King Industrial CT-508 User manual

Service Manual / Manuel de Service
20” Planer
Raboteuse 20”
CT-508C
Revised/Revisé 08/2008 Cutterhead Diagram /
Diagramme de la Tête de Coupe

Service Manual / Manuel de Service
20” Planer
Raboteuse 20”
CT-508C
Revised/Revisé 08/2008 Table & Column Diagram /
Diagramme de la Table et Colonne

Service Manual / Manuel de Service
20” Planer
Raboteuse 20”
CT-508C
Revised/Revisé 08/2008 Base & Gear Box Diagram /
Diagramme du Support et Boîtier D’Engrenage

Parts Pricing List / Liste de Prix des Pièces CT-508C
Diag.
1
2
3
3-1
4
4-2
4-3
5
6
7
8
9
9-1
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
Order # Com.
0805080010
0805080020
0805080030
0805080031
0805080040
0805080042
0805080043
KKC-20
0805080060
0805080070
0805080080
0805080090
0805080091
0805080100
0805080110
0805080120
0805080130
0805080140
0805080150
0805080160
0805080170
0805080180
0805080190
0805080200
0805080210
0805080220
0805080230
0805080240
0805080250
0805080260
0805080270
0805080280
0805080290
0805080300
0805080310
0805080320
0805080330
0805080340
0805080350
0805080360
0805080370
0805080380
0805080390
0805080400
0805080410
0805080420
0805080430
English Description
HEAD CASTING
SET SCREW
CUTTER HEAD (4 KNIVES)
CUTTERHEAD (4 KNIVES) ASS'Y
CONE SPRING
STRAIGHT SPRING
KNIFE JACK SCREW
KNIFE SET (4)
KNIFE LOCKING BAR
KNIFE SETTING SCREW
KNIFE GAUGE BAR
KNIFE GAUGE
KNIFE GAUGE ASS'Y
SET SCREW
RETAINING RING "E"
BALL BEARING
CUTTERHEAD KEY
CUTTERHEAD PULLEY (3 BELTS)
SPECIAL WASHER (LARGE)
SET SCREW
MOTOR PULLEY
20" INFEED ROLLER
ROLLER BUSHING
SPRING
ADJUSTING SCREW (HEADLESS)
PLATE
HEX. BOLT
SET SCREW
HEX. NUT
KEY
CHAIN SPROCKET
WASHER
HEX. BOLT
20" OUTFEED ROLLER
DOUBLE SPROCKET -31T
CHIPBREAKER ROD
RETAINING RING/SHAFT
CHIPBREAKER
HEX. NUT
PLATE SPRING
WASHER
HEX. BOLT
PIVOT ROD
CHIPBREAKER BRACKET
PRESSURE PLATE
SPRING WASHER
ADJUSTING SHAFT
Description Française
TETE EN FONTE
VIS SANS TETE
TETE DE COUPE (4 COUTEAUX)
TETE DE COUPE (4 COU.) COMP.
RESSORT CONIQUE
RESSORT DROIT
VIS D'ELEVATION DES COUTEAUX
JEU DE COUTEAUX (4)
BARRE DE RETENUE
BOULON DE VERROUILLAGE
TIGE DU JAUGE A COUTEAUX
JAUGE A COUTEAUX
JAUGE A COUTEAUX COMPLET
VIS SANS TETE
ANNEAU DE RETENU "E"
ROULEMENT A BILLES
CLE DE RETENUE
POULIE DE LA TETE (3 COURROIES)
RONDELLE SPECIALE (LARGE)
VIS SANS TETE
POULIE DU MOTEUR
ROULEAU D'ALIMENTATION
SUPPORT DU ROULEAU
RESSORT
VIS D'AJUSTEMENT (SANS TETE)
PLAQUE DE SOUTIEN
BOULON HEXAGONAL
VIS SANS TETE
ECROU HEXAGONAL
CLE DE RETENUE
ENGRENAGE A PIGNON
RONDELLE
BOULON HEXAGONAL
ROULEAU DE SORTIE 20"
ENGRENAGE DOUBLE -31DENTS
TIGE DU BRISE-COPEAUX
ANNEAU DE RETENU/TIGE
BRISE COPEAUX
ECROU HEXAGONAL
PLAQUE A RESSORT
RONDELLE
BOULON HEXAGONAL
TIGE DE PIVOTEMENT
SUPPORT DU BRISE-COPEAUX
PLAQUE DE PRESSION
RONDELLE A RESSORT
TIGE D'AJUSTEMENT
Price/Prix
$572.70
$2.01
$373.75
$684.25
$2.13
$2.01
$2.13
-
$27.31
$2.70
$11.10
$10.18
$34.44
$1.67
$1.55
$22.94
$2.59
$22.94
$3.16
$1.67
$34.33
$194.35
$12.59
$4.54
$4.54
$3.62
$1.78
$1.67
$1.67
$1.96
$38.93
$1.90
$1.67
$159.85
$67.56
$22.83
$1.55
$103.44
$1.78
$4.43
$1.55
$1.67
$19.26
$14.78
$43.30
$1.67
$5.69
Pricing subject to change without prior notice. / Prix sujet à changement sans préavis.
Qty./Qté.
1
8
1
1
8
8
8
1
4
24
1
2
1
1
4
1
1
1
2
2
1
1
4
4
4
4
8
4
8
2
1
2
5
1
1
1
1
1
2
3
26
20
1
2
1
2
2

Parts Pricing List / Liste de Prix des Pièces CT-508C
Diag.
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
66-1
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
83-2
84
85
86
87
88
Order # Com.
0805080440
0805080450
0805080460
0805080470
0805080480
0805080490
0805080500
0805080510
0805080520
0805080530
0805080540
0805080550
0805080560
0805080570
0805080580
0805080590
0805080600
0805080610
0805080620
0805080630
0805080640
0805080650
0805080660
0805080661
0805080670
0805080680
0805080690
0805080700
0805080710
0805080720
0805080730
0805080740
0805080750
0805080760
0805080770
0805080780
0805080790
0805080800
0805080810
0805080820
0805080830
0805080832
0805080840
0805080850
0805080860
0805080870
0805080880
English Description
SET SCREW
SET SCREW
PLATE SPRING
CHIP DEFLECTOR PLATE
ANTI-KICKBACK FINGER
COLLAR
ANTI-KICKBACK SHAFT
RETAINING RING "E"
CUT LIMITER PLATE
SINKING HD. SCREW
UPPER COVER
FOAM SEAL
DUST COLLECTOR HOOD
ROLLER BRACKET
ROLLER
CAP SCREW
WORM HOUSING
CAP SCREW
WORM GEAR SHAFT
BALL BEARING
RETAINING RING/SHAFT
KEY
HANDWHEEL
HANDWHEEL ASS' Y
WASHER
HANDLE
DEPTH SCALE
HEX. HD. BOLT
CUT LIMIT POINTER
SPRING WASHER
CHAIN GEAR COVER
SPRING PIN
SAFETY HATCH (RIGHT)
HEX. BOLT
SAFETY HATCH (LEFT)
CAP SCREW
BELT GUARD (INSIDE)
SPACER BOLT
WASHER
HEX. NUT
V-BELT (OLD)
V-BELT
BELT COVER
LOCKING KNOB
MOUTING SWITCH PLATE
MAGNETIC SWITCH (220V-15A)
HEX. NUT
Description Française
VIS SANS TETE
VIS SANS TETE
PLAQUE A RESSORT
PLAQUE DE DEFLECTION
DOIGT ANTI-RETOUR
COLLIER
TIGE DES ANTI-RETOURS
ANNEAU DE RETENU "E"
PLAQUE DE LIMITE DE COUPE
VIS FRAISER
COUVERCLE SUPERIEUR
JOINT D'ETANCHEITE EN MOUSSE
COLLECTEUR DE COPEAUX
SUPPORT DU ROULEAU
ROULEAU
BOULON A TETE CYLINDRIQUE
BOITIER D'ENGRENAGE
BOULON ATETE CYLINDRIQUE
TIGE A ENGRENAGE SANS FIN
ROULEMENT A BILLES
ANNEAU DE RETENU/TIGE
CLE DE RETENUE
MANIVELLE D'OP…RATION
MANIVELLE ET POIGNEE ASS.
RONDELLE
POIGNEE DE LA MANIVELLE
ECHELLE DE PROFONDEUR
BOULON A TETE HEXAGONAL
INDICATEUR DE PROFONDEUR
RONDELLE A RESSORT
COUV. DES ENGRENAGES A CHAINE
GOUPILLE A RESSORT
PLAQUE DE SECURITE (DROITE)
BOULON HEXAGONAL
PLAQUE DE SECURITE (GAUCHE)
BOULON A TETE CYLINDRIQUE
PROTECTEUR DES COURROIES
BOULON ESPACEUR
RONDELLE
ECROU HEXAGONAL
COURROIE EN "V" (ANCIENNE)
COURROIE EN "V"
COUVERCLE DES COURROIES
BOUTON DE VERROUILLAGE
PLAQUE DE MONTAGE DE L'INTER.
INTER. MAGNETIQUE 220V-15A
ECROU HEXAGONAL
Price/Prix
$1.61
$1.78
$3.85
$22.94
$4.54
$2.70
$21.68
$2.01
$4.31
$1.78
$61.70
$4.54
$137.83
$15.93
$29.61
$2.24
$68.83
$3.05
$37.55
$11.10
$2.36
$1.78
$61.81
$68.94
$1.90
$12.25
$11.44
$1.55
$3.74
$1.78
$68.60
$1.78
$6.15
$1.67
$6.50
$2.13
$49.16
$4.54
$1.55
$1.55
$14.89
$14.78
$80.33
$4.54
$11.10
$195.33
$1.55
Pricing subject to change without prior notice. / Prix sujet à changement sans préavis.
Qty./Qté.
3
2
1
1
57
58
1
2
1
2
1
1
1
3
2
9
1
3
1
1
1
1
1
1
1
1
1
2
1
3
1
2
1
4
1
1
1
2
2
2
3
3
1
2
1
1
2

Parts Pricing List / Liste de Prix des Pièces CT-508C
Diag.
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
Order # Com.
0805080910
0805080920
0805080930
0805080940
0805080950
0805080960
0805080970
0805080980
0805080990
0805081000
0805081010
0805081020
0805081030
0805081040
0805081050
English Description
CHAIN
RELIEF BUSHING
POWER CORD
TOOTH WASHER
CAP SCREW
SET SCREW
PLATE W/HOLE
COLLAR (SPACER)
TENSION WHEEL SHAFT
TENSION WHEEL
WHEEL BRACKET
THREADED SHAFT
HANGER
SPRING
COLLAR
Description Française
CHAINE
BAGUE DE RETENUE
CORDON D'ALIMENTATION
RONDELLE DENTELEE
BOULON A TETE CYLINDRIQUE
VIS SANS TETE
PLAQUE AVEC TROU
ESPACEUR
TIGE DE LA ROUE A TENSION
ROUE DE TENSION
SUPPORT DE LA ROUE
TIGE VISSEE
CROCHET
RESSORT
COLLET
Price/Prix
$25.70
$2.47
$37.78
$1.67
$1.73
$1.90
$2.24
$3.74
$5.69
$6.15
$5.35
$6.15
$4.20
$2.70
$2.70
Pricing subject to change without prior notice. / Prix sujet à changement sans préavis.
Qty./Qté.
1
2
1
4
14
1
4
1
1
1
1
1
1
1
1
Diag.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Order # Com.
0805082010
0805082020
0805082030
0805082040
0805082050
0805082060
0805082070
0805082080
0805082090
0805082100
0805082110
0805082120
0805082130
0805082140
0805082150
English Description
MIDDLE TABLE
ROLLER
BALL BEARING
ECCENTRIC SHAFT
SET SCREW
THREADED BUSHING
LOCKING BOLT
LOCK BUSHING
LOCKING KNOB
CAP SCREW
ROLLER FRAME
ROLLER
HEX. BOLT
WASHER
RETAINING RING/SHAFT
Description Française
TABLE DU CENTRE
ROULEAU
ROULEMENT A BILLES
TIGE EXCENTRIQUE
VIS SANS TETE
BAGUE FILETEE
TIGE VISSEE DE VERROUILLAGE
BAGUE DE VERROUILLAGE
BOUTON DE VERROUILLAGE
BOULON A TETE CYLINDRIQUE
SUPPORT POUR ROULEAU
ROULEAU
BOULON HEXAGONAL
RONDELLE
ANNEAU DE RETENU/TIGE
Price/Prix
$569.25
$50.43
$11.10
$12.59
$1.61
$5.69
$16.85
$5.35
$9.60
$1.84
$21.45
$39.96
$2.01
$1.55
$1.55
Qty./Qté.
1
2
4
4
4
2
2
2
2
8
4
2
8
4
4
SECTION 200
Diag.
1
2
3
4
5
6
7
8
9
10
Order # Com.
0805083010
0805083020
0805083030
0805083040
0805083050
0805083060
0805083070
0805083080
0805083090
0805083100
English Description
BASE
SET SCREW
COLUMN
HANDWHEEL COLUMN
LEAD SCREW
HANDWHEEL LEAD SCREW
ELEVATING NUT
BUSHING
RETAINING RING/BORE
KEY
Description Française
SOCLE
VIS SANS TETE
COLONNE
COLONNE DE LA MANIVELLE
TIGE D'ELEVATION
TIGE D'ELEVATION POUR MANIVELLE
ECROU POUR ELEVATION
BAGUE
ANNEAU DE RETENU/ALESAGE
CLE DE RETENUE
Price/Prix
$538.20
$2.01
$114.83
$114.83
$52.84
$57.33
$10.75
$9.03
$2.70
$1.78
Qty./Qté.
1
8
3
1
3
1
4
1
1
1
SECTION 300

Parts Pricing List / Liste de Prix des Pièces CT-508C
Diag.
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Order # Com.
0805083110
0805083120
0805083130
0805083140
0805083150
0805083160
0805083170
0805083180
0805083190
0805083200
0805083210
0805083220
0805083230
0805083240
0805083250
0805083260
0805083270
0805083280
0805083290
0805083300
English Description
WORM GEAR
RETAINING RING/SHAFT
BALL BEARING
RETAINING RING/BORE
KEY
CHAIN SPROCKET
WASHER
SPECIAL HEX. NUT
WASHER
HEX. BOLT
SPROCKET BRACKET
SPROCKET SHAFT
CHAIN SPROCKET
RETAINING RING/SHAFT
CHAIN
LIFTING BAR
RETAINING RING/SHAFT
PROTECTOR RING
PAN HD. SCREW
COLUMN PROTECTOR
Description Française
ENGRENAGE SANS FIN
ANNEAU DE RETENU/TIGE
ROULEMENT A BILLES
ANNEAU DE RETENU/ALESAGE
CLE DE RETENUE
ENGRENAGE A PIGNON
RONDELLE
ECROU HEXAGONAL SPECIAL
RONDELLE
BOULON HEXAGONAL
SUPPORT DE L'ENGRENAGE
TIGE D'ENGRENAGE A PIGNON
ENGRENAGE A PIGNON
ANNEAU DE RETENU/TIGE
CHAINE
BARRE DE SOULEVEMENT
ANNEAU DE RETENU/TIGE
ANNEAU POUR PROTECTEUR
VIS A TETE BOMBEE
PROTECTEUR DE COLONNE
Price/Prix
$29.73
$1.55
$11.44
$2.47
$1.78
$25.24
$1.67
$2.59
$2.13
$1.84
$6.84
$11.33
$25.24
$1.55
$52.73
$14.55
$2.24
$5.69
$1.67
$11.33
Pricing subject to change without prior notice. / Prix sujet à changement sans préavis.
Qty./Qté.
1
1
4
4
4
4
4
4
2
2
1
1
1
1
1
4
4
16
32
8
SECTION 300 CONT.
Diag.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14-2
15
16
17
18
19
20
21
Order # Com.
0805084010
0805084020
0805084030
0805084040
0805084050
0805084060
0805084070
0805084080
0805084090
0805084100
0805084110
0805084120
0805084130
0805084140
0805084142
0805084150
0805084160
0805084170
0805084180
0805084190
0805084200
0805084210
English Description
CABINET STAND
VENT COVER
SINKING HD. SCREW
CONNECTING ROD
MOTOR MOUNT PLATE
SET SCREW
COLLAR
ADJUST BOLT
HEX. NUT
WASHER
HEX. BOLT
WASHER
HEX. NUT
MOTOR -3 HP
STARTING CAPACITOR
KEY
HEX. BOLT
POWER SUPPLY WIRE
RELIEF BUSHING
WASHER
HEX. BOLT
MOTOR CORD
Description Française
SUPPORT CABINET
COUVERCLE D'AERATION
VIS A TETE FRAISER
TIGE DE PIVOTEMENT
PLAQUE SUPPORT DU MOTEUR
VIS SANS TETE
COLLET
BOULON D'AJUSTEMENT
ECROU HEXAGONAL
RONDELLE
BOULON HEXAGONAL
RONDELLE
ECROU HEXAGONAL
MOTEUR 3 CV
CONDENSATEUR DE DEMARRAGE
CLE DE RETENUE
BOULON HEXAGONAL
CABLE ELECTRIQUE
BAGUE DE RETENUE
RONDELLE
BOULON HEXAGONAL
CORDON DU MOTEUR
Price/Prix
$373.75
$63.25
$1.78
$16.04
$28.69
$1.90
$3.74
$11.90
$1.78
$1.90
$1.96
$1.90
$1.61
$562.35
$29.84
$2.13
$2.82
$29.50
$2.70
$1.61
$2.24
$21.79
Qty./Qté.
1
2
8
2
1
4
1
2
8
4
4
4
4
1
1
1
4
1
1
4
2
1
SECTION 400

Parts Pricing List / Liste de Prix des Pièces CT-508C
Diag.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
17-1
20
21
22
23
24
25
27
28
29
30
31
32
33
34
35
36
37
38
39
40
61
62
63
64
65
66
67
555-5
Order # Com.
0805085010
0805085020
0805085030
0805085040
0805085050
0805085060
0805085070
0805085080
0805085090
0805085100
0805085110
0805085120
0805085130
0805085140
0805085171
0805085200
0805085210
0805085220
0805085230
0805085240
0805085250
0805085270
0805085280
0805085290
0805085300
0805085310
0805085320
0805085330
0805085340
0805085350
0805085360
0805085370
0805085380
0805085390
0805085400
0805085610
0805085620
0805085630
0805085640
0805085650
0805085660
0805085670
0805085555
080508MENG
080508MFRE
English Description
GEAR BOX HOUSING
OIL SEAL
BALL BEARING
HELICAL GEAR
CAP SCREW
WASHER
CAP SCREW
BALL BEARING
GEAR
GEAR SHAFT
KEY
GEAR
KEY
DOUBLE GEARED SHAFT
DOUBLE GEAR ASS'Y
KEY
STEEL BALL
SPRING
SHAFT FOR GEAR
OIL SEAL
CHAIN SPROCKET (12 TEETH)
CHAIN
HEX. BOLT
CLUTCH FORK
CLUTCH SHAFT
WASHER
HEX. BOLT
OIL RING
SPEED SHAFT KNOB
SPRING PIN
GASKET
GEAR BOX COVER
CAP SCREW
OIL PLUG
CAP SCREW
OPEN END WRENCH 8-10MM
OPEN END WRENCH 12-14MM
OPEN END WRENCH 17-19MM
ALLEN KEY (M3)
ALLEN KEY (M4)
ALLEN KEY (M5)
ALLEN KEY (M6)
COMPLETE HARDWARE BAG
ENGLISH MANUAL CT-508
FRENCH MANUAL CT-508
Description Française
BOITIER DE LA BOITE A ENGRENAGE
ANNEAU D'ETANCHEITE
ROULEMENT A BILLES
ENGRENAGE HELICOIDAL
BOULON A TETE CYLINDRIQUE
RONDELLE
BOULON A TETE CYLINDRIQUE
ROULEMENT A BILLES
ENGRENAGE
TIGE D'ENGRENAGE
CLE DE RETENUE
ENGRENAGE
CLE DE RETENUE
TIGE D'ENGRENAGE
ENGRENAGE DOUBLE ASSEMBLE
CLE DE RETENUE
BILLE EN ACIER
RESSORT
TIGE POUR ENGRENAGE
JOINT D'ETANCHEITE
ENGRENAGE A PIGNON (12 DENTS)
CHAINE
BOULON HEXAGONAL
FOURCHETTE D'EMBRAYAGE
TIGE D'EMBRAYAGE
RONDELLE
BOULON HEXAGONAL
ANNEAU D'ETANCHEITE
BOUTON DE LA TIGE DES VITESSES
GOUPILLE ARESSORT
JOINT D'ETANCHEITE DU BOITIER
COUV.DE LA BOITE A ENGRENAGE
BOULON ATETE CYLINDRIQUE
BOUCHON AL'HUILE
BOULON ATETE CYLINDRIQUE
CLE OUVERTE 8-10MM
CLE OUVERT12-14MM
CLE OUVERTE 17-19MM
CLE HEXAGONALE (M3)
CLE HEXAGONALE (M4)
CLE HEXAGONALE (M5)
CLE HEXAGONALE (M6)
SAC DE QUINCAILLERIE COMPLET
MANUEL ANGLAIS CT-508
MANUEL FRANCAIS CT-508
Price/Prix
$96.43
$20.64
$22.94
$21.56
$2.70
$2.13
$2.47
$11.10
$33.75
$20.30
$1.84
$34.33
$1.78
$27.43
$103.39
$2.24
$2.01
$2.70
$34.44
$16.04
$17.08
$17.19
$1.67
$15.93
$14.55
$1.55
$1.67
$2.01
$3.39
$2.01
$10.06
$67.68
$2.70
$3.39
$2.47
$4.43
$4.54
$4.89
$2.59
$2.70
$2.82
$2.59
$52.73
$15.00
$15.00
Pricing subject to change without prior notice. / Prix sujet à changement sans préavis.
Qty./Qté.
1
1
2
1
1
2
1
5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
5
2
4
1
1
1
1
1
1
1
1
1
1
SECTION 500
