Kingsman Fireplaces VRB46 User manual

Installation Instructions
Model Number VRB46
Zero Clearance Vented Gas Fireplace Heater
Stock #’s: VRB46N, VRB46NE, VRB46LP, VRB46LPE
Conforms to: ANSI Z21.88-2016 • CSA 2.33-2016
VENTED GAS FIREPLACE HEATER
Printed in Canada September 6, 2017 Part # 46VRB-MAN16
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, Manitoba, Canada R2R 2V3
Ph: [phone]
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
This Appliance Is Only Approved With
Kingsman Flex Vent System, Except When
Using The Power Venting Option.
This appliance may be installed in an
aftermarket permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.

VRB46 Table of Contents
Table of Contents……………………………………………………………..........................................
2-3
Pre-installation Questions and Answers…………………………………...........................................
4
Operating Instructions………………………………………………………..........................................
4
Warnings, Installations, and Operations…………………………………...........................................
5-6
Mobile Home/Manufactured Housing Installation……………………...............................................
7
INSTALLATION
Framing Your Gas Fireplace............................................................................................................
8
Nailing Tab Guide............................................................................................................................
9
VRB46 -Facing Requirements- ALL UNITS- Chase Not Vented or Vented Chase.........................
10
Facing Kit for VRB46- Z46PRO4.....................................................................................................
11
Locating your Appliance..................................................................................................................
12
Fireplace Dimensions......................................................................................................................
12
Unvented Chase VS Vented Chase- Choose Your Installation.......................................................
13
INSTALLATION - CHASE NOT VENTED
Framing Dimensions -Chase Not Vented- Ventilation Plates In Place -As Shipped........................
14
Mantel Clearances –Chase Not Vented- Ventilation Plates In Place –As Shipped.........................
15
Clearance to Combustibles –Chase Not Vented-Ventilation Plates in Place -As Shipped..............
16
INSTALLATION – VENTED CHASE
Vented Chase –Removal of Ventilation Plates- See Framing for Vented Chase............................
17
Vented Chase – Style 1 – Opening With No Grill............................................................................
18-19
Vented Chase – Style 2 – Opening With Grill..................................................................................
20-21
Vented Chase -Style 2 – Opening With Grill - Kingsman V46EG....................................................
22
V46EG Grill Installation....................................................................................................................
23
Framing Dimensions –Vented Chase -Ventilation Plates Removed................................................
24
Mantel Clearances –Vented Chase -Ventilation Plates Removed...................................................
25
Clearance to Combustibles –Vented Chase -Ventilation Plates Removed.....................................
26
COMPONENTS AND ACCESSORIES
Surround Dimensions......................................................................................................................
27
Surround Clearances.......................................................................................................................
27
Surround Installation........................................................................................................................
28
UHS Box..........................................................................................................................................
29
Component Locations......................................................................................................................
29
Fan Kit Installation...........................................................................................................................
30
Split Receptacle- Fan Speed Control Outside of Fireplace.............................................................
31
Door and Glass Information.............................................................................................................
32
Valve Access Cover Removal.........................................................................................................
33
Removable Lower Face Panel.........................................................................................................
33
Porcelain Liner Installation Guide………………………………………………………………………...
34
Child Safety Screen.........................................................................................................................
35
GAS LINE AND MAINTENANCE
Gas Line Installation……………………………………………………………………………………….
36
Millivolt System, Lighting, & Burner Control.....................................................................................
37
Trouble Shooting The Gas Control System.....................................................................................
38
Burner System Maintenance...........................................................................................................
39
Gas Conversion Part A....................................................................................................................
40
Gas Conversion Kit For Top Convertible Pilot PART B...................................................................
41
2

Gas Conversion for Modulator – PART C........................................................................................
42
Burner Tube Removal......................................................................................................................
43
Burner System Removal/Installation Guide.....................................................................................
43
LOGS AND MEDIA
ULK2 Universal Light Kit (Optional Accent Lighting Kit)..................................................................
44-45
RBCB1 -Cannonballs- Installation Instructions................................................................................
46
MQ Dealer Accessories for VRB46.................................................................................................
47-48
MQRBD3 5 Piece Driftwood Log Set…………………………………………………………………….
49
IPI ELECTRONIC IGNITION SYSTEM
IPI Electronic Ignition System..........................................................................................................
50
Remote Control Operation...............................................................................................................
51
IPI Electronic Ignition Parts List – Standard System.......................................................................
52
Configuration #1: Basic System......................................................................................................
53
Configuration #2: Remote On/Off....................................................................................................
54
EGTM / GTM System -No Batteries................................................................................................
55
Configuration #3: Remote ON/OFF, variable HI/LO, and fan..........................................................
56
IPI Lighting Instructions...................................................................................................................
57
VENTING SECTION
Vent Termination.............................................................................................................................
58
General Vent Installation Information..............................................................................................
59
Installation Of Side Wall Venting.....................................................................................................
59
Venting Table..................................................................................................................................
60
Horizontal Snorkel Terminations......................................................................................................
61
Vertical Venting................................................................................................................................
62-63
Glass Safety / Termination Cap Safety -All Units-...........................................................................
64
Approved for Power Vent PVH58………………………………………………………………………...
65
PARTS LISTS
PVH58 Parts List.............................................................................................................................
66
VRB46 Parts List.............................................................................................................................
67-68
WARRANTY
Limited Lifetime Warranty................................................................................................................
69
3

Pre-installation Questions and Answers
About curing of the paint
Your stove or fireplace has been painted with the highest quality silicone stove paint. This paint dries quickly in 15-20
minutes when first applied at the factory. However, due to the high temperature silicone components, the paint will cure
when heat is applied to the appliance as it is first used. The following information applies to the curing process to get the
paint fully hard and durable.
Fire the appliance four successive times for 10 minutes each firing and a 5 minute cool down between each. Be aware
during log and firebox paint curing that a white deposit may be developing on the inside of the glass doors. It is important
to remove this white deposit from the glass doors using a fireplace glass cleaner.
Babies, small children, pregnant women and pets should leave the area during the cure phase.
Ventilate well, open doors and windows.
Do not touch during curing.
Why does my fireplace or stove give off odour?
It is normal for your fireplace to give off some odor at first. This is due to the curing of the paint, adhesives, silicones and
any undetected oil from the manufacturing process as well as the finishing materials used with the installations (e.g.
marble, tile and the adhesives used to adhere this product to the walls can react with heat and cause odours).
It is recommended that you burn your gas fireplace or stove for a minimum of four hours at a time with the fan off (if a fan
is present) after the curing of the paint has been completed. These odours can last upward to 40 hours of burn time; keep
burning at a minimum of four hours per use until odours dissipate.
Noise coming from the fireplace?
Noise is caused by the expansion and contraction of metal as the appliance heats up and cools down. This is normal and
is similar to the sounds produced by a furnace or heating duct. This noise does not affect the operation or longevity of
your fireplace.
It is also normal for the fan to make some noise when it comes on. This noise can be reduced somewhat by turning down
the speed of the fan with the variable speed control. Be aware, however, that this will reduce the volume of heated air
circulated into the room by the fan.
Note to the Installer:
Be sure appliance is working properly and its operation (including remote control operation, if included) is fully explained
to and understood by the customer.
Operating Instructions
1. Be sure to read and understand all the instructions in this manual before operation of appliance.
2. Ensure all wiring is correct and properly enclosed to prevent possible shock.
3. Check for gas leaks.
4. Make sure the glass door is properly installed before operation. Never operate the appliance with the glass door
removed.
5. Make sure venting and termination cap are installed and unobstructed.
6. If brick or porcelain liners are used, ensure they are installed.
7. Verify that the pilot can be seen when lighting the appliance. If not, the log or rock placement is incorrect.
8. If the unit is turned off, you must wait a minimum of 60 seconds before re-lighting it.
4

Warnings, Installations and Operations
Installation Regulations
This gas appliance must be installed by a qualified installer in accordance with local building codes, or in the absence of local codes, with the current
CAN/CSA-B149.1 or .2 Installation Code (in Canada) or the current National Fuel Gas Code Z223.1- NFPA 54 when installed in the United States.
This appliance, when installed, must be electrically connected and grounded in accordance with local codes, or in the absence of local codes, with the
current CSA C22.1 Canadian Electrical Code or with the National Electrical Code; ANSI/NFPA 70 when installed in the United States.
In the U.S.A. Thermostats are not permitted for Vented Gas Fireplaces (ANSI Z21.50b-Decorative).
WARNING
FOR SAFE INSTALLATION AND OPERATION OF YOUR GAS FIREPLACE PLEASE NOTE THE FOLLOWING:
1. Do not clean when the glass is hot.
2. Do not use abrasive cleaners.
3. Using a substitute glass will void all product warranties.
4. For safe operation, glass doors must be closed.
5. When purging the gas line, the glass front must be removed.
6. Do not strike or abuse glass. Take care to avoid breakage.
7. Do not alter gas orifice.
8. No substitute materials may be used other than factory
supplied components.
9. This appliance gives off high temperatures and should be
located out of heavy traffic areas and away from furniture and
draperies.
10. Children and adults should be alerted to the hazards of the high
surface temperatures of this appliance and should stay away to avoid burns or ignition of clothing.
11. Young children should be carefully supervised when they are in the same room as the appliance. Toddlers, young children
and others may be susceptible to accidental contact burns. A physical barrier is recommended if there are at risk individuals
in the house. To restrict access to a fireplace or stove, install an adjustable safety gate to keep toddlers, young children and
other at risk individuals out of the room and away from hot surfaces.
12. Under no circumstances should any solid fuels (wood, paper) be used in this appliance.
13. Under no circumstances should this appliance be modified. Any parts that have to be removed for servicing should be
replaced prior to operating this appliance.
14. Any safety screen, guard, or barrier removed for servicing an appliance must be replaced prior to operating the appliance.
15. Installation and repair should be done by a qualified service person. The appliance should be inspected before use and at
least annually by a professional service person. More frequent cleaning may be required due to excessive lint from
carpeting, bedding material, et cetera. It is imperative that control compartments, burners and circulating air passageways
of the appliance be kept clean. Make sure that the gas valve and pilot light are turned off before you attempt to clean this
unit.
16. Clothing or other flammable material should not be placed on or near the appliance. This appliance should not be used as a
drying rack for clothing nor should Christmas stockings or decorations be hung from it.
17. Do not use this heater if any part has been under water. Immediately call a qualified service technician to inspect the heater
and to replace any part of the control system and any gas control which has been under water.
18. Do not operate appliance unless completely installed as per installation instructions.
19. Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this
appliance may result in property damage or personal injury.
20. WARNING: Do not operate appliance with the glass front removed, cracked or broken. Replacement of the glass
should be done by a licensed or qualified service person.
21. The appliance area must be kept clear and free from combustible materials, gasoline, and other flammable vapors and
liquids.
22. The front of the fireplace gives off high temperatures that could ignite combustible material which is kept close to the front of
the unit.
23. Ensure that power to the Fireplace is turned off before servicing.
24. Do not operate this Fireplace without the glass front or with a broken glass.
25. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to the
owner’s information manual provided with this appliance. For assistance or additional information consult a qualified
installer, service agency, or the gas supplier.
26. Operation of this appliance when not connected to a properly installed and maintained venting system or tampering with the
blocked vent shutoff system can result in carbon monoxide (CO) poisoning and possible death.
27. This appliance is equipped with a three-prong (grounding) plug for your protection against shock hazard and should be
plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug.
5

Gas fired appliances may be used only for supplemental heat and/or decorative purposes and under no circumstances shall they
provide a primary heat source.
This appliance must not be connected to a chimney flue serving a separate solid-fuel burning appliance.
NOTE: It is recommended that a Carbon Monoxide (CO) Detector be installed in or near bedrooms and on all levels of your home.
Place a detector about 15ft [4.5m] outside the room that houses your gas appliance.
Certified for installation in a bedroom or bed/sitting room. In Canada must be installed with listed millivolt thermostat.
In the U.S.A. Thermostats are not permitted for Vented Gas Fireplaces (ANSI Z21.50b-Decorative).
In USA see local codes.
Operations and Maintenance Instructions
For safe installation and operation note the following:
•Venting systems should be periodically examined by a qualified agency.
•The flow of combustion and ventilation air must not be obstructed.
•The Burner/Log Assembly has been engineered and permanently adjusted for proper flame control.
•Periodically remove the logs from the grate assembly and vacuum any loose particles from the grate and burner areas. See Log
Placement page to remove logs. Vacuum burner parts and replace logs.
•Never use your gas fireplace as a cooking device.
•Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify
proper operation after servicing.
Installation Requirements for the Commonwealth of Massachusetts
In the Commonwealth of Massachusetts, the installer or service agent shall be a plumber or gas fitter licensed by the Commonwealth.
When installed in the Commonwealth of Massachusetts or where applicable codes; the unit shall be installed with a CO detector per the
requirements listed below.
1. For direct-vent appliances, mechanical-vent heating appliances or domestic hot water equipment, where the bottom of the vent
terminal and the air intake is installed below four feet above grade the following requirements must be satisfied:
A. If there is not one already present, on each floor level where there are bedroom(s), a carbon monoxide detector and alarm
shall be placed in the living area outside the bedroom(s). The carbon monoxide detector shall comply with NFPA 720.
B. A carbon monoxide detector shall be located in the room that houses the appliance or equipment and shall:
Be powered by the same electrical circuit as the appliance or equipment such that only one service switch services
both the appliance and the carbon monoxide detector;
Have battery back-up power;
Meet ANSI./UL 2034 Standards and comply with NFPA 720; and
Have been approved and listed by a Nationally Recognized Testing Laboratory as recognized under 527 CMR.
C. A Product-approved vent terminal must be used, and if applicable, a Product-approved air intake must be used.
Installation shall be in strict compliance with the manufacturer’s instructions. A copy of the installation instructions shall
remain with the appliance or equipment at the completion of the installation.
D. A metal or plastic identification plate shall be mounted at the exterior of the building, four feet directly above the location of
vent terminal. The plate shall be of sufficient size to be easily read from a distance of eight feet away, and read “Gas Vent
Directly Below”.
2. For direct-vent appliances, mechanical-vent heating appliances or domestic hot water equipment where the bottom of the vent
terminal and the air intake is installed above four feet above grade the following requirements must be satisfied:
A. If there is not one already present, on each floor level where there are bedroom(s), a carbon monoxide detector and alarm
shall be placed in the living area outside the bedroom(s). The carbon monoxide detector shall comply with NFPA 720.
B. A carbon monoxide detector shall:
Be located in the room that houses the appliance or equipment;
Be either hard-wired or battery powered or both; and
Shall comply with NFPA 720.
A Product-approved vent terminal must be used, and if applicable, a Product-approved air intake must be used. Installation shall be in
strict compliance with the manufacturer instructions. A copy of the installation instructions shall remain with the appliance or equipment
at the completion of the installation.
For the state of Massachusetts a T-handle gas shut-off valve must be used on a gas appliance. This T-handle gas shut-off valve must be listed and
approved by the state of Massachusetts. This is in reference to the state of Massachusetts state code CMR238.
6

Mobile Home/Manufactured Housing Installation
This Direct Vent System Appliance must be installed in accordance with the manufacturer’s installation instructions and the
Manufactured Home Construction and Safety Standard Title 24 CFR, Part 3280, or the current Standard for Fire Safety Criteria for
Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240 MH Mobile Home Standard in
Canada.
THE VENTED GAS FIREPLACE HEATERS (ANSI Z21.88-2009) IN THIS MANUAL MAY BE INSTALLED IN MANUFACTURED
(MOBILE) HOMES AFTER FIRST SALE IN THE USA.
THE VENTED GAS FIREPLACE HEATERS (ANSI Z21.88-2009) IN THIS MANUAL MAY BE INSTALLED IN MANUFACTURED
(MOBILE) HOMES IN CANADA.
Please follow the current ANSI/NFPA 70 National Electrical Code in the USA and CAN/CSA C22.1 Canadian National
Electrical Code in Canada.
An appliance must be grounded to the steel chassis of the home with 8 ga. copper wire using a serrated or star washer to
penetrate paint or protective coating to insure grounding.
Use carriage bolt at the attachment point (see diagram above) to secure the appliance to the floor.
For required venting components see venting installation in appropriate section of this manual.
Certified for installation in a bedroom or bed/sitting room. In Canada must be installed with listed millivolt thermostat. In USA see local
codes.
Warning: Do not compromise the structural integrity of the manufactured home wall, floor
or ceiling, during installation of appliance or venting.
Appliance Must Be Secured To
Structure Using Supplied Nailing
Tabs And Or Fastened To Floor.
Use Existing Hole Or Remove
Existing Screw To Mount Ground
Wire (Nailing Tab Screw).
Serrated Or Star Washer
Ground Wire From Appliance To Steel
Chassis Of Mobile Home. USE 8GA
COPPER WIRE.
7

VRB46 Framing Your Gas Fireplace
This section is intended for qualified installers only. Before beginning, make note of where the gas and electrical accesses are
located on the unit. This will streamline the construction process. Furthermore, familiarize yourself with the venting and
clearance requirements (see Venting section) for this appliance. Failure to comply with those requirements can seriously
compromise the safety and operation of the fireplace.
Specifications
1.Cold climate installation recommendation: When installing this fireplace against non insulated exterior wall or chase,
it is recommended that the outer walls be insulated to conform to applicable insulation codes. Drywall & vapor barrier
must be installed over insulation to prevent contact of insulation and unit.
2.Choose fireplace location and frame in accordance with the fireplace framing dimensions specified (view diagrams).
3.Drywall or other combustible material can extend up to the Drywall Stops located on the sides of the unit, and up to
the bottom and top.
4.A Hearth is not required for this unit.
Certified for installation in a bedroom or bedsitting room. In Canada must be installed
with listed millivolt thermostat (Not permitted for decorative vented gas fireplaces installed
in the U.S.A.). In USA see local codes.
Stand-off Locations
Make note of where the stand-off locations are. These stand-offs are provided as indicators to illustrate the
boundaries for framing. Therefore, no framing material is permitted to extend beyond these stand-offs.
Vertical Venting in Cold Climates
In cold climate conditions where temperatures go below -10 degrees Celsius or 14 degrees Fahrenheit, we recommend
that the chase be insulated and where the vent pipe enters into the attic space that the pipe be wrapped with an
insulated Mylar sleeve. This will increase the temperature of the vent and help the appliance to vent properly in cold
weather conditions.
It is also important in vertical vented direct vent appliances that the appliance be operated daily during the winter months
as this will help stop the termination from freezing up. We recommend using a thermostat (Not permitted for decorative
vented gas fireplaces installed in the U.S.A.) set at room temperature to allow the unit to cycle.
For IPI models it may be necessary to set the appliance to Standing Pilot mode to maintain heat in the cavity. The
purpose of this procedure is to prevent cold air from penetrating the chimney and then onto the living space. Therefore,
when the internal temperature is slightly elevated the fireplace is able to freely exhaust its combustion and hence making
it easier to startup.
Nailing Tabs
Caution: Standoffs on top
of the unit must be folded
into position & screwed
down Prior to installation.
Holes are provided in bottom of
unit to secure appliance to floor
after installation.
8

VRB46 Nailing Tab Guide
These Nailing Tabs can be used in two ways:
1/2” Drywall Flush with Face of Fireplace –Fireplace and
Combustible Wall to be covered with a surround and / or
Non-Combustible Materials (e.g. Stone around Fireplace).
Framing Flush with Face of Fireplace -Fireplace to be
covered with Non-Combustibles (e.g. Concrete Board) for
Flat Wall appearance.
[Qty]2 Nailing Tabs are
located on each side of the
fireplace front frame.
Nailing Tab
Framing Stud
Drywall
Concrete Board
Surround
Concrete Board
Drywall
Framing Stud
Nailing Tab
Nailing Tab
Framing Mount
Nailing Tabs Must
Be Rotated 180°
And Folded Back
Onto Framing Stud.
Framing Stud
Nailing Tab
Nailing Tab
Framing Stud
9

VRB46 -Facing Requirements- ALL UNITS- Chase Not Vented or Vented Chase-
NOTE: ANY MATERIALS COVERING THE FACE OF
THE FIREPLACE BESIDE AND ABOVE THE
FIREPLACE OPENING MUST BE NON-
COMBUSTIBLE (i.e. brick, stone, tile, concrete
board). FIREPLACE WITH SCREEN ONLY (AS
SHIPPED) SHOWN HERE.
When finishing the wall around the fireplace, it is
critical that the wall covering be fastened properly. It is
acceptable to pre-drill holes and use self-tapping screws
which may be used to fasten a backer for tile, marble,
etc. Screws being installed through non-combustible
board should be self-tapping type with a maximum
length of 2 inches.
Do not drill or install longer screws (over 2”) as this
may damage internal components.
 We recommend that CONCRETE BOARD (non-
combustible material) be tied in to the entire perimeter of
the fireplace for durability.
Finishing Recommendations (Obtained from
professional construction contractors and finishers):
 Frame unit with metal studs (minimum 20
gauge).Wooden studs may be used, but may cause
drywall screws to pop or pull due to wood studs
drying out.
 Minimum of 1/2” CONCRETE BOARD cement board
(this non-combustible panel is ULC listed as a wall
shield/floor protector) and fasten to the entire perimeter
framing.
 Use fiberglass (mesh) tape for all joints in area of the
fireplace.
 Use Yellow joint mud (contains high amounts of glue) –
two coats, finishing with one coat of green topping mud,
sand and prep for painting.
 If not using a surround, a metal “L” Trim may be used to
finish perimeter of CONCRETE BOARD.
 OTHER NOTES:
-A full single sheet of non-combustible board (no joints)
above the unit is recommended if possible.
-It is preferred to attach the non-combustible board to
framing only and not directly to the unit to allow for
expansion and contraction during normal operation.
-Lighter colored painted surfaces may discolor due to
heat exposure.
Non-Combustible Material
Screwed to Framing
REQUIRED: NON COMBUSTIBLE
OVER FACE OF APPLIANCE
(46-5/8” x 35-1/2”)
SUGGESTED: NON COMBUSTIBLE
MATERIAL SCREWED TO FRAMING
(48” x 45-1/4”)
Non-Combustible Material
This area can have a combustible
surface (i.e. drywall, hearth)
10

VRB46 -Facing Kit for VRB46- Z46PRO4
This kit is recommended for Clean View Facing of the VRB46.
 Promat precut boards can be installed with standard drywall screws (pre-drilling into fireplace
face required) or self-drilling drywall screws.
It may be desirable to countersink the screw holes for easier finishing later.
NOTE: Do not use screws longer than 1 inch as internal parts of fireplace may be damaged.
 Use standard joint filler and paint.
11

VRB46 Locating Your Appliance
LOCATION KEY:
A. Flat on Wall
B. Across the Corner
C. As an Island
D. As a Room Divider
E. Flat on Wall Corner
F. Exterior Wall
See Mantel Leg Clearances Instruction for
the proper placement of fireplace.
Island installation with a top vent is
possible as long as the horizontal portion
of the vent system does not exceed 20
feet (6.1 m).
VRB46 Fireplace Dimensions
FRONT
TOP
LEFT
12

VRB46 –Unvented Chase VS Vented Chase- Choose Your Installation
Look at the following chart before you begin the installation.
Low
Enclosure
Cool Touch
Wall
TV above Fireplace with
Recessed Installation
option
Mantel Height
Heat can be
directed to
second room
UNVENTED CHASE
64”
No
No
2” at 37-1/2”
No
VENTED CHASE
70”
Yes
Yes
Any size at 35-9/16”
Yes
UNVENTED CHASE:
This is a traditional fireplace installation where the fireplace is
built into an unvented chase.
 Enclosure height is lower.
 Temperature of chase walls will be higher.
 No TV above Fireplace
 Mantel height is higher.
Fireplace will be installed with Ventilation Plates in place (as
shipped).
VENTED CHASE:
The fireplace is installed into a vented chase. There are
many different styles of vented chase. See pages in
manual for installation details and information.
 Enclosure height is higher.
 Chase walls will be much cooler to the touch.
 A TV is allowed above the fireplace.
 Mantel height is lower.
Fireplace will be installed with Ventilation Plates
removed (see instructions in manual).
A minimum opening of 105 square inches of ventilation
area is required.
Kingsman V46EG Grill may be used.
If a custom grill is used, free air opening must total 105
square inches with no sloping louvers.
See “Chase Not Vented” Framing Section
See “Vented Chase” Framing Section
13

VRB46- Framing Dimensions -Chase Not Vented- Ventilation Plates In Place-
-As Shipped
Determine whether face of fireplace will be:
 flush with finished wall (e.g., for surround, cultured stone or other non combustible covering).
 flush with framing (to be covered with concrete board for a Flat Wall appearance).
Refer to Nailing Tab Guide section also.
43-3/4”
HEADER
52” MIN
Plus Rise of 1/4”
Per Foot
33-3/4”
To Face
Framing
MIN 64”
Ceiling &
Enclosure
MIN 64”
Ceiling &
Enclosure
Fig.1
Framing for Horizontal Vent
Termination
(See Installation of Side
Wall Venting Section)
Vertical Venting MUST maintain 1” clearance to combustibles.
These structures are not
load bearing.
Note: If using optional surround, maximum thickness for non-combustible material is 3/4”.
Fig. 1
Shown flush
with framing.
14

VRB46 -Mantel Clearances –Chase Not Vented- Ventilation Plates In Place
-As Shipped
Mantel Leg Clearances
Before installing any mantels it is
important to determine the
combustibility of its material(s). There
are two types of mantels to consider:
Combustible and Non-Combustible.
A Combustible Mantel is one that
consists of material(s) that may
discolor, combust, or lose its integrity
in the presence of heat. These types
of mantels must strictly conform to the
dimensional requirements shown.
Conversely, a Non-Combustible
Mantel is one that is constructed with
material(s) that will not combust.
Check your local codes and
regulations to determine whether your
mantel is Combustible or Non-
Combustible.
The advantage to Non-Combustible
Mantels is that it may extend right up
to the tile lip of the fireplace.
Combustible mantels must adhere to
the dimensional restrictions shown.
-Combustible Objects on Non-
Combustible Mantel Warning-
Combustible objects must not be placed
on a Non-combustible Mantel unless the
mantel meets the dimensional
requirements for a Combustible Mantel.
Determine whether your mantel
conforms to the requirements of a
Combustible Mantel.
Adjacent Wall
Adjacent Wall
Top View
Mantel Dimensions
are from front face
or Non-Combustible
Facing Materials
covering fireplace.
15

VRB46 -Clearance to Combustibles –Chase Not Vented-
Ventilation Plates in Place -As Shipped
Clearance to Combustibles VRB46 –Chase Not Vented-
Front
36” [92cm]
Back (from Stand-offs)
0” [0cm]
Side (from Stand-offs)
0” [0cm]
Floor*
0” [0cm]
Minimum Ceiling Height (from bottom of fireplace)
64” [162.5cm]
Top (from Stand-offs)
0” [0cm]
Top of 90° Bend in minimum Enclosure of 64”
8-1/2” [21.6cm]
Top of 90° Bend in Enclosure over 64”
4” [10.2cm]
VENTING SYSTEMS
Top of Horizontal Pipe
1/1/2” [3.8cm]
Side & Bottom of Horizontal Pipe
1” [2.5cm] All Vent Systems
Vertical Vent Pipe
1” [2.5cm] All Vent Systems
16

VRB46 -Vented Chase –Removal of Ventilation Plates-
See Framing for Vented Chase
⚠ CAUTION: Ventilation Plates must be removed before VRB46 is installed into a Vented Chase.
STEP 1: Remove [Qty 2] Knockouts from Outer Heat Shield.
STEP 2: Remove [Qty 2] Ventilation Plates.
Outer Heat Shield
Knockouts
Cut tabs
STEP 1: Remove [Qty 2] Knockouts from Outer Heat
Shield
.
Cut tabs to remove
STEP 2: Remove [Qty 2] Ventilation Plates.
Remove 1/4” drive screws and pry loose from
sealant.
TOP VIEW After Outer Heat Shield Knockouts
and Ventilation Plates have been removed.
See “Vented Chase” Framing
Section
17

VRB46 – Vented Chase – Style 1 – OPENING WITH NO GRILL
 VENTILATION PLATES MUST BE REMOVED.
 Minimum Enclosure Height is 70” from the bottom of
the appliance.
 For vertical venting use a Firestop (ZDVFS) or Attic
Insulation (ZDVAIS, Z7AIS24) Shield through
enclosure top.
 Minimum Opening is 105 square inches free air.
⚠NOTE: ENCLOSURE MUST BE SEALED
Air heated by circulation over the heating surfaces of
the appliance must not be discharged directly into the
walls, floor, or ceiling.
⚠NOTE: You may not vent enclosure to a second
room without also venting to room in which fireplace
is installed.
FRAMING TO CEILING-
OPEN FRONT
NO GRILL
Finished Minimum
Opening is 105 square
inches of free air.
OPEN CHASE
FRAMING-
ENCLOSURE MIN
1-1/4” BELOW
CEILING
Finished Minimum
Opening is 105
square inches of
free air.
Requires 1-1/4”
Minimum Opening
below Ceiling
Opening
directly below
Enclosure
Top / Ceiling
FRAMING TO CEILING-
OPEN SIDES
NO GRILLS
Finished Minimum
Opening is 105 square
inches of free air.
NOTE: Sides of
enclosure must have
equal sized openings.
Openings are
directly below
Enclosure
Top / Ceiling
Openings are
directly below
Enclosure
Top / Ceiling
FRAMING TO
CEILING- OPEN
FRONT AND BACK
(to second room)
NO GRILL
Finished Minimum
Opening for each room
must be 105 square
inches of free air.
18

VRB46 –Vented Chase- Style 1 – OPENING WITH NO GRILL
Variable
Variable
Vertical Venting must use
Firestop Spacer (ZDVFS) or Attic
Insulation Shield and Sealant
TOP VIEW
Optional Attic
Insulation Shield
(ZDVAIS, ZDVAIS24)
Firestop
Optional
Recess
52”
MIN
43-3/4”
47”
FRAMING
I.D.
10” Hole cut through
combustibles
Open Area
Open Area
Open Area
Open Area
Finished Minimum Opening is 105 square
inches of free air.
Finished Openings must be at ceiling level.
NOTE: Air heated by circulation over the
heating surfaces of the appliance must not
be discharged directly into the walls, floor,
or ceiling.
Ceiling / Enclosure Top
Ceiling / Enclosure Top
VENTILATION PLATES MUST BE REMOVED
19

VRB46 – Vented Chase – Style 2 – OPENING WITH GRILL
 VENTILATION PLATES MUST BE REMOVED.
 Grill openings must be within 2” of enclosure top.
 Minimum Enclosure Height is 70” from the bottom of
the appliance.
 For vertical venting use a Firestop (ZDVFS) or Attic
Insulation (ZDVAIS, Z7AIS24) Shield through
enclosure top.
 If Kingsman V46EG Grill is used, minimum rough
opening required is 2-5/8” x 46-3/4”. Any obstacles,
such as vertical studs should be notched back 1-1/2”
from finished face of wall.
⚠NOTE: ENCLOSURE MUST BE SEALED
Air heated by circulation over the heating surfaces of
the appliance must not be discharged directly into
the walls, floor, or ceiling.
⚠NOTE: You may not vent enclosure to a second
room without also venting to room in which fireplace
is installed.
⚠NOTE:
Outsourced grills must have 105 square inches
minimum free air opening and no sloping louvers
FRAMING TO CEILING-
GRILL AT FRONT
Grill must have a total of 105
square inches free air
minimum.
FRAMING TO CEILING-
GRILLS AT FRONT
AND BACK (to Second
Room)
Each grill must be 105
square inches free air
minimum.
2”
MAX
2”
MAX
Grill Opening must be
within 2” of Enclosure Top
Grill Opening must be
within 2” of Enclosure Top
Grill
Opening
must be
within 2” of
Enclosure
Top
FRAMING TO
CEILING-
SIDE GRILLS
Grills must have a
total of 105 square
inches free air
minimum.
NOTE: Sides of
enclosure must have
equal sized grills.
FRAMING TO CEILING- MINIMUM
ENCLOSURE- GRILL AT FRONT
Grill must have a total of 105
square inches free air minimum.
Grill Opening must be
within 2” of Enclosure Top
(Continued on next page)
20
