Kingpan KP700SDR User manual

E Battery Charger Manual
Max Output Power 576W/1152W/2304W
Suitable for E Batteries
Please read this manual carefully before use.
适用于E系列电池
最大输出功率576W/1152W/2304W
E系列电池充电器使用说明书
Shut off point（关断点）
Time（时间）
Voltage（电压）
Current（电流）
Lithium battery charging curve
锂电池充电曲线
Declaration of Conformity
Object of the declaration:
Product Name: E Battery Charger
Model: KP700SDR, KP2000DR, KP3000DR
Company Name:
Guangdong ePropulsion Technology
Limited
Address:
Room 201, Bldg.17A, 4th XinZhu Road,
SongShan Lake District, Dongguan City,
Guangdong Province, China
The object of the declaration is in conformity
with the following directives:
EMC Directive 2014/30/EU
LVD Directive 2014/35/EU
Applied Standards:
EN 55014-1:2006/A2:2011
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 60335-1:2012/A11:2014
EN 60335-2-29:2010
EN 62233:2008
The original certificate was issued by
HTS INSPECTION & CERTIFICATION UK
LIMITED
Signature:
Product Name
产品名称
Model
机型
Max Output Power
最大输出功率
Max Output Voltage
最大输出电压
Output Current
输出电流
Input Voltage
输入电压
Dimensions
外壳尺寸
E Battery
Charger
10A L
E Battery
Charger
10A H
E Battery
Charger
20A L
E Battery
Charger
20A H
E Battery
Charger
40A L
E Battery
Charger
40A H
KP700SDR
576W
57.6V
10A
90～132
VAC
220*120*90mm
KP2000DR
1152W
57.6V
20A
235*175*110mm
KP3000DR
2304W
57.6V
40A
265*175*110mm
185～255
VAC
90～132
VAC
185～255
VAC
90～132
VAC
185～255
VAC

一、本机特性：
1.本充电器散热风扇采用智能化控制，机内温度达到40℃风扇将自动启动，机内温度低于40℃风
扇将自动关闭。
2.本电池充电器具有反接保护、过流保护、过压保护、短路保护功能。
3.本电池充电器具有过热保护功能，机内温度达到75℃（异常状态）整机自动关闭。夏天，在临界
状态下，会反复出现暂停数分钟、再恢复工作数分钟的情况，这会延长充电时间，此时，可采取
外部辅助散热措施。
4.KP700SDR的防水等级为IP54，KP2000DR和KP3000DR的防水等级为IP65。
二、安装使用方法：
1.本充电器适配的是E系列电池。
2.检查当地交流电压是否和充电器输入电压一致。然后将充电器插入壁式插座。电源指示灯
LED1亮红灯，说明电源连接正常。
3.不接负载或电池充满，则LED2亮绿灯。已接负载并在充电状态中，则LED2亮红灯。
备注：本系列充电器采用继电器作输出保护，重接负载必须间隔1分钟，否则会使保护失效。
三、注意事项：
1.请勿将机器置于热源或太阳直射的地方存放、使用。
2.请将机器置于通风、干燥、无尘埃的地方存放、充电。
3.请勿遮挡进出封口，进风侧与墙体之间、出风侧与墙体之间至少留有10cm空间。
4.请勿覆盖充电器，避免小孩触摸充电器。
5.为保护安全，如果电源插头无接地针，则使用时充电器外壳必须用大于2.5mm²导线可靠接
地。
6.如果发现充电器不工作，请检查电池与充电器是否已正确连接；电压是否符合充电要求；充电
器是否已进入过热过流保护状态。逐一排查后，断电数秒，再重新连接电源。如仍未解决，请与
厂家联系。
7.如出现以上第6点之外的其他故障，请及时与厂家联系。
8.请勿自行打开充电器，否则保修将失效。
五、保修：
逸动科技（ePropulsion）E系列电池充电器的保修期限为自购买日起2年。保修期间产品购买者
可享受保修范围内的免费保修服务。
四、装箱清单：
充电器1台 使用说明书1份
E. Warranty:
ePropulsion E Battery Charger is guaranteed against any manufacturing defects for TWO
years from date of purchase.
A. Features:
1. E battery chargers have an intelligent heat dissipation system, the fans only operate
when the intra-housing temperature is above 40°C.
2. This charger is configured with reverse polarity, over current, over voltage, and short
circuit protections.
3. This charger has over-temperature protection, which shuts down the charger when the
internal temperature is above 75°C. In extreme heat conditions of equatorial countries,
the charger could enter into a perpetual cycle of suspension (several minutes) and
restart. In such cases, it is necessary to take additional measures to reduce environment
heat if delay in charge completion is to be avoided.
4. KP700SDR is IP54 waterproof, KP2000DR and KP3000DR are IP65 waterproof.
B. Operations:
1. This charger is suitable for the E batteries.
2. Confirm the charger's AC input voltage level conforms to the local main/grid/AC voltage
level. Then connect the charger system to a wall socket strongly. When the LED1 is red, it
means the power is on.
3. LED2 remains red until the battery is fully charged, at which point LED2 turns green. A
green LED2 indicates either the battery is fully charged or no battery is connected.
Note: This charger uses relay for output protection. Reconnecting the load must wait for
one minute, otherwise protection failure will occur.
C. Notices:
1. Do not store and use under direct heat/radiation or near the source of heat/radiation.
2. Use in damp, dusty, or non-ventilated environment could cause damage to the charger
and battery.
3. Do not cover the wind/cooling channels. Keep a minimum of 10cm between any
obstructions and the wind channels (or front and back panels where the wind inlet and
outlets are located).
4. Do not cover the charger. Keep the charger away from the reach of children.
5. If a two pins AC plug is used, the charger housing must grounded with an earthing wire
of 2.5mm² or greater.
6. Should the charger not work proper, please follow this check list:
*is the battery and charger corrected connected?
*is the voltage level appropriate?
*Has the charger entered into over-temperature or over-current protection?
After troubleshooting and fixing the problem, disconnect power for a few seconds, then
reconnect to mains. If the charger still does not work properly, contact manufacturer
immediately.
7. For any faults beyond the Sixth aforementioned, please contact the manufacturer for
technical support.
8.Opening the housing of the charger without prior written consent from the manufacturer
voids the manufacturer's warranty immediately.
D. Packing List:
Charger x 1 User Manual x 1
