Kistler 8766AxAx User manual

AMERICAN
3
Connector (male) out
(end of connector)
5.3
[0.21] X
Z
GND
Y
Y
Z
X
4 pin connector (¼–28 UNF-2A thd.)
X
B
B
CB
AType 8766AxBx
Type 8766A050/100Bx Type 8766A250/500Bx
A 23.2 [0.91] 20.7 [0.81]
B 12.5 [0.49] 10.9 [0.43]
C 6-32 UNC-2B mtg. thd., Typ. 3 5-40 UNC-2B mtg. thd., Typ. 3
Type 8766A050/100Ax Type 8766A250/500/1K0Ax
A 21.1 [0.83] 18.2 [0.72]
B 12.5 [0.49] 10.9 [0.43]
C 6-32 UNC-2B mtg. thd., Typ. 3 5-40 UNC-2B mtg. thd., Typ. 3
AMERICAN
3
X
Z Y
Y
Z
Connector (male) out
(end of connector)
4 pin connector (M4.5 x 0.35 thd.)
C
GND
B
B
3.9
[0.15]
X
B
AType 8766AxAx
Type 8766AxCsp
Type 8766A050/100CBsp Type 8766A250/500/1K0CBsp
D 28.2 [1.11] 25.4 [1.00]
E 12.5 [0.49] 10.9 [0.43]
F 6-32 UNC-2B mtg. thd., Typ. 3 5-40 UNC-2B mtg. thd., Typ. 3
D
10.9
[0.43]
E
10.9
[0.43]
CUSTOMER SPECIFIED LENGTH (mm [in])
20 METERS MAXIMUM
F ¼–28 MALE 4 PIN CONNECTOR
EE
Page 1/6
Acceleration
Miniature PiezoStar Accelerometer
IEPE Triaxial Accelerometer Cube (50 ... 1,000 g)
8766A_000-841e-01.21
© 2007 ... 2021 Kistler Group, Eulachstraße 22, 8408 Winterthur, Switzerland
Tel. [phone], [e-mail], www.kistler.com. Kistler Group products are
protected by various intellectual property rights. For more details visit www.kistler.com.
This information corresponds to the current state of knowledge. Kistler reserves the
right to make technical changes. Liability for consequential damage resulting from
the use of Kistler products is excluded.
Type 8766AxAx,
8766AxBx,
8766AxCsp
Description
Type 8766A... is an IEPE triaxial accelerometer designed for high
temperature applications. Type 8766A… accelerometer uses
Kistler’s PiezoStar shear element design which provides a wide
operating frequency range and extremely low sensitivity to tem-
perature changes, as shown in Figure 1 (see pg. 3). The IEPE
sensor combines PiezoStar crystals and high gain integral hybrid
microelectronics to achieve very low sensitivity variation over the
operating temperature range, compared to other sensing element
designs. The Kistler shear element technology also ensures high
immunity to base strain errors. The accelerometer uses a welded
titanium construction for low mass and an industry standard 4pin
connector, as well as a mini 4 pin connector for lower mass and
wider frequency operation. An integral silicone cable variant is
available for application of underwater vibration testing at up to
10 bars [150 psi]. All variations provide reliable measurements and
long-term stability, especially at higher operating temperatures.
• IEPE, 50 ... 1,000 g ranges
• PiezoStar element with very low sensitivity to temperature
• Miniature, low mass
• Hermetic, titanium construction
• Mini and standard, 4 pin connector options
• High temperature +165°C [+330°F] option
• Water resistant IP68 (up to 10 bars) option available
• Conforming to ä
Type 8766A... miniature accelerometer family (50 ... 1,000 g)
measures simultaneous shock and vibration in three orthogonal
axes.
Dimensions are shown in mm [in], unless otherwise noted.
Dimensions are shown in mm [in], unless otherwise noted.Dimensions are shown in mm [in], unless otherwise noted.

Page 2/6
Miniature PiezoStar Accelerometer – IEPE Triaxial Accelerometer Cube, Type 8766…
8766A_000-841e-01.21
© 2007 ... 2021 Kistler Group, Eulachstraße 22, 8408 Winterthur, Switzerland
Tel. [phone], [e-mail], www.kistler.com. Kistler Group products are
protected by various intellectual property rights. For more details visit www.kistler.com.
This information corresponds to the current state of knowledge. Kistler reserves the
right to make technical changes. Liability for consequential damage resulting from
the use of Kistler products is excluded.
Technical data
Type Unit 8766A050xx 8766A100xx 8766A250xx 8766A500xx 8766A1K0x
Acceleration range g ±50 ±100 ±250 ±500 ±1,000
Acceleration limit gpk ±100 ±200 ±500 ±1,000 ±2,000
Threshold (1 … 10 kHz) grms <0.002 <0.004 <0.006 <0.01 <0.02
Sensitivity at 100 Hz, 10 grms mV/g 100
(+15%/–10%)
50
(+20%/–10%)
20
(+20%/–10%)
10
(± 10%)
5
(± 10%)
Resonant frequency mounted kHz >20 >30 >55 >55 >55
Frequency response
Type 8766AxAx (±5%) Hz 1 … 6,000 1 … 10,000 0.5 … 10,000 0.5 … 10,000 1 ... 12,000
Type 8766AxAx (±10%) Hz 0.5 ... 8,000 0.5 … 15,000 0.5 … 12,000 0.5 … 15,000 0.5 ... 20,000
Type 8766AxBx (±5%) Hz 1 ... 5,000 1 … 8,000 0.5 … 8,000 0.5 … 8,000 –
Type 8766AxBx (±10%) Hz 0.5 ... 6,500 0.5 … 12,000 0.5 … 10,000 0.5 … 12,000 –
Amplitude non-linearity %FSO ±1 ±1 ±1 ±1 ±1
Time constant nom. s 0.5 0.5 1.2 1.2 1.4
Transverse sensitivity (typ. / max.) % 1.5/5 1.5/5 1.5/5 1.5/5 1.5/5
Long-term stability % ±1 ±1 ±1 ±1 ±1
Environmental
Base strain sensitivity @ 250 µe g/µε0.004 0.004 0.005 0.005 0.005
Random vibration max. grms 1,000 1,000 1,000 1,000 2,000
Shock limit (1 ms pulse), max. gpk 5,000 5,000 5,000 5,000 5,000
Temperature coeff. of sensitivity %/°C
[%/°F]
–0.01
[–0.006]
+0.002
[+0.001]
–0.005
[–0.003]
–0.004
[–0.002]
–0.009
[–0.005]
Operating temperature range
Type 8766AxxB/T °C
[°F]
–54 ... 120
[–65 … 250]
–54 ... 120
[–65 … 250]
–54 ... 120
[–65 … 250]
–54 ... 120
[–65 … 250]
–54 ... 120
[–65 … 250]
Type 8766AxxH/TH/M08 °C
[°F]
–54 … 165
[–65 ... 330]
–54 … 165
[–65 ... 330]
–54 … 165
[–65 ... 330]
–54 … 165
[–65 ... 330]
–54 … 165
[–65 ... 330]
Output
Bias nom. VDC 11 11 11 11 11
Impedance Ω <100 <100 <100 <100 <100
Voltage full-scale V ±5 ±5 ±5 ±5 ±5
Power supply
Voltage VDC 20 … 30 20 … 30 20 … 30 20 … 30 20 ... 30
Constant current mA 2 … 18 2 … 18 2 … 18 2 … 18 2 ... 18
Construction
Sensing element type PiezoStar PiezoStar PiezoStar PiezoStar PiezoStar
Housing/base material titanium titanium titanium titanium titanium
Sealing – housing/connector
(EN 60529) type hermetic hermetic hermetic hermetic hermetic
Sealing – Type 8766A...CBsp
integral cable option type IP68 – tested for 16 bars during 48 hours
1 g = 9.80665 m/s2, 1 in = 25.4 mm, 1 Gram = 0.03527 oz, 1 lbf-in = 0.113 N·m

Page 3/6
Miniature PiezoStar Accelerometer – IEPE Triaxial Accelerometer Cube, Type 8766…
8766A_000-841e-01.21
© 2007 ... 2021 Kistler Group, Eulachstraße 22, 8408 Winterthur, Switzerland
Tel. [phone], [e-mail], www.kistler.com. Kistler Group products are
protected by various intellectual property rights. For more details visit www.kistler.com.
This information corresponds to the current state of knowledge. Kistler reserves the
right to make technical changes. Liability for consequential damage resulting from
the use of Kistler products is excluded.
Technical data (continued...)
Type Unit 8766A050xx 8766A100xx 8766A250xx 8766A500xx 8766A1K0x
Connector
Type 8766AxAx type 4 pin (M4.5) 4 pin (M4.5) 4 pin (M4.5) 4 pin (M4.5) 4 pin (M4.5)
Type 8766AxBx type 4 pin (¼–28) 4 pin (¼–28) 4 pin (¼–28) 4 pin (¼–28) -
Type 8766AxCBsp type integral cable terminated with 4 pin (¼–28)
Ground isolated type with accessory with accessory with accessory with accessory with accessory
Mass (housing)
Type 8766AxAx grams 6.4 6 4 3.7 3.7
Type 8766AxBx/CBsp grams 6.9 6.4 4.3 4 -
Mounting type 6-32 UNC-2B 6-32 UNC-2B 5-40 UNC-2B 5-40 UNC-2B 5-40 UNC-2B
Mounting torque N·m
[lbf-in]
0.85±0.06
[7.5±0.5]
0.85±0.06
[7.5±0.5]
0.85±0.06
[7.5±0.5]
0.85±0.06
[7.5±0.5]
0.85±0.06
[7.5±0.5]
1 g = 9.80665 m/s2, 1 in = 25.4 mm, 1 Gram = 0.03527 oz, 1 lbf-in = 0.113 N·m

Page 4/6
Miniature PiezoStar Accelerometer – IEPE Triaxial Accelerometer Cube, Type 8766…
8766A_000-841e-01.21
© 2007 ... 2021 Kistler Group, Eulachstraße 22, 8408 Winterthur, Switzerland
Tel. [phone], [e-mail], www.kistler.com. Kistler Group products are
protected by various intellectual property rights. For more details visit www.kistler.com.
This information corresponds to the current state of knowledge. Kistler reserves the
right to make technical changes. Liability for consequential damage resulting from
the use of Kistler products is excluded.
Mounting
Reliable and accurate measurements require that the mounting
surface be clean and flat. The sensor can be attached to the struc-
ture with wax, adhesive or the supplied mounting stud. Several
optional ground isolated mounting accessories are also available
for added mounting flexibility. Type 8766A250/500/1K0..., with
three 5-40 UNC-2B threaded holes, and Type 8766A050/100,
with three 6-32 UNC-2B threaded holes, offer flexible stud
mounting on a test object, fully utilizing each mounting side of
the cube design. In addition, the three threaded holes provide
reliable mounting for calibration of each orthogonal axis. The
instruction manual for Type 8766A… provides detailed informa-
tion regarding mounting surface preparation.
CAUTION: The 50 g range contains a high output Piezostar
element combined with a sensitive electronic. Use care when
handling the sensor during mounting and un-mounting, es-
pecially when using a magnetic base or releasing the sensor
from adhesive mount. Failure to do so may cause irrepairable
damage to the sensor.
Fig. 1: PiezoStar sensitivity variation with temperature (typical plot)
Measurements
Horizontal
Verticle
AMERICAN METRIC GERMAN
Diminsional Text
0.55
10
8
6
4
0
-2
-4
-6
2
-8
-10
4 (-20) 68 (20) 140 (60) 212 (100)-76 (-60) 284 (140) 356 (180)
TEMPERATURE °F (°C)
% DEVIATION
Typical Temperature Response
10
8
6
4
0
-2
-4
-6
2
-8
-10
4 (-20) 68 (20) 140 (60) 212 (100)-76 (-60) 284 (140) 356 (180)
Temperatur °F (°C)
Abweichung in %
Typischer Temperaturgang
Application
This miniature and lightweight triaxial accelerometer family is
ideally suited for structural analysis of small components or sub-
systems, full vehicle testing for aviation, space, and automotive,
as well as a wide range of general test structures. The PiezoStar
accelerometer technology excels in operational testing over
dynamic test conditions.
Type 8400K06 Type 8400K04 Type 8440K01:
5-40
Type 8436 Type 8452
5-40 to 10-32
Ground isolated
mounting base
5-40 to M6
Ground isolated
mounting base
Type 8440K04:
6-32
Ground isolated
adhesive
mounting base
Adhesive ground
isolated, hex.
mounting base
with 10-32
thd. hole
Magnet
mounting base
with 10-32
thd. hole
Fig. 2: Mounting accessories

Page 5/6
Miniature PiezoStar Accelerometer – IEPE Triaxial Accelerometer Cube, Type 8766…
8766A_000-841e-01.21
© 2007 ... 2021 Kistler Group, Eulachstraße 22, 8408 Winterthur, Switzerland
Tel. [phone], [e-mail], www.kistler.com. Kistler Group products are
protected by various intellectual property rights. For more details visit www.kistler.com.
This information corresponds to the current state of knowledge. Kistler reserves the
right to make technical changes. Liability for consequential damage resulting from
the use of Kistler products is excluded.
Note: Type 1784B…K03 is used for Type 8766A…A…; Type 1756C… and Type 1734A… are used for Type 8766A…B…
and Type 8766A...CBsp
Measuring chains
IEPE Sensor and Customer IEPE Compatible DAQ
IEPE Sensor and Kistler LabAmp
Measuring Connecting Amplifying Acquiring Analyzing
Type 8766A... Types 1734A..., 1756C...,
1784B...K03 (4 pin neg. to
3x BNC pos.)
IEPE Compatible Data Acquisition
Unit (customer supplied)
Laptop (customer supplied)
Measuring Connecting Amplifying Acquiring Analyzing
Type 8766A... Ethernet Cable Notebook with LabAmp GUI Type 5165A...
Conditioning and Data Acquisition
Analog Output ±10 V
Type 1511
Types 1734A..., 1756C...,
1784B...K03 (4 pin neg. to
3x BNC pos.)
1631C
1761B
1592A
1792A
Ethernet Kabel
1756C
1635C
1511

Page 6/6
Miniature PiezoStar Accelerometer – IEPE Triaxial Accelerometer Cube, Type 8766…
8766A_000-841e-01.21
© 2007 ... 2021 Kistler Group, Eulachstraße 22, 8408 Winterthur, Switzerland
Tel. [phone], [e-mail], www.kistler.com. Kistler Group products are
protected by various intellectual property rights. For more details visit www.kistler.com.
This information corresponds to the current state of knowledge. Kistler reserves the
right to make technical changes. Liability for consequential damage resulting from
the use of Kistler products is excluded.
Ordering key Type 8766A...
Measuring range
±50 g 050
±100 g 100
±250 g 250
±500 g 500
±1,000 g 1K0
Connector
Mini, M4.5x0.35, 4 pin (pos.) A
¼–28, 4 pin (pos.)
[only 050, 100, 250, and 500 g ranges] B
Waterproof IP68 C
TEDS Templates/Variants
Standard, base temperature B
High temperature* H
High temperature/TEDS
[only 050, 250, and 500 g ranges]
[for the 500g ¼-28, 4 pin (pos.)
version, order 8766M08]
TH
Default, IEEE 1451.4
V0.9 Template 0 (UTID 1)* T
IEEE 1451.4 V0.9 Template 24
(UTID 116225)* T01
LMS Template 117, Free Format Point ID* T02
LMS Template 118, Automotive
Format (Field 14 Geometry = 0)* T03
LMS Template 118, Aerospace
Format (Field 14 Geometry = 1)* T04
P1451.4 v1.0 Template 25 –
Transfer Function Disabled* T05
P1451.4 v1.0 Template 25 –
Transfer Function Enabled* T06
* Only with A and B connectors type as a standard.
For any combination of both TEDS and waterproof
capabilities, please contact Kistler.
Cable length
To be specified upon order
(for integral cable waterproof
Type 8766AxCB only) – Max. = 20 m
SP
No integral cable —
Optional cables Type/Art. No.
• Fluoropolymer jacketed breakout cable 1756CxxK04
¼–28, 4 pin (neg.) to 3x BNC (pos.)
= length: 3, 5 & 10 meters. For oth-
er special length, use 1756CK04sp
• Fluoropolymer jacketed breakout cable,
M4.5, 4 pin (neg.) to 3x BNC (pos.)
1784BxxK03
(xx = length: 1, 3, 5 & 10 meters)
• Flexible silicone jacketed breakout cable,
¼–28, 4 pin (neg.) to 3x BNC (pos.)
1734AxxK04
(xx = length: 1, 3, 5 & 10 meters)
• Fluoropolymer jacketed cable, 1784AK02
M4.5, 4 pin (neg.) to ¼–28, 4 pin
(pos.); (1784AK02 length = 0.5, for
other special length use 1784AK02sp
Optional accessories Type/Art. No.
• 5-40 to 10-32 male ground isolated
mounting base
8400K06
• 6-32 to M6 male ground isolated
mounting base
8400K05
• 5-40 to M6 male ground isolated
mounting base
8400K04
• 5-40 male ground isolated mounting base 8440K01
• 6-32 male ground isolated mounting base 8440K04
• 10-32 female ground isolated adhesive
mounting base
8436
• Magnet mounting base
with 10-32 thd. hole
8452A
with Type 8766A250/500...
• 5-40 to 10-32 mounting stud 8416
• 5-40 to M6 mounting stud 8418
• Mounting wax
(except for integral cable version)
8432
• ISO 17025 Calibration Certificate
Included accessories
with Type 8766A050/100...
Type/Art. No.
• 6-32 to 10-32 mounting stud 8430K03
• Mounting wax
(except for integral cable version)
8432
• ISO 17025 Calibration Certificate
