kinetic T-2400 User manual

MODEL
T-2400 USER MANUAL
RISER RING AND BIKE
NOT INCLUDED WITH
TRAINER
©2015 KINETIC BY KURT ALL RIGHTS RESERVED
REGISTER WARRANTY ONLINE: WWW.KURTKINETIC.COM/WARRANTY
AND RECEIVE A FREE TRAINING VIDEO DOWNLOAD
MAGNETIC

www.kurtkinetic.com
Page 2
When unpacking, check that the
following components are present
IN THE BOX SAFETY WARNING
T-740
Skewer
FLYWHEEL
QUICK RELEASE
LEVER
LOCK RING
NON-DRIVE SIDE
CONE CUP
DRIVE SIDE
CONE CUP
LEG BOLT RESISTANCE UNIT
TRAINER DETAILS
LEFT
TENSIONING
KNOB
RIGHT
TENSIONING
KNOB
ROLLER TENSION KNOB
RESISTANCE UNIT THUMB CONTROLLER
RECOMMENDED SKEWER
AND CONE COMBINATION
FOR YOUR SAFETY
We recommend using the
T-740 Skewer that shipped
with your trainer.

T-2202
Roller Tension Knob
and Washer
T-2201
Cross bar and
screws
T-2203
Spring
T-2204
Mounting Bolt
and Nut
T-740
Skewer
www.kurtkinetic.com
TRAINER PARTS
Page 3
REGISTER YOUR TRAINER:
www.kurtkinetic.com/warranty
If any components listed here are missing, please contact Customer Service at
www.kurtkinetic.com/contact
ROLLER
FLY
WHEEL
YOKE
Because we
test each
trainer there
will be tire
marks on the
roller.
SERIAL
NUMBER
T-699R
Resistance
Unit
T-2210
Frame
T-2111
Standard
Cone Cup
(Installed on trainer)
T-2103
Slotted
Cone Cup
(Installed on trainer)

www.kurtkinetic.com
MOUNTING THE BIKE
First loosen roller tension knob to create space for tire. Next loosen lock
ring and turn left tensioning knob to center bike
Tighten right tensioning knob on quick release side of trainer until
wheel is rmly centered on resistance unit roller
Turn roller tension knob until roller touches tire, then add 2 to 5 full turns
Tighten lock ring when wheel is centered on resistance unit and bike is
rmly locked in at the skewer
1
3
5
Push right tensioning knob tight against skewer, close quick release
and tighten right tensioning knob until tire is centered on roller
2
4
RIGHT
SIDE
QUICK
RELEASE
LEFT
SIDE
Roller tension knob is fully
tightened at factory and
must be loosened before
mounting bike.
GRIP
FRAME
AT SEAT
STAY
TIP: Test tire friction
by sharply moving
tire a 1/4 turn back
and forth. Apply
another 1/2 turn on
roller tension knob
if needed.
ROLLER TENSION KNOB
Page 4
TENSION KNOB
SHIM PADS
SHIM PADS
Attach thumb controller to handlebar. Use included shim pad
6

»Be sure that your bike is correctly installed and securely locked
into the trainer before riding.
»Do not over-tighten the roller tension knob. Over-tightening will
cause both tire and unit damage. Tighten only enough to avoid tire
slippage.
»When using the trainer for normal use or for extended periods of time,
the resistance unit will get hot. DO NOT touch the resistance unit
while it is in use or while it is hot.
»Always consult a doctor before beginning any exercise routine or
using any tness product including the Kinetic Trainer. Should you
become ill, feel dizzy, light-headed or nauseous while riding the
trainer, stop riding immediately and seek medical attention.
»While in use, the wheel of your bike and the resistance unit may be
spinning at high speeds. For this reason keep children, pets and all
items safely away from your trainer while in use.
»Always use the trainer on a at surface.
»Single-speed bikes with nutted axles require an additional standard
cone cup for proper use.
SAFETY WARNINGS
Page 5
www.kurtkinetic.com
1. Remove thumb controller from handlebar
2. Loosen the adjustment knob on the resistance unit to back the
roller away from the tire until it no longer touches.
3. Reduce axle tension by loosening the right axle knob a minimum of
two turns to allow for disengagement of the quick release.
4. Firmly grasp your bike seat stay to stabilize the bike.
5. Disengage the quick release on the right side of the trainer and
slide the axle knob to the fully open position. The bike can now be
removed from the left cone cup.
REMOVING THE BIKE
ACCESSORIES (Available at kurtkinetic.com and Kinetic dealers)
RISER RINGS TRAINER MATS SWEAT GUARDS TRAINER BAGS TRAINER TIRES PRO FLYWHEEL
ADDITIONAL BIKE MOUNTING SOLUTIONS (Ordering & information: kurtkinetic.com)
STANDARD CONE CUP
PART NO: T-2111
SLOTTED CONE CUP
PART NO: T-2103
TRACK CONE CUP
PART NO: T-2104
SHALLOW CONE CUP
PART NO: T-2105
INTERNAL CA CONE CUP
PART NO: T-2106
BMX CONE CUP
PART NO: T-2107
Pre-installed on all Kinetic
trainers and ts most
nutted axles and track
bikes.
Comes in the trainer box
and works with many
non-Kinetic quick release
skewers.
An oversized version of the
Standard Cone Cup for track
axle nuts larger than 15mm.
Designed with a shallow
outside diameter to work on
any frame with a tight drive-
side dropout tolerance.
Works with chain-actuated
internal hubs like Sturmey
Archer. Great for Brompton
bikes.
For oversized 14mm bmx
axles with axle nuts 19mm
and larger.
KINETIC TRAXLE FINE
PART NO: T-2100
For ne-threaded 12mm thru-axle systems
including: Syntace X-12, DT SWISS (Tapered
and Flat) and Specialized
KINETIC TRAXLE FINE XL
PART NO: T-2120
Same thread pitch as Fine Traxle, with wider
width. For Santa Cruz bikes with closed
dropout on the drive side -requires removal
of hex cap in drive side dropout.
KINETIC TRAXLE MEDIUM
PART NO: T-2102
For medium-threaded 12mm thru-axle
systems including: SHIMANO SM-AX75 and
SM-AX65 142mm x 12mm
KINETIC TRAXLE COARSE
PART NO: T-2101
For coarse-threaded 12mm thru-axle
systems including: RockShox Maxle, Trek
APB Maxle and others

WARRANTY
CRASH REPLACEMENT POLICY
CARING FOR YOUR TRAINER
By purchasing the Kinetic Trainer you’ve made an investment in a top-
quality piece of equipment. When used according to the manufacturer’s
instructions and cared for with common sense, your Kinetic trainer will
provide a lifetime of training. Store the trainer indoors, out of the rain
and away from temperature extremes. Since sweat is corrosive, you can
extend the life of your trainer by wiping it o after your workout.
Kinetic trainers come with a lifetime warranty on the frame and the
resistance unit to the original owner.
However, we understand that accidents can happen involving our
products, so we also oer a crash replacement policy for incidents
not covered by our lifetime warranty. Here is how it works: Kinetic will
replace any part or parts on your Kinetic Trainer that are damaged due
to an accident, regardless of the cause of that accident, and within
reason for a $50.00 cost plus the cost of parts and shipping charges.
We reserve the right to reject any product that has been so severely
damaged that it cannot be rebuilt. To be eligible, you must complete the
warranty registration process online. Crash replacement repairs require
warranty information and the serial number of your unit. This crash
replacement policy and its related charge may be subject to change
without notice.
To process a claim, please call our Customer Service Hotline at 877-
226-7824 or email us at [e-mail]. You will be given
instructions for returning the product to us. In some cases replacement
parts may be shipped to you.
Kinetic by Kurt oers the original owner a lifetime warranty against
manufacturing defects for the frame and the resistance unit. This
warranty is not applicable to damage caused by misuse, abuse, neglect,
accident or unauthorized modication of materials or parts. If the unit is
disassembled by the consumer, this warranty is void. There are no other
warranties, expressed or implied.
It is the responsibility of the purchaser to le a warranty card via mail
or on-line with Kinetic in the event that repairs are needed. It is also the
responsibility of the purchaser to retain receipts for proof of purchase in
the event that repairs are needed. No warranty repairs will be accepted
without the warranty registration and the serial number of the trainer
located on the resistance unit.
WARRANTY REGISTRATION
Please complete the warranty within 30 days of purchase at
www.kurtkinetic.com.
WARRANTY CLAIMS/REPLACEMENT PARTS
If you experience problems with your trainer, please call our Customer
Service Hotline at 877-226-7824 or email us at kineticbykurt@kurt.
com. To help us handle your call as eciently as possible, please have
your trainer’s serial number ready to give to the customer service
representative.
After determining what repairs or replacement parts may be needed, you
will be provided with procedures for returning your product to Kinetic.
In some cases replacement parts may be shipped directly to you,
depending on the nature of the problem.
RECORD THE SERIAL NUMBER OF YOUR KINETIC TRAINER HERE
5280 Main Street NE Minneapolis, MN 55421 •1.877.226.7824
