TECHNICAL DATASHEET
Benefits of Microlene's Kinetico Water Softeners
Microlene’s Kinetico water softeners are a hard
working non-electric design offering continuous
supply of soft water using a twin tank system.
NON ELECTRIC
Only Microlene Kinetico uses the kinetic
energy of moving water to power its system
instead of electricity – thanks to the patented
turbine. So you’ll never have to worry about
costly repairs or higher electricity bills.
24/7
Our twin tank design allows our system to
backwash without ever going offline, for round
the clock operation. You’ll never be interrupted
or inconvenienced by regeneration.
METERED REGENERATION
Based on your water hardness, the system
measures water use to accurately determine
when it’s time to regenerate with clock like
precision, resulting in up to 20% less waste water
and up to 40% savings in salt. Your softener
automatically adjusts to your water use patterns.
SOFT WATER RINSE
Uses only soft conditioned water to clean the
media, which extends the life of the system.
COUNTER CURRENT REGENERATION
Unlike most other systems, ours regenerates in
counter-current mode, a more even and efficient
use of resin beads, resulting in less waste water,
less salt use and a longer lasting system.
OPERATING PROFILE
The softener can remove hardness to less than
9 mg/l when operated in accordance with the
operating instructions. The system comprises
two tanks. This duplex configuration operates
with one tank on-line during service.
During regeneration cycles, one tank provides
water to service and to the regenerating
tank. An internal water meter initiates system
regeneration. The water meter measures the
processed volume and can be adjusted based
on water hardness to be treated. Service flow is
down-flow and regeneration flow is up-flow.
Microlene Kinetico
Water Softener
Model Number: MACH2025s
WS
Applications
Ideal for reducing calcium, magnesium, manganese and
iron from water sources to supply soft water to :-
• make cleaning easier
• make clothes and hair softer
• reduce scale in pipes and appliances
With Technology by Kinetico
Softener
Reverse
Osmosis
With Technology by Kinetico

microlene.com.au |microlene.co.nz
This literature is not a complete guide to product usage. All images provided in this document are for illustration purposes only. Further information
is available from your Davey Dealer, Davey Support Centre and from the relevant product Installation and Operating Instructions. Must be read in
conjunction with the relevant product Installation and Operating Instructions and all applicable statutory requirements. Product specifications may
change without notice. ® Davey and Microlene are registered trademarks of Davey Water Products Pty Ltd. © Davey Water Products Pty Ltd 2017.
DWP1116/0717
Microlene Kenetico Softener
REGENERATION CONTROL VALVE
The regeneration control valve is mounted on top of the
media tank, and manufactured from non-corrosive materials.
A control valve provides service and regeneration control
for two media tanks. Inlet and outlet ports accept a quick
connect, double o-ring sealed adapter. Interconnection
between tanks is made through the regeneration valve with
a quick connect adapter. The control valve operates using a
minimum inlet pressure of 1 Bar. Pressure is used to drive all
valve functions. No electric hook-up is required. The control
valve incorporates four operational cycles: service, brine draw,
slow rinse, and a combined fast rinse and brine refill. The
brine cycle is up-flow, opposite the service flow, providing a
counter current regeneration (opposite for MACH2020cHF).
The control valve contains a fixed orifice eductor nozzle
and self-adjusting backwash flow control. The control valve
will prevent the bypass of hard water to service during the
regeneration cycle.
MEDIA TANKS
The tanks are designed for a maximum working pressure of 8.6
Bar and hydrostatically tested at 20.7 Bar. Tanks are made of
engineered plastic with a 63.5mm threaded top opening. The
tanks are NSF approved. The upper distribution system is a
slot design. The lower distribution system is a flat plate design.
Distributors will provide even flow of regeneration water and the
collection of processed water.
CONDITIONING MEDIA
Each softener includes non solvent cation resin having a
minimum exchange capacity of 18 g/l when regenerated with
240.3g/l.
BRINE SYSTEM
The combination salt storage and brine production tank
is manufactured of
corrosion-resistant
plastic. The brine tank
has a chamber to
house the brine valve
assembly. The brine
float assembly allows
for adjustable salt
settings and provides
for a shut-off to the
brine refill. The brine
tank includes a safety
overflow connection
to be plumbed to a
suitable drain.
DISC SELECTION ( Compensated hardness** ) – Disc 4 Fitted
Model Regeneration
setting Hardness capacity Efficiency Dosing
Meter
Disc
1 2 3 4 5 6 7 8
2025s 0.45kg 260g 571g/kg 53g/l 68 137 205
2025s 0.6kg* 304g 536g/kg 70g/l 86 188 274 359 428
Litres processed before regeneration 2,771 1,385 924 693 554 Not recommended
Max continuous flow to storage 44 26 17 13 10 Not recommended
*Certified by NSF and/or WQA
**Compensated hardness in mg/l = (Hardness + 51 x Fe in mg/l)
SPECIFICATIONS
INLET WATER QUALITY
Pressure Range 1.0-8.6 Bar
Temperature Range 2 - 50oC
pH Range 5 – 10 SU
Free Chlorine Cl2 (Max.) 2.0mg/l
Hardness as CaCO3 (Max.) 428mg/l
OPERATING SPECIFICATIONS
Flow Range (1.0 – 2.1 Bar) 30 - 45 lpm
Flow Configuration Alternating
Dimensions (w x d x h) 432 x 210 x 584mm
Operating Weight 55kg
Shipping Weight 36kg
SYSTEM COMPONENTS
Media Vessel Quantity 2
Size 203 x 432mm
Media Vessel Construction Fibreglass Wrapped
Engineered Plastic
Empty Bed Volume 11 litres
Media Type Non Solvent Cation Resin
Media Volume 8.5 litres
Bed Depth 305mm
Free Board 127mm
Riser Tube 25mm ABS
Distributor Upper 0.36mm Slots, ABS Basket
Distributor Lower 0.23mm Slots, Stainless Steel
Flat Plate
Under bedding None
Regeneration Control Non-electric Use Meter
Regeneration Type Counter Current
Meter Type 1.1-94.6 lpm Polypropylene
Turbine
CONNECTIONS
Inlet / Outlet Connections 25mm Custom Adapter and
E-clip
Drain Connection 13mm Tube
Brine Line Connection 10mm Tube
Power None
BRINE TANK OPTIONS
Tank Description (inches) 12 x 40
Brine Tank Part Number 7202
Tank Height 508mm
Tank Footprint 305 x 406mm
Material HDPE
Salt Capacity 22.7kg
REGENERATION SPECIFICATIONS
Regeneration Volume 72 litres
Regeneration Time 29 minutes
Backwash Flow Control 7.6 lpm
Brine Refill Flow Control 1.5 lpm
Dimensions (mm)
432
44.5
584
203
