. Shelf Life:.................................................................................................................................21
9. Maintenance:..........................................................................................................................21
10. Disposal:..................................................................................................................................21

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
5
1. Safety Instructions:
This manual contains instructions for unpacking, mounting, installation and operation of a Sirius
Module. Please read this manual carefully before operating the system and follow all warnings and
safety instructions to prevent accidents. The Sirius Module must be installed by trained personnel.
1.1 Symbols Convention:
Safety instructions and general information that appear in this manual are described.
1.2 Safety Precautions:
The Sirius Modules are designed to provide years of trouble-free operation. Proper handling is
required to avoid damage to the Module. In particular the following precautions should be observed.
•Personal Safety:
→Always wear proper personal protective equipment (eyes protection, gloves and safety shoes).
→Always make sure the charger is set as recommended.
→Always make sure the chargers are disconnected while working on the Modules.
Caution!
‘Caution” indicates hazardous situation which, if not avoided could result in
minor or moderate injury.
Warning!
‘Warning” indicates hazardous situation which, if not avoided could result
in major injury or death.
Danger!
‘Danger” indicates hazardous situation which, if not avoided could result in
serious injury or death.
Note!
‘Note” provides tip that are valuable for optimal operation of your
product.

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
6
•Module Safety:
→Do not subject the Module to strong impact.
→Do not crush or puncture the Module.
→Do not dispose the Module in a fire.
→Do not charge the Module when the temperature is below -30oC.
→Do not charge the Module when the temperature is above 80oC.
→Do not operate the Module above the specified voltage.
→Under no circumstance charge/discharge the Module at more than 40A.
→Under no circumstance must the charging voltage exceed 13.5 Vdc for more than 60 seconds.
→Do not expose the Module to temperature in excess of 80°C.
→Do not place the Module near a heat source, such as a fireplace.
→Do not disassemble the Module under any circumstances.
→Do not lift the Module by the terminal posts.
→Do not touch the Module with wet hands.
→Do not expose the Module to moisture or liquids.
→Keep the Module away from children and animals.
→Ensure precautions to prevent short-circuit under all circumstances.
→Do not connect or disconnect terminals from the Module without first disconnecting the load.
→Do not touch the terminals with conductors while the Module is charged. Serious burns, shock, or
material fusing may occur.
→Protect surrounding electrical components from incidental contact.
→When connecting to external devices ensure that galvanic isolation does not exceed 1000V.
→Do not use the Module in open-environment, in rain or in a place exposed to water and other
liquids.
→Do not subject the Module to high pressure.
→Do not place any objects on top of the Module.
→Do not step on the Module.
→Mount the Modules only in horizontal direction.
→Do not drop the Module. Internal damage may occur that will not be visible.
→Do not stack Modules once they have been removed from the packaging, instead the Modules
should be placed on shelving.
→In case the Module is physically damaged due to any event, do not install and energize the Module
under any circumstances and immediately contact your Reseller.

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
7
1.3 Modules Connection Safety Precautions:
→All Modules must be at 100% SOC before connecting in series or in parallel.
→The maximum number of Modules that can be connected in series is 4.
→Do not connect more than 4 Modules in series.
→There is no limit on the Modules while connecting in parallel.
→Modules cannot be connected in series-parallel combination under any circumstance.
1.4 Shipping:
Sirius Modules are shipped out via Air and Sea.
•If you receive the Modules shipped by Air, please follow the instructions given below:
•Carefully remove the nails from all the four sides of the wooden box and open it.
•Remove the foam and cling wrap and open the carton box and lift the Module manually.
•If you receive the Modules shipped by Sea, please follow the instructions below:
•Carefully remove the Module from the pallets after cutting the packing strip holding the
Modules to the shipping pallets.
•Open the carton box and lift the Module manually.
1.5 Qualified Installer:
Selling and installation of this Module is only through the Company’s Resellers who are trained on
installation, operation and maintenance of the Sirius Modules.
Note!
If you want to connect more than 4 Modules in series, please contact your
Reseller.
Danger!
The Module must be removed from the carton by lifting it from the base.
Do not hold the Module from the terminal posts.
Note!
Do not stack more than 2 Modules.

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
8
2. Product Introduction:
2.1 Product Part Number:
1) Capacity of Module in Wh
2) Nominal Voltage of the Module
3) Terminals are on the Front Side
4) Maximum Charge Rate of the Module
5) 5,6,7,8,9 Not Available
10) Street Light Module
2.2 Product Overview:
2.2.1 Appearance:
The appearance of the Sirius Capacitor Module is shown below:

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
9
2.2.2 Mechanical Drawings:

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
10
2.2.3 Dimensions and Weight:
Width
110
Depth
901 mm
Height
106 mm
weight
12 Kg

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
11
2.3 Product Description:
1. Power Switch:
When the power button is switched ON, the Module electronics are powered up and it will raise
alarm during overvoltage, undervoltage, overcurrent and overtemperature. If the switch is OFF then
there will be no alarm.
2. Fault Reset Button:
Fault Reset is a push button which is used to reset alarm raised during overvoltage, undervoltage,
overcurrent and overtemperature faults.
3. Terminals:
F05 terminals are used to connect the load or charger to the Module. There are positive and negative
cables in the jumper cable set. The red one is positive (+), the black one is negative (-).
Note!
Never connect the red cable to the negative battery terminal.

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
12
3. Module Installation:
3.1 Inspection:
Inspect the shipping carton for visible damage including cracks, dents, deformation and other visible
abnormalities prior to unpacking the Module. Document (photograph) any damage and report this to
your Reseller as well as to the shipping agent immediately. Remove the Module from the shipping
carton and retain the shipping materials until the unit has been inspected and is determined to be
operational.
3.2 Safety Gear:
Installation must strictly follow the national safety regulations in compliance with the enclosure,
installation, creepage, clearance, casualty, markings and segregation requirements of the end-use
application. Installation must be performed by professional installers only. Switch OFF the system and
check for hazardous voltages before altering any connection! Sirius Modules must be handled only by
qualified and trained personnel. Installation should not exert bending or twisting torque to the Module
enclosure.
3.3 Unpacking and Contents Check:
Check the contents of the package. Only two items are included in the package.
1) Sirius Capacitor Module: 1KWh12VDC
2) Bolts × 2
3) Washers × 4
Note!
Read the safety Instruction sheet before installation.
1
2
3

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
13
4. Electrical Installation:
4.1 Cable Size:
We recommend a cable size of 16mm2thick and 1m length to hold current up to 50A. Please use thick
cable size for lengths longer than 1m.
4.2 Connecting Cable Lugs, Washers and Bolts to Module Terminals:
Follow the sequence below to connect the washers, lugs and bolts to the positive and negative
terminals of the Sirius Module. Make sure connection is not loose.
Figure 1.Connecting washers, lugs and bolts to negative terminal of Module
Figure 2. Connecting washers, lugs and bolts to positive terminal of Module











Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
14
4.3 Connecting Module to Power Supply:
•Connect positive and negative terminals of charger to the positive and negative terminals of the
Sirius Module respectively.
•Make sure to activate the Module by turning ON the power switch to get the output from the
terminal.
•Turn ON theCharger.









Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
15
4.4 Connecting Module to Load:
•Connect positive and negative terminals of discharger to the positive and negative terminals of the
Sirius Module respectively.
•Make sure to activate the Module by turning ON the power switch to get the output from the
terminal.
•Turn ON thedischarger.

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
16
4.5 Connecting Modules in Parallel:
Any number of Modules can be connected in parallel.
•Steps to Connect Modules in Parallel:
Refer to the parallel combination of the Sirius Modules as shown below and make your connection
accordingly.
•Connect the positive (+) terminal of all the Modules to the positive busbar.
•Connect the negative (-) terminal of all the Modules to the negative busbar.
•Take out the output positive terminal and output negative terminal from the respective common
point.
Note!
Modules cannot be connected in series-parallel combination under any
circumstance.
Caution!
Charge all the Modules to 100% SOC or same voltage level before connecting
them in parallel.

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
17
4.6 Connecting Modules in Series:
A maximum of 4 Modules can be connected in series.
•Steps to Connect Modules in Series:
Refer to the series combination of the Sirius Modules as shown below and make your connection
accordingly.
•Connect the positive (+) of the F05 terminal of the first Module with the negative (-) of the F05
terminal of the next Module.
•Take the output negative from first Module and output positive from the last Module.

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
18
5. Operation Procedures:
5.1 Module Configuration:
Follow the steps below to switch ON the Module.
Step 1: Module Start-Up:
1. Connect charger to switch ON the Module.
2. Turn ON the power switch button in order to give alarm during overvoltage, undervoltage,
overcurrent and overtemperature faults.
Step 2: Module Shut-Down:
1. The Module can be shut down by disconnecting the load.
Note!
The Module should only be operated within the specified voltage and
temperature ratings.
Note!
Observe polarity indicated on Module. Do not reverse polarity.
Note!
Always turn OFF the Module when not in use because the Module is self-
powered. It can result in faster self-discharge of the Module.

Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
19
6. Recovery Procedure:
Use the steps below to recover the Module.
1. A power supply having voltage range of 11Vdc to 13.5Vdc and current range of 1A to 40A will be
required.
2. Connect the positive terminal of the power supply to the positive terminal of the F05 terminals
and negative terminal of the power supply to the negative terminal of the F05 terminals.
3. Once the connection is done, turn ON the charger.
4. The event may take several minutes depending on the power supply used.
•Recommended Charger for Recovery:
Maximum Current
40 A
Recommended Voltage
11V-13.5V






Sirius Capacitor Module –User Manual Model Number -500-12-B-1C-X-X-X-X-X-SL
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
20
7. Trouble Shooting:
Switch ON the power switch button on the front panel to determine the state of the Module. A
warning state is triggered when a condition, such as voltage, current or temperature, is beyond design
limitations. When the Module falls outside prescribed limits, it enters a warning state. When a warning
is reported, the buzzer alarms.
The possible warning alarms are as follows:
Warning Messages
Description
Trouble Shooting
Over-Current (OC)
Over-current occurs when
the current goes above 40A
or when the Module is
short-circuited. In this
event, the buzzer alarms
which can be reset by fault
reset button.
Switch OFF the Module and check
the continuity across the Module
terminals to find whether there is a
short circuit. In case of a short
circuit, check the operating
circuitry and clear the short circuit.
Over-Temperature (OT)
Over-temperature occurs
when the Module
temperature goes above
80°C. In this event, the
buzzer alarms which can be
reset by fault reset button.
Shut down the Module and check
the surrounding temperature and
ensure the ambient temperature is
less than 80°C. If not leave the
Module to cool till the temperature
comes below 80°C.
Over-voltage (OV)
Over-voltage occurs when
the Module voltage has
increased the cut-off limit
of 13.5V. In this event, the
buzzer alarms which can be
reset by fault reset button.
Check the charger’s upper cut-off
limit and ensure it is set below
13.5V. The Module becomes
operational when the Module’s
surface charge is cleared, and the
voltage drops below 13.5V.
Under-voltage (UV)
Under-voltage occurs when
the Module voltage goes
beyond cut-off limit of 11V.
In this event, the buzzer
alarms which can be reset
by fault reset button.
Check for the operating load lower
cut-off limit and ensure it is above
the lower threshold limit of 11V.
The Module becomes operational
when the voltage goes above 11V.
