KingsBottle KBU-328 SERIES User manual
www.kingsbottle.com! 2
CONGRATULATIONS#
Congratulations and thank you for choosing
our KingsBottle beverage coolers . We are
sure you will find your new appliance a
pleasure to use . Before installing and
operating the beverage cooler, we
recommend that you read through this
manual which provides a description of your
beverage cooler and its functions .#
To avoid the risks that are always present
when you use an electric appliance, it is
important that the appliance is installed
correctly and that you read the safety
instructions carefully to avoid misuse and
hazards .#
We recommend that you keep this
instruction booklet for future reference and
pass it on to any future owners .#
After unpacking the appliance, please
inspect it to verify it is not damaged. If in
doubt, do not use the appliance but contact
us or your local customer care centre#
CONTENTS
TABLE OF CONTENTS
CHAPTER
CONTENTS
PAGE
Part I
Important Safety & Pre-Use Instructions
3
Part II
Diagram & Description of Beverage Cooler
4
Part III
Installation Instructions!
5-6
Part IV
Operating Your Beverage Cooler
7-8
Part V
Layout & Storage
9
Part VI
Care and Maintenance
10
Part VII
Troubleshooting Guide
11
Part VIII
Technical Data
12
Part IX
Warranty Information
12
COMPRESSOR BEVERAGE COOLER
www.kingsbottle.com! 3
PART I IMPORTANT SAFETY INSTRUCTIONS
Please read this user manual carefully and store in a handy
place for later reference . The symbols you will see in this
booklet have these meanings:#
This symbol indicates information concerning your personal safety
This symbol indicates information on how to avoid damaging the
appliance
This symbol indicates tips and information about use of the
appliance
This symbol indicates tips and information about economical and
ecological use of the appliance
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK,
OR INJURY WHEN USING YOUR APPLIANCE, FOLLOW
THESE BASIC PRECAUTIONS:
1. Read all instructions before using the beverage cooler.
2. DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not only problems of the
past. Junked or abandoned appliances are still dangerous…
even if they will “just sit in the garage for a few days”.
3. Before you throw away your old beverage cooler:
•Take off the door.
•Leave the Shelves in pieces so that children may not
climb inside easily.
4. Never allow children to operate, play with, or crawl inside
the appliance.
1. The beverage cooler must be plugged into its own
dedicated 110-115V, 50/60Hz AC electrical outlet .
2. The plug must be accessible when the cooler is in
position.
3. It is essential the power point is properly grounded .
Consult a qualified electrician if you are unsure .
4. Don’t use extension cords or adapter plugs with this
cooler .
5. If the power cord is damaged, have it replaced by a
qualified service technician .
6. Unplug the cooler before cleaning it, or changing the light
bulb to avoid electric shock .
7. Never clean appliance parts with flammable fluids. The
fumes can create a fire hazard or explosion.
8. Never unplug the cooler by pulling the electrical cord as
this may damage it. Grip the plug firmly and pull straight
out .
9. Choose a location for your cooler that isn’t too cold . The
ambient room temperature should be above 50°F .
10. Stand your cooler in a dry place – avoid areas of high
moisture or humidity .
11. Don’t put the cooler in frosty or unprotected areas like a
garage or on the verandah .
12. Keep the cooler out of direct sunlight .
13. Don’t locate the cooler near stoves, fires or heaters .
14. Do not store in the vicinity of any other appliance. Do not
store near gasoline or any other flammable vapors. The
fumes can create a fire hazard or explosion.
15. When installed correctly, your cooler should:
•Have adequate space at the back and sides for air
circulation. (See Page 5)
•Be aligned to the surrounding cupboards .
•Have doors that will self-close from a partially open
position
16. Please inspect and clean the filter in front venting grill
every month. Failure to clean will void the warranty and
increase the running costs.
BEFORE USING YOUR BEVERAGE COOLER
1. Remove the exterior and interior packing.
2. Before connecting the beverage cooler to the power
source, let it stand upright for approximately 24 hours.
This will reduce the possibility of a malfunction in the
cooling system from handling during transportation.
3. Clean the interior surface with lukewarm water using a
soft cloth.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
SAFETY
!
www.kingsbottle.com! 4
PART II"" DIAGRAM & DESCRIPTION OF BEVERAGE COOLER
FEATURES
MODEL:
KBU55M
MODEL:
KBU56M
MODEL:
KBU328M
INDOOR & OUTDOOR OPTIONS:
Condenser Fan (C-FAN): Set it to L ( LOW fan speed) for INDOOR use; H (HIGH san speed) for OUTDOOR use.
HEATED GLASS FUNCTION: Set LOW-E to L (Low), H (High) or OFF according to the humidity and condensation on the glass."
Electrically glass doors are coated with a transparent conductive film on the glass. With the power on, the glass heats to prevent the"formation of
water droplets on the outer surface. The heated function starts and stops"when the compressor operates.
Control Panel and Temperature Settings
Door
Handle
Cabinet
Front Ventilation Base
4-Adjustable Feet
2-Shelf
Housing
Condensation Fan 2 Modes: L/H
Heated Glass Manual Control
3 Modes: L/OFF/H
Condenser Fan 2 Modes: L / H
Control Panel and Temperature Settings
Cabinet
Shelf
4-Adjustable Feet
Front Ventilation Base
Handle
Door
Housing
Condensation Fan 2 Modes: L/H Heated Glass Manual Control
3 Modes: L/OFF/H
Condenser Fan 2 Modes: L / H
Control Panel and Temperature Settings
Front Ventilation Base
Cabinet
2-Small shelf
Door
6-Adjustable Feet
Handle
Housing
2-Big shelf
Condensation Fan 2 Modes: L/H
Heated Glass Manual Control
3 Modes: L/OFF/H
Condenser Fan 2 Modes: L / H
www.kingsbottle.com! 5
PART III"INSTALLATION INSTRUCTIONS
INSTALLATION
Installing Unit Into Under Counter
✦The unit is designed to be fully built Into
cabinets.
✦If the unit is on hardwood floor, we recommend
a rubber mat under the unit and some
polystyrene or sound proofing material on rear
wall of the opening to help deaden the noise.
✦Leave at least a 0.40-0.6” (10-15 mm) shadow
line around the unit and 2” (50mm) minimum at
rear to allow for the door swings and electrical
plug.
✦Place the unit out of sunlight, direct weather and
away from heating appliances.
✦Make sure that installation allows for the unit to
be removed, if required, as the condenser will
need periodic cleaning and to allow for servicing
if necessary.
4
2-IMPORTANT SAFETY INSTRUCTIONS
WARNING To reduce the risk of fire, electrical shock, or injury when
using your appliance, follow these basic precautions:
Read all instructions before using the bar fridge
Do not attempt to touch any working or electrical parts during operation, apart from main control panel.
Never allow children to operate, play with, or crawl inside the appliance.
Never clean appliance parts with flammable fluids.
Don’t clean S/Steel parts with any citrus style cleaners, special SS cleaner or hot water is best
Do not store or use gasoline or any other flammable vapors in the vicinity or any other appliance. The fumes
can create a fire hazard or explosion.
-Save these instructions-
3-INSTALLATION INSTRUCTIONS
Installation diagram for the built-in models
Installing unit into cavity
*Unit is designed to be Fully Built Into cavity, no ventilation
is required.
*If units on hardwood floor we recommend a rubber mat
under unit and some polystyrene or sound proofing material
on rear cavity wall to help a little deaden noise.
*Leave at least a 10-15mm ‘shadow line’ around unit and
50mm at rear minimum to allow for door swings and
electrical plug.
*Just use common sense, place out of sunlight, direct
weather and away from heating appliances.
*Make sure that installation allows for unit to be removed if
required, as condenser will need periodic cleaning and also
to allow for servicing in the event of break down.
4
2-IMPORTANT SAFETY INSTRUCTIONS
WARNING To reduce the risk of fire, electrical shock, or injury when
using your appliance, follow these basic precautions:
Read all instructions before using the bar fridge
Do not attempt to touch any working or electrical parts during operation, apart from main control panel.
Never allow children to operate, play with, or crawl inside the appliance.
Never clean appliance parts with flammable fluids.
Don’t clean S/Steel parts with any citrus style cleaners, special SS cleaner or hot water is best
Do not store or use gasoline or any other flammable vapors in the vicinity or any other appliance. The fumes
can create a fire hazard or explosion.
-Save these instructions-
3-INSTALLATION INSTRUCTIONS
Installation diagram for the built-in models
Installing unit into cavity
*Unit is designed to be Fully Built Into cavity, no ventilation
is required.
*If units on hardwood floor we recommend a rubber mat
under unit and some polystyrene or sound proofing material
on rear cavity wall to help a little deaden noise.
*Leave at least a 10-15mm ‘shadow line’ around unit and
50mm at rear minimum to allow for door swings and
electrical plug.
*Just use common sense, place out of sunlight, direct
weather and away from heating appliances.
*Make sure that installation allows for unit to be removed if
required, as condenser will need periodic cleaning and also
to allow for servicing in the event of break down.
24.43”
33.13”
22.26”
23.44”
21.47”
32.31”
36.05”
34.08”
22.06”
35.46”
21.47”
33.88”
4
2-IMPORTANT SAFETY INSTRUCTIONS
WARNING To reduce the risk of fire, electrical shock, or injury when
using your appliance, follow these basic precautions:
Read all instructions before using the bar fridge
Do not attempt to touch any working or electrical parts during operation, apart from main control panel.
Never allow children to operate, play with, or crawl inside the appliance.
Never clean appliance parts with flammable fluids.
Don’t clean S/Steel parts with any citrus style cleaners, special SS cleaner or hot water is best
Do not store or use gasoline or any other flammable vapors in the vicinity or any other appliance. The fumes
can create a fire hazard or explosion.
-Save these instructions-
3-INSTALLATION INSTRUCTIONS
Installation diagram for the built-in models
Installing unit into cavity
*Unit is designed to be Fully Built Into cavity, no ventilation
is required.
*If units on hardwood floor we recommend a rubber mat
under unit and some polystyrene or sound proofing material
on rear cavity wall to help a little deaden noise.
*Leave at least a 10-15mm ‘shadow line’ around unit and
50mm at rear minimum to allow for door swings and
electrical plug.
*Just use common sense, place out of sunlight, direct
weather and away from heating appliances.
*Make sure that installation allows for unit to be removed if
required, as condenser will need periodic cleaning and also
to allow for servicing in the event of break down.
34.08”
22.06”
53.19”
52.60”
21.47”
33.88”
KBU55
KBU56
KBU328
This manual suits for next models
5
Other KingsBottle Kitchen Appliance manuals
KingsBottle
KingsBottle KBU-55 SERIES User manual
KingsBottle
KingsBottle KBU165BW User manual
KingsBottle
KingsBottle KBU-52 Series User manual
KingsBottle
KingsBottle KBU145BX User manual
KingsBottle
KingsBottle KBU50DX-FG User manual
KingsBottle
KingsBottle KBU145DX User manual
KingsBottle
KingsBottle KB50WX-FG User manual
KingsBottle
KingsBottle KBUSF66BW User manual
KingsBottle
KingsBottle KBU28LRX User manual
KingsBottle
KingsBottle KBUSF50B User manual
